NH530 Honor Drone
USER MANUAL

01
DISCLAIMER AND SAFETY GUIDELINES
1. DO NOT look directly into the drone light.
2. DO NOT treat the product as household waste.
3. DO NOT fly above or near obstacles, crowds, open water, public road, high voltage
power lines or trees.
4. DO NOT use the drone in severe weather conditions. These include wind, snow, rain,
smog, hail, lightning, tornadoes or hurricanes.
5. Stay away from the rotating propellers and motors to avoid some tiny objects (e.g. hair)
to get into them.
6. This drone does not come with GPS module. Please fly the drone within the control
range.
7. Be sure to observe all local regulations, obtain appropriate authorizations and understand
risks. Please note it is solely your responsibility to comply with all flight regulations.
NEHEME accept no liability for damage, injury or any legal responsibility incurred directly
or indirectly from the use of this product. The user shall observe safe and lawful practices
including, but not limited to, those set forth in these Safety Guidelines. NEHEME reserves
the right to update this user manual.
MAINTENANCE AND CARE
1. Thoroughly check the drone after crash or violent impact.
2. Do not charge battery before it cools down.
3. Remove the batteries if the product will not be in use for a long time.
4. Do not over charge the battery. Unplug the charger once it’s fully charged.
5. Store the drone and remote in a cool, dry place away from direct sunlight.
6. Do not charge the battery next to inflammables, such as carpet, timber floor etc., or on the
surface of electro-conductive objects. Please always keep an eye on the battery while
charging.
7. Please use the original battery provided. Use an incorrect type of battery may lead to fire
hazards.
8. Do not dispose of the battery in fire or a hot oven, cut or mechanically crush the battery,
as this may cause explosions.
9. Do not leave the battery in an extremely high-temperature environment that can result in
an explosion or the leakage of flammable liquid or gas.
10. Do not expose the battery to the extremely low air pressure, as this may result in an
explosion or the leakage of flammable liquid or gas.

02
PRODUCT OVERVIEW
FLIGHT PREPARATION
1. Install the propeller guards.
Blades
HD Camera
OFF/ON Blade Guards
360 Flip
OFF/ON
Left Control Stick
Headless Mode
One Key Return
High-Speed Rotate
Circle Fly
Photo/Video
Right Control Stick
Speed One Key Take
Off / Landing
Rightward Trim
Leftward Trim
Forward Trim
Backward Trim

03
2. Charge the drone battery
3. Install the battery into the drone after it’s fully charged.
4. Install the remote batteries.
5. Install the Phone Clamp into the remote. (Optional)
3 X 1.5V AAA
(Batteries not included)

04
6. Extend the phone clamp to mount your mobile device. (Optional)
7. Replace the propellers when it’s needed. (Optional)
FLIGHT OPERATION GUIDE
Note:
* Make sure you power on the drone first, then the remote in each flight.
* Do repeat the pairing procedure each time when the drone or remote is restarted.
* For all flight functions and modes, the operator and tail of the drone must be aligned.
Pair the Remote with the Drone
Step 1: Turn on the drone, then the remote. The LED on the drone start to flash, then put the
drone on a flat surface with the head forward.
Step 2: Push the Left Control Stick forward to the top, then pull it backward till the bottom.
Pairing is successful when the LED on the drone is solid on.

05
Option 1:
a. Push two levers down to 45° as picture shows, the lights on drone keep flashing, after 2-3s,
the lights keep on.
b. Press the button to take off.
Option 2:
a. Push two levers down to 45° as picture shows, the lights on drone keep flashing, after 2-3s,
the lights keep on.
b. Move the Left Control Stick to lower left in 45° and the Right Control Stick to lower
right in 45° at the same time until four rotor blades start rotating.
c. Slowly push the Left Control Stick forward to take off.
Take-off
①. Pull the left control stick down slowly and hold it on the bottom for 2-3s until the
blades stop spinning.
②. Press the button to landing.
③. Long press button for Emergency stop, the drone will fall down slowly.
Landing
*Long press for
emergency stop

06
Ascend and descend
Push the Left Control Stick
forward and the drone will
ascend; pull it backward
and the drone will descend.
Push the Left Control Stick
leftward and the drone will
rotate to the left; pull it
rightward and the drone will
rotate to the right.
Rotate Left and Rotate Right
Instructions of the Remote
Left Control Stick
Forward and Backward Push the Right Control
Stick forward and the
drone will fly forward;
pull it backward and the
drone will fly backward.
Push the Right Control
Stick leftward and the
drone will fly leftward;
pull it rightward and the
drone will fly rightward.
Leftward and Rightward
Right Control Stick

07
If the drone drift forward or
backward when hovering,
press the Backward Trim
button or the Forward Trim
button to adjust.
If the drone drift leftward or
rightward when hovering,
press the Rightward Trim
button or the Leftward
Trim button to adjust.
Flight Trimming
This is one of the default settings in the drone. When you release the Left Control Stick after
the ascending/descending action, the drone will hover at the current flight height. For a stable
flight, press the trim buttons to adjust accordingly.
Altitude Hold / Hover
Press the Headless button to activate the function. In this mode, the drone will fly following
the direction of the Right Control Stick regardless of the position of your drone’s head or
the tail. The LED on the drone will flash and there is beeping sound from the remote. Press
the same button again to exit this mode.
Headless Mode
Standard Mode Headless Mode

08
After flying the drone to a height over 2 meters, press the 360 ° flip button to activate 360 °
flip function. Then move the Right Control Stick forward/backward/leftward/rightward to
flip the drone accordingly.
The drone is set to low speed by default. Press the Speed button down once for medium
speed and there are two beeps from the remote. Press it down again for high speed and there
are three beeps from the remote. A third press will get back to low speed and there is one
beep from the remote.
360 °Flip
Speed Switch
* Noted:When you fly in high
wind, please use the high speed
to control your drone.
Low
Speed mph
1-3
4-7
8-12 12-19
6-11
1-5 0.3-1.5
1.6-3.3
3.4-5.4
km/h m/s
Mid
High

09
Press the button, and then the drone will fly toward its back following a path parallel to
its original take-off path. When the drone is returning, the green rear LEDs on the drone keep
flashing.
Press the button to make the drone rotate at high speed. Press the button again or move
the Right Control Stick forward to exit this mode.
Ensure that there are no obstacles within a radius of 5 meters around the drone. Press the
button, and the drone will fly in circles. Press the button again or move the Right Control
Stick forward to exit this mode.
One key Return
High-Speed Rotation
Circle Fly
*Note: This function can’t be activated when the battery of the drone is low.

10
1.Download and install Neheme Honor into your mobile device from App Store / Google
Play or scanning the QR code below.
2. Turn on the drone first, go to the WIFI settings of your mobile device and connect to the
wifi NEHEME_NH530_***
*NOTE:
1. If you want to fly the drone with the controller, then turn on the drone and
controller for pairing together first.
2. To fly the drone with App, pair the drone with the app first, then you can use
the smart phone to control the drone flying.
3. Open Neheme Honor App. Tap CONNECT for video viewing surface.
App Operation Guide
For Android 4.4 or later For IOS 9.0 or later
Back Photo Video Album Gesture
Controller
Switch Speed moreGravity Path Circle fly
Mirror
VR
Rotate fly
Headless mode
Calibration
Voice Control
One key landing
One key take off
360 flip
Emergency Stop

11
Tap to activate this mode. Draw a path in the blank area on the right side of the screen
and the drone will fly following the path.
Fly / Land / Forward / Backward / Left / Right.
* This function only can be activated in drone controlled by mobile directly.
Path Flight:
Voice Control:
VR device (not included) is required to activate VR Mode.
VR Mode:

12
SPECIFICATIONS
Drone
Remote
Operating Temperature
Frequency Range
Frequency Range
Transmit Power (EIRP)
32°F to 104°F (0℃ to 40℃)
Model NH530: 2.416-2.475 GHz
Model NH530: 2.416-2.475 GHz
Model NH530: 2.4GHz<18dBm

13

14
This device complies with Part 15 of FCC Rules. Operation is subject to the following two
conditions:(1) this device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frenquency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following
measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
-Consult Customer Service or an experienced radio/TV technician for help.
Warning! Any changes or modifications not expressly approved by the party responsible
for compliance could void the use’s authority to operate the equipment.
FCC Caution:
Manufacturer
Guangzhou Huosejie Trading Co., Ltd.
eVatmaster Consulting GmbH
EVATOST CONSULTING LTD
Bettinastr. 30 60325 Frankfurt am Main, Germany
Suite 11, First Floor, Moy Road Business Centre, Taffs Well,
Carfiff, Wales, CF15 7QR
[e-mail]
[e-mail]
Address: 407-52N, 4th Floor, Building 3, No. 133 Yanling Road, Tianhe District,
Guangzhou, China
EC REP
UK REP

www.neheme.com / [email protected]
