NEILPRYDE RS:FLIGHT F4 User manual

ASSEMBLY MANUAL
NPWS RSFLIGHT F4 FOIL ASSEMBLY MANUAL Size: 210mmH x 297mmW
www.neilpryde.com

Tail Wing Adjustment:
Tail Wing
Adjustment
Neutral
DownTilted:
More lift and
stability at
lower speed.
UpTilted:
Lower lift and less
drag at higher
speeds.
0
Tools:
Parts:
Exploded:
#4 Allen key
T-shaft fuselage
x 1pc
#3 Allen key
1
1
Front high lift wing
x 1pc
2
2
Fronthigh speedwing
x 1pc
3
3
Tail wing x 1pc
4
4
M6x25 screw
x 3pcs
5
5
M5x9 screw
x 2pcs
M5x12 screw
x 2pcs
6 7
7
6
Before adjusting the angle of the tail wing first loosen the two side screws to make
sure tail is free to pivot up and down.
In order to tilt the wing up, loosen the upper screw by 5 turns from the middle position
and then tighten the bottom screw until it gets tight. Now re-tighten the top screw as
well as side screws to ensure solid, movement free connection.
In order to tilt the wing down, loosen the bottom screw by 5 turns from the middle
position and then tighten the top screw until it gets tight. Now re-tighten the bottom
screw as well as side screws to ensure solid, movement free connection.
