NetApp FAS9000 Manual

Pre-setup 1. Unpack all boxes and inventory contents.
Attention: Customers with specific power requirements must check Hardware Universe for their configuration options.
2. Watch the Setup Videos.
3. Review the NetApp ONTAP Configuration Guide.
Prepare for installation Install hardware Cable storage Complete system setup
and configuration
1 2 3 4
FAS9000 Systems
Installation and Setup Instructions
Screwdriver
Phillips #2
Laptop or console
With a USB/serial connection and
access to a Web browser to configure
your storage system
Rack space
8U per chassis
Prepare for installation |1
You provide
In the box
Controller-to-controller cablesHost cables
10 GbE network cable
Part number 112-00299,
112-00300, or 112-00301
40 GbE network cable
Part number 112-00543
Optical network cable
Part number 112-00188,
112-00189, or 112-00090
Storage cables
MiniSAS HD cable
Part number 112-00436,
112-00437, or 112-00438
40 GbE cluster interconnect cable
Part number 112-00542 or 112-00543
Ethernet cables
Additional network cables
For connecting your storage
to your network switch and client
Power cables
USB console cable
Part number 112-00508
215-15154_2020-12_en-us
Slide rail kit
Cable management device
Note: For more cable information and
part numbers, see the Hardware Universe.

Install hardware |2
• Unpack all boxes and inventory contents.
• Install rail kits, as needed, using the rail kit
installation instructions.
• Install the empty chassis into the system cabinet or rack.
• Reinstall the system components into the chassis,
matching the chassis slot ID with the slot ID
sticker on the component.
• Attach cable management device.
• Place the bezel on the front of the system.
Unpack and install the system.
Cable controller to switches (choose option A or B below)
See your network administrator for help connecting to your switch.
DO NOT power on controllers
at this point.
Handles and cable
management device
240 lbs. (109 kg)
Fully-populated chassis
A5
A6
A4
A3
A2
A1
A10
A9
A8
A7
A11
B5
B6
B4
B3
B2
B1
B10
B9
B8
B7
B11
6-2
6-1
6-2
6-1
1
1
2To management
network switches
3
To data
network
switches
3
To data
network
switches
90 lbs. (41 kg)
Empty chassis
2
1
A5
A6
A4
A3
A2
A1
A10
A9
A8
A7
A11
B5
B6
B4
B3
B2
B1
B10
B9
B8
B7
B11
6-2
6-1
6-2
6-1
2To management
network switches
3
To data
network
switches
3
To data
network
switches
1
To cluster switches
1
To cluster switches
Switchless cluster: Cable cluster
interconnect ports A together in slot
A4 and B4 (e4a) and again in slot
A8 and B8 (e8a).
Switched cluster: Connect ports a
in slot A4, B4, A8 and B8 (e4a, e8a)
to the cluster switch. Use the cables
supported by your switch.
Connect the wrench ports
to the management switches.
Connect the e4b and e8b ports
to the data switches.
Connect the e2a, e2c, e10a and
e10c ports to the data switches.
Strap the cables to the cable
management arms (not shown).
Connect the power cables to the
PSUs and connect them to dierent
power sources.
4
5
1
2
3
Cluster interconnect cable
10 GbE network cable
Ethernet cable
Power cable
Switchless cluster
Switched cluster
Controller A
PSU 1
Controller B
PSU 2 PSU 3 PSU 4
Controller A
PSU 1
Controller B
PSU 2 PSU 3 PSU 4
PSU 1 and PSU 3
provide power to
all side A FRUs,
PSU 2 and PSU 4
provide power to
all side B FRUs.
A
PSU 1 PSU 2 PSU 3 PSU 4
B
2nd
power
source
1st
power
source
40 GbE network cable

Cable storage |3
321 Connect the shelf-to-shelf ports Connect the controllers to Stack 1 Connect the controllers to Stack 2
Cabling a FAS9000 with external storage
(DS212C or DS224C disk shelves)
Multipath HA cabling
Quad-path HA cabling
(optional)
Insert SAS cable tab UP or tab DOWN and gently push into place until it clicks.
IOM12 21
L N K L N K
43
L N K L N K
IOM12 21
L N K L N K
43
L N K L N K
IOM12 21
L N K L N K
43
L N K L N K
IOM12 21
L N K L N K
43
L N K L N K
1
2
AC AC
1
2
AC AC
IOM12 21
L N K L N K
43
L N K L N K
IOM12 21
L N K L N K
43
L N K L N K
1
2
AC AC
A5
A6
A4
A3
A2
A1
A10
A9
A8
A7
A11
B5
B6
B4
B3
B2
B1
B10
B9
B8
B7
B11
6-2
6-1
6-2
6-1
Stack 1
Controller 1 Controller 2
Stack 2
First shelf
Last shelf
IOMA IOMB
IOMA IOMB
Mini-SAS HD cable
(PN 112-00436, 112-00437, or 112-00438)

Complete initial cluster setup with network discovery:
Note: If your laptop does not support network discovery, see the Detailed guide.
Connect your laptop to the management switch and access the network computers and devices.
Power on the shelves and set shelf IDs:
1. Plug the power cords into the shelf power supplies, connect them to power sources on dierent circuits,
and then turn on the power switches to boot the shelves.
2. If you need to change the shelf IDs,
continue with substeps a through e;
otherwise, skip to “Power on the
controllers” below.
Repeat these steps for any
remaining drive shelves.
aOpen File Explorer
c
Double-click either ONTAP icon.
Note: Accept any certificates displayed on your screen.
b
Click network in the left pane.
Then right click and select refresh.
Laptop Management Switch
Completing setup:
1. Click...
a) mysupport.netapp.com c) Download and install Active IQ Config Advisor
b) Create/log in to your account d) Register your system
2. Verify the health of your system by running Config Advisor.
3. After you have completed the initial configuration, go to the NetApp ONTAP Resources
page for information about configuring additional features in ONTAP.
Use System Manager Guided Setup to configure your cluster.
Turn on the power
switches to all nodes:
PSU 1 and PSU 3 provide
power to all side A FRUs,
PSU 2 and PSU 4 provide
power to all side B FRUs.
Remove end cap
Shelf ID number
0 0
a
Shelf ID number
0 9
c
Press and hold shelf ID button until 2nd
digit blinks, then push to advance to 0-9.
Note: The first digit stops blinking, and
the second digit continues to blink.
Wait 10 seconds for the
Amber LED (!) to appear,
then power-cycle the
drive shelf to set shelf ID.
e
0 9
Replace end cap
d
Shelf ID button
Faceplate
Press and hold shelf ID button until 1st digit
blinks, then push to advance to 0-9.
Note: The first digit continues to blink.
b
A
PSU 1 PSU 2 PSU 3 PSU 4
B
2nd
power
source
1st
power
source
Complete system setup and configuration |4
1
2
3
4
5
A5
A6
A4
A3
A2
A1
A10
A9
A8
A7
A11
B5
B6
B4
B3
B2
B1
B10
B9
B8
B7
B11
6-2
6-1
6-2
6-1
A
B
1
2
PSU 1 PSU 2 PSU 3 PSU 4
