• Fast 54Mbps wireless – 802.11g standard for
performance yo can rely on
• Backwards Compatible with 11Mbps – 802.11b
standard
• Easy Web-based set p – specially designed for
A stralian ADSL & Cable service providers
• Active firewall to protect yo r PC or network from
Internet hackers
• 5VPN endpoints to sec rely join networks or
comp ters over the Internet
WIRED AND WIRELESS – QUICKLY
NetComm’s NB5540’s integrated 802.11g wireless A and 4-port
10/100 Mbps switch make it quick and easy to deploy wireless and
wired LAN without the extra costs of a wireless access point, hub or
switch. The NB5540’s efficient antenna has a range of up to 150
meters and provides up to 128 bit WE data encryption for high-
level security.
KEEP YOUR OLD WIRELESS EQUIPMENT
If you already use 11Mbps wireless equipment it can still be used
with the NB5540 because the 802.11g standard is backwards
compatible with 802.11b
EASY TO USE
NetComm’s web-based One- age-Setup means you do not need to
install any drivers on your computer. All you need is a web browser,
such as Internet Explorer, on any computer using any Operating
System and you will be able to configure your connection.
SAFELY S ARE YOUR INTERNET CONNECTION
With just one IS account and a Cable or ADSL modem, you can
allow up to 253 Windows®, Macintosh or any other Ethernet-
enabled computers safe access to the internet to send and receive
emails, surf the web and so on. The Active Firewall will guard against
several forms of Denial of Service attacks as well as other types of
Hacking by using Stateful acket Inspection technology (see side
panels for details)
MAKE USING T E INTERNET EASIER
Universal lug and lay allows Internet applications such as MSN
Messenger©to operate automatically over your firewall without the
need for extra configuration.
JOIN NETWORKS AND COMPUTERS SECURELY
NetComm’s NB5540 supports automatic V N pass-through to allow
any existing V N client applications to continue to work through your
router. Alternatively you can use the five built-in I sec end points to
join to other office networks.
FIND FAULTS EASILY
To assist in configuring your network and fault finding, NetComm has
added email logging, ing and Trace Route diagnostics to the
NB5540.
54Mbps WIRELESS FIREWALL VPN ROUTER WITH 10/100 4-PORT SWIT H
NB5540
CHECK THESE GREAT FEATURES
The NB55554400is designed to get A stralians sharing the Internet easily, safely and wirelessly – witho t the need for technical
expertise. F lly feat red to cover a wide range of ses, it incl des an Active Firewall to help protect yo r comp ters from
attack and 55VPN endpoints so yo can connect to the office from home or anywhere in the world via the Internet.

Your Netcomm dealer:
Model Number NB5540
Standards IEEE 802.3 (10BaseT),
IEEE 802.3u (100BaseTX)
IEEE 802.11g Wireless
Ports WAN: One 10/100 RJ-45 port
LAN: Four 10/100 RJ-45 ports
All ports with auto cross-over detection
Wireless access point
Protocol TC /I , UD , NAT,DHC , oE,
Heartbeat, CHA , A
Maximum Users Up to 253 users
Cabling Type UT Category 5or better
IP Setting WAN: DHC client, Static I
LAN: DHC auto-assignment,
Static I
VPN Endpoints – IPSec
• Maximum tunnels: up to 5
• Local secure group: I , Subnet or I range.
• Remote secure group: I , Subnet, I range, Host or Any
• Remote security Gateway: I , FQDN, Any
• Encryption: DES, 3DES or none
• Authentication: MD5, SHA or none
• Authentication method: reshared key
• Key Management: Auto IKE ( FS or none) or Manual
(Encry, Auth, In-S I, Out S I)
VPN Pass-through (NAT traversal)
• I Sec enable/disable
• T enable/disable
• Concurrent sessions: up to 50 dependent on data
Firewall & Security
• revent Dos attack: ing of Death, LAND, I spoofing,
SYN flood, I Smurfing
• Stateful packet inspection (check inbound against
outbound)
• NAT deny external Intruder
• ACL Filter: I , MAC, URL keyword
• Block all: roxy, Active X, Java /script, cookies,
time of day/week
Management
• Web-based configuration
• Admin assword login
• Fault tolerant TFT upgradable firmware
• Reset button or Factory default reset
• SNM
Inbound Routing
• Special Application ( ort Triggering)
• ort Forwarding
• U n + ort Translation
• DMZ host / Multi DMZ.
LAN Routing
• Dynamic (RI 1& 2, independent Tx / Rx)
• Static
Wireless
• 802.11g standard • 802.11b standard
• Auto/manual data rates of 54, 48, 36, 24, 18, 12, 11,
9, 6, 5.5, 2, 1 Mbps
• WE 64/128bit
• MAC Filtering
Power External, 12V DC, 1A
Environmental Operating Temp 0 ~ 45˚C
Storage Temp -20 ~ 60˚C
Humidity 0% ~ 90% Non-Condensing
Certifications C-Tick (N367)
Dimensions 122 (L) x 175 (W) x 31 (H) mm
System Requirements
Operating system independent – ideal for
Windows®Macintosh, Linux & TC /I systems
KEY FEATURES
• NetComm NB5540 Wireless Firewall Router
• Cat-5RJ45 Straight-through Ethernet Cable
• lug ack 12V D , 1A
• Installation Guide
PACKAGE CONTENTS
• One- age-Setup (covers oE ADSL, Optus cable,
DHC , Telstra Cable Hear tbeat, Static I )
• Active Firewall featuring Stateful acket Inspection (S I)
and prevention of DoS attack (see side panel)
• 54Mbps wireless IEEE 802.11g standard with auto-
selection of optimum data rates
• Network Address Translation (NAT)
• 5V N Endpoints
• V N ass-through or NAT Traversal ( T & I Sec
enable/disable)
• Universal lug and lay
• ing Diagnostics
• Trace Route Diagnostics
• Back up & Restore Configuration
• Online Log viewer/Syslog/email reporting
• DDNS (Dynamic DNS)
• DHC Server
• Access Control (ACL’s by I /Mac/URL keyword)
• ort Forwarding
• Special Application ( ort Triggering)
• DMZ host/Multi DMZ
• Web-based Administration (configuration)
• Remote Administration (via the Internet configuration)
• SNM support (4Communities, Enable/Disable)
• Dynamic Routing (RI 1& 2)
• Static Routing
• 1 + 2 Year Warranty (Conditional upon registration online.)
TECHNICAL SPECIFICATIONS
Trademarks and registered trademarks are the property of NetComm Limited or their respective owners. Specifications are subject to change without notice. Images shown may vary slightly from the product.
NB5540
Fo r 10/100 a to-sensing
switched ports
Power ADSL or Cable
modem
Ethernet port
Reset b tton
