introduction 1-1
CHAPTER 1: INTRODUCTION
The NETGEAR Model GS524T 24-Port Copper Gigabit Switch provides you with a
low-cost,high-performance network solution and is designed to anchor and intercon-
nect 10/100/1000 megabits per second (Mbps) workgroups using copper Gigabit links.
Features
The Model GS524T switch has the following key features:
•24 full-duplex copper Gigabit ports with standard RJ-45 connectors
•Automatic address learning function to build the packet-forwarding
information table. The table contains up to 32,000 media access control (MAC)
addresses (that is, the switch can support networks with as many as 32,000
devices).
•Address aging function to automatically track changes in network configuration
•Protocol independence and compatibility with all common protocols, such as
TCP/IP,Netware, DECNet, Microsoft Networks, and AppleTalk
•Full-duplex mode to double throughput of point-to-point connections by letting indi-
vidual ports transmit and receive concurrently when the other end also supports
full-duplex mode
•Wire-speed filtering and forwarding of the traffic
•Store-and-forward intelligent processing to minimize erroneous packets on the net-
work
•Easy Plug and Play installation with no software to configure, which saves time and
minimizes the potential for configuration errors
•Auto UplinkTM in all ports to make the right connection
•Auto-negotiation with link partners to speeds of 10,100, or 1000Mbps on all ports
•Flow control traffic management to ensure no packets are dropped if there are
back-ups or bottlenecks in the network
R

introduction 1-2
Package Contents
Figure 1-1 illustrates the Model GS524T switch package contents.
Figure 1-1. Model GS524T Switch Package Contents
Verify that your package contains the following:
•Model GS524T switch
•Rubber footpads for tabletop installation
•The Installation Guide
•Rack mount kit for 19-inch rack installation
•Warranty & Owner Registration Card
•Support Information Card
•Power cord
GS524T
MODEL
Gigabit Fiber Switch
24PORT
10/100Mbps
Ethernet

physical description 2-1
CHAPTER 2: PHYSICAL DESCRIPTION
This chapter describes the hardware features of the NETGEAR Model GS524T Copper
Gigabit Switch.
Front Panel
The front panel of the Model GS524T switch contains the following LEDs that corre-
spond to each network port: FDX/COL (full-duplex/collision),Activity(RX/TX)/10Mbps .
Each network port has its own link and speed LEDs (located above each port).
Figure 2-1. Front Panel of the Model GS524T Switch
GS524T
MODEL
Gigabit Fiber Switch
24PORT
10/100Mbps
Ethernet
Link and Speed LEDs

physical description 2-2
RJ-45 Ports
The Model GS524T switch has 24 auto-sensing 10/100/1000 Mbps UTP ports.
Each port can operate at 1000 Mbps full-duplex mode,100 Mbps full/half duplex
mode,or 10Mbps full/half duplex mode,and provide a standard UTP for Category 5
or Category 5e cable.Figure 2-2 shows a RJ-45 connector.For further information
about Category 5 cables and connectors,refer to Appendix B,“Connector Pin
Assignments,”and Appendix C,“Cabling Guidelines.”The 1000BASE-T requires
very careful cable installation.
Key:
1 = 1000M Link LED
2 = 100M Link LED
Figure 2-2. RJ-45 Connector with Built-in LEDs
Auto Uplink
To simplify the procedure for attaching devices,all RJ-45 ports on the GS524T
Switch support Auto Uplink.This technology allows you to attach devices to the RJ-
45 ports using either straight-through or crossover cables.When you insert a cable
into the switch's RJ-45 port, the switch automatically:
•Senses whether the cable is a straight-through or crossover cable, and
•Determines whether the link to the attached device requires a "normal" connection
(such as when connecting the port to a PC) or an "uplink" connection (such as
when connecting the port to a router, switch, or hub).
After detecting this information, the switch automatically configures the RJ-45 port
to enable communications with the attached device,without requiring user interven-
tion. In this way, the Auto Uplink technology compensates for setting uplink connec-
tions, while eliminating concern about whether to use crossover or straight-through-
cables when attaching devices.
735EA
1 2

physical description 2-3
Note: Using Auto Uplink to create multiple active paths between any two network
devices can cause undesirable loops in the network,resulting in an endless broadcast
traffic that disables your network. Loops occur when there are alternate routes
between two network devices. In Figure 2-3,for example,a loop is created by con-
necting two RJ-45 ports on a GS524T Switch to a router containing a 4-port
switch.Figure 2-4 shows another scenario where a router with a 4-port switch con-
nects to a hub and to a GS524T Switch; the hub and switch, in turn, connect back
to the same router,creating multiple active paths between all three devices.
Figure 2-3. Warning! Creating loops disables your network(Example 1)
Figure 2-4. Warning! Creating loops disables your network(Example 2)
GS524T
MODEL
Gigabit Fiber Switch
24PORT
10/100Mbps
Ethernet
Model GS524T
FR314 Router

EN524 Hub
GS524T
MODEL
GigabitFiber Switch
24PORT
10/100Mbps
Ethernet
FR314 Router

Model GS524T
EN524
MODEL
®

physical description 2-4
100-240 VAC 50-60 Hz
AC power Receptacle
Fans
LEDs
Table 2-1 describes the activity of the LEDs.
Table 2-1. LED Descriptions
Label Color Activity Description
Power Green On Power is supplied to the switch.
Off Power is disconnected.
FDX/COL Green On The port is operating in full-duplex mode.
Off The port is operating in half-duplex mode.
Yellow Blinking Data collisions are occurring on the port. In a full-duplex
environment,there is no collision. In a half-duplex environment,
some collisions are normal.
Activity/ Green Blinking Packet transmission or reception is occurring on the port.
10M On A valid 10 Mbps link is established on the port.
Off No Activity on the port.
1000M Green On A valid 1000Mbps link is established on the port.
Off A link is not established on the port.
100M Green On A valid 100 Mbps link is established on the port.
Off A link is not established on the port.
Rear Panel
As illustrated in Figure 2-5,the rear panel of the Model GS524T switch has fans for cool-
ing and a standard AC Power Receptacle for the supplied power cord.
Figure 2-5. Rear Panel of the Model GS524T Switch

applications 3-1
CHAPTER 3: APPLICATIONS
This chapter presents an overview of the topologies possible by incorporating the
NETGEAR Model GS524T Copper Gigabit Switch into your network.
Desktop Switching
Figure 3-1 illustrates the Model GS524T switch,used as a desktop switch to build
a powerful network that enables users to have 1000 Mbps access to a file server.
If a full-duplex adapter card is installed in the server or PC,a 2000 Mbps connec-
tion will be provided to each server and PC.
Figure 3-1. Model GS524T Switch Used as a Desktop Switch
GS524T
MODEL
Gigabit Fiber Switch
24PORT
10/100Mbps
Ethernet
Servers with
GA622T Gigabit
network cards
PCs with
GA302T Gigabit
network cards
Model GS524T
Switch
technology of the

applications 3-2
Segment Switching and Bridging from 10 Mbps or 100 Mbps to 1000 Mbps
The Model GS524T switch,as illustrated in Figure 3-2,connects multiple power
workgroups and servers using high-speed gigabit links.Each power workgroup is
anchored by a NETGEAR Model FS518T switch.Other workgroups are connected
by a NETGEAR FS524 switch. Because each copper link can be up to 100 m long,
these workgroups can be located on separate floors.
Figure 3-2. Model GS524T Switch Used as a Segment Switch
GS524T
MODEL
Gigabit Fiber Switch
24PORT
10/100Mbps
Ethernet
MAC MAC
Model GS524T switc
h
Server with
GA622T Gigabit
network card

installation 4-1
CHAPTER 4: INSTALLATION
This chapter describes the installation procedures for the NETGEAR Model GS524T
Copper Gigabit Switch.
Preparing the Site
Before you begin installing your switch,prepare the installation site.Make sure your
operating environment meets the operating environment requirements of the equip-
ment listed inTable 4-1.
Table 4-1. Operating Environment Requirements
Characteristic Requirements
Temperature Ambient temperature between 0 and 40ºC (32 and 104ºF).
No nearby heat sources such as direct sunlight,warm air exhausts, or heaters.
Operating humidity Maximum relative humidity of 90%,noncondensing.
Ventilation Minimum 2 inches (5.08 cm) on all sides for cooling.
Adequate airflow in room or wiring closet.
Operating conditions At least 6 ft (1.83 m) to nearest source of electromagnetic noise
(such as photocopy machine or arc welder).
Power Adequate power source within 6 ft (1.83 m).
Checking Package Contents
Unpack the contents of the package and verify them against the following list:
•NETGEAR Model GS524T Gigabit Ethernet Switch
•Self-adhesive rubber footpads for desktop installation
•Rack Mount Kit for rack installation
•AC power cord
•Warranty & Owner Registration Card

installation 4-2
•The Installation Guide
•Support Information Card
Installing the Switch on a Flat Surface
To install the switch on a flat surface,be sure to attach the rubber footpads to the
bottom of the switch.
Installing the Switch in a Rack
Refer to Figure 4-1 when installing the switch in a rack.
Figure 4-1. Attaching Mounting Brackets
Connecting Devices to the Switch
To connect the switch:
1. Connect the devices to the network ports on the switch, using Category 5 (Cat5)
or Category 5e (Cat5e) UTP cable.
Note:Ethernet specifications limit the cable length between your PC or
server and the switch to 100 m.
2. Connect one end of the AC power adapter cable to the power receptacle on the
rear panel of the switch and the other end of the power adapter cable to
the wall outlet.
GS516T
MODEL
CopperGigabit Switch
100/1000Mbps
Power
Ethernet

installation 4-3
Refer to Figure 4-2 when connecting the switch.
Figure 4-2. Connecting to the Model GS524T Switch
Verifying Installation
When power has been applied to the switch,verify that:
•The green power LED on the front panel is on.
•The green link LED on each connected port is on.
When the switch is connected and operating,refer toTable 2-1 “LED Descriptions”
for information about the LEDs and their activity.
GS508T
MODEL
GigabitFiberSwitch
16PORT
10/100Mbps
Ethernet
1000 Mbps
100 Mbps
10 Mbps
Key

CHAPTER 5: TROUBLESHOOTING
This chapter provides information about troubleshooting the NETGEAR Model
GS524T Copper Gigabit Switch.Table 5-1 lists symptoms, causes, and solutions of
possible problems.
Table 5-1. Troubleshooting Information
Symptom Cause Solution
Power LED is off. No power is received Check the power cord connections for the switch
at the switch. and the connected device.
Make sure all cables used are correct and comply
with Ethernet specifications.
1000M or 100M Port connection is Check the crimp on the connectors and make
LED is off or not functioning. sure that the plug is properly inserted and
intermittent. locked into the port at both the switch and the
connecting device.
Make sure all cables used are correct and comply
with Ethernet specifications.See Appendix C.
Check for a defective adapter card, cable, or port
by testing them in an alternate environment where
all products are functioning.
File transfer is slow Half- or full-duplex Make sure the remote link partner is set to
or performance setting on the switch auto negotiate.
degradation is and the connected
a problem. device are not the same.
A segment or device One or more devices Verify that the cabling is correct.Be sure all
is not recognized as are not properly cable connectors are securely positioned in the
part of the network. connected, or cabling required ports. Equipment may have been
does not meet accidentally disconnected.
Ethernet guidelines.
COL LED is Collisions are Some collisions are normal when the connection
blinking yellow occurring on the is operating in half-duplex mode.
excessively. connected segment.
Duplex modes are Recheck the link partner settings.
mismatched.
troubleshooting 5-1
