WG602
54 Mbps Wireless Access Point
Up to 5x Faster and Backward Compatible with 802.11b
Wireless Networks
NETGEAR’s WG602 Wireless Access Point lets you add IEEE 802.11g wireless access to your
network. With its high-speed data transmission of up to 54 Mbps network users can share a
broadband Internet connection, access e-mail, download large files, videoconference, and
distribute and play digital images, videos, and MP3 files. Easy to set up and use, NETGEAR’s
Smart Wizard install assistant makes installations a cinch. And with Wi-Fi Protected Access
(WPA2-PSK) security, you can rest assured that your wireless network communications
are private.
Simultaneously supports both IEEE 802.11b and 802.11g standard devices and networks. This dual
mode capability protects your 802.11b wireless investment and, at the same time, has you ready
for the up to five times faster 802.11g. Provides connectivity to a wired or wireless network for
expanded bandwidth. Higher speeds expedite large file downloads and facilitate videoconferencing
and the distribution and playing of high-quality multimedia content.
Provides the highest available level of industry-standard WEP encryption: 128-bit for both 802.11b
and 802.11g devices. MACaddress authentication offers enhanced security byensuring only
authorized users can access the network. Wi-Fi Protected Access using a pre-shared key WPA2-PSK
is also supported.
Connect two LANS wirelessly using the bridge mode. Extend your wireless signal by adding a
WG602 in repeater mode. Dynamic rate shifting according to environmental conditions achieves
the fastest possible connections. Thorough testing ensures quality and reliable operation, which
NETGEAR backs up with a solid 1-year warranty.
High-speed
Secure
Dependable
• Help is there when you need it!
NETGEAR provides, 24x7
technical support* in English,
with selected local language
support during office hours.
Notebook PC with
WG511 54 Mbps
Wireless PC Card
WG602 54 Mbps
Wireless Access Point
Broadband
modem
FVS114 ProSafe VPN
Firewall Router
POWER
CABLE
STATUS
ETHERNET
USB
Broadband Cable M
odem
Desktop PC with
WG311 802.11g
Wireless PCI Adapter
Notebook PC with
WAG511 Dual Band
Wireless PC Card
Notebook PC with
MA521 802.11b
Wireless PC Card
Internet

Technical Specifications
802.11b/g
•Radio Data Rate:
-1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48 & 54 Mbps
•Modulation Type:
-OFDM with BPSK, QPSK, 16QAM, 64QAM,
DBPSK, DQPSK, CCK
•Frequency:
-2.412 ~ 2.462 GHz (US)
-2.412 ~ 2.484 GHz (Japan)
-2.412 ~ 2.472 GHz (Europe ETSI)
-2.457 ~ 2.462 GHz (Spain)
-2.457 ~ 2.472 GHz (France)
•Antenna:
-Single detachable 2 dBi antenna
-Transmit Power: 16 dBm
•Security:
-40-bit (also called 64-bit), 128-bit WEP
encryption
-MAC Address filtering
-WPA2-PSK
-802.11i
•Features:
-Smart Wizard for easy installation
-Firmware upgradable via a web browser
-Backwardcompatible with existing IEEE
802.11b devices
-SSID Broadcast enable/disable
-Supports repeater mode
•Power Adapter:
-7.5V,1A; plug is localized to country of sale
•Physical Specifications:
-Dimensions: 28 x 175 x 118 mm
(1.1 x 6.9 x 4.7 in.)
-Weight: 0.3 kg (0.7 lb)
•Electromagnetic Compliance:
FCC Part 15 Sub Class B, CE
•Environmental Specifications:
-Operating Temperature: 0 to 40˚ C
(32 to 104˚ F)
-Operating Humidity: 5-95% (noncondensing)
•Warranty:
-NETGEAR 1-year warranty*
WG602 54 Mbps Wireless Access Point
Package Contents
-54 Mbps Wireless Access Point WG602v3
-Power adapter
-Ethernet cable
-Resource CD
-User's guide
-Warranty/Support information card
Minimum System Requirements
-Pentium®Class PC
-Microsoft®Windows®98SE, ME, 2000 or XP
NETGEAR Related Products
-WAG511 Dual Band 802.11a/b/g Wireless PC Card
-WG511 54 Mbps Wireless PC Card
-WG311 54 Mbps Wireless PCI Adapter
-WG111 54 Mbps Wireless USB 2.0 Adapter
-WGR614 54 Mbps Wireless Router
-FWG114P ProSafe 802.11g Wireless VPN Firewall with
USB Print Server
4500 Great America Parkway
Santa Clara, CA 95054 USA
Phone: 1-888-NETGEAR
E-mail: [email protected]
www.NETGEAR.com
©2007 NETGEAR, Inc. NETGEAR, the
NETGEAR logo, Connect with Innovation,
Everybody’s connecting, the Gear Guy logo,
IntelliFi, ProSafe, RangeMax and Smart
Wizard are trademarks or registered
trademarks of NETGEAR, Inc. in the United
States and/or other countries. Microsoft and
Windows are trademarks or registered
trademarks of Microsoft Corporation in the
United States and/or other countries. Other
brand and product names are trademarks
or registered trademarks of their respective
holders. Information is subject to change
without notice. All rights reserved.
Maximum wireless signal rate derived
from IEEE Standard 802.11 specifications.
Actual data throughput will vary. Network
conditions and environmental factors,
including volume of network traffic,
building materials and construction,
and network overhead, lower actual
data throughput rate.
* Free basic installation support provided
for 90 days from date of purchase.
Advanced product features and
configurations are not included in free
basic installation support; optional
premium support available.
D-WG602-7
