NeuroTek EyeScan Deluxe User manual

LiabilityDisclaimer
This product is a tool designed to assist the clinician in the administration of
EMDR. The purchaser/clinician agrees to accept full responsibility for any
harmful results and/or undesirable consequences obtained from the use of
thismachine.
The manufacturer of this machine shall not be held liable for adverse affects
caused to clients resulting from the administration of EMDR or any other
form of therapy using this machine.
Any unexpected reactions, results, or behavior noted as a result of the
administration of EMDR, either using this product or by other methods,
should be immediately reported to the EMDR Institute.
The EMDR Clinician's Assistant
Please read all instructions
completely before operating.
EyeScan Deluxe
TM
Warning
This instrument should not be used with
any person who has a history of seizures.
LimitedWarranty
The manufacturer warrants this equipment to the original purchaser against
defective material or workmanship during the warranty period from the date
of purchase. The manufacturer’s responsibility under this warranty is
limited to the repair or replacement of defective parts.
Thewarrantyperiod:
90 days on components that connect with wires. This includes cables,
wired pulsers, headphones and AC Adapters. One year on all other parts
and components. The manufacturer reserves the right to determine whether
the part or parts failed because of defective material, workmanship or other
causes. Failure caused by accident, normal wear, alteration, misuse,
tampering, negligence or improper packaging of returned units is not
coveredbythiswarranty.Thiswarrantyisvoidwhen productisusedby
multipletherapistsin a shared environment. Please be advised that if a
product is returned for warranty service and no defects are found or the
problem is due to a weak/dead battery or operator error a shop charge and
return shipping costs may be charged.All warranty repairs must be done
by NeuroTek or a representative designated by NeuroTek.Any repair to the
equipment other than by these authorized facilities voids this warranty. The
rights under this warranty are limited to the original purchaser and may not
be transferred to subsequent owners. To receive warranty service, you
mustfirstcontactNeuroTekfora returnauthorizationnumber. This
number will be used for tracking your return. Send the complete unit,
postage paid, to NeuroTek. Include a description of the problem you are
having and a daytime phone number.
303420-8680Voice
303422-9440 FAX
[email protected]
12100W.52ndAve.#116
WheatRidgeCO80033
www.neurotekcorp.com
TM
NeuroTek
Corporation

GettingStarted:
The EyeScan Deluxe comes with 7 main components, the light bar, the remote control, a
tripod, headphones, pulsers, audio interface cable and theAC adapter. The light bar is designed to
mountdirectly tothetripod. First,connect thetripodto thelightbar. Ifyoumountthelightbaron
the tripod with the handle positioned parallel to the light bar, you will be able to adjust the
horizontal/verticalaxis. Ifthehandleispositionedouttheback,youwillnotbeabletoadjustthe
angle. Next, connect the headphones and pulsers to the light-bar as shown. Finally, connect the
AC adapter to the light bar and plug theAC adapter to a wall outlet power source. If you are using
the music option, connect the interface cable from the external audio input on the light-bar to the
headphone jack on your tape or CD player. Set the volume on your music player to maximum.
Turning on the Power: The on/off switch is located on the back of the light-bar. When you are
ready to start an EMDR session, turn the power switch to the on position. The lights will make
one complete scan and then stop in the center of the light bar. After finishing your session, turn
the power switch off.
The Remote Control: The remote control sensors are located on each end of the light-bar in the
displaywindows.Reducedsensitivitytotheremotecontrolmayberealizedifremotecontrolis
pointeddirectlyinfrontof,orinbackofthelight-bar.AllbuttonfunctionsontheRemoteControl
are illustrated in the diagram to the right. The green indicator on the remote control will flash when
any button is pushed. If the light fails to flash, replace the 2AAbatteries in the remote.
To begin scanning press the “Start” button. To stop scanning press the “Stop” button. The
lights will always stop in the center of the light-bar. All modes and settings may be changed
whether scanning or stopped.
TheNumericDisplay:TheEyeScanDeluxe has twonumericdisplays, one convenientlylocated
oneachend of thelight-bar. Each 3-digitdisplaywill indicate 8differentinformationmodes:
counter, visual mode, audio mode, volume, speed, and pulser intensity, brightness and color. To
select the between the different display modes, press the "Mode /\" or the "Mode \/" buttons
repeatedly until the desired display mode is reached. See display mode diagrams to the right.
CountDisplayMode: This isthedefaultdisplay modewhentheEyeScan 4000 isfirstturned on.
To select the count display mode, push the "Mode /\" or the "Mode \/" buttons until the 3 dots
at the bottom of the display window are off. When count display mode is selected, the com-
pleted number of repetitions for the current set are displayed. The counter will count up to 999
before starting over. When the EyeScan is stopped between sets, the counter will continue to
display the most recent count. When the next set is started, the counter will reset to zero. The
EyeScan always keeps track of the current count even if the Count display mode is not selected
on the display. Pressing the "/\" or "\/" buttons in count mode will adjust the speed.
VisualDisplay Mode:To select the "visual display mode", press the press the "Mode/\"or the
"Mode \/" buttons repeatedly until all three red dots are on and the left digit displays a "1". When
"visualdisplaymode"isselected,therightdigitwilldisplaya"S"for scan mode or "E" for ends
onlymode. Press the "/\" or "\/" buttons to switch between "Scan"or "Ends only" modes.
AudioDisplay Mode:To select the "audio display mode", press the press the "Mode/\"or the
"Mode \/" buttons repeatedly until all three red dots are on and the left digit displays a "2".
Headphones
Tripod
Connects
Here
EyeScan Deluxe Operating Instructions
When audio display mode is selected, the right digit will display a "I" for
internaltoneor"E"for externalaudiomode.Pressthe"/\" or "\/"
buttonstoswitch between"InternalTone"or"ExternalAudio" modes.
VolumeDisplay Mode:To select the "volume display mode", press the
"Mode/\"or the "Mode\/"buttons repeatedly until all three red dots are
on and the left digit displays a "3". When "volume display mode" is
selected, a volume number between 1 & 15 is displayed. Press the "/\" or
"\/" buttons to increase or decrease the volume.
SpeedDisplayMode:Toselectthe"speeddisplaymode",pressthe"Mode
/\"or the "Mode \/" buttons repeatedly until all three red dots are on and
the left digit displays a "4". When "speed display mode" is selected, a
speed reference number between 1 & 40 is being displayed. Pressthe"/\" or
"\/" buttons to increase or decrease the speed of alternations.
PulserIntensityDisplayMode:Toselectthe"pulserintensitydisplaymode",
press the "Mode /\"or the "Mode \/"buttons repeatedly until all three red
dots are on and the left digit displays a "5". When "pulser intensity
display mode" is selected Press the "/\" or "\/" buttons to increase or
decrease the pulser intensity.
BrightnessDisplaymode: Press the"Mode/\" or the"Mode \/"buttons
repeatedly until all three red dots are on and the left digit displays a "6"
Press the "/\" or "\/" buttons to increase or decrease the brightness of
the lights.
AC Adapter
NumericDisplay
Numeric Display
Remote Control
Green Indicator
Pulsers
Gray pulser is left side
Black pulser
is right side
External Audio
To CD or tape player's
headphone jack
Display in
count mode
(dots are off)
Display shows
scan selected
(dots are on)
Display shows
external audio selected
(dots are on)
Display shows
volume at 15
(dots are on)
Display shows
speed at 25
(dots are on)
Displays tactile
intensity at 14
(dots are on)
Displaymodes
ColorDisplaymode: Press the "Mode/\"orthe"Mode\/" buttons repeatedlyuntilall threered
dots are on and the left digit displays a "7" Press the "/\" or "\/" buttons to select color.
1=green,2=blueand 3=red.Selectingcolormode 4willalternatethrough allcolors.
Battery:The EyeScan Deluxe will operate from the integrated 9 volt battery or by plugging into a
wall outlet. The battery door is located on the back side of the light-bar. When theAC adapter is
plugged into the light-bar, the battery is internally disconnected. Whenusingbatterypower, if
youexperienceanyabnormaloperationsuchasintermittentpulsersorremotecontrol
problems,thebatteryisprobablygettingweakandshouldbereplaced.
Displays brightness
at 15 (dots are on) Displays color
1=green
(dots are on)
