Olympus EVIS EUS EU-ME2 User manual

CAUTION: This quick reference guide is only a summary of the EU-ME2, EU-ME2 Premier Plus Instructions for Use. For detailed operating instructions, be sure to follow
the EU-ME2, EU-ME2 Premier Plus Instruction Manual included with your EU-ME2 or EU-ME2 Premier Plus purchase.
EU-ME2, EU-ME2 Premier Plus
Quick Reference Guide - Basics
Frequency
1
Select the MAIN MENU tab on the LCD touch panel.
2
Press the FREQUENCY buttons to adjust the ultrasound transmission frequency.
* The selected frequency can be confirmed on the left hand side of the screen in green.
* Available frequencies vary from scope to scope.
Mechanical radial scanning: C5, C7.5, C12, and C20
Electronic scanning: 5, 6, 7.5, 10, and 12MHz
Enhancement
1
Select the MAIN MENU tab on the LCD touch panel.
2
Press the ENHANCE button to turn on image enhancement.
3
Press the ENHANCE button again to turn off image enhancement.
* When ENHANCE is on, the frequency is highlighted with a green background.

2
CAUTION: This quick reference guide is only a summary of the EU-ME2, EU-ME2 Premier Plus Instructions for Use. For detailed operating instructions, be sure to follow
the EU-ME2, EU-ME2 Premier Plus Instruction Manual included with your EU-ME2 or EU-ME2 Premier Plus purchase.
EU-ME2, EU-ME2 Premier Plus
Quick Reference Guide - Basics
Gain
Contrast
1
Press the GAIN keys to adjust the brightness of the ultrasound image.
* The selected gain is shown on the left hand side of the screen.
* The gain can be adjusted in 16 steps.
1
Select the IMAGE ADJUST tab on the LCD touch panel.
2
Press the CONTRAST buttons to adjust the contrast of the ultrasound image.
* The selected contrast is shown on the left hand side of the screen.
* The contrast can be adjusted in 8 steps.
GAIN Key

3
CAUTION: This quick reference guide is only a summary of the EU-ME2, EU-ME2 Premier Plus Instructions for Use. For detailed operating instructions, be sure to follow
the EU-ME2, EU-ME2 Premier Plus Instruction Manual included with your EU-ME2 or EU-ME2 Premier Plus purchase.
EU-ME2, EU-ME2 Premier Plus
Quick Reference Guide - Basics
Depth / Range
1
The DEPTH/RANGE keys can be used to magnify or shrink ultrasound images.
2
Shrink the image with the key and magnify the image with the key.
* The display range is shown in the lower left (in green).
* The adjustable depth/range is variable depending on the type of scope.
Mechanical radial scanning: 2, 3, 4, 6, 9, and 12 cm
Electronic scanning: 2, 3, 4, 5, 6, 7, 8, 9, and 12 cm
DEPTH/RANGE Keys
Display Area
1
Select the MAIN MENU tab on the LCD touch panel and press the DISPLAY AREA buttons to switch between Full Circle
and Top/Bottom Sector images.
* This function is available with radial scanning scopes ONLY.
* The trackball (or SCROLL key) on the keyboard also enables movement of the ultrasound images as desired.
Full Circle Bottom Sector

4
CAUTION: This quick reference guide is only a summary of the EU-ME2, EU-ME2 Premier Plus Instructions for Use. For detailed operating instructions, be sure to follow
the EU-ME2, EU-ME2 Premier Plus Instruction Manual included with your EU-ME2 or EU-ME2 Premier Plus purchase.
EU-ME2, EU-ME2 Premier Plus
Quick Reference Guide - Basics
Image Rotation / Scroll / Cine Review
Direction
1
Press the I.R. key, SCROLL key, or CINE REVIEW key near the trackball and confirm the corresponding indicator (green light)
is lit.
2
Use the trackball or ARROW keys to rotate (I.R.), move (SCROLL), or select (CINE REVIEW) images.
* Scroll is availalbe with radial scanning scopes only.
* In LIVE mode, the EU-ME2 can store ultrasound images that are saved a few seconds before the image is frozen. The saved images can be reviewed
retrospectively just after freezing with CINE REVIEW.
* CINE REVIEW is available only when the image is frozen. The frame number displayed on the monitor consists of “the frame number of the image being
selected and viewed” and “the total number of saved image frames.” The new frame number is “1.”
1
Select the MAIN MENU tab on the LCD touch panel.
2
Press the DIR button to switch the viewing direction of the ultrasound image.
* The DIR button switches whether the ultrasound image is displayed as the view from the distal end of the ultrasound scope/probe (NORMAL) or the
insertion direction (INVERSE).
CINE REVIEW Key
ARROW Keys
CINE REVIEW Key
Trackball
SCROLL KeyI.R. Key

5
CAUTION: This quick reference guide is only a summary of the EU-ME2, EU-ME2 Premier Plus Instructions for Use. For detailed operating instructions, be sure to follow
the EU-ME2, EU-ME2 Premier Plus Instruction Manual included with your EU-ME2 or EU-ME2 Premier Plus purchase.
EU-ME2, EU-ME2 Premier Plus
Quick Reference Guide - Basics
Measurement
1
Press the CALIPER key near the trackball to show the +marking.
2
Using the trackball, move the +marking to the desired starting point for the measurement.
3
Press the SET key to establish the starting point.
4
Using the trackball, move the +marking to the desired end point for the measurement.

6
CAUTION: This quick reference guide is only a summary of the EU-ME2, EU-ME2 Premier Plus Instructions for Use. For detailed operating instructions, be sure to follow
the EU-ME2, EU-ME2 Premier Plus Instruction Manual included with your EU-ME2 or EU-ME2 Premier Plus purchase.
EU-ME2, EU-ME2 Premier Plus
Quick Reference Guide - Basics
Measurement (Continued)
5
Press the SET key to establish the end point. The measurement results are shown.
6
With the completion of the measurement, the second measurement starts and a new +marking appears. By following
steps 2 to 5 above, up to 4 simultaneous measurements are possible.
* To clear the measurement results, press the CLEAR key on the keyboard or CLEAR button in the MEASUREMENT tab on the LCD touch panel.
* The MEASUREMENT menu on the LCD touch panel is on the second page, which can be accessed by using the CHANGE PAGE button.
* Press the CALIPER key again to end measurements while keeping the previous results.
MEASUREMENT Keys
Trackball
MEASUREMENT MenuCHANGE PAGE Button
D1
Example
Measurement
Results
Measurement
results display area
Marking

7
CAUTION: This quick reference guide is only a summary of the EU-ME2, EU-ME2 Premier Plus Instructions for Use. For detailed operating instructions, be sure to follow
the EU-ME2, EU-ME2 Premier Plus Instruction Manual included with your EU-ME2 or EU-ME2 Premier Plus purchase.
EU-ME2, EU-ME2 Premier Plus
Quick Reference Guide - Basics
Comment
1
Press the ADD key above the trackball and confirm that a CURSOR appears.
2
Using the trackball, move the CURSOR to the desired location to add comments.
3
Enter comments by using the alphanumeric keys or TEXT buttons located in the COMMENT tab on the LCD touch panel.
4
When the CURSOR is moved after entering comments, a new CURSOR appears and new comments can be added.
Follow steps 2 and 3 above to proceed.
* To clear comments, press the CLEAR key on the keyboard or CLEAR COMMENT button in the COMMENT tab on the LCD touch panel.
* The COMMENT menu on the LCD touch panel is on the second page, which can be accessed by using the CHANGE PAGE button.
CHANGE PAGE Button COMMENT Menu
Example
TEXT Buttons
COMMENT
Keys
Trackball 1. CURSOR
3. Input "Ao"
2. Moving CURSOR

8
CAUTION: This quick reference guide is only a summary of the EU-ME2, EU-ME2 Premier Plus Instructions for Use. For detailed operating instructions, be sure to follow
the EU-ME2, EU-ME2 Premier Plus Instruction Manual included with your EU-ME2 or EU-ME2 Premier Plus purchase.
EU-ME2, EU-ME2 Premier Plus
Quick Reference Guide - Basics
Save / Release
Picture-in-Picture (PIP)
1
Press the SAVE/REC key to store images on the EU-ME2.
2
Images can be released to a black and white printer by pressing the RELEASE key.
1
Press the PIP key to display an ultrasound image and an endoscopic image, together on the monitor.
2
Press the PIP key again to remove the endoscopic image.
SAVE/REC Key
RELEASE Key
PIP Key
Endoscopic
(sub screen)
Olympus is a registered trademark of Olympus Corporation, Olympus America Inc., and/or their affiliates.
3500 Corporate Parkway, PO Box 610, Center Valley, PA 18034
For more information, contact your Olympus
sales representative, or call 800-848-9024.
