New Holland BC5000 Series
Small Square Baler Specifications
BC5050 BC5060 BC5070 BC5080
Page 1 of 2
MODEL BC5050 BC5060 BC5070 BC5080
BALE IZE:
Cross section, in. (cm) 14x18 (36x46) 14x18 (36x46) 14x18 (36x46) 16x18 (41x48)
Length, in. (cm) ................................................................................Adjustable, 12 to 52 (31 to 132) ..............................................................................
UPER- WEEP PICKUP:
Width inside, in. (m) 65 (1.65) 65 (1.65) 75 (1.9) 75 (1.9)
Width on flare, in. (m) 70 (1.8) 70 (1.8) 80 (2) 80 (2)
Number of teeth 88 on four tooth bars 110 on five tooth bars 156 on six tooth bars 156 on six tooth bars
Floating windguard Eight rods Eight rods Thirteen rods Thirteen rods
Drive ........V-belt to roller chain to “lost motion” reel drive .......... ——
Gauge wheel 3.00x12; semi-pneumatic 3.00x12; semi-pneumatic 15x6.00x6 15x6.00x6
ROTARY FEEDING Y TEM:
Type — Packer fork in combination Packer fork in combination Packer fork in combination
with two paired rotors with three paired rotors with three paired rotors
Drive — ............................Chain from main drive shaft; sealed ball bearings on all shafts ..........................
FLOW-ACTION®FEEDING Y TEM:
Type Six feeder tines on a moving —— —
finger bar
Drive Chain; sealed ball bearings —— —
FEED OPENING, sq. in. (cm3) 283 (1826) 283 (1826) 283 (1826) 318 (2052)
PLUNGER:
Stroke length, in. (cm) 30 (76.2) 30 (76.2) 30 (76.2) 30 (76.2)
Speed (540 rpm) 79 SP 93 SP 93 SP 93 SP
Construction ..........High-strength steel throughout; modified extension is built into the plunger face, eliminating the need for bolt-on extensions ........
TYING MECHANI M :
Type Knotter Knotter or twister Knotter or twister (heavy-duty) Knotter (heavy-duty)
Protection Shearbolt Shearbolt Shearbolt Shearbolt
Capacity (twine) Four balls Six balls Eight balls Eight balls
(wire) NA Four coils Four coils NA
MAIN DRIVE:
Flywheel diameter, in. (cm) 22 (56) 22 (56) 22 (56) 22 (56)
PTO Three-joint Three-joint Three-joint Three-joint
Protection ..........................................................................Shearbolt, overrunning and slip clutches ........................................................................
Gearbox ................................................Hypoid with tapered roller bearings; heat-treated alloy steel running in oil ..............................................
TIRE :
Flotation (right) 25x7.50-15, 6PR 27x9.50-15, 6 PR 27x9.50-15, 6PR 11Lx15, 6PR
(left) 27x9.50-15, 6PR 31x13.50-15, 6PR 31x13.50-15, 6PR 14Lx16.1, 6PR
DIMEN ION :
Height (max.), in. (cm) 58 (146) 70 (178) 71 (180) 71 (180)
Width, in. (cm) 108 (275) 110 (279) 120 (304) 120 (304)
Length:, in. (cm)
With 3-joint PTO and
quarter-turn bale chute 240 (610) 247 (626) 247 (626) 247 (626)

New Holland BC5000 Series
Small Square Baler Specifications
BC5050 BC5060 BC5070 BC5080
Page 2 of 2
MODEL BC5050 BC5060 BC5070 BC5080
WEIGHT (APPROXIMATE):
With three-joint PTO,
twine version, lb. (kg) 3,085 (1399) 3,400 (1542) 3,715 (1685) 4,200 (1905)
With three-joint PTO,
wire version, lb. (kg) NA 3,536 (1603) 3,851 (1746) NA
RECOMMENDED TRAN PORT PEED,
mph (km/h) 20 (32) 20 (32) 20 (32) 20 (32)
TRACTOR REQUIREMENT*
Horsepower (min.), hp (kW) 35 (26) 62 (45) 75 (56) 80 (60)
*Tractor weight must be greater than baler weight; excludes bale thrower.
OPTION BC5050: two- or three-joint PTO (Cat. IV); hydraulic pickup lift; hydraulic tongue swing; needle slot baffle kit; auxiliary
lights; road light kit; safety chain; wagon hitch and bale loading chute; triple-purpose chute; quarter-turn bale chute;
hydraformatic bale tension; ball hitch (BC5070, BC5080 only); replaceable bale chamber, hydraulic doors kit and bale
case extension kit (BC5080 only); bale case extension; grass feeder kit; safety chain; two-position hitch.
Safety begins with a th r ugh understanding f
the equipment. Always make sure y u and
y ur perat rs read the Operat r’s Manual
bef re using the equipment. Pay cl se
attenti n t all safety and perating
decals and never perate machinery
with ut all shields, pr tective devices
and structures in place.
Design, materials and/ r specificati ns are subject t
change with ut n tice and with ut liability theref r.
Specificati ns are applicable t units s ld in Canada, the
United States, its territ ries and p ssessi ns, and may
var y utside these areas.
