New Holland
T5000 Series Tractor Specifications
T5040 T5050 T5060 T5070
P ge 1 of 2
T5040 T5050 T5060 T5070
ENGINE*
Type .......................................................New Holland 4-cycle diesel, parent-bore block .......................................................
Cylinders/Aspiration .................................................................4 / Turbocharged and intercooled .................................................................
Displacement, cu. in. (L) 274 (4.5) 274 (4.5) 274 (4.5) 274 (4.5)
Rated speed, rpm 2300 2300 2300 2300
ross engine hp (kW) 85 (63.4) 95 (70.9) 105 (78.3) 115 (85.7)
PTO hp (kW) 70 (52.2) 80 (59.7) 90 (67.1) 96 (71.6)
Torque rise 43% 39% 47% 30%
Air cleaner ..........................................................................Dry type, dual element..........................................................................
Fan .........................................................10-blade fixed, 18.9-in. (480 mm) diameter .........................................................
Emission legislation Tier III Tier III Tier III Tier III
Fuel tank capacity, gal. (L) 33.5 (127) 33.5 (127) 33.5 (127) 33.5 (127)
ELECTRICAL
System voltage, volts 12 12 12 12
Battery, cca 960 960 960 960
Alternator, amps 120 120 120 120
Cold start aid ................................................................................... rid heater ...................................................................................
TRANSMISSION
Standard configuration: Base .........................................12x12 with a mechanical shuttle.......................................... 12x12 power shuttle
Option 1 .............................................12x12 with a power shuttle.............................................. —
Option 2 ..................................20x12 Creeper with a mechanical shuttle................................... —
Deluxe configuration .......................................... 24x24 with a Dual Command™ electrohydraulic power shuttle..........................................
Clutch type / size (mechanical) ...................................... Dry / 12-inch (305 mm) diameter, heavy-duty cerametallic material......................................
Clutch type / size (electrohydraulic) ................................................... Wet / six plates 5.2 in. (133 mm), organic material...................................................
ears: 2–9 mph working range** ............................................12x12 Transmission: 7 gears; 24x24 Transmission: 14 gears ...........................................
ears: <1 mph** .........................................................................20x12 Creeper: 7 gears .........................................................................
Maximum speed**, mph (kph) ....................................................Standard Tractor: 19 (30); Deluxe Tractor: 25 (40)....................................................
PTO
Type ..............................................................................Fully independent..............................................................................
Base speed 540 rpm .................................540/1000 rpm with interchangeable shaft...............................
Operator control, Standard configuration .........................................Mechanical engagement, optional: Electrohydraulic engagement.........................................
Operator control, Deluxe configuration ....................................................................Electro-hydraulic engagement ....................................................................
Engine speed ....................................2199 engine rpm at 540 PTO rpm; 2261 engine rpm at 1000 PTO rpm....................................
Shaft size .................................................540 rpm: 1-3/8, 6 spline / 1000 rpm: 1-3/8, 21 spline .................................................
3-POINT HITCH
Category II II II II
Draft sensing ...................................................................Mechanical, lower link sensing ...................................................................
Base ASAE lift capacity @ 24 in., lbs. (kg) 5745 (2605) 5745 (2605) 5745 (2605) 5745 (2605)
Optional ASAE lift capacity @ 24 in., lbs. (kg) 6805 (3086) 6805 (3086) 6805 (3086) 6805 (3086)
Base equipment ...........................Flexible link arms, telescoping stabilizers, Lift-O-Matic™ upper/lower limit setting...........................
HYDRAULICS
System type Open center Open center Open center Open center
System pressure, psi (bar) 2871 (198) 2871 (198) 2871 (198) 2871 (198)
Implement pump flow, gpm (L/min.) 16.1 (61) 16.1 (61) 16.1 (61) 16.1 (61)
Steering & services pump, gpm (L/min.) 10.4 (39.5) 10.4 (39.5) 10.4 (39.5) 10.4 (39.5)
Hydraulic flow @ mid-mount valve gpm (L/min.) ..........................................................................maximum 21.0 (79.5) ..........................................................................
Remote valves, Standard configuration ..................................................................................Open center ..................................................................................
Remote valves, Deluxe configuration ............................Closed center with flow control (one less flow control than number of remotes) ............................
Remotes — Base / optional .....................................................................2 / 3 (4 & 5 w/ loader valve) .....................................................................

New Holland
T5000 Series Tractor Specifications
T5040 T5050 T5060 T5070
P ge 2 of 2
T5040 T5050 T5060 T5070
REAR AXLE
Type Flange Flange Flange Flange
Diff lock engagement – Rear .....................................................................2WD Standard – Mechanical.....................................................................
................................................FWD Standard, 2WD & FWD Deluxe - Electrohydraulic ................................................
Track adjustment, in. (mm) .........................................................................64.1–83.8 (1628–2128).........................................................................
Dimension across flange, in. (mm) 69.7 (1770) 69.7 (1770) 69.7 (1770) 69.7 (1770)
Axle capacity, lbs. (kg) 10,141 (4600) 10,141 (4600) 10,141 (4600) 10,141 (4600)
FRONT AXLE
2WD
Track adjustment, in. (mm) .........................................................................58.8–82.4 (1494–2094).........................................................................
Axle capacity (restricted), lbs. (kg) 7716 (3500) 7716 (3500) 7716 (3500) 7716 (3500)
Maximum steering angle 55° 55° 55° 55°
Oscillation 12° 12° 12° 12°
FWD
FWD engagement ............................................................................... Electrohydraulic...............................................................................
Differential lock – Standard configuration ...................................................................................Limited slip...................................................................................
Differential lock – Deluxe configuration ...................................................Electrohydraulically engaged full locking differential...................................................
Track adjustment, in. (mm) .........................................................................68.9–84.7 (1751–2151).........................................................................
Axle capacity (restricted), lbs. (kg) 9920 (4500) 9920 (4500) 9920 (4500) 9920 (4500)
Maximum steering angle – FWD 60° 60° 60° 60°
Oscillation 11° 11° 11° 11°
DIMENSIONS
Platform type ..............................................................................Flat deck platform..............................................................................
Turning radius
(FWD disengaged, w/o brakes), in. (mm) 159 (4050) 159 (4050) 159 (4050) 159 (4050)
Turn-around diameter (w/o brakes), in. (mm) 248 (6300) 248 (6300) 248 (6300) 248 (6300)
Wheelbase – 2WD, in. (mm) 92.2 (2342) 92.2 (2342) 92.2 (2342) 92.2 (2342)
Wheelbase – FWD, in. (mm) 92.5 (2350) 92.5 (2350) 92.5 (2350) 92.5 (2350)
Overall length – 2WD, in. (mm) 160.8 (4085) 160.8 (4085) 160.8 (4085) 160.8 (4085)
Overall length – FWD, in. (mm) 162.2 (4120) 162.2 (4120) 162.2 (4120) 162.2 (4120)
ROPS height**, in. (mm) 108.9 (2766) 108.9 (2766) 108.9 (2766) 108.9 (2766)
Cab height**, in. (mm) 100.8 (2560) 100.8 (2560) 100.8 (2560) 100.8 (2560)
*Manufacturer’s estimate
**With 18.4 x 30 rear tires
Safety begins with a th r ugh understanding f
the equipment. Always make sure y u and
y ur perat rs read the Operat r’s Manual
bef re using the equipment. Pay cl se
attenti n t all safety and perating
decals and never perate machinery
with ut all shields, pr tective devices
and structures in place.
Design, materials and/ r specificati ns are subject t
change with ut n tice and with ut liability theref r.
Specificati ns are applicable t units s ld in Canada, the
United States, its territ ries and p ssessi ns, and may
var y utside these areas.
© 2008 CNH America LLC
New H lland is a registered trademark f CNH America LLC.
Visit ur Web site at www.newholland.com/na. Or, call t ll-free 866-NEW-HLND (866-639-4563).
