NI PXIe-1092DC Owner's manual

SAFETY, ENVIRONMENTAL, AND REGULATORY INFORMATION
PXIe-1092DC
10-Slot 3U PXI Express Chassis
Read this document before you install, configure, operate, or maintain this product. Users are required to familiarize themselves with installation and wiring
instructions in addition to requirements of all applicable codes, laws, and standards. Visit ni.com/manuals for more information about your product, including
specifications, pinouts, and instructions for connecting, installing, and configuring your system.
Icons
Refer to the following descriptions if one of these icons is marked on your product or used in this guide.
Notice Take precautions to avoid data loss, loss of signal integrity, degradation of performance, or damage to the product.
Caution Take precautions to avoid injury. Consult the product documentation for cautionary statements when you see this icon printed on the
product. Cautionary statements are localized into French for compliance with Canadian requirements.
Caution: Possibility of Electric Shock Take precautions to avoid electrical shock.
Protective Conductor Terminal (PE) Indicates a terminal that connects to accessible dead metal parts of the product. Connect the PE terminal(s) to
an earth ground system (protective conductor) for safety.
General Guidelines
Note Refer to the instrument-level documentation for information about the instruments installed in this product, including proper use, I/O
connections and pinouts. All I/O must be connected per the ratings of the individual components included in the product.
Note The Data Record System AD User Manual contains guidelines and instructions for preparing the vehicle and setting up the product for the first
time.
Note Only remove panels when qualified personnel perform maintenance and repair procedures.
Note Disconnect the product from its power source before performing maintenance and repair procedures.
Note Ensure that maintenance is performed only by qualified personnel. Verify that all equipment is in a safe state after maintenance, prior to
returning the product to operation.
Note The safety of the product and any equipment integrated into the product is the responsibility of the integrator. Refer to the instrument-level
documentation for cautions and safe use of integrated equipment.
Safety Guidelines
Caution Observe all instructions and cautions in the user documentation. Using the product in a manner not specified can damage the product and
compromise the built-in safety protection.
Attention Suivez toutes les instructions et respectez toutes les mises en garde de la documentation d'utilisation. L'utilisation du produit de toute autre
façon que celle spécifiée risque de l'endommager et de compromettre la protection de sécurité intégrée.
Warning Risk of Electric Shock: For vehicular or mobile applications where there is no available external protective earthing system, all PXI(e)
modules and any external connections to the chassis are restricted to 30 VAC, 42.4 Vpk, or 60 VDC maximum.
Mise en garde Risque de choc électrique: pour les applications mobiles ou en véhicule, lorsqu'aucun système de mise à la terre externe n'est
disponible, tous les modules PXI(e) et toutes les connexions externes au châssis sont limités à 30 V CA, 42,4 V pic ou 60 V CC maximum.

Safety Compliance Standards
This product is designed to meet the requirements of the following electrical equipment safety standards for measurement, control, and laboratory use:
• IEC 61010-1, EN 61010-1
• UL 61010-1, CSA C22.2 No. 61010-1
Note For safety certifications, refer to the product label or the Product Certifications and Declarations section.
EMC Guidelines
This product was tested and complies with the regulatory requirements and limits for electromagnetic compatibility (EMC) as stated in the product
specifications. These requirements and limits are designed to provide reasonable protection against harmful interference when the product is operated in its
intended operational electromagnetic environment.
This product is intended for use in commercial and light-industrial locations. However, harmful interference may occur in some installations, when the product
is connected to a peripheral device or test object, or if the product is used in residential areas. To minimize interference with radio and television reception and
prevent unacceptable performance degradation, install and use this product in strict accordance with the instructions in the product documentation.
Furthermore, any changes or modifications to the product not expressly approved by NI could void your authority to operate it under your local regulatory
rules.
EMC Notices
Notice For EMC declarations and certifications, and additional information, refer to the Product Certifications and Declarations section.
Notice Changes or modifications to the product not expressly approved by NI could void your authority to operate the product under your local
regulatory rules.
Notice The performance of this product can be disrupted if subjected to Electrostatic Discharge (ESD) during operation. To prevent damage,
industry-standard ESD prevention measures must be employed during installation, maintenance, and operation.
Notice Operate this product only with shielded cables and accessories.
Notice The length of all I/O cables must be no longer than 3 m (10 ft).
Notice Do not connect the power input to a DC mains supply or to any supply requiring a connecting cable longer than 30 m (100 ft). A DC mains
supply is a local DC electricity supply network in the infrastructure of a site or building.
EMC Standards
This product meets the requirements of the following EMC standards for electrical equipment for measurement, control, and laboratory use:
• EN 61326-1 (IEC 61326-1): Class A emissions; Basic immunity
• EN 55011 (CISPR 11): Group 1, Class A emissions
• AS/NZS CISPR 11: Group 1, Class A emissions
Note Group 1 equipment is any industrial, scientific, or medical equipment that does not intentionally generate radio frequency energy for the
treatment of material or inspection/analysis purposes.
Note In Europe, Australia, and New Zealand (per CISPR 11) Class A equipment is intended for use in non-residential locations.
Environmental Guidelines
Notice Failure to follow the mounting instructions in the product documentation can cause temperature derating.
Notice This product is intended for use in indoor applications or mobile applications where only non-conductive pollution occurs or occasional
temporary conductivity caused by condensation is expected.
Notice All cabling should be strain-relieved near input connectors. Take care not to directionally bias cable connectors within input connectors when
applying strain relief. Refer to the Data Record System AD User Manual for information on how to strain relieve cabling.
Notice Cover all empty slots using filler panels.
2| ni.com | PXIe-1092DC Safety, Environmental, and Regulatory Information

Environmental Characteristics
Temperature
Operating 0 °C to 55 °C for ≤ 58 W module operation
0 °C to 40 °C for > 58 W module operation
Storage -40 °C to 71 °C
Humidity
Operating 10% to 90%, noncondensing
Storage 5% to 95%, noncondensing
Pollution Degree 2
Maximum altitude 2,000 m
Ventilation Clearance and Cooling
Cooling
Module Forced air circulation (positive pressurization) through two 210 CFM fans
Secondary cooling Forced air circulation (positive pressurization) through one 70 CFM fan
Power supply Forced air circulation through two integrated fans
Minimum chassis cooling clearances
Top and sides 44.45 mm (1.75 in.)
Back 101.60 mm (4.00 in.)
Environmental Standards
This product meets the requirements of the following environmental standards for electrical equipment.
• IEC 60068-2-1 Cold
• IEC 60068-2-2 Dry heat
• IEC 60068-2-78 Damp heat (steady state)
Note To verify marine approval certification for a product, refer to the product label or visit ni.com/certification and search for the certificate.
Power Requirements
Power Guidelines
Notice This product is for use only with the Data Record System AD 500W DC Power Supply (NI part number 861354-01).
Power Specifications
Input voltage rating19 V at 68 A
30 V at 19 A
Operating voltage range 9 VDC to 30 VDC
Maximum power consumption
PXI backplane power 12 V at 22.3 A
5 Vaux at 3 A
5 V at 26.5 A
3.3 V at 36 A
-12 V at 1.75 A
Total available output power 283 W
Maximum power consumption per PXI slot 58 W at 55 °C, 82 W at 40 °C
Main power disconnect The installation must contain a suitable switch or circuit breaker for power
disconnect. It must be suitably located and easily reached, and marked as the
disconnect device for the equipment.
Required power cord 2.5 mm2 to 16 mm2 (14 AWG to 6 AWG) conductor
Select the proper conductor size based on power source and cable routing.
Ensure conductor insulation and cable construction are sufficient for the
application and adhere to applicable electrical codes. Ensure none of the
conductor is exposed.
1Do not exceed the current rating of the branch circuit providing power to the chassis.
PXIe-1092DC Safety, Environmental, and Regulatory Information | © National Instruments Corporation | 3

Physical Characteristics
Dimensions and Weight
Dimensions
Width 303.3 mm (11.94 in.)
Depth 463.6 mm (18.25 in.)
Height 177.1 mm (6.97 in.)
Weight (empty chassis with power supply installed) 11.7 kg (25.7 lbs)
DC Power Supply Field Wiring Specifications
Notice Use only copper wire. For use in class 1 circuits only.
Note Refer to the Data Record System AD User Manual for the power supply connection requirements.
Gauge 2.5 mm2 to 16 mm2 (14 AWG to 6 AWG) conductor
Wire strip length 12 mm
Temperature rating 60 °C minimum
Wires per terminal 1
Torque for screw terminals 1.7 to 1.8 N · m (15 to 15.9 lb · in.)
Single ferrule
Barrel length 12 mm (0.47 in.)
Maximum cross section of conductor plus ferrule 16 mm2 (6 AWG)
Recommended crimping tool Crimpfox 16 S crimping tool
Connector securement
Securement type Screw locking
Torque for screw flanges 0.3 N · m (2.7 lb · in.)
Protective Earthing
When using the product with hazardous voltage PXIe modules or I/O (>30 VAC, 42.4 Vpk, 60 VDC), connect the product to the protective earth terminal
before connecting to DC power.
Notice The facility installation shall provide a means for connection to protective earth, and qualified personnel shall install a protective earthing
conductor from the protective earthing terminal on the product to the protective earth wire in the facility.
Notice Use only copper wire to connect the protective earthing terminal of your product to the protective earth wire in the facility.
Protective Earth Terminal Wiring
Grounding wire gauge 2.1 mm2 (14 AWG)
Ring lug # 8
Protective earth terminal torque 1.13 N · m (10 lb · in.)
Export Compliance
This product is subject to control under the U.S. Export Administration Regulations (15 CFR Part 730 et. seq.) administered by the U.S. Department of
Commerce's Bureau of Industry and Security (BIS) (www.bis.doc.gov) and other applicable U.S. export control laws and sanctions regulations. This product
may also be subject to additional license requirements of other countries' regulations.
Additionally, this product may also require export licensing before being returned to NI. The issuance of a Return Material Authorization (RMA) by NI does
not constitute export authorization. The user must comply with all applicable export laws prior to exporting or re-exporting this product. See ni.com/legal/
export-compliance for more information and to request relevant import classification codes (e.g. HTS), export classification codes (e.g. ECCN), and other
import/export data.
Environmental Management
NI is committed to designing and manufacturing products in an environmentally responsible manner. NI recognizes that eliminating certain hazardous
substances from our products is beneficial to the environment and to NI customers.
For additional environmental information, refer to the Commitment to the Environment web page at ni.com/environment. This page contains the environmental
regulations and directives with which NI complies, as well as other environmental information not included in this document.
4| ni.com | PXIe-1092DC Safety, Environmental, and Regulatory Information

Waste Electrical and Electronic Equipment (WEEE)
EU Customers At the end of the product life cycle, all NI products must be disposed of according to local laws and regulations. For more
information about how to recycle NI products in your region, visit ni.com/environment/weee.
电子信息产品污染控制管理办法（中国 RoHS）
540
e
NI 符合中国电子信息产品中限制使用某些有害物质指令(RoHS)。关于 NI 中国 RoHS 合规性信息，请登录 ni.com/
environment/rohs_china。(For information about China RoHS compliance, go to ni.com/environment/rohs_china.)
Product Certifications and Declarations
Refer to the product Declaration of Conformity (DoC) for additional regulatory compliance information. To obtain product certifications and the DoC for NI
products, visit ni.com/product-certifications, search by model number, and click the appropriate link.
NI Services
Visit ni.com/support to find support resources including documentation, downloads, and troubleshooting and application development self-help such as
tutorials and examples.
Visit ni.com/services to learn about NI service offerings such as calibration options, repair, and replacement.
Visit ni.com/register to register your NI product. Product registration facilitates technical support and ensures that you receive important information updates
from NI.
NI corporate headquarters is located at 11500 N Mopac Expwy, Austin, TX, 78759-3504, USA.
PXIe-1092DC Safety, Environmental, and Regulatory Information | © National Instruments Corporation | 5
