Nilfisk-Advance E130.3 X-TRA User manual

E 130.3, E 140.3, E 145.3
User Manual
128332518
EN-DA-NO-SV-FI-DE-FR-NL-IT-ES-PT-EL-
TR-CS-HU-PL-HR-SL-SK-LV-LT-ET-RU-ZH

User Manual ................................................................ 3 - 20
Instruktionsbok ............................................................
Instruksjonsbok............................................................
Instruktionsbog ............................................................
Käyttöohje....................................................................
Betriebsanleitung.........................................................
Instructions d’utilisation ...............................................
Gebruiksaanwijzing .....................................................
Istruzioni sull’uso .........................................................
Instrucciones de manejo..............................................
Instruções de operação...............................................
Οδηγίες χρήσης...........................................................
Kullanım Kılavuzu........................................................
Návod k obsluze..........................................................
Használati útmutató.....................................................
Instrukcja użycia ..........................................................
Priručnik za korisnike...................................................
Navodila za uporabo....................................................
Návod na používanie...................................................
Lietošanas instrukcijae ................................................
Naudojimosi instrukcija................................................
Kasutamisjuhend .........................................................
Руководство ...............................................................
操作说明 ......................................................................
EN
DA
NO
SV
FI
DE
FR
NL
IT
ES
PT
EL
TR
CS
HU
PL
HR
SL
SK
LV
LT
ET
RU
ZH

3Original Instructions
EN
DA
NO
SV
FI
DE
FR
NL
I
T
ES
PT
E
L
T
R
C
S
H
U
P
L
HR
SL
SK
L
V
LT
ET
R
U
Z
H
Contents
1 Introduction.................................................................................................. 4
1.1 Symbols used to mark instruction.......................................................................4
2 Safety precautions and working techniques................................................4
3 Before you start using your high pressure washer................................ 11
3.1 Mounting of trolley handle, hose hook and hose reel .......................................11
3.2 Mounting of quick coupling ...............................................................................11
3.3 Telescopic handle .............................................................................................11
4 Operating your high pressure washer..................................................... 12
4.1 Connection of high pressure hose ....................................................................12
4.2 Mounting of spray lance and Click&Clean nozzles ...........................................12
4.3 Water Connection .............................................................................................12
4.4 Starting the high pressure washer....................................................................13
4.5 Pressure regulation on the TORNADO® PR-nozzle.........................................13
4.6 Stationary use...................................................................................................13
5 Fields of application and working methods............................................ 14
5.1 General .............................................................................................................14
5.2 Typical fields of application ...............................................................................15
6 After using the pressure washer.............................................................. 16
6.1 Stopping the high pressure washer ..................................................................16
7 Maintenance............................................................................................... 16
8 Troubleshooting......................................................................................... 17
9 Accessories and detergents..................................................................... 18
10 Warranty Conditions ................................................................................. 18
11 Main technical Data ................................................................................... 18
12 Declaration of Conformity......................................................................... 19

4Original Instructions
EN
DA
NO
SV
FI
DE
FR
NL
I
T
ES
PT
E
L
T
R
C
S
H
U
P
L
HR
SL
SK
L
V
LT
ET
R
U
Z
H
1 Introduction
1.1 Symbols used to mark instruction
All pictograms attached to the high pressure washer and its components are shown and ex-
plained in this manual.
Safety instructions marked with this symbol must be observed to prevent personal injury or
serious damage to property.
Caution where there is a risk of damaging the machine or its individual components.
This symbol indicates tips and instructions to simplify work and to ensure a safe operation of
the high pressure washer.
2 Safety precautions and working techniques
Before starting up your machine for the first time, this instruction manual must be read through
carefully. Save the instructions for later use.
WARNING!
• Inhalation of aerosols can be hazardous to health.
Where applicable use a device in order to avoid or re-
duce aerosols production, e.g., a shield covering the
nozzle. For protection against aerosols use a respira-
tory mask of class FFP 2 or higher.
• The high water pressure generated by the machine
and the power connection are particular sources of
danger.
• Children should be supervised to ensure that they do
not play with the machine.
• Before starting up your machine please check it care-
fully for any defects. If you find any, do not start up
your machine, contact your Nilfisk distributor. The in-
sulation of the electric cable should be faultless and
without any cracks. If the electric cable is damaged,
an authorized Nilfisk distributor should replace it.
• The operator and anyone in the immediate vicinity of
the site of cleaning should take action to protect them-
selves from being struck by debris dislodged during
operation.
• Always unplug the power plug before cleaning or
maintenance and when replacing parts or converting


5Original Instructions
EN
DA
NO
SV
FI
DE
FR
NL
I
T
ES
PT
E
L
T
R
C
S
H
U
P
L
HR
SL
SK
L
V
LT
ET
R
U
Z
H
the machine to another function.
• Observe the national safety regulations issued, for
example, by the employers liability insurance associa-
tion, social security institutions, occupational safety
and health authorities or other organizations.
Accessories and spare parts
• To ensure the machine safety only use original spare
parts from Nilfisk or approved by Nilfisk.
• High pressure hoses, fittings and couplings are impor-
tant for the safety of the machine. Only use hoses, fit-
tings and couplings recommended by Nilfisk.
Physical, sensory or mental conditions
• This machine is not intended for use by persons
(including children) with reduced physical, senso-
ry or mental capabilities or lack of experience and
knowledge.
• Anyone who has consumed alcohol, medicines or
drugs affecting their ability to react must not operate
the machine.
Applications
This machine has been developed for domestic use
such as:
• Car, motorbike, boat, caravan, trailer, patio/drive/flag-
stones, woodwork, brickwork, barbecue, garden furni-
ture, lawn mower.
Any other use is considered as improper use. Nilfisk
accepts no liability for any damage resulting from such
use. The risk for such use is borne solely by the user.
Proper use also includes proper operation, servicing
and repairs as specified in this instruction.
Clothing and equipment
Always take action to protect yourself when operating
the machine.
• Wear shoes with non-slip soles.
• Wear goggles, ear protection and protective clothes
during operation.


6Original Instructions
EN
DA
NO
SV
FI
DE
FR
NL
I
T
ES
PT
E
L
T
R
C
S
H
U
P
L
HR
SL
SK
L
V
LT
ET
R
U
Z
H
Transporting the high pressure washer
• When transporting the machine in or on a vehicle, it
must be secured, e.g. with straps, so that it cannot slip
or tip over.
• Nilfisk recommends that the machine is positioned
horizontally on the backside, when transported in or
on a vehicle.
Detergents
• This machine has been designed for use with clean-
ing agents supplied or recommended by Nilfisk. The
use of other cleaning agents or chemicals may ad-
versely affect the function of the machine.
Before starting the work
Inspecting the machine
• Do not use the machine if a supply cord or important
parts of the machine are damaged, e.g., safety de-
vice, high pressure hose, and spray handle and spray
attachments.
• The trigger of the spray handle must move easily and
automatically return to its starting position when re-
leased.
• Always keep high pressure hose and spray attach-
ment in good condition (clean, moving easily) and cor-
rectly assembled.
Electrical connection
WARNING!
Minimize the risk for electrical shock:
• Voltage and frequency of the machine (see rating
plate) must match the voltage of and frequency of the
mains supply.
• Only connect the machine to electrical installation
made by a certified electrician and comply with IEC
60364-1.
• It is recommended that the electrical supply to the
machine should include a residual current device that
will interrupt the supply if the leakage current to earth



7Original Instructions
EN
DA
NO
SV
FI
DE
FR
NL
I
T
ES
PT
E
L
T
R
C
S
H
U
P
L
HR
SL
SK
L
V
LT
ET
R
U
Z
H
exceeds 30 mA for 30 ms.
• Inadequate extension cables can be dangerous. If an
extension cable is used, it shall be suitable for outdoor
use, and the connection has to be kept dry and off the
ground
• Nilfisk recommends use of an extension cable drum
when cable extension is needed which keeps the
socket at least 60 mm above the ground.
• Cables on extension cable drums should always be
completely unwound to prevent overheating. Exten-
sion cables must comply with the below-mentioned re-
quirements for length and cable dimensions:
1.0 mm² Max. 12.5 m
1.5 mm² Max. 20.0 m
2.5 mm² Max. 30.0 m
• If the electric cable is damaged, it must be replaced
by an authorized Nilfisk distributor or similar qualified
person in order to avoid a hazard.
Water connection
High pressure washer not suitable for connection to the
potable water mains.
• Connection of the machine to the drinking water
mains according to national regulations.
• According to EN 60335-2-79 this machine is only al-
lowed to be connected with the drinking water mains
when an appropriate backflow preventer has been
installed. Type BA according to EN 60335-2-79. The
backflow preventer can be ordered under number
106411177.
• As soon as drinking water has flown through the back-
flow preventer, it is no longer regarded as drinking
water.
• Operation by suction (e.g. a rainwater vessel) is car-
ried out without a backflow preventer – see “Connec-
ting to a pressureless water supply”. The machine
can be connected to water mains with a max. inlet
pressure of 1 MPa/10 bars and max. 60°C.
• An ordinary ½" garden hose of min. 10 m and max. 25

8Original Instructions
EN
DA
NO
SV
FI
DE
FR
NL
I
T
ES
PT
E
L
T
R
C
S
H
U
P
L
HR
SL
SK
L
V
LT
ET
R
U
Z
H
m will be suitable for normal operation at 3 bar inlet
pressure.
IMPORTANT !
• Only use water without any impurities.
• If there is a risk of running sands in the inlet water
(i.e. from your own well), an additional filter should be
mounted.
During work
WARNING!
• Never use the machine in an environment where there
could be a danger of explosions. If any doubt arises
contact the local authorities.
• It is not allowed to clean asbestos-containing surfaces
with high pressure.
• Never draw in fluids containing solvents (e.g., gaso-
line, heating oil, paint thinner or acetone) These sub-
stances damage the materials used in the machine.
Their spray is highly combustible, explosive and poi-
sonous.
• Never direct the water jet at yourself, other persons,
not even to clean clothing or footwear - risk of injury.
• Never direct the water jet at pets or other animals.
• Never direct the water jet at live electrical equipment
or the machine itself - danger of short-circuiting.
• Hold the spray lance firmly with both hands. The spray
lance is affected by a thrust of up to 16.4 N during
operation.
• This high pressure washer machine must not be ope-
rated at temperatures below 0°C.
• Never start up a frozen machine. Frost damages are
not covered by the guarantee!
• Always ensure firm and safe footing.
• Keep the machine as far away as possible from the
object being cleaned.
• Always adjust the distance and thus the pressure of
the nozzle to the surface, which is to be cleaned to
avoid any damage to the surface being cleaned.



9Original Instructions
EN
DA
NO
SV
FI
DE
FR
NL
I
T
ES
PT
E
L
T
R
C
S
H
U
P
L
HR
SL
SK
L
V
LT
ET
R
U
Z
H
• The machine shall be operated in an upright position.
• Do not cover the machine or use it in a room without
adequate ventilation.
• If the machine is left or not used for 5 minutes, it must
be switched off on the start/stop switch "O" (1).
After finishing the work
WARNING!
• Always switch off the machine and unplug the power
plug from the socket after work and when leaving the
machine unattended.
• Disconnect water inlet hose between machine and
water supply.
• Wind up electrical cable and high pressure hose – to
avoid damage of cable, plug, high pressure hose and
fittings.
• Always empty pump, hose and accessories of water
after use of the machine and prior to storing.
Maintenance and repairs
WARNING!
• Always disconnect the electrical plug from the socket
prior to maintenance, cleaning and repair.
• Any repair should always be made in Nilfisk
authorized workshop with original Nilfisk spare parts.
• Do not attempt any maintenance not described in the
instructions.
• If the machine refuses to start, stops, pulsates, pres-
sure fluctuates, motor busses, fuse blows or no wa-
ter comes out, check the trouble shooting diagram
in these instructions. In case other problems occur,
please contact your local Nilfisk distributor.
Recycling the high pressure washer
Make the old machine unusable immediately.
• Unplug the machine.
• Cut the electric cable.

10 Original Instructions
EN
DA
NO
SV
FI
DE
FR
NL
I
T
ES
PT
E
L
T
R
C
S
H
U
P
L
HR
SL
SK
L
V
LT
ET
R
U
Z
H
Do not discard electrical appliances with household
waste. As specified in European Directive 2002/96/EC
on old electrical and electronic appliances, used elec-
trical goods must be collected separately and recycled
ecologically. Contact your local authorities or your near-
est dealer for further information.
