Nitto Kohki delvo DLV04C/10C10L-AY User manual

INSTRUCTION
MANUAL
Parts List
Professional tool ELECTRIC SCREWDRIVER
Model: DLV04C/10C10L-AY
Manufactured by.
NITTO KOHKI CO., LTD. 9-4, Nakaikegami 2-chome, Ohta-ku, Tokyo, 146-8555, Japan
Tel : [phone] Fax : [phone]
EN
This document is for the special repair operator.
General users should never disassemble the product.
When repair of the tool or part replacement becomes necessary, contact the retailer where you
purchased the tool.
FR
Le présent document est destiné aux techniciens de réparation spécialisés.
Les utilisateurs généraux ne doivent jamais démonter le produit.
Lorsqu'une réparation ou le remplacement de pièces est nécessaire, contactez le revendeur auprès
duquel vous avez acheté l'outil.
DE
Dieses Dokument gilt für speziell ausgebildete Wartungstechniker.
Allgemeine Nutzer dürfen das Produkt niemals zerlegen.
Wenn das Werkzeug repariert oder ein Teil ausgetauscht werden muss, wenden Sie sich an den
Händler, von dem Sie das Werkzeug erworben haben.
IT
Questo documento è destinato all'operatore addetto alle riparazioni speciali.
Gli utenti generici non devono mai tentare di smontare il prodotto.
Per la riparazione dell'utensile o qualora si renda necessaria la sostituzione di un pezzo, rivolgersi al
rivenditore presso il quale è stato acquistato l'utensile.
ES
Este documento es para el operador de reparaciones especiales.
Los usuarios generales no deberán desmontar jamás el producto.
Para la reparación de la herramienta o si resulta necesaria la sustitución de piezas, póngase en
contacto con el vendedor del que adquirió la herramienta.
PT
Este documento destina-se ao operador de reparações específico.
Os utilizadores gerais não devem nunca desmontar o produto.
Se for necessário substituir alguma peça ou reparar a ferramenta, entre em contacto com o
revendedor onde adqiriu a ferramenta.
SC
ׁၭܰ᎟ၓ࿅ኙၕᅃغᏮเ኎Ꮃֻȃ
ᇜֈቂᆒّٛ൰ȃ
ᅍᇋၕᅃࢗનড࢑ெ໢ˈข஍Ⴜࢭళࢗનܿெ༌ຟȃ
JP
本書は、専門修理業者向けの資料です。
一般ユーザーの方は、絶対に製品を分解しないでください。
工具の修理や部品の交換が必要な場合は、お買い求めの販売店にお問い合わせください。
(Original Instructions)
 Please read manual carefully before you attempt to use your tool so that you may use it properly and safely.
• Due to continuous product development/improvement the specifications and configurations in this document
are subject to change without prior notice.
TV07790-1 06/2017
TV07790-1DLV10C.indb1TV07790-1DLV10C.indb1 2017/06/289:06:282017/06/289:06:28

2
EXPLODED VIEW (DLV04C/10C10L-AY)
1
10
2345
6
7
8
11
12
9
9
13
15
16
17
18
19
20
20
20
21
22
23
23
22
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
43
37
14
19pcs
TV07790-1DLV10C.indb2TV07790-1DLV10C.indb2 2017/06/289:06:282017/06/289:06:28

3
PARTS LIST (DLV04C/10C10L-AY)
No. Parts Name Parts No. Q'ty
1 Coupling TV07681 1
2 Accent Ring (Silver) (DLV04C) TV07725 1
Accent Ring (Gold) (DLV10C) TV07126 1
3 Stop Ring TV06619 1
4 Holder Collar TV05124 1
5 Holder Spring TV00356 1
6 Holder Clamp TV05126 1
7 Stop Ring LP10494 1
8 Stop Ring TP13905 1
9 Steel Ball DIA 2.381
(HEX 6.35 mm (1/4") Type) CP20000 2
10 Bit Holder Assembly TD08814 1
11 Ball Bearing TV04541 1
12 Bit Holder
(HEX 6.35 mm (1/4") Type) TV07801 1
13 Washer TV07115 1
14 Ball Assembly (DIA 2, 19pcs) TD08847 1
15 Thrust Plate TV07114 1
16 Stop Ring LP10494 1
17 Roller Pin Assembly (DIA 3×19.8L) TD08848 1
18 Bearing Case Assembly TD08702 1
19 O-Ring TV07677 1
20 Screw M2.6×5L TV07117 3
21 Gear Case Assembly TD08843 1
22 Gear Base Assembly TD05521 2
23 Idle Gear Assembly TD08845 2
24 Spindle Gear Assembly TD08844 1
25 Gear Stopper TV05490 1
26 Motor Gear Assembly TD08846 1
27 Motor Coupling Assembly TD05524 1
28 Motor Assembly (DLV04C) TD08550 1
Motor Assembly (DLV10C) TD08549 1
29 LED Display Plate TV07123 1
30 Switch Assembly TD07932 1
31 Screw M2×4L TV04867 2
32 Spacer TV07122 2
33 LED Board Assembly TD07928 1
34 LED Harness Assembly TD07933 1
35 Control Base Assembly (DLV04C) TD08717 1
Control Base Assembly (DLV10C) TD08704 1
36 Receptacle Assembly TD08709 1
37 Frame Handle AB Assemnbly TD07436 1
38 Roller Pin DIA 2×17.8L TV00109 1
No. Parts Name Parts No. Q'ty
39 Spring TV00235 1
40 Trigger TV06702 1
41 Rating Plate 1
42 Warning Plate 1
43 Tapping Screw 3×14L TV07124 3
44 Connection Cord Assembly TD09144 1
45 Suspension Bail TD08711 1
