Nokia Flexi Multiradio BTS Operator's manual

WCDMA RAN, Rel. RU50 and
RU50 EP1, Operating
Documentation, Issue 03
Flexi Multiradio BTS Radio
Module and Remote Radio
Head Description
DN0951745
Issue 05
Approval Date 2014-05-30


NokiaNetworks

The information in this document applies solely to the hardware/software product (“Product”) specified
herein,andonlyasspecifiedherein.
ThisdocumentisintendedforusebyNokiaSolutionsandNetworks'customers(“You”)only,anditmaynot
beusedexceptforthepurposesdefinedintheagreementbetweenYouandNokiaSolutionsandNetworks
(“Agreement”) under which this document is distributed. No part of this document may be used, copied,
reproduced, modified or transmitted in any form or means without the prior written permission of Nokia
Solutions and Networks. If you have not entered into an Agreement applicable to the Product, or if that
Agreementhasexpiredorhasbeenterminated,YoumaynotusethisdocumentinanymannerandYou
areobligedtoreturnittoNokiaSolutionsandNetworksanddestroyordeleteanycopiesthereof.
The document has been prepared to be used by professional and properly trained personnel, and You
assumefullresponsibilitywhenusingit.NokiaSolutionsandNetworkswelcomeYourcommentsaspartof
theprocessofcontinuousdevelopmentandimprovementofthedocumentation.
This document and its contents are provided as a convenience to You. Any information or statements
concerningthesuitability, capacity,fitnessfor purposeorperformanceoftheProductaregiven solely on
an“asis”and“asavailable”basisinthisdocument,andNokiaSolutionsandNetworksreservestheright
to change any such information and statements without notice. Nokia Solutions Networks has made all
reasonableeffortstoensurethatthecontentofthisdocumentisadequateandfreeofmaterialerrorsand
omissions, and Nokia Solutions and Networks will correct errors that You identify in this document. But,
NokiaSolutionsandNetworks'totalliabilityforanyerrorsinthedocumentisstrictlylimitedtothecorrection
ofsucherror(s).NokiaSolutionsandNetworksdoesnotwarrantthattheuseofthesoftwareintheProduct
willbeuninterruptedorerror-free.
NOWARRANTYOFANY KIND,EITHEREXPRESS ORIMPLIED, INCLUDING BUTNOT LIMITED TO
ANY WARRANTY OF AVAILABILITY, ACCURACY, RELIABILITY, TITLE, NON-INFRINGEMENT,
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, IS MADE IN RELATION TO THE
CONTENT OF THIS DOCUMENT. IN NO EVENT WILL NOKIA SOLUTIONS AND NETWORKS BE
LIABLE FOR ANY DAMAGES, INCLUDING BUT NOT LIMITED TO SPECIAL, DIRECT, INDIRECT,
INCIDENTAL OR CONSEQUENTIAL OR ANY LOSSES, SUCH AS BUT NOT LIMITED TO LOSS OF
PROFIT, REVENUE, BUSINESS INTERRUPTION, BUSINESS OPPORTUNITY OR DATA THAT MAY
ARISEFROMTHEUSEOFTHISDOCUMENTORTHEINFORMATIONINIT,EVENINTHECASEOF
ERRORSINOROMISSIONSFROMTHISDOCUMENTORITSCONTENT.
ThisdocumentisNokiaSolutionsandNetworks’proprietaryandconfidentialinformation,whichmaynotbe
distributed or disclosed to any third parties without the prior written consent of Nokia Solutions and
Networks.
Nokiais a registered trademark ofNokia Corporation. Other product names mentionedin this document
maybetrademarksoftheirrespectiveowners,andtheyarementionedforidentificationpurposesonly.
Copyright©2014NokiaSolutionsandNetworks.Allrightsreserved.
fImportant Notice on Product Safety
Thisproductmaypresentsafetyrisksduetolaser,electricity,heat,andothersourcesofdanger.
Only trained and qualified personnel may install, operate, maintain or otherwise handle this
productandonlyafterhavingcarefullyreadthesafetyinformationapplicabletothisproduct.
The safety information is provided in the Safety Information section in the “Legal, Safety and
EnvironmentalInformation”partofthisdocumentordocumentationset.
Nokia Solutions and Networks is continually striving to reduce the adverse environmental effects of its
productsandservices.Wewouldliketoencourageyouasourcustomersanduserstojoinusinworking
towardsacleaner,saferenvironment.Pleaserecycleproductpackagingandfollowtherecommendations
forpoweruseandproperdisposalofourproductsandtheircomponents.
IfyoushouldhavequestionsregardingourEnvironmentalPolicyoranyoftheenvironmentalserviceswe
offer,pleasecontactusatNokiaSolutionsandNetworksforanyadditionalinformation.
FlexiMultiradioBTSRadioModuleandRemoteRadioHeadDescription
2 DN0951745 Issue:05

Table of Contents
Thisdocumenthas61pages
 
Summaryofchanges..................................................................... 6
 
1 RSS-310compliance..................................................................... 7
 
2 EURoHSstatement.......................................................................8
 
3 CEmarking.................................................................................... 9
 
4 FCCPart15compliance.............................................................. 10
 
5 Overview.......................................................................................11
5.1 OverviewofFlexiMultiradioBTSRFModule...............................11
5.1.1 RFModulefrequencyrangeandbandwidth................................ 13
5.1.2 RFModuleisometricview............................................................ 16
5.2 OverviewofFlexiMultiradioBTSRRH........................................ 18
5.2.1 RRHfrequencyrangeandbandwidth.......................................... 19
5.2.2 RRHisometricview......................................................................21
 
6 RFModuleandRRHmainblocks................................................24
6.1 RFModulemainblocks................................................................24
6.2 RRHModulemainblocks.............................................................25
 
7 RFModuleandRRHinterfaces................................................... 28
7.1 FrontpanelviewsofRFModule.................................................. 28
7.2 RFModulefrontpaneldescription............................................... 30
7.3 RFModuleantennalinedevicesupport.......................................33
7.4 FrontpanelviewsofRRH............................................................ 36
7.5 RRHfrontpaneldescription......................................................... 37
7.6 RRHantennalinedevicesupport................................................ 39
 
8 Powerrequirementsandoutputpower........................................ 42
8.1 RFModulepowerrequirementsandoutputpower...................... 42
8.2 RRHModulepowerrequirements................................................49
 
9 RFModuleandRRHModuledimensionsandweight................. 52
 
10 RFModuleandRRHModuleLEDindications............................. 55
 
11 RFModuleandRemoteRadioHeadtemperaturerange............ 58
 
12 AppendixB:CompliancewithEMC,RF,andsafety.................... 59
 
13 AppendixC:AvoidingPassiveIntermodulationduringRFModule
andRRHoperation...................................................................... 61
FlexiMultiradioBTSRadioModuleandRemoteRadioHeadDescription
Issue:05 DN0951745 3

List of Figures
Figure1 ListofcountriesrespectingEUDirective1999/5/EC............................9
Figure2 IsometricviewofRFModuleFXDx,FXEx,FXFx,FXCx....................16
Figure3 IsometricviewofRFModuleFXCA....................................................16
Figure4 Isometricviewof3x80WRFModuleFXxx........................................17
Figure5 IsometricviewofRFModuleFRGP................................................... 17
Figure6 IsometricviewofRFModuleFRGT/FRGS........................................ 17
Figure7 Isometricviewof6x40WRFModule................................................. 18
Figure8 Isometricviewofthe2x40WRRH.....................................................21
Figure9 IsometricviewoftheRemoteRadioHead(FRLB).............................21
Figure10 Isometricviewofthe2x60WRRH.....................................................22
Figure11 IsometricviewoftheRemoteRadioHead(FRGY)............................23
Figure12 Isometricviewofthe4x30WRRH.....................................................23
Figure13 Functionalblocksofthe3-sectorRFModule..................................... 25
Figure14 Functionalblocksofthe2TXRRH..................................................... 26
Figure15 Functionalblocksofthe4TXRRH..................................................... 27
Figure16 FXDA,FXEA,andFXDJfrontpanelview.......................................... 28
Figure17 FXFxandFXCAfrontpanelview....................................................... 28
Figure18 FXDBandFXEBfrontpanelview...................................................... 29
Figure19 FXCBandFXFCfrontpanelview...................................................... 29
Figure20 FRGP_A/B,FRGTfrontpanelview....................................................30
Figure21 6x40WRFModulefrontpanelview....................................................30
Figure22 2x40WRRHfrontpanelconnectors................................................. 36
Figure23 2x60WRRHfrontpanelconnectors................................................. 37
Figure24 4x30WRRHfrontpanelconnectors.................................................. 37
FlexiMultiradioBTSRadioModuleandRemoteRadioHeadDescription
4 DN0951745 Issue:05

List of Tables
Table1 RFModulenamingconvention...........................................................12
Table2 RFModulefrequencyrangeandbandwidth.......................................13
Table3 RFModuleFRGTandFRGSoutputpowerinRU40......................... 15
Table4 RRHnamingconvention.....................................................................18
Table5 RRHfrequencyrangeandbandwidth................................................ 19
Table6 RFModuleexternalinterfaces............................................................30
Table7 RFModuleantennalinedevicesupport............................................. 33
Table8 RRHexternalinterfaces..................................................................... 37
Table9 RRHantennalinedevicesupport.......................................................39
Table10 DCCableRequirementsfor80WRFModules..................................43
Table11 DCcablerequirementsfor6TX40WFRMC,FRPA,FRPBModules.44
Table12 DCcablerequirementsfor6TX40WFRHC,FRHFModules............ 45
Table13 RFModuleinputvoltagerange.......................................................... 46
Table14 RFModulepowerconsumption..........................................................47
Table15 RRHModuleinputvoltagerange....................................................... 49
Table16 RRHpowerconsumption....................................................................50
Table17 RadioModuledimensionsandweight................................................52
Table18 RRHdimensionsandweights............................................................ 52
Table19 RF/RRHModuleunitstatusLEDindications......................................55
Table20 RFModulefan/TXstatusLEDindications..........................................56
Table21 2x40WRRHTXStatusLED..............................................................56
Table22 RFModuletemperaturerange........................................................... 58
Table23 RRHtemperaturerange..................................................................... 58
Table24 TypicalreferencesensitivitydegradationwithdifferentAntennaline
PIMperformance............................................................................... 61
FlexiMultiradioBTSRadioModuleandRemoteRadioHeadDescription
Issue:05 DN0951745 5

Summary of changes
Changesbetweendocumentissuesarecumulative.Therefore,thelatestdocument
issuecontainsallchangesmadetopreviousissues.
Changes between issues 04 (2014-01-17) and 05 (2014-05-30)
RF Module and RRH Module LED indications
•LEDindications(stableredandblinkingred)havebeenupdated.
RF Module power requirements and output power
•Basicconditionsforoutputpowermeasurementhavebeenupdated
•Powerconsumptionvaluesofthefollowingmoduleshavebeenupdated:FRPA/B,
FRMC,FXCB,FRIE,FRHC,FRHF,FXEB,FXDB,FXFC.
•InformationonFXDJhasbeenmergedwithFXDAinTable14:RFModulepower
consumption.
RRH front panel description
•Table9:RRHantennalinedevicesupporthasbeenadded.
RRH Module power requirements
•Powerconsumptionvaluesofthefollowingmoduleshavebeenupdated:FHDA,
FHDB,FHEA,FHEB,FRIG,FRHD,FRHE.
Overview of Flexi Multiradio BTS RF Module
•FRIEisa3x60WRFModule.Table1:RFModulenamingconventionhasbeen
corrected.
RF Module front panel description
•Table7:RFModuleantennalinedevicesupporthasbeenadded.
•InformationonRETinterface(8-pincircular)hasbeencorrectedforthefollowingRF
Modules:FRMC,FRHC,FRHF,FRPA.
Changes between issues 03 (2013-12-13) and 04 (2014-01-17)
•Editorialchangeshavebeenmade.
Changes between issues 02 (2013-11-28) and 03 (2013-12-13)
•Powerrequirementssectionhasbeenupdated.
•AppendixC:AvoidingPassiveIntermodulationduringRFModuleandRRHoperation
hasbeenadded
•ReferencetotheFlexiMultiradioBTSRFSharingReleasedConfigurations;
DN09123381;Issue11;GSMEDGEBSSRel.RG20(BSS),RG30(BSS);WCDMA
RANRel.RU30,RU40;LTERANRel.RL30,RL40,RL50OperatingDocumentation
hasbeenadded
Summaryofchanges FlexiMultiradioBTSRadioModuleandRemoteRadio
HeadDescription
6 DN0951745 Issue:05
 

1 RSS-310 compliance
ThisequipmentcomplieswithRSS-310ofIndustryCanada.Operationissubjecttothe
conditionthatthisdevicedoesnotcauseharmfulinterference.
FlexiMultiradioBTSRadioModuleandRemoteRadio
HeadDescription
RSS-310compliance
Issue:05 DN0951745 7
 

2 EU RoHS statement
ThisequipmentcomplieswiththeEuropeanUnionRoHSDirective2011/65/EUonthe
restrictionoftheuseofcertainhazardoussubstancesinelectricalandelectronic
equipment.Thedirectiveappliestotheuseoflead,mercury,cadmium,hexavalent
chromium,polybrominatedbiphenyls(PBB),andpolybrominateddiphenylethers(PBDE)
inelectricalandelectronicequipment.
EURoHSstatement FlexiMultiradioBTSRadioModuleandRemoteRadio
HeadDescription
8 DN0951745 Issue:05
 

3 CE marking
Declaration of Conformity with Regard to the EU Directive 1999/5/EC (R&TTE
Directive)
Hereby,NSNdeclaresthatthisequipmentisincompliancewiththeessential
requirementsandotherrelevantprovisionsofDirective:1999/5/EC.TEST
Figure1 ListofcountriesrespectingEUDirective1999/5/EC
AT üFR üLV üLI ü
BE üDE üLT üRO ü
BG üGB üLU üSK ü
CY üGR üMT üSI ü
CZ üHU üNL üES ü
DK üIS üNO üSE ü
EE üIE üPL üCH ü
FI üIT üPT
R&TTEDirective1 5/5/EC
üTR ü
Thisdeclarationisonlyvalidforconfigurations(combinationsofsoftware,firmware,and
hardware)providedand/orsupportedbyNSN.
FlexiMultiradioBTSRadioModuleandRemoteRadio
HeadDescription
CEmarking
Issue:05 DN0951745 9
 

4 FCC Part 15 compliance
ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassAdigital
device,pursuanttoPart15oftheFCCRules.Theselimitsaredesignedtoprovide
reasonableprotectionagainstharmfulinterference,inacommercialenvironment.This
equipmentgenerates,uses,andcanradiateradiofrequencyenergyand,ifnotinstalled
andusedinaccordancewiththeinstructionmanuals,mightcauseharmfulinterference
toradiocommunications.Operationofthisequipmentinaresidentialareaislikelyto
causeharmfulinterferenceinwhichcasetheuserwillberequiredtocorrectthe
interferenceathisownexpense.Changesormodificationsnotexpresslyapprovedby
thepartyresponsibleforcompliancecouldvoidtheuser´sauthoritytooperatethe
equipment.
FCCPart15compliance FlexiMultiradioBTSRadioModuleandRemoteRadio
HeadDescription
10 DN0951745 Issue:05
 

5 Overview
tThisdocumentiscommonforallRadioAccessTechnologies(RAT).Youwill
findhereinformationaboutsolutionsthatarenotavailableorsupportedina
specificSWreleaseorRAT.ForfeaturessupportedinyourSWrelease,see
respectivefeaturedocumentationchapterinthesystemlibrary.
tForinformationonsupportedconfigurationinyourSWrelease,see:
FlexiMultiradioBTSRFSharingReleasedConfigurations;DN09123381;Issue
11;GSMEDGEBSSRel.RG20(BSS),RG30(BSS);WCDMARANRel.RU30,
RU40;LTERANRel.RL30,RL40,RL50OperatingDocumentationdocument.
5.1 Overview of Flexi Multiradio BTS RF Module
TheFlexiMultiradioRadioFrequencyModuleorRFModule,isathree-sector,multi-
standardradiotransceivermodule.Themoduleconsistsofindependentbranches,
capableoftransmittingandreceivingsignalsofmultipleradiotechnologiesconcurrently:
•uptosixGSMcarrierswith400kHzminimumcarrierseparation
•uptofourWCDMAcarrierswith3.8MHzminimumcarrierseparation
•LTEsignalwith1.4MHz,3MHz,5MHz,10MHz,15MHz,and20MHzcarrier
bandwidth
•MultiRAToperationwithcombinationofGSM,WCDMA,andLTE
FlexiMultiradioBTSRadioModuleandRemoteRadio
HeadDescription
Overview
Issue:05 DN0951745 11
 

gInthisdocumentthefollowingnamingconventionofRFModuleshasbeen
adopted:
Table1 RFModulenamingconvention
RF Module variant RF Module variant names
2x30WRFModule
FRMA
FRMD
3x60WRFModule
FXCA
FXDA
FXDJ
FXEA
FXFB
FRGP_A
FRGP_B
FRHA
FRIE
FRMA
FRMD
3x80WRFModule
FXCB
FXDB
FXEB
FXFC
FRGT
FRGS
6x40WRFModule
FRPA
FRPB
FRHC
FRHF
FRMC
gThefollowingRFModulevariantsdonotsupportthelegacyMHA/TMAusing
Motorolaprotocol:FXCB,FXDB,FXEB,FXFC,FRGT,FRGS.MaximumInrush
currentsupportedis1Amp.
RFModuleisa3Uhighmodulewithanintegrated,replaceablefanassemblyformodule
cooling.Thesupportedfunctionsare:
•chaininguptothreeRFModuleswithOBSAIRP3_01
Overview FlexiMultiradioBTSRadioModuleandRemoteRadio
HeadDescription
12 DN0951745 Issue:05
 

•2-wayreceivediversityinthereceiverchains
•Integratedantennalinesupervision
•MHA
•RemoteElectricalTilt(RET)
TheRFModulecanbeinstalledinsideoroutsideonastack,pole,orwall.Polemounting
kitssupportedbytheRFModulesareFlexiPoleMountingKit(FPKA/C)andPole
MountingKit(VMPB).Forwallinstallations,theRFModuleismounteddirectlytothe
wall.
5.1.1 RF Module frequency range and bandwidth
TheFlexiMultiradioRFModulevariantsandtheirfrequencyrangeandbandwidthsare
listedbelow:
Table2 RFModulefrequencyrangeandbandwidth
RF Module
variant
TX
frequency
range
[MHz]
RX
frequency
range
[MHz]
DL
instantane
ous
bandwidth
[MHz]
UL instantaneous
bandwidth
[MHz]
DL filter
bandwidth
[MHz]
UL filter
bandwidth
[MHz]
RFM3x60W
850MHzFXCA
869-894 824-849 15
18MHzin
GSM
dedicated
mode
15
18MHzinGSM
dedicatedmode
15
18MHzinGSM
dedicatedmode
15
18MHzin
GSM
dedicated
mode
RFM6x40W
700MHzFRPA
758-793 703-738 35 35 35 35
RFM6x40W
700MHzFRPB
773-803 718-748 30 30 30 30
RFM3x60W
800MHzFRMA
791-821 832-862 20 20 30 30
RFM3x60W
800MHzFRMD
791-806 832-847 15 15 15 15
RFM6x40W
800MHzFRMC
801-821 832-862 20 30 20 20
RFM3x80W
850MHz
FXCB1)
869-894 824-849 35 25 25 25

1) 60WinRU30and80WinRU40.
FlexiMultiradioBTSRadioModuleandRemoteRadio
HeadDescription
Overview
Issue:05 DN0951745 13
 

Table2 RFModulefrequencyrangeandbandwidth(Cont.)
RF Module
variant
TX
frequency
range
[MHz]
RX
frequency
range
[MHz]
DL
instantane
ous
bandwidth
[MHz]
UL instantaneous
bandwidth
[MHz]
DL filter
bandwidth
[MHz]
UL filter
bandwidth
[MHz]
RFM3x60W
900MHzFXDA
925-960 880-915 20 20 20 20
RFM3x80W
900MHz
FXDB1)
925-960 880-915 35 35 35 35
RFM3x60W
900MHzFXDJ
935-960 890-915 12.5 12.5 12.5 12.5
RFM3x60W
2100/1700MHz
FRIE
2110-2170 1710-1770 20 20 45 45
RFM3x60W
1800MHz
FXEA
1805-1880 1710-1785 25 30 30 30
RFM3x80W
1800MHz
FXEB1)
1805-1880 1710-1785 35 60 75 75
RFM3x80W
1900MHz
FXFC1)
1930-1990 1850-1915 35 60 65 65
RFM3x60W
1900MHz
FXFB
1930-1990 1850-1910 20 20 20 20
RFM3x60W
2100MHz
FRGP_A/FRGP
_B
2110-2170 1920-1980 20 20 20 20
RFM3x80W
2100MHz
FRGT1)2)
2110-2170 1920-1980 60 60 60 60

2) InRU40outputpowerdependsonDLbandwidth,seeTable3:RFModuleFRGTandFRGSoutputpower
inRU40.
Overview FlexiMultiradioBTSRadioModuleandRemoteRadio
HeadDescription
14 DN0951745 Issue:05
 

Table2 RFModulefrequencyrangeandbandwidth(Cont.)
RF Module
variant
TX
frequency
range
[MHz]
RX
frequency
range
[MHz]
DL
instantane
ous
bandwidth
[MHz]
UL instantaneous
bandwidth
[MHz]
DL filter
bandwidth
[MHz]
UL filter
bandwidth
[MHz]
RFM3x80W
2100MHz
FRGS2)
1920-1980 2110-2170 40 40 40 40
RFM6x40W
2600MHz
FRHC
2620-2675 2500-2555 40 40 55 55
RFM6x40W
2600MHz
FRHF
2640-2690 2520-2570 40 40 50 50
RFM3x60W
2600MHz
FRHA
2620-2690 2500-2570 20 20 70 70
Table3 RFModuleFRGTandFRGSoutputpowerinRU40
RF Module variant DL bandwidth
[MHz]
Output power [W]
FRGT,FRGS 0-20 80
FRGS 20-40 703)
FRGT 20-45 703)
FRGT 45-60 60

3) BTScanbecommissionedas80W(forexample4x20Wperpipe)andRFMinternalpowercontrollimits
thetotalpowerto70Wwhenneeded.
FlexiMultiradioBTSRadioModuleandRemoteRadio
HeadDescription
Overview
Issue:05 DN0951745 15
 

5.1.2 RF Module isometric view
Figure2 IsometricviewofRFModuleFXDx,FXEx,FXFx,FXCx
Figure3 IsometricviewofRFModuleFXCA
gTheFXFxandFXCxvariantshaveextraQMAconnectorsforE911positioning
systems.
Overview FlexiMultiradioBTSRadioModuleandRemoteRadio
HeadDescription
16 DN0951745 Issue:05
 

Figure4 Isometricviewof3x80WRFModuleFXxx
Figure5 IsometricviewofRFModuleFRGP
Figure6 IsometricviewofRFModuleFRGT/FRGS
FlexiMultiradioBTSRadioModuleandRemoteRadio
HeadDescription
Overview
Issue:05 DN0951745 17
 

Figure7 Isometricviewof6x40WRFModule
5.2 Overview of Flexi Multiradio BTS RRH
TheFlexiMultiradioRadioRemoteRadioHead(RRH),isaonesector,multi-standard
radiotransceivermodule.Eachbranchconsistsofatransmitterandreceiverchain.Itis
intendedforoutdoormountingandoptimizedforfeederlessapplications.
gInthisdocumentthefollowingnamingconventionhasbeenadopted:
Table4 RRHnamingconvention
RF Module variant RF Module variant list
2x40WRRH
FHCA
FHDA
FHEA
FRGQ
FRHB
FRMB
2x60WRRH
FHEB
FHDB
FRGY
4x30WRRH
FRIG
FRHD
FRHE
gThefollowing2x60WRRHvariantsdonotsupportthelegacyMHA/TMA:
FHDB,FHEB.DualMHAwhichoperatesinASIGmode.CurrentModeisnot
supported.
Overview FlexiMultiradioBTSRadioModuleandRemoteRadio
HeadDescription
18 DN0951745 Issue:05
 

Themoduleconsistsoftwoorfourindependentbranches,capableoftransmittingand
receivingsignalsofmultipleradiotechnologiesconcurrently:
•uptosixGSMcarrierswith400kHzminimumcarrierseparation
•uptofourWCDMAcarrierswith3.8MHzminimumcarrierseparation
•multi-carrierLTEsignalwith1.4MHz,3MHz,5MHz,10MHz,15MHz,and20MHz
carrierbandwidth
•multiRAToperationwithacombinationofGSM,WCDMA,andLTE
Thesupportedfunctionsare:
•chaininguptothreeRFModuleswithOBSAIRP3-01
•integratedantennalinesupervision
•MHAandRETsupport
•digitalandcontrolcircuitry,opticalinterface,DCpowerinput,andothernecessary
functionalities
•integratedDClineOVP,ClassIIratedto5kApulse
•inputDCvoltagemonitoring
TheRRHisinstalledonapoleorwall.PolemountingkitssupportedbytheRRHsare
FlexiPoleMountingKit(FPKA/C)andPoleMountingKit(VMPB).Forwallinstallations,
theRRHismounteddirectlytothewall.TheRRHhasnocoolingfans,andrelieson
convectioncooling.Toensurepropercooling,RRHshouldalwaysbemountedina
verticalorientationwithconnectorsonthebottomside.
5.2.1 RRH frequency range and bandwidth
TheFlexiMultiradioBTSRRHvariantsandtheirfrequencyrangeandbandwidthsare
listedbelow.
Table5 RRHfrequencyrangeandbandwidth
RF Module
variant
TX frequency
range
[MHz]
RX frequency
range
[MHz]
DL
instantaneous
bandwidth
[MHz]
UL
instantaneou
s bandwidth
[MHz]
DL filter
bandwidth
[MHz]
UL filter
bandwidth
[MHz]
RRH2x40W
730MHzFRLB
729-745 699-715 16 16 16 16
RRH2x40W
800MHzEU
FRMB
791-821 832-862 20 20 30 30
RRH2x40W
850MHzFHCA
869-894 824-849 15 15 25 25
RRH2x40W
900MHzFHDA
925-960 880-915 254)
30.25)
35 35 35

4) A.10xversion
5) A.20xversion
FlexiMultiradioBTSRadioModuleandRemoteRadio
HeadDescription
Overview
Issue:05 DN0951745 19
 

Table5 RRHfrequencyrangeandbandwidth(Cont.)
RF Module
variant
TX frequency
range
[MHz]
RX frequency
range
[MHz]
DL
instantaneous
bandwidth
[MHz]
UL
instantaneou
s bandwidth
[MHz]
DL filter
bandwidth
[MHz]
UL filter
bandwidth
[MHz]
RRH2x60W
900MHzFHDB
925-960 880-915 35 35 35 35
RRH2x40W
1800MHzFHEA
1805-1880 1710-1785 234)
255)
40 75 75
RRH2x60W
1800MHzFHEB
1805-1880 1710-1785 35/406)
407)
60 75 75
RRH2x60
W/4x30W1700
MHz/2100MHz
FRIG
2110-2155 1710-1755 45 45 45 45
RRH2x40W
2100FRGQ
2110-2170 1920-1980 20 60 60 60
RRH2x60W
2100FRGY
2110-2170 1920-1980 40 40 60 60
RRH4x30W
2600MHzFRHE
2620-2675 2500-2555 40 40 55 55
RRH4x30W
2600MHzFRHD
2640-2690 2520-2570 40 40 50 50
RRH2x40W
2600FRHB
2620-2690 2500-2570 20 20 70 70

6) relevantforWCDMA/LTEwhensharedwithGSM
7) relevantforWCDMAandLTE
Overview FlexiMultiradioBTSRadioModuleandRemoteRadio
HeadDescription
20 DN0951745 Issue:05
 
