Nokia Music Pack User manual

Nokia Music Pack
9245924/2

ENGLISH
The crossed-out wheeled bin
means that within the European
Union the product must be taken
to separate collection at the
product end-of-life. Do not
dispose of these products as unsorted
municipal waste.
Copyright © 2006 Nokia. All rights
reserved.
Reproduction, transfer, distribution or
storage of part or all of the contents in
this document in any form without the
prior written permission of Nokia is
prohibited.
Nokia, Nokia Connecting People, and
Pop-Port are trademarks or registered
trademarks of Nokia Corporation. Other
product and company names mentioned
herein may be trademarks or tradenames
of their respective owners.
Nokia operates a policy of continuous
development. Nokia reserves the right to
make changes and improvements to any
of the products described in this
document without prior notice.
Under no circumstances shall Nokia be
responsible for any loss of data or income
or any special, incidental, consequential,
or indirect damages howsoever caused.
The contents of this document are
provided "as is". Except as required by
applicable law, no warranties of any kind,
either expressed or implied, including, but
not limited to, the implied warranties of
merchantability and fitness for a
particular purpose, are made in relation to
the accuracy, reliability or contents of this
document. Nokia reserves the right to
revise this document or withdraw it at any
time without prior notice.
The availability of particular products may
vary by region. Please check with the
Nokia dealer nearest to you.
Export Controls
This device may contain commodities,
technology or software subject to export
laws and regulations from the US and
other countries. Diversion contrary to law
is prohibited.

ENGLISH
Get started
With the Nokia Music Pack, you can listen
to the music player of your compatible
mobile phone through stereo headphones
or a home stereo system.
The Nokia Music Pack includes a USB card
reader and memory card that allow you to
copy music files from a compatible PC to
your mobile phone. If your phone does not
have a compatible music player, you can
install the Music application from the
memory card as instructed in the user
guide of your phone.
To use the Nokia Music Pack, you need a
compatible Nokia phone that has a
memory card slot and a Pop-PortTM
connector that supports stereo audio
output.
Keep all accessories and enhancements
out of the reach of small children.
Parts
The Nokia Music Pack contains the
following items:
• The Nokia Audio Adapter (AD-46)
allows you to connect the supplied
HS-61 Nokia Music Headphone or
your stereo headphones equipped with
a standard 3.5-mm plug to your
mobile phone that has a Pop-Port
connector.
• The USB MMC/SD card reader allows
you to transfer music files through the
USB port of your compatible PC to the
memory card that is supplied with the
Nokia Music Pack.
• The CA-72U stereo audio cable allows
you to connect your mobile phone
(with the Nokia Audio Adapter) to your
compatible stereo system. The cable
has a 3.5-mm plug at one end and two
RCA plugs at the other.

ENGLISH
• The memory card allows you to
transfer music files from a compatible
PC to your mobile phone.
USB MMC/SD card reader
The USB MMC/SD card reader is compliant
with the USB specification version 2.0 and
the USB Device Class Definition for Mass
Storage, Bulk-Transport, version 1.0. The
card reader can be used with the
following operating systems: Windows
XP/2000/ME/98(SE), Mac OS 10.0 or later,
and Linux 2.4.
If you have Windows 98 or 98 SE, install a
driver that you can download from the
Nokia Web site at www.nokia.com. To
install the driver, run setup.exe, and follow
the displayed instructions. The driver is
included in other operating systems than
Windows 98 and 98 SE and does not need
to be installed separately.
To use the card reader, turn on your
computer, and plug the card reader into a
compatible USB port of your PC. The card
reader appears as a removable disk in the
operating system.
The card reader supports the following
memory cards: MultimediaCard (MMC),
Reduced-Size MultiMediaCard (RS-MMC),
Secure Digital (SD), miniSD, and microSD
(when used with an adapter).
Use only compatible memory cards with
this device. Other memory cards do not fit
in the memory card slot and are not
compatible with this device. Using an
incompatible memory card may damage
the memory card as well as the device,
and data stored on the incompatible card
may be corrupted.
The card reader has an indicator light.
When the light is shown continuously, the
card reader is ready for use. When the
light flashes, the PC is writing or reading
files on the memory card.

ENGLISH
Important: Do not remove
the memory card in the
middle of an operation when
the card is being accessed.
Removing the card in the middle of an
operation may damage the memory card
as well as the device, and data stored on
the card may be corrupted.
Set up and use
1. If your phone does not have a music
player that supports MP3 or AAC audio
files, insert the memory card into the
memory card slot of the compatible
phone, and install the Music
application from the memory card to
the phone. For details, see the user
guide for your phone.
2. Remove the memory card from your
phone.
3. If you have an MMC, RS-MMC, or SD
memory card, insert it into the slot of
the USB card reader so that the golden
contacts face down. If you have a
miniSD or microSD (attached to an
adapter) memory card, insert it into
the slot of the USB card reader so that
the golden contacts face up. Check
that the bevelled corner of the card
points to the right. Carefully push the
card into the slot.
4. Plug the other end of the card reader
into a compatible USB port of your PC
so that the indicator light is on the
right.
5. Create music files from your CDs using
the Nokia PC Suite software or the
Windows Media Player application.
6. Copy the music files to the memory
card using the file manager of your
operating system. Remember to make
back-up copies of all important data.
7. Remove the memory card from the
card reader, and insert it into your
phone as instructed in its user guide.
8. Plug the Pop-Port connector of the
Nokia Audio Adapter into the Pop-Port
socket of your phone so that the

ENGLISH
“Nokia” text printed on the connector
faces up.
9. To use the supplied headset or your
headphones for listening, plug the
3.5-mm connector of the headset or
headphones into the socket of the
audio adapter.
The audio adapter supports the use of
16-ohm or higher impedance
headphones.
To use your compatible stereo system
for listening, plug the 3.5-mm
connector of the stereo audio cable
into the socket of the audio adapter,
and attach the two RCA connectors of
the audio cable to the left and right
channel audio outputs of your stereo
system.
10. Start the music player application in
your phone, and play the music files
from the memory card as instructed in
the user guide of your phone. If you
want to use the Music application
supplied on the memory card, see
“Music application”.
11. To handle calls while you use the
audio adapter, press the key on the
adapter to dial, answer, or end a call.
During a call, speak to the microphone
opening next to the “Nokia” text on
the audio adapter, and adjust the
volume using the key at the side of the
adapter.
Warning: Listen to music at a
moderate level. Continuous
exposure to high volume may
damage your hearing.
Music application
To play music files, start the Music
application. Open the All songs, Artists,
Albums, Recently added, or Playlists view,
and select a song. The phone plays the
selected song and the others in the
current view. To use other features of the
Music application, see its help function.

ENGLISH
Care and maintenance
Your devices are products of superior
design and craftsmanship and should be
treated with care. The suggestions below
will help you protect your warranty
coverage.
• Keep the devices dry. Precipitation,
humidity, and all types of liquids or
moisture can contain minerals that
will corrode electronic circuits. If your
devices do get wet, allow them to dry
completely.
• Do not use or store the devices in
dusty, dirty areas. Their moving parts
and electronic components can be
damaged.
• Do not store the devices in hot areas.
High temperatures can shorten the life
of electronic devices, and warp or melt
certain plastics.
• Do not store the devices in cold areas.
When the devices return to their
normal temperature, moisture can
form inside the devices and damage
electronic circuit boards.
• Do not attempt to open the devices.
• Do not drop, knock, or shake the
devices. Rough handling can break
internal circuit boards and fine
mechanics.
• Do not use harsh chemicals, cleaning
solvents, or strong detergents to clean
the devices.
• Do not paint the devices. Paint can
clog the moving parts and prevent
proper operation.
If any devices are not working properly,
take them to the nearest authorized
service facility for service.
