Nokia Lumia 820 User manual

User Guide
Nokia Lumia 820
Issue 2 EN-US

Contents
Safety 4
Get started 5
Keys and parts 5
Back, start, and search key 5
Antenna locations 6
Remove the back cover 6
Insert the SIM card 7
Remove the SIM card 10
Insert the memory card 10
Remove the memory card 12
Charge your phone 12
First start-up 15
Lock the keys and screen 17
Change the volume 18
Connect the headset 19
Icons shown on your phone 19
Basics 21
Get to know your phone 21
Personalize your phone 26
Take a screenshot 30
Extend battery life 31
Save on data roaming costs 32
Write text 33
Scan codes or text 36
Clock 37
SkyDrive 38
Nokia account 39
People & messaging 40
Calls 40
Contacts 43
Social networks 46
Messages 48
Mail 52
Camera 57
Take a photo 57
Use different scene modes 58
Download Nokia Lenses from Store 60
Record a video 60
Camera tips 60
Save your photos and videos to a
memory card 60
Save location info to your photos and
videos 61
Share your photos and videos 61
Manage and edit your shots 61
Maps & navigation 65
Switch location services on 65
Download Nokia Drive+ from Store 65
Nokia Maps 65
Check nearby events and places with
Local Scout 70
Positioning methods 71
Internet 72
Define internet connections 72
Connect your computer to the web 73
Web browser 73
Search the web 75
Close all internet connections 76
Entertainment 77
Watch and listen 77
Nokia Music 78
User Guide
Nokia Lumia 820
© 2013 Nokia. All rights reserved.
2

Sync music and videos between your
phone and computer 80
Store 80
Games 82
Office 84
Microsoft Office Mobile 84
Write a note 87
Continue with a document on another
device 87
Calendar 88
Make a calculation 89
Use your work phone 89
Tips for business users 90
Phone management & connectivity 92
Keep your phone up to date 92
Use a high speed connection 93
Wi-Fi 94
NFC 95
Bluetooth 96
Memory and storage 97
Copy content between your phone and
computer 98
Security 99
Access codes 100
Help and support 102
Product and safety information 103
Copyrights and other notices 108
© 2013 Nokia. All rights reserved.
3

Safety
Read these simple guidelines. Not following them may be dangerous or illegal.
SWITCH OFF IN RESTRICTED AREAS
Switch the device off when cell phone use is not allowed or when it may cause interference or
danger, for example, in aircraft, in hospitals or near medical equipment, fuel, chemicals, or
blasting areas. Obey all instructions in restricted areas.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep your hands free to operate the vehicle while driving. Your first
consideration while driving should be road safety.
INTERFERENCE
All wireless devices may be susceptible to interference, which could affect performance.
QUALIFIED SERVICE
Only qualified personnel may install or repair this product.
BATTERIES, CHARGERS, AND OTHER ACCESSORIES
Use only batteries, chargers, and other accessories approved by Nokia for use with this device.
Third-party chargers that comply with the IEC/EN 62684 standard, and that can connect to
your device micro USB connector, may be compatible. Do not connect incompatible products.
KEEP YOUR DEVICE DRY
Your device is not water-resistant. Keep it dry.
GLASS PARTS
The device screen is made of glass. This glass can break if the device is dropped on a hard
surface or receives a substantial impact. If the glass breaks, do not touch the glass parts of
the device or attempt to remove the broken glass from the device. Stop using the device until the
glass is replaced by qualified service personnel.
PROTECT YOUR HEARING
To prevent possible hearing damage, do not listen at high volume levels for long periods.
Exercise caution when holding your device near your ear while the speakerphone is in use.
© 2013 Nokia. All rights reserved.
4

Get started
Get to grips with the basics and have your phone up and running in no time.
Keys and parts
Explore the keys and parts of your phone.
1Earpiece
2 Front camera
3 Connector for headphones and
speakerphones (3.5 mm)
4Volumekeys
5 Power/lock key
6 Camera key
7Searchkey
8Startkey
9Microphone
10 Back key
11 Camera flash
12 Camera
13 Micro-USB connector
14 Speakerphone
Back, start, and search key
The back, start, and search keys help you navigate your phone.
• To switch between open apps, press and hold , swipe left or right, and tap the app you want.
• To go back to the previous screen you were in, press . Your phone remembers all the apps and
websites you've visited since the last time your screen was locked.
• To go to the start screen, press . The app you were in remains open in the background.
• To control your phone with your voice, press and hold , and say a voice command.
This feature is not available in all languages. For more info on feature and service availability, see
the How-to section at www.windowsphone.com.
© 2013 Nokia. All rights reserved.
5

• To search the web, press .
Antenna locations
Learn where the antennas are located on your phone to get the best possible performance.
Avoid touching the antenna area while the antenna is in use. Contact with antennas affects the
communication quality and may reduce battery life due to higher power level during operation.
The antenna areas are highlighted.
Remove the back cover
Learn how to remove the back cover of your phone.
Note: Switch the device off and disconnect the charger and any other device before removing
any covers. Avoid touching electronic components while changing any covers. Always store and
use the device with any covers attached.
Do not use any tools to open the back cover.
1. With the back of the phone facing you, place your thumb on the back of the phone next to the
camera lens.
2. At the top left corner, put your fingernail in the seam between the screen frame and the back cover.
Bend the cover until a side seam opens slightly.
3. Repeat on the other corner, and remove the cover.
© 2013 Nokia. All rights reserved.
6

Replace the back cover
Press the bottom edge of the back cover against the bottom edge of the phone. Then press the back
of the cover until it snaps into place.
Insert the SIM card
Read on to learn how to insert your SIM card into your phone.
Important: This device is designed to be used with a mini-UICC SIM card, also known as a micro-
SIM card only. A micro-SIM card is smaller than the standard SIM card. Use of incompatible SIM
cards may damage the card or the device, and may corrupt data stored on the card.
Note: Switch the device off and disconnect the charger and any other device before removing
any covers. Avoid touching electronic components while changing any covers. Always store and
use the device with any covers attached.
© 2013 Nokia. All rights reserved.
7

Make sure the phone is switched off.
1. With the back of the phone facing you, place your thumb on the back of the phone next to the
camera lens.
2. At the top left corner, put your fingernail in the seam between the screen frame and the back cover.
Bend the cover until a side seam opens slightly.
3. Repeat on the other corner, and remove the cover.
4. If the battery is in, lift it out.
5. Push the SIM into the card slot until it locks into place. Make sure the contact area is face down.
© 2013 Nokia. All rights reserved.
8

6. Line up the battery contacts, and replace the battery.
7. Press the bottom edge of the back cover against the bottom edge of the phone.
8. Press the back of the cover until it snaps into place.
© 2013 Nokia. All rights reserved.
9

Remove the SIM card
Got a new SIM card? Learn how to remove the previous card from your phone.
1. Switch the phone off.
2. Remove the back cover.
3. If the battery is in, lift it out.
4. Push the card in until you hear a click, then pull the card out.
Insert the memory card
Learn how to insert the memory card.
Use only compatible memory cards approved for use with this device. Incompatible cards may
damage the card and the device and corrupt data stored on the card.
Some microSD cards may not be compatible with this phone. We recommend that you use your
phone’s internal memory for saving photos and videos. On the start screen, swipe left, and tap
Settings > phone storage. Switch Store new pictures on to phone. For more info on using a microSD
card with your phone, go to http://www.nokia.com/us-en/support/memorycard.
Your phone supports memory cards with a capacity of up to 64 GB.
Note: Switch the device off and disconnect the charger and any other device before removing
any covers. Avoid touching electronic components while changing any covers. Always store and
use the device with any covers attached.
1. With the back of the phone facing you, place your thumb on the back of the phone next to the
camera lens.
2. At the top left corner, put your thumbnail in the seam between the screen frame and the back
cover. Bend the cover until a side seam opens slightly.
3. Repeat on the other corner, and remove the cover.
© 2013 Nokia. All rights reserved.
10

4. If the battery is in, lift it out.
5. Push the memory card into the memory card slot until it locks into place.
6. Line up the battery contacts, and replace the battery.
7. Press the bottom edge of the back cover against the bottom edge of the phone.
© 2013 Nokia. All rights reserved.
11

8. Press the back of the cover until it snaps into place.
Remove the memory card
Need to change your memory card? Here's how you remove the card from your phone.
1. Switch the phone off.
2. Remove the back cover.
3. If the battery is in, lift it out.
4. Push the memory card in until you hear a click, then pull the card out.
Charge your phone
There's more than one way to charge your phone.
Charge your phone with a USB charger
Your battery has been partially charged at the factory, but you may need to recharge it before you
can switch the phone on for the first time.
Make sure you use a compatible USB charger to charge your phone.
1. First connect the USB cable to the charger, and plug the charger into a wall outlet, then connect
the micro-USB end of the cable to your phone.
© 2013 Nokia. All rights reserved.
12

2. When the battery is full, disconnect the charger from the phone, then from the wall outlet.
B
You don't need to charge the battery for a specific length of time, and you can use the phone while
it's charging.
If your phone is off when you start charging, it automatically switches on.
If the battery is completely discharged, it may take several minutes before the charging indicator is
displayed or before any calls can be made.
Tip: You can use USB charging when a wall outlet is not available. Data can be transferred while
charging the device. The efficiency of USB charging power varies significantly, and it may take
a long time for charging to start and the device to start functioning.
First connect the USB cable to the computer, then to your phone. When the battery is full, first
disconnect the USB cable from your phone, then from the computer.
© 2013 Nokia. All rights reserved.
13

Charge your phone wirelessly
No need for hassle with cables, just pop your device on a wireless charger, and it immediately starts
charging.
Your phone supports Qi, the global standard for wireless charging, and is compatible with any Qi
wireless charger. The charging areas on the phone and the charger need to touch, so make sure you
align the phone and charger properly. Not all phone models fit in all chargers.
You need a Nokia Wireless Charging Shell, marked with the Qi logo inside the shell, for wireless
charging to work. The shell may be included in the sales box, or it may be available separately. Only
use original Nokia Wireless Charging Shells.
Nokia Wireless Chargers are available separately.
Use only Qi chargers for wireless charging.
1. Make sure the wireless charger is switched on.
2. Place your phone on the wireless charger so that the charging areas touch together.
3. When the battery is full, remove your phone from the charger.
The charging area is highlighted.
© 2013 Nokia. All rights reserved.
14

Warning: Make sure there’s nothing between the charger and the device. Do not attach anything,
such as stickers, to the device surface near the charging area.
For more info on wireless charging, see the user guide of your charger.
Battery
Take good care of your battery, it's the life force of your phone.
Use only Nokia approved chargers designated for this phone. You can also use a compatible USB
cable to charge your phone (included).
First start-up
Learn how to get your new phone up and running.
Your new phone comes with great features that will be installed when you start your phone for the
first time. Allow some minutes for your phone to be ready.
Switch the phone on
Are you ready? Switch your phone on, and start exploring it.
Press and hold the power key until the phone vibrates.
© 2013 Nokia. All rights reserved.
15

Switch the phone off
Press and hold the power key, and drag the lock screen down.
Microsoft account
With a Microsoft account, you can access all Microsoft services with a single username and password
on your computer or phone. You can also use the same username and password on your Xbox.
With your Microsoft account, you can, for example:
• Download content from Store
• Back up your contacts
• Upload, store, and share pictures and documents.
• Back up your phone on SkyDrive.
• Play Xbox games
• Get your avatar and gaming achievements on your phone, and add to them when you play games
on your phone
• Keep track of and lock your lost phone with Find My Phone
© 2013 Nokia. All rights reserved.
16

• Get feeds from social networking services to your People hub
To learn more about Microsoft account and what can you do with it, go to
www.windowsphone.com.
Create your Microsoft account
Spice up your life and get more from your phone – create a Microsoft account.
To create a Microsoft account, you need an internet connection. If you don't have a data plan, the
data transmission costs may pile up quickly. For info about possible data costs, contact your network
service provider. If you can't connect to the internet, you can create the account later.
1. Switch on your phone with the SIM card in the phone.
2. To set up your phone, follow the instructions shown on the screen.
3. Create your Microsoft account, or sign in with your existing username and password.
Tip: Forgot your password? You can request it to be sent to you in a mail or text message.
Tip: To create a Microsoft account later, open a Microsoft app or service on your phone. Or on
the start screen, swipe left, and tap Settings > email+accounts > add an account. To create
your account on the internet, go to www.live.com.
To make an emergency call during the initial set-up, tap emergency call.
Lock the keys and screen
Want to avoid accidentally making a call when your phone is in your pocket or bag?
Press the power key.
© 2013 Nokia. All rights reserved.
17

Unlock the keys and screen
Press the power key, and drag the lock screen up.
Set the keys and screen to lock automatically
On the start screen, swipe left, tap Settings > lock screen > Screen times out after, and select
the length of time after which the keys and screen are locked automatically.
Change the volume
Trouble hearing your phone ringing in noisy environments, or calls too loud? You can change the
volume to your liking.
Use the volume keys.
© 2013 Nokia. All rights reserved.
18

The volume keys control all sounds, including the volume of alarms and reminders.
Tip: When you change the volume, you can also switch your phone to silent or normal mode. On
the volume control bar at the top of the screen, tap , , or .
Connect the headset
Enjoy your favorite music, or free your hands for other things when in a call.
Connect the headset to your phone.
Do not connect products that create an output signal, as this may damage the device. Do not connect
any voltage source to the audio connector. If you connect an external device or headset, other than
those approved by Nokia for use with this device, to the audio connector, pay special attention to
volume levels.
Icons shown on your phone
The bar at the top of the screen tells you the current time, battery and signal strength, and much
more.
Tip: To see hidden icons, tap the status bar.
© 2013 Nokia. All rights reserved.
19

Signal strength
Battery power level
The battery is charging.
Battery saver mode is switched on.
Your calls are forwarded to another number or your voice mailbox.
There is no SIM card in your phone.
Your SIM card is locked.
A Bluetooth device is connected to your phone.
A Wi-Fi connection is available.
A Wi-Fi connection is active.
An EDGE data connection is open.
A GPRS data connection is open.
Your phone is connected to a 3G network.
An LTE data connection is open.
An HSDPA/HSUPA data connection is open.
Your phone is connected to a 4G network.
An app or service is using your location info.
Your phone is roaming and not on your home mobile network.
Vibrate mode is switched on.
Airplane mode is switched on.
Silent mode is switched on.
The icons may vary depending on your region or network service provider.
© 2013 Nokia. All rights reserved.
20
