Nokia N71 User manual

Nokia XXX User Guide
9237522
ISSUE 1 EN DRAFT
R1114_en.book Page 1 Friday, September 16, 2005 9:36 AM

DECLARATION OF CONFORMITY
We, NOKIA CORPORATION declare under our sole
responsibility that the product RM-67 is in conformity
with the provisions of the following Council Directive:
1999/5/EC. A copy of the Declaration of Conformity
can be found at http://www.nokia.com/phones/
declaration_of_conformity/
Copyright © 2005 Nokia. All rights reserved.
Reproduction, transfer, distribution or storage of part or all of the contents in this
document in any form without the prior written permission of Nokia is prohibited.
Nokia, Nokia Connecting People, and Pop-Port are trademarks or registered
trademarks of Nokia Corporation. Other product and company names mentioned
herein may be trademarks or tradenames of their respective owners.
Nokia tune is a sound mark of Nokia Corporation.
This product includes software licensed from Symbian Software Ltd (c) 1998-
200(5). Symbian and Symbian OS are trademarks of Symbian Ltd.
Java™ and all Java-based marks are trademarks or registered trademarks of Sun
Microsystems, Inc.
Stac ®, LZS ®, ©1996, Stac, Inc., ©1994-1996 Microsoft Corporation. Includes one
or more U.S. Patents: No. 4701745, 5016009, 5126739, 5146221, and 5414425.
Other patents pending.
Hi/fn ®, LZS ®,©1988-98, Hi/fn. Includes one or more U.S. Patents: No. 4701745,
5016009, 5126739, 5146221, and 5414425. Other patents pending.
Part of the software in this product is © Copyright ANT Ltd. 1998. All rights
reserved.
US Patent No 5818437 and other pending patents. T9 text input software
Copyright (C) 1997-2005. Tegic Communications, Inc. All rights reserved.
MPEG-4
This product is licensed under the MPEG-4 Visual Patent Portfolio License (i) for
personal and noncommercial use in connection with information which has been
encoded in compliance with the MPEG-4 Visual Standard by a consumer engaged
in a personal and noncommercial activity and (ii) for use in connection with
MPEG-4 video provided by a licensed video provider. No license is granted or shall
be implied for any other use. Additional information including that relating to
promotional, internal and commercial uses may be obtained from MPEG LA, LLC.
See <http://www.mpegla.com>.
Nokia operates a policy of continuous development. Nokia reserves the right to
make changes and improvements to any of the products described in this document
without prior notice.
Under no circumstances shall Nokia be responsible for any loss of data or income
or any special, incidental, consequential or indirect damages howsoever caused.
The contents of this document are provided ‘as is’. Except as required by applicable
law, no warranties of any kind, either express or implied, including, but not limited
to, the implied warranties of merchantability and fitness for a particular purpose,
are made in relation to the accuracy, reliability or contents of this document. Nokia
reserves the right to revise this document or withdraw it at any time without prior
notice.
The availability of particular products may vary by region. Please check with the
Nokia dealer nearest to you.
Export Controls
This device may contain commodities, technology or software subject to export
laws and regulations from the US and other countries. Diversion contrary to law is
prohibited.
FCC / INDUSTRY CANADA NOTICE
Your device may cause TV or radio interference (for example, when using a
telephone in close proximity to receiving equipment). The FCC or Industry Canada
can require you to stop using your telephone if such interference cannot be
eliminated. If you require assistance, contact your local service facility. This device
complies with part 15 of the FCC rules. Operation is subject to the condition that
this device does not cause harmful interference.
ISSUE 1 EN, 9237522
legal-information1.fm Page 2 Thursday, September 22, 2005 11:19 AM

3
For your safety...........................................6
Your Nokia N71.........................................9
Essential indicators............................................................... 9
Attach the wrist strap........................................................10
Configure settings...............................................................10
Nokia support on the Web................................................10
Help .........................................................................................10
Clock........................................................................................11
Volume and loudspeaker control ....................................12
File manager .........................................................................12
Useful shortcuts...................................................................14
Personalise your device .......................... 15
Profiles—Set tones...............................................................16
Transfer content from another device...........................17
Change the look of your device.......................................17
Active standby mode..........................................................18
Make calls ............................................... 20
Voice calls..............................................................................20
Video calls..............................................................................22
Video sharing .......................................................................23
Answer or reject a call.......................................................26
Log ...........................................................................................28
Contacts (Phonebook).............................31
Save names and numbers.................................................31
Copy contacts.......................................................................32
Add ringing tones for contacts .......................................33
Create contact groups .......................................................33
Camera......................................................36
Take pictures.........................................................................36
Edit images ...........................................................................41
Tips on taking good photographs...................................42
Record videos .......................................................................43
Edit video clips.....................................................................45
Gallery.......................................................50
View images and video clips............................................50
View presentations .............................................................51
Albums ...................................................................................51
Imaging.....................................................64
Image print ...........................................................................64
RealPlayer™...........................................................................65
Movie Director .....................................................................67
Messaging.................................................69
Write text..............................................................................70
Write and send messages .................................................72
R1114_en.book Page 3 Friday, September 16, 2005 9:36 AM

4
Inbox—receive messages................................................... 75
My folders ............................................................................ 76
Mailbox .................................................................................. 76
Outbox—messages waiting to be sent.......................... 79
View messages on a SIM card......................................... 79
Messaging settings............................................................. 79
Calendar....................................................85
Create calendar entries.....................................................85
Calendar views..................................................................... 86
Remove calendar entries................................................... 86
Calendar settings ................................................................ 87
Web...........................................................88
Access the Web ................................................................... 88
Bookmarks view................................................................... 89
Make a connection............................................................. 89
Browse.................................................................................... 90
Download and purchase items........................................92
End a connection ................................................................ 92
Web settings......................................................................... 92
Office........................................................94
Calculator.............................................................................. 94
Converter............................................................................... 94
To-do ...................................................................................... 95
Notes ...................................................................................... 95
Recorder................................................................................. 96
My own.....................................................97
Go to—add shortcuts.......................................................... 97
IM—Instant messaging (chat) ........................................ 97
Visual Radio .......................................... 104
Listen to the radio.............................................................105
View visual content..........................................................105
Saved stations....................................................................105
Settings................................................................................106
Connectivity .......................................... 107
Bluetooth connection ......................................................107
PC connections ..................................................................110
Connection manager........................................................111
Remote synchronisation..................................................112
Device manager.................................................................113
Tools....................................................... 115
Settings................................................................................115
Cover display settings......................................................124
Voice commands ...............................................................124
Memory card tool..............................................................125
Application manager........................................................126
Activation keys—handle copyright-protected files .128
R1114_en.book Page 4 Friday, September 16, 2005 9:36 AM

5
Troubleshooting .................................... 129
Q&A...................................................................................... 129
Battery information.............................. 132
Charging and discharging.............................................. 132
Nokia battery authentication guidelines................... 132
Care and maintenance ......................... 134
Additional safety information............. 135
R1114_en.book Page 5 Friday, September 16, 2005 9:36 AM

6
For your safety
Read these simple guidelines. Not following them may be
dangerous or illegal. Read the complete user guide for
further information.
SWITCH ON SAFELY Do not switch the phone
on when wireless phone use is prohibited or
when it may cause interference or danger.
ROAD SAFETY COMES FIRST Obey all local
laws. Always keep your hands free to operate
the vehicle while driving. Your first
consideration while driving should be road
safety.
INTERFERENCE All wireless phones may be
susceptible to interference, which could affect
performance.
SWITCH OFF IN HOSPITALS Follow any
restrictions. Switch the phone off near medical
equipment.
SWITCH OFF IN AIRCRAFT Follow any
restrictions. Wireless devices can cause
interference in aircraft.
SWITCH OFF WHEN REFUELLING Do not use
the phone at a refuelling point. Do not use
near fuel or chemicals.
SWITCH OFF NEAR BLASTING Follow any
restrictions. Do not use the phone where
blasting is in progress.
USE SENSIBLY Use only in the normal
position as explained in the product
documentation. Do not touch the antenna
unnecessarily.
QUALIFIED SERVICE Only qualified personnel
may install or repair this product.
ENHANCEMENTS AND BATTERIES Use only
approved enhancements and batteries. Do not
connect incompatible products.
WATER-RESISTANCE Your phone is not
water-resistant. Keep it dry.
BACK-UP COPIES Remember to make
back-up copies or keep a written record of all
important information stored in your phone.
R1114_en.book Page 6 Friday, September 16, 2005 9:36 AM

7
CONNECTING TO OTHER DEVICES When
connecting to any other device, read its user
guide for detailed safety instructions. Do not
connect incompatible products.
EMERGENCY CALLS Ensure the phone is
switched on and in service. The keypad is
active only in the Fold open mode. Press
as many times as needed to clear the display
and return to the start screen. Enter the
emergency number, then press . Give your
location. Do not end the call until given
permission to do so.
About your device
The wireless device described in this guide is approved for
use on the EGSM 900/1800/1900 and UMTS 2100
networks. Contact your service provider for more
information about networks.
When using the features in this device, obey all laws and
respect privacy and legitimate rights of others.
When taking and using images or video clips, obey all laws
and respect local customs as well as privacy and
legitimate rights of others.
Warning: To use any features in this device, other
than the alarm clock, the device must be switched on.
Do not switch the device on when wireless device use
may cause interference or danger.
Network Services
To use the phone you must have service from a wireless
service provider. Many of the features in this device
depend on features in the wireless network to function.
These network services may not be available on all
networks or you may have to make specific arrangements
with your service provider before you can utilize network
services. Your service provider may need to give you
additional instructions for their use and explain what
charges will apply. Some networks may have limitations
that affect how you can use network services. For instance,
some networks may not support all language-dependent
characters and services. Network features are designated
in this guide by (network services).
Your service provider may have requested that certain
features be disabled or not activated in your device. If so,
they will not appear on your device menu. Your device may
also have been specially configured. This configuration
may include changes in menu names, menu order and
icons. Contact your service provider for more information.
This device supports WAP 2.0 protocols (HTTP and SSL) that
run on TCP/IP protocols. Some features of this device, such
as MMS, browsing, e-mail and content downloading via
R1114_en.book Page 7 Friday, September 16, 2005 9:36 AM

8
browser or over MMS, require network support for these
technologies.
For availability and information on using SIM card services,
contact your SIM card vendor. This may be the service
provider, network operator, or other vendor.
Enhancements, batteries, and
chargers
Always switch the device off and disconnect the charger
before removing the battery.
Check the model number of any charger before use with
this device. This device is intended for use when supplied
with power from a DC-4, AC-3 and AC-4 charger, and from
an AC-1, ACP-7, ACP-8, ACP-9, ACP-12, LCH-8, LCH-9, or
LCH-12 charger when used with the charger adapter
CA-44 delivered with your phone.
The battery intended for use with this device is BL-5B.
Warning: Use only batteries, chargers, and
enhancements approved by Nokia for use with this
particular model. The use of any other types may
invalidate any approval or warranty, and may be
dangerous.
For availability of approved enhancements, please check
with your dealer. When you disconnect the power cord of
any enhancement, grasp and pull the plug, not the cord.
R1114_en.book Page 8 Friday, September 16, 2005 9:36 AM

Your Nokia NXX
9
Your Nokia NXX
Settings
Your Nokia NXX normally has MMS, GPRS, streaming, and
Internet settings automatically configured in the device,
based upon your service provider or network operator
information. You may have settings from your service
providers already installed in your device, or you may
receive the settings from the service providers as a special
text message.
Transfer content from
another device
You can copy content such as contacts and calendar
entries from a compatible Nokia phone to your Nokia NXX
using Bluetooth connectivity or infrared. The type of
content that can be copied depends on the phone model.
Copyright protections may prevent some images, music
(including ringing tones), and other content from being
copied, modified, transferred or forwarded.
You can insert your SIM card in the other device. When
Nokia N80 is switched on without a SIM card, the offline
profile is automatically activated.
To avoid duplicate entries, you can transfer the same type
of information (for example, contacts) from the other
device to your Nokia XXX only once.
Transfer content
1Press , and select Tools >Transfer >Copy data on
your Nokia XXX.
2In the information view, select Continue.
3Select whether you want to use Bluetooth connectivity
or infrared to transfer the data. Both devices must
support the selected connection type.
4If you select Bluetooth connectivity:
To have Nokia XX search for devices with Bluetooth
connectivity, select Continue. Select your other device
from the list. You are asked to enter a code on your
Nokia XXX. Enter a code (1-16 digits), and select OK.
Enter the same code on the other device, and select
OK. The devices are now paired. See ‘Pair devices’,
p. 78.
For some phone models, the Transfer application is
sent to the other device as a message. To install
Transfer on the other device, open the message, and
follow the instructions on the display.
If you select infrared, connect the two devices. See
‘Infrared connection’, p. 79.
R1114_en.book Page 9 Friday, September 16, 2005 9:36 AM

Your Nokia NXX
10
5From your Nokia XXX, select the content you want to
copy from the other device.
Content is copied from the memory and memory card (if
inserted) of the other device to the corresponding location
in your Nokia XXX and memory card (if inserted). Copying
time depends on the amount of data to be transferred.
You can cancel copying and continue later.
Essential indicators
The device is being used in a GSM network.
The device is being used in a UMTS network (network
service).
You have one or more unread messages in the Inbox
folder in Messaging.
You have received new e-mail in the remote mailbox.
There are messages waiting to be sent in the Outbox
folder.
You have missed calls.
Shown if Ringing type is set to Silent and Message
alert tone,IM alert tone, and E-mail alert tone are set
to Off.
The device keypad is locked.
A clock alarm is active.
The second phone line is being used (network service).
All calls to the device are diverted to another
number. If you have two phone lines (network service), the
indicator for the first line is and for the second
.
A headset is connected to the device.
The connection to a headset with Bluetooth
connectivity has been lost.
A loopset is connected to the device.
A TTY is connected to the device.
A data call is active.
A GPRS or EDGE packet data connection is available.
A GPRS or EDGE packet data connection is active.
A GPRS or EDGE packet data connection is on hold.
A UMTS packet data connection is available.
A UMTS packet data connection is active.
A UMTS packet data connection is on hold.
Bluetooth connectivity is on.
Data is being transmitted using Bluetooth
connectivity.
A USB connection is active.
R1114_en.book Page 10 Friday, September 16, 2005 9:36 AM

Your Nokia NXX
11
An infrared connection is active. If the indicator is
blinking, the device is trying to connect to the other device
or the connection has been lost.
Keypad lock (keyguard)
To lock the keys, close the sliding keypad, and select Yes
when Lock keypad? is displayed. To lock the keys when the
slide is closed, press the power key, and select Lock
keypad.
To unlock, open the sliding keypad, or press (Unlock),
and select OK when Unlock keypad? is displayed.
When the keypad lock is on, calls may be possible to the
official emergency number programmed into your device.
Volume and loudspeaker control
To increase or decrease the
volume level when you have
an active call or are listening
to a sound, press or .
The built-in loudspeaker allows you to speak and listen
from a short distance without having to hold the device to
your ear.
Warning: Do not hold the device near your ear
when the loudspeaker is in use, because the volume
may be extremely loud.
To use the loudspeaker during a call, select Options >
Activate loudsp..
To turn off the loudspeaker, select Options >Activate
handset.
Clock
Press , and select Clock. To set a new alarm, select
Options >Set alarm. When an alarm is active, is
shown.
To turn off the alarm, select Stop, or to stop the alarm for
5 minutes, select Snooze.
If the alarm time is reached while the device is switched
off, the device switches itself on and starts sounding the
alarm tone. If you select Stop, the device asks whether you
want to activate the device for calls. Select No to switch
off the device or Yes to make and receive calls. Do not
select Yes when wireless phone use may cause
interference or danger.
To cancel an alarm, select Clock >Options >Remove
alarm.
R1114_en.book Page 11 Friday, September 16, 2005 9:36 AM

Your Nokia NXX
12
Clock settings
To change the clock settings, select Clock >Options >
Settings.
To change the time or date, select Time or Date.
To change the clock shown in the standby mode, select
Clock type >Analog or Digital.
To allow the mobile phone network to update the time,
date, and time zone information to your device (network
service), select Auto time update >On.
To change the alarm tone, select Clock alarm tone.
World clock
To open the world clock view, open Clock, and press .
In the world clock view, you can view the time in different
cities.
To add cities to the list, select Options >Add city. You
can add a maximum of 15 cities to the list.
To set your current city, scroll to a city, and select
Options >My current city. The city is displayed in the
clock main view, and the time in your device is changed
according to the city selected. Check that the time is
correct and matches your time zone.
Headset
Connect a compatible
headset to the Pop-PortTM
connector of your device.
Warning: When you
use the headset, your ability
to hear outside sounds may
be affected. Do not use the
headset where it can
endanger your safety.
Wrist strap
Thread the strap as shown,
and tighten it.
Memory card
You can purchase a compatible miniSD memory card and
use it as extra storage space to save the memory on your
device. You can also back up information from your device
to the memory card.
R1114_en.book Page 12 Friday, September 16, 2005 9:36 AM

Your Nokia NXX
13
Use only compatible miniSD memory cards with this
device. Other memory cards, such as Reduced Size
MultiMediaCards, do not fit in the memory card slot and
are not compatible with this device. Using an incompatible
memory card may damage the memory card as well as the
device, and data stored on the incompatible card may be
corrupted.
Keep all memory cards out of the reach of small children.
Insert the memory card
1To insert the memory
card, place your finger in
the recess on top of the
door of the memory card
slot, and open the door.
2Insert the memory card in
the slot. Make sure that
the contact area on the
card is facing up and
towards the slot with the
bevelled corner facing
the base of the device.
3Push the card in. You can hear a
click when the card locks into
place.
4Close the door. You cannot use
the memory card if the door is
open.
Eject the memory card
1Before you eject the card, press
the power key, and select Remove mem. card. All
applications are closed.
2When Remove memory card and press 'OK' is
displayed, open the door of the memory card slot.
3Press the memory card to release it from the slot.
4Remove the memory card. If the device is switched on,
select OK.
Important: Do not remove the memory card in the
middle of an operation when the card is being accessed.
Removing the card in the middle of an operation may
damage the memory card as well as the device, and data
stored on the card may be corrupted.
Memory card tool
Press , and select Tools >Memory. You can use a
miniSD memory card as extra storage space and for
backing up the information in the device memory.
R1114_en.book Page 13 Friday, September 16, 2005 9:36 AM

Your Nokia NXX
14
To back up information from the device memory to a
memory card, select Options >Backup phone mem.
To restore information from the memory card to the
device memory, select Options > Restore from card.
Format a memory card
When a memory card is reformatted, all data on the card
is permanently lost.
Some memory cards are supplied preformatted and others
require formatting. Consult your retailer to find out if you
must format the memory card before you can use it.
To format a memory card, select Options >Format mem.
card. Select Yes to confirm.
File manager
Many features of the device, such as contacts, messages,
images, videos, ringing tones, calendar notes, documents,
and downloaded applications, use memory to store data.
The free memory available depends on how much data is
already saved in the device memory.
You can use a memory card as extra storage space.
Memory cards are rewritable, so you can delete old
information and save new data on a memory card.
To browse files and folders in the device memory or on a
memory card (if inserted), press , and select Tools >File
mgr.. The device memory view ( ) opens. Press to
open the memory card view ( ) (if available).
To move or copy files to a folder, press and at the
same time to mark a file, and select Options >Move to
folder or Copy to folder.
To find a file, select Options >Find and the memory from
which to search, and enter a search text that matches the
file name.
View memory consumption
To view what types of data you have in the device and how
much memory the different data types consume, select
Options >Memory details. The amount of available free
memory is shown in Free memory.
Memory low—free memory
The device notifies you if the device or the memory card
memory is low.
To free device memory, transfer data to a memory card, if
you have one. Mark files to be moved, and select Move to
folder > Memory card, and a folder.
R1114_en.book Page 14 Friday, September 16, 2005 9:36 AM

Your Nokia NXX
15
You can also transfer media files to a compatible PC, for
example, using the transfer option in Gallery. See ‘Gallery’,
p. 29.
Tip! You can use Nokia Phone Browser available in
Nokia PC Suite to view the different memories in your
device and transfer data.
To remove data to free memory, use File mgr., or go to the
respective application. For example, you can remove the
following:
• Messages from Inbox,Drafts, and Sent folders in
Messaging
• Retrieved e-mail messages from the device memory
• Saved Web pages
• Saved images, videos, or sound files
• Contact information
•Calendarnotes
• Downloaded applications. See also ‘Application
manager’, p. 98.
• Any other data that you no longer need
Useful shortcuts
Use shortcuts to quickly get the most from your device.
Refer to the relevant sections in this user guide for further
details of the functions.
Standby mode
• To switch between applications that are open, press
and hold , and select an application. If memory is
low, the device may close some applications. The
device saves any unsaved data before closing an
application.
Leaving applications running in the background
increases the demand on battery power and reduces
the battery life.
• To start the camera, press and hold the capture key for
more than 1 second.
• To call your voice mailbox (network service), press and
hold .
• To open multimedia applications, press or press and
hold . See ‘ICON- Media key’, p. 88.
• To change the profile, press , and select a profile.
• To switch between Normal and Silent profiles, press
and hold . If you have two phone lines, this action
switches between the two lines.
• To open the last dialed numbers list, press .
• To use voice commands, press and hold .
• To start a connection to Web, press and hold . See
‘Web’, p. 64.
For further shortcuts available in the standby mode, see
‘Active standby mode’, p. 87.
R1114_en.book Page 15 Friday, September 16, 2005 9:36 AM

Your Nokia NXX
16
Edit text and lists
• To mark an item in a list, scroll to it, and press and
at the same time.
• To mark multiple items in a list, press and hold
while you press or . To end the selection, release
, then release .
• To copy and paste text: To select letters and words,
press and hold . At the same time, press or
to highlight text. To copy the text to clipboard, while
still holding , select Copy. To insert the text into a
document, press and hold , and select Paste.
Help
Your device has context-sensitive help. When an
application is open, select Options >Help to access help
for the current view.
When you are reading the instructions, to switch between
help and the application that is open in the background,
press and hold .
To open help from the main menu, select Tools >Help.
Select the desired application to view its help topics.
Tutorial
The tutorial gives you information about some of the
features of your device. To access the tutorial in the menu,
press , and select My own >Tutorial and the section
you want to view.
R1114_en.book Page 16 Friday, September 16, 2005 9:36 AM

Camera
17
Camera
Your Nokia Nxx has two cameras, a high resolution camera
on the back of the device, and a lower resolution camera
above the main display, which is visible when the cover is
opened. Both cameras can be used to take still pictures and
video.
To activate the camera, open the cover, and select Camera.
In the viewfinder, you can see the view to be captured. To
switch between cameras, select Options > Use front
camera or back camera.
The images and video clips are automatically saved in the
Gallery. The cameras produce .jpeg images. Video clips are
recorded in the .3gpp file format with the .3gp file
extension (Normal and Sharing video quality modes) or in
the .mp4 file format (High video quality mode). See ‘Video
settings’, p.17.
You can send images in a multimedia message as an e-mail
attachment, or by using a Bluetooth connection.
Tip! You can insert an image into a contact card. See
‘Save names and numbers’, p.61
Your Nokia Nxx supports an image capture resolution of up
to 1600 x 1200 pixels using the back camera. The image
resolution in these materials may appear different.
Take pictures
If the camera is in video mode, open the image mode by
selecting Options > Image mode.
To select the front camera to, for example, include
yourself in the picture, select Options > Use front
camera. To use the main camera again, select Options >
Use back camera.
To take a picture, press . Do not move the phone before
the image is saved. The image is saved automatically in
the Images&Video folder of Gallery. See ‘Gallery’, p. 29.
To view the Last image, to select Image scenes, or to
adjust Flash or White balance settings before taking a
picture:
• If the viewfinder is active, press or to activate
the camera setup settings.
R1114_en.book Page 17 Friday, September 16, 2005 9:36 AM

Camera
18
•Press or to
choose the item to be
viewed or adjusted, and
press . The settings
available depend on
which camera is
selected??.
• To re-activate the
viewfinder, press Cancel
or .
See ‘Setup settings—Adjust
colour and lighting’, p. 12, and ‘Scenes’, p. 12.
Imaging mode camera indicators show the following:
• The phone memory ( ) and memory card ( )
indicators (1) show where images are saved.
• The images indicator (2) estimates how many images,
depending on the selected image quality, can fit in the
remaining memory of your phone or the memory card.
• The scene indicator (3) shows the active scene. See
‘Scenes’,p. 12.
• The flash indicator (4)
shows if the flash is set to
Automatic (AF), , On (),
or Off ().
• The night mode indicator
(5) shows that night mode
is active.
• The self-timer indicator
(6) shows that the
self-timer is activated. See
‘You in the picture—self-
timer’, p. 11.
• The sequence mode indicator (7) shows that the
sequence mode is active. See ‘Take pictures in a
sequence’, p. 11.
Press or to zoom in and zoom out. The zoom
indicator, which appears on the side of the viewfinder,
shows the zoom level.
Saving the captured image may take longer if you change
the zoom, lighting, or colour settings.
When taking a picture, note the following:
• Keep the camera still by using both hands.
• To take images in different environments, use the
proper scene for each environment. See ‘Scenes’, p. 12.
• The quality of a zoomed picture is lower than that of a
non-zoomed picture.
Graphic: Screenshot to
indicate the setup (lower)
part of the screen being
active.
Graphic: Screenshot to
show position of the
indicators (to be
numbered).
R1114_en.book Page 18 Friday, September 16, 2005 9:36 AM

Camera
19
• The camera goes into battery saving mode if you do not
make any key presses for a while. To continue taking
pictures, press .
After the image is taken:
• If you do not want to keep the image, select Options >
Delete.
• To send the image Via multimedia,Via e-mail, or Via
Bluetooth, select Options > Send. For more
information, see ‘Messaging’, p. 38 and ‘Bluetooth
connectivity’, p. 76. This option is not available during
an active call.
• To send an image to the other party during an active
call, select Options > Send to caller.
• To edit the picture, select Options > Edit. See ‘Edit
images’, p. 14.
• To print the picture, select Options > Print. See ‘Image
print’, p. 33.
Take pictures in a sequence
Select Options > Time lapse to set the camera to take six
pictures in a sequence. You can set the time lapse to be
Fast,Med or Slow.
The pictures are automatically saved in Gallery.
You can also use the
sequence mode with the
Self-timer. See ‘You in the
picture—self-timer’, p. 11.
After taking the pictures,
they are shown in a grid on
the main display. To view a
picture, press to open it.
To return to the sequence
mode viewfinder, press ????.
You in the picture—self-timer
Use the self-timer to delay the taking of a picture so that
you can include yourself in the picture. To set the
self-timer delay, select Options > Self-timer > 10
seconds,20 seconds or 30 seconds. To activate the self-
timer, select Activate. The self-timer indicator ( ) blinks
and the phone beeps when the timer is running. The
camera takes the picture after the selected delay has
elapsed. You can also use the Self-timer in the sequence
mode. See ‘Take pictures in a sequence’, p. 11.
The flash
Keep a safe distance when using the flash. Do not use the
flash on people or animals at close range. Do not cover
the flash while taking a picture.
Graphic: Screenshot to
show a grid of pictures in
Gallery.
R1114_en.book Page 19 Friday, September 16, 2005 9:36 AM

Camera
20
The camera has an LED flashlight for low light conditions.
The following flashlight modes are available: Automatic,
On, and Off.
To use the flash, press or to highlight Flash and
select On.
If the flash is set to Off or Automatic during bright
conditions, the flash still emits a low light when an image
is captured. This allows the subject of the picture to see
when the picture is taken. There is no flash effect on the
resultant picture.
Setup settings—Adjust colour and
lighting
To enable the camera to reproduce colours and lighting
more accurately, or to add effects to your pictures or
videos, select Options > Open setup and select from the
following:
Video scenes/Image scenes—Select a scene which is
appropriate for the environment in which you are taking
pictures. See ‘Scenes’, p. 12.
Flash (images only)—Set the flash according to the
lighting conditions. See ‘The flash’, p. 11.
White balance—Select the appropriate setting which
matches the lighting conditions. This allows the camera to
reproduce colours more accurately.
Colour tone—Select the colour effect you want.
The display changes to match any settings made.
The settings return to the default settings when you close
the camera. If you select a new scene, the settings are
replaced by the settings of the selected scene. See ‘Scenes’,
p. 12. If you need to change the setup settings, however,
you can change them after selecting a scene.
The settings available will vary depending on whether you
have the front or main camera selected.
Scenes
A scene helps you to obtain the correct colour and lighting
settings for the current environment. Select the
appropriate scene for taking pictures or recording video
clips from the scenes list. The settings of each scene have
been set to match a certain style or environment. Select
Options > Open setup > Video scenes/Image scenes:
Video scenes
Normal (default)—Use this scene in any conditions.
Night—Use this scene in low light conditions. The night
mode is indicated with .
Image scenes
Automatic (default)—Use this scene in any conditions.
R1114_en.book Page 20 Friday, September 16, 2005 9:36 AM
