Nokia X6-00m User manual

Nokia X6-00m User guide
3333333
Issue 1
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Contents
Safety 5
About your device 6
Network services 7
Get started 9
Keys and parts 9
Insert the SIM card and battery 11
Charge the battery 13
Switch the device on 15
Lock the keys and touch screen 15
Home screen 16
Media key 18
Access the menu 18
Touch screen actions 18
Change the ringing tone 21
Support 21
Open Ovi with your device 21
Find help 21
In-device help 22
Extended user guide 22
Update software using your PC 23
Access codes 23
Your device 24
Find an item with adaptive search 24
Shortcuts 24
Antenna locations 25
Contacts bar 26
Offline profile 26
Sensor settings and display
rotation 27
Headset 27
Remove the SIM card 28
Attach a wrist strap 29
China Mobile services 30
Make calls 30
Touch screen during calls 30
Calls 31
Write text 31
Automatic input modes 32
Keys and functions 32
Chinese handwriting recognition 33
Enter text with alphanumeric
keypad 34
Chinese input with virtual
keyboard 38
Touch input settings 38
Phonebook manager 39
Messaging 39
Messaging main view 39
Write and send messages 40
2Contents
www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Set up e-mail 42
Nokia Messaging 42
Mail for Exchange 43
Music player 44
Play a song or a podcast 44
Playlists 46
Transfer music from a computer 48
My favorites 48
Camera 48
Activate the camera 48
Image capture 49
Video recording 53
Positioning (GPS) 55
About GPS 55
Assisted GPS (A-GPS) 55
Hold your device correctly 56
Connectivity 57
Nokia Video Centre 58
View and download video clips 58
Video feeds 60
My videos 60
Transfer videos from your PC 61
Video centre settings 61
Web browser 62
Browse the web 63
Browser toolbar 64
Bookmarks 65
Empty the cache 66
Connection security 66
Monternet 67
Accessories 68
Battery 69
Battery and charger information 69
Nokia battery authentication
guidelines 70
Taking care of your device 71
Recycle 72
China ROHS Table 72
Additional safety information 72
Small children 72
Operating environment 72
Medical devices 73
Vehicles 73
Potentially explosive
environments 74
Emergency calls 74
Certification information (SAR) 74
Contents 3
www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

MANUFACTURER’S LIMITED
WARRANTY 75
Warranty period 75
How to get warranty service 75
What is not covered? 76
Other important notices 77
Limitation of Nokia's liability 77
Statutory obligations 77
Terms of use, OVI SERVICE TERMS
and privacy policy 78
Terms of Use 78
First use of your device 78
Software updates 78
Other important information 78
OVI SERVICE TERMS 79
WE CARE ABOUT YOUR PRIVACY 83
Index 88
4Contents
www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Safety
Read these simple guidelines. Not following them may be dangerous or illegal. Read
the complete user guide for further information.
SWITCH ON SAFELY
Do not switch the device on when wireless phone use is prohibited or
when it may cause interference or danger.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep your hands free to operate the vehicle
while driving. Your first consideration while driving should be road
safety.
INTERFERENCE
All wireless devices may be susceptible to interference, which could affect
performance.
SWITCH OFF IN RESTRICTED AREAS
Follow any restrictions. Switch the device off in aircraft, near medical
equipment, fuel, chemicals, or blasting areas.
QUALIFIED SERVICE
Only qualified personnel may install or repair this product.
Safety 5
www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

ACCESSORIES AND BATTERIES
Use only approved accessories and batteries. Do not connect
incompatible products.
WATER-RESISTANCE
Your device is not water-resistant. Keep it dry.
GLASS PARTS
The front cover of the device is made of glass. This glass can break if the
device is dropped on a hard surface or receives a substantial impact. If
the glass breaks, do not touch the glass parts of the device or attempt to
remove the broken glass from the device. Stop using the device until the
glass is replaced by qualified service personnel.
About your device
The wireless device described in this guide is approved for use on the (E)GSM 850,
900, 1800, and 1900 networks. Contact your service provider for more information
about networks.
Your device supports several connectivity methods and like computers may be
exposed to viruses and other harmful content. Exercise caution with messages,
connectivity requests, browsing, and downloads. Only install and use services and
software from trustworthy sources that offer adequate security and protection,
such as applications that are Symbian Signed or have passed the Java Verified™
testing. Consider installing antivirus and other security software on your device and
any connected computer.
6Safety
www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Your device may have preinstalled bookmarks and links for third-party internet sites
and may allow you to access third-party sites. These are not affiliated with Nokia,
and Nokia does not endorse or assume liability for them. If you access such sites,
take precautions for security or content.
Warning:
To use any features in this device, other than the alarm clock, the device must be
switched on. Do not switch the device on when wireless device use may cause
interference or danger.
When using this device, obey all laws and respect local customs, privacy and
legitimate rights of others, including copyrights. Copyright protection may prevent
some images, music, and other content from being copied, modified, or transferred.
Make back-up copies or keep a written record of all important information stored
in your device.
When connecting to any other device, read its user guide for detailed safety
instructions. Do not connect incompatible products.
The images in this guide may differ from your device display.
Refer to the user guide for other important information about your device.
Network services
To use the device you must have service from a wireless service provider. Some
features are not available on all networks; other features may require that you make
specific arrangements with your service provider to use them. Network services
involve transmission of data. Check with your service provider for details about fees
in your home network and when roaming on other networks. Your service provider
can explain what charges will apply. Some networks may have limitations that affect
how you can use some features of this device requiring network support such as
Safety 7
www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

support for specific technologies like WAP 2.0 protocols (HTTP and SSL) that run on
TCP/IP protocols and language-dependent characters.
Your service provider may have requested that certain features be disabled or not
activated in your device. If so, these features will not appear on your device menu.
Your device may also have customized items such as menu names, menu order, and
icons.
8Safety
www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Get started
Keys and parts
1 – Earpiece
2 – Touch screen
3 – Menu key
4 – Call key
5 – Light sensor
6 – Secondary camera
7 – Media key
8 – Proximity sensor
9 – End key
Get started 9
www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

10 – Power key
11 – Charger connector
12 – Nokia AV Connector (3.5 mm)
13 – Micro USB connector
14 – Volume/Zoom key
15 – Camera lens
16 – Lock switch
17 – Capture key
18 – Microphone
19 – Camera flash
20 – Loudspeakers
21 – SIM card slot cover
22 – Xinji is the logo of China Mobile
customised devices.
Do not cover the area above the touch screen, for example, with protective film or
tape.
10 Get started
www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Insert the SIM card and battery
Insert the SIM card
Important: To prevent damage to the SIM card, always remove the battery before
you insert or remove the card.
1 Remove the back cover.
2 If the battery is inserted, remove the battery.
Always switch the device off and disconnect the charger before removing the
battery.
3 Open the cover of the SIM card slot.
Get started 11
www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

4 Insert a SIM card in the slot. Ensure that the contact area on the card is facing
up and the bevelled corner is facing toward the device. Push the card in.
5 Close the cover of the SIM card slot. Ensure that the cover is properly closed.
If the SIM card is not properly in place, the device can only be used in the offline
profile.
12 Get started
www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Insert the battery
1 Insert the battery.
2 To replace the cover, direct the top locking catches toward their slots, and press
down until the cover locks into place.
See "Remove the SIM card", p. 28.
Charge the battery
Your battery has been partially charged at the factory. If the device indicates a low
charge, do the following:
1 Connect the charger to a wall outlet.
Get started 13
www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

2 Connect the charger to the device.
3 When the device indicates a full charge, disconnect the charger from the device,
then from the wall outlet.
You do not need to charge the battery for a specific length of time, and you can use
the device while it is charging. If the battery is completely discharged, it may take
several minutes before the charging indicator appears on the display or before any
calls can be made.
Tip: Disconnect the charger from the wall outlet when the charger is not in use. A
charger that is connected to the outlet consumes power even when it is not
connected to the device.
14 Get started
www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Switch the device on
1 Press and hold the power key.
2 If the device asks for a PIN code or lock code, enter it, and select OK. To delete
a number, select . The factory setting for the lock code is 12345.
3 Select your location. If you accidentally select the wrong location, select Back.
4 Enter the date and time. When using the 12-hour time format, to switch
between a.m. and p.m., select any number.
Lock the keys and touch screen
To lock or unlock the touch screen and the keys, slide the lock switch on the side of
the device.
When the touch screen and keys are locked, the touch screen is switched off and
the keys are inactive.
Get started 15
www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

To change settings for automatic screen and key locking, select Menu > Settings
and Phone > Phone mgmt. > Auto. keyguard > Keypad autolock period.
Home screen
The home screen is your starting point where you can collect all your important
contacts or application shortcuts.
Interactive display elements
To open the clock application, select the clock (1).
16 Get started
www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

To open the calendar, or to change the profile, select the date or the profile name
(2).
To make a phone call, select Telephone or (4).
To open the contacts list, select Contacts or (5).
To open the main menu, press the menu key (6).
Start using the contacts bar
To start using the contacts bar, and to add your contacts to the home screen, select
> Options > New contact, and follow the instructions.
Change the home screen theme
To change the home screen theme or the shortcuts, select Menu > Settings and
Personal > Home screen.
Music keys
When music or the radio is playing in the background, music keys (play/pause, skip
backward, and skip forward) are displayed in the home screen.
Get started 17
www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Media key
To access applications such as the music player or browser, select the media key
() to open the media bar, and select the application.
Access the menu
To access the menu, press the menu key.
To open an application or folder in the menu, tap it.
Touch screen actions
Tap and double-tap
To open an application or other element on the touch screen, you normally tap it
with your finger. However, to open the following items, you must tap them twice.
18 Get started
www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

•List items in an application, such as the Drafts folder in the folder list in
Messaging
Tip: When you open a list view, the first item is already highlighted. To open
the highlighted item, tap it once.
•Applications and folders in the menu when using the list view type
•Files in a file list, for example, an image in the images and videos view in Gallery.
If you tap a file or similar item once, it is not opened, it becomes highlighted.
To view the options available for the item, select Options or, if available, select
an icon from a toolbar.
Select
In this user documentation, opening applications or items by tapping them once or
twice is called "selecting". If you need to select several items in a sequence, the
display texts to select are separated by arrows.
Example: To select Options > Help, tap Options, and then tap Help.
Drag
To drag, place your finger on the screen, and slide it across the screen.
Example: To scroll up or down on a web page, drag the page with your finger.
Get started 19
www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Swipe
To swipe, slide your finger quickly left or right on the screen.
Scroll
To scroll up or down in lists that have a scroll bar, drag the slider of the scroll bar.
To scroll longer lists, flick the list. The faster you flick, the faster the list moves. If
you flick up, the list continues the movement and moves down.
To select an item from a spinning list and to stop the movement, tap the item.
Tip: To view a brief description of an icon, place your finger on the icon. Descriptions
are not available for all icons.
Touch screen light
To turn the screen light on, tap it.
If the touch screen and keys are locked, tapping the screen does not turn the screen
light on. To unlock the screen and keys, slide the lock switch.
20 Get started
www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
