Nokia Essence BH-610 User manual

Nokia Bluetooth Stereo Headset
BH-610
1111111/1
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Introduction
About your headset
With the Nokia Bluetooth Headset
BH-610, you can handle calls
hands-free and listen to music on
the go. Active noise cancellation
(ANC) helps you enjoy high audio
quality also in noisy
environments. The headset iseasy
to pair with compatible devices.
The surface of this product is nickel-
free.
Warning: This product may
contain small parts. Keep them out
of the reach of small children.
Parts of the product are magnetic.
Metallic materials may be attracted
to the product. Do not place credit
cards or other magnetic storage
media near the product, because
information stored on them may be
erased.
Read this user guide carefully before
using the product. Also, read the user
guide for the device that you connect
to the product.
For support, go to
www.nokia.com/support.
About Bluetooth
connectivity
You can use Bluetooth to make a
wireless connection to other
compatible devices, such as
mobile devices.
Devices do not need to be in direct
line-of-sight, but they must be
within 10 metres (33 feet) of each
other. The connection may be
affected by obstructions such as
walls or other electronic devices.
This device is compliant with
Bluetooth Specification 2.1 + EDR
supporting the following profiles:
ENGLISH
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Headset Profile (HSP) 1.2, Hands-Free
Profile (HFP) 1.5, Advanced Audio
Distribution Profile (A2DP) 1.2, and
Audio Video Remote Control Profile
(AVRCP) 1.0. Check with the
manufacturers of other devices to
determine their compatibility with
this device.
Get started
Keys and parts
1Charger connector
2Indicator light
3Volume keys
4Clip
5Rewind key
6Play/Pause key
7Fast-forward key
8Treble key
9Bass key
10 Multifunction key
11 Active noise cancellation (ANC)
switch
12 Neck strap
13 Microphone
14 Earpiece
15 Near Field Communication
(NFC) area
Charge the battery
Before using the headset, you
must charge the battery.
When you unplug a charger, hold
and pull the plug, not the cord.
1. Connect the charger to a wall
outlet.
2. Connect the charger cable to
the charger connector on the
headset. The red indicator light
ENGLISH
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

turns green when the battery is
fully charged.
3. Disconnect the charger from
the headset, then from the wall
outlet.
The fully charged battery has
power for up to 8 hours of talk
time or music playing time, or up
to 35 hours of standby time with
active noise cancellation (ANC)
activated. To increase standby
time, deactivate ANC if you are not
using the headset. When ANC is
not activated, the standby time is
up to 240 hours.
After 15 minutes of charging, the
battery has power for over 4 hours
and 30 minutes of talk or music
playing time.
When the battery charge is low,
the headset beeps every 5
minutes and the red indicator
light flashes.
If you activate ANC without
switching the headset on, when
the battery charge is low, the
headset doesn't beep and the red
indicator light stays on.
Check the battery charge —
With your headset connected to
your mobile device, press . A
green light indicates a sufficient
charge level. If the light is yellow,
you may need to recharge the
battery soon. If the light is red,
recharge the battery.
Switch the headset on or off
To switch the headset on, press
and hold for 2 seconds. The
headset beeps, and a green
indicator light flashes once. The
headset automatically connects
to the last connected device. If you
have never paired the headset
with a device, or you have cleared
ENGLISH
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

the paired devices list, pairing
mode is automatically activated.
To switch the headset off, press
and hold for 4 seconds. The
headset beeps, and a red indicator
light flashes once.
If the headset is not connected to
a device within 30 minutes, it
switches off.
Wear the headset
You can attach the headset to your
clothing using the clip, or carry it
on your neck using the neck strap.
To attach the neck strap, slide the
earpiece cable into the neck strap
clip, and twist the cable 90
degrees to lock it into place.
The headset is provided with
different-sized rubber earpieces.
Select the ones that fit you best.
Make sure you insert the earpiece
marked with Linto your left ear
and the one marked with Rinto
your right ear.
Use active noise
cancellation (ANC)
Active noise cancellation (ANC)
reduces background noise, so you
can enjoy high audio quality also
in noisy environments. As you can
listen at a lower volume, ANC
helps protect your hearing.
Use the ANC switch to activate or
deactivate ANC.
You can activate ANC even when
your headset is switched off, and
use your headset as ear plugs to
reduce background noise, for
example, when on a plane.
Tip: To save battery
power, make sure ANC is
not activated when you
are not using the headset.
ENGLISH
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Make calls
Make and receive calls
Make a call — When the headset
is connected to your compatible
mobile device, make a call
normally using your mobile
device.
Answer or end a call — Press
.
Mute or unmute the
microphone — Press .
Reject a call — Press twice.
You can redial the number you last
called or use your voice to make a
call, if your mobile device
supports these features with the
headset.
Redial the last called
number — When no call is in
progress, press twice.
Activate voice dialling — When
no call is in progress, press and
hold for 2 seconds, and
follow the instructions in the user
guide of your mobile device.
Change the volume
Use the volume keys. To change
the volume quickly, press and hold
the volume keys.
To avoid increasing the volume in
noisy environments, use active
noise cancellation (ANC).
ENGLISH
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Pair the device
Pair and connect the
headset
Before using the headset with a
compatible device for the first
time, you must pair and connect
them.
Pair the headset manually
1. Make sure the headset is
switched off.
2. Switch the compatible device
on, and activate the Bluetooth
feature on the device.
3. Switch the headset on. If you
have previously paired your
headset with another device,
press for 5 seconds. The
blue indicator light starts to
flash quickly.
4. Set your device to search for
Bluetooth devices. For details,
see the user guide of the
device.
5. On your device, select the
headset from the list of found
devices.
6. If required, enter the passcode
0000.
In some devices, you may need to
make the connection separately
after pairing.
Pair and connect the
headset using NFC
With Near Field Communication
(NFC), you can pair and connect
your headset to your compatible
device easily. If the compatible
device supports NFC, activate its
NFC feature, and touch the NFC
area on the headset with the NFC
area on your device. The headset
ENGLISH
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

switches on and connects to the
device automatically. You can also
disconnect the headset using NFC.
For details on NFC, see the user
guide of the device.
If the device does not support NFC,
pair the headset manually.
Connect the headset to
your device
When you switch your headset on,
it automatically connects to the
last device it was used with. If the
last connected device is not
available, the headset tries to
connect to the next device on its
paired devices list.
If your mobile device does not
support the A2DP profile for
listening to music, you can
separately pair the headset with a
music player that supports this
profile. If you have paired and
connected the headset to your
mobile device, disconnect the
headset from it before pairing the
headset with the music player.
The paired devices list on your
headset can contain up to 8
devices. You can connect the
headset to 2 compatible devices
at the same time: 1 mobile device
and 1 music player.
Connect the headset to the last
used device manually — If no
other device is connected, press
and hold for 2 seconds. The
headset beeps once.
ENGLISH
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Listen to music
Play music
The headset must be paired and
connected to a mobile device that
supports the A2DP Bluetooth
profile and has a music player
feature, or to a compatible music
player that supports this profile.
Warning: Continuous
exposure to high volume may
damage your hearing. Listen to
music at a moderate level.
Play a song — Select the song in
the music player, and press .
Pause or resume playing —
Press .
If you receive or make a call while
listening to music, the music is
paused.
Play the next song — Press .
Play the previous song — Press
twice.
Start the current song from the
beginning — Press .
Scroll through the current song
quickly — Press and hold or
.
Stop playing — Press and hold
.
Adjust the bass or treble
When you are listening to music,
you can change the tone,
adjusting the treble or bass.
Emphasise the low frequency
sounds — Press the bass key.
Emphasise the high frequency
sounds — Press the treble key.
Emphasise all sounds
(loudness) — Press the bass and
treble keys
ENGLISH
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

When you are listening to music
with bass or treble active, the
indicator light of the respective
key blinks.
Settings
Switch the indicator lights
off
When the headset is connected to
a device, press and hold and
the volume down key for 5
seconds. The yellow indicator
light flashes once. Some indicator
lights may still be shown, for
example, when the battery charge
is low.
Switch the lights back on —
Press and hold and the
volume up key for 5 seconds. The
green indicator light flashes once.
Clear the pairings
Switch the headset off, and press
and hold for 9 seconds.
The headset beeps twice, and the
red and green indicator lights
alternate. After the settings are
cleared, pairing mode is activated.
Troubleshooting
Cannot connect the headset to a
compatible device? Make sure
that the headset is charged,
switched on, and paired with the
device.
Did the headset stop functioning
even though it is charged? Plug
the charger into a wall outlet, and
while you press and hold ,
connect the headset to the
charger.
ENGLISH
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Product and safety information
Battery and charger
information
This device has an internal,
nonremovable, rechargeable
battery. Do not attempt to remove
the battery from the device as you
may damage the device.
This device is intended for use when
supplied with power from the
following chargers: AC-3, AC-4, AC-5,
AC-8, AC-15, and DC-4. The exact
charger model number may vary
depending on the type of plug. The
plug variant is identified by one of
the following: E, X, AR, U, A, C, K, or B.
The battery can be charged and
discharged hundreds of times, but it
will eventually wear out.
Talk and standby times are estimates
only. Actual times are affected by,for
example, device settings, features
being used, battery condition, and
temperature.
If the battery has not been used for
a long time, to begin charging, you
may need to connect the charger,
then disconnect and reconnect it.
If the battery is completely
discharged, it may take several
minutes before the charging
indicator is displayed.
When your charger is not in use,
unplug it from the electrical plug and
the device. Do not leave a fully
charged battery connected to a
charger, as overcharging may
shorten the battery’s lifetime. If left
unused, a fully charged battery will
lose its charge over time.
Always keep the battery between
15°C and 25°C (59°F and 77°F).
Extreme temperatures reduce the
capacity and lifetime of the battery.
ENGLISH
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

A device with a hot or cold battery
may not work temporarily.
Do not dispose of batteries in a fire
as they may explode. Dispose of
batteries according to local
regulations. Recycle when possible.
Do not dispose as household waste.
Use the charger for its intended
purpose only. Improper use or use of
unapproved chargers may present a
risk of fire, explosion, or other
hazard, and may invalidate any
approval or warranty. If you believe
the charger is damaged, take it to a
service centre for inspection before
continuing to use it. Never use a
damaged charger. Only use the
charger indoors.
Take care of your device
Handle your device, battery, charger
and accessories with care. The
following suggestions help you
protect your warranty coverage.
•Keep the device dry.
Precipitation, humidity, and all
types of liquids or moisture can
contain minerals that corrode
electronic circuits.
•Do not use or store the device in
dusty or dirty areas. Moving parts
and electronic components can
be damaged.
•Do not store the device in high
temperatures. High temperatures
can shorten the life of the device,
damage the battery, and warp or
melt plastics.
•Do not store the device in cold
temperatures. When the device
warms to its normal temperature,
moisture can form inside the
device and damage electronic
circuits.
•Do not attempt to open the
device.
•Unauthorised modifications may
damage the device and violate
ENGLISH
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

regulations governing radio
devices.
•Do not drop, knock, or shake the
device. Rough handling can break
internal circuit boards and
mechanics.
•Only use a soft, clean, dry cloth to
clean the surface of the device.
•Do not paint the device. Paint can
clog the moving parts and
prevent proper operation.
Recycle
Always return your used electronic
products, batteries, and packaging
materials to dedicated collection
points. This way you help prevent
uncontrolled waste disposal and
promote the recycling of materials.
Check product environmental
information and how to recycle your
Nokia products at www.nokia.com/
werecycle, or with a mobile device,
http://nokia.mobi/werecycle.
Crossed-out wheeled-bin symbol
The crossed-out wheeled-bin
symbol on your product,
battery, literature, or
packaging reminds you that
all electrical and electronic
products, batteries, and
accumulators must be taken to
separate collection at the end of
their working life. This requirement
applies in the European Union. Do
not dispose of these products as
unsorted municipal waste. For more
information on the environmental
attributes of your device, see
www.nokia.com/ecodeclaration.
ENGLISH
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Copyright and other notices
DECLARATION OF CONFORMITY
Hereby, NOKIA CORPORATION
declares that this BH-610 product is
in compliance with the essential
requirements and other relevant
provisions of Directive 1999/5/EC. A
copy of the Declaration of Conformity
can be found at www.nokia.com/
phones/declaration_of_conformity/.
© 2011 Nokia. All rights reserved.
Nokia, Nokia Connecting People, and
the Nokia Original Accessories logo
are trademarks or registered
trademarks of Nokia Corporation.
Nokia tune is a sound mark of Nokia
Corporation. Other product and
company names mentioned herein
may be trademarks or tradenames of
their respective owners.
Reproduction, transfer, distribution,
or storage of part or all of the
contents in this document in any
form without the prior written
permission of Nokia is prohibited.
Nokia operates a policy of
continuous development. Nokia
reserves the right to make changes
and improvements to any of the
products described in this document
without prior notice.
The contents of this document are
provided "as is". Except as required
by applicable law, no warranties of
any kind, either express or implied,
including, but not limited to, the
implied warranties of
merchantability and fitness for a
particular purpose, are made in
relation to the accuracy, reliability or
contents of this document. Nokia
reserves the right to revise this
ENGLISH
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

document or withdraw it at any time
without prior notice.
To the maximum extent permitted
by applicable law, under no
circumstances shall Nokia or any of
its licensors be responsible for any
loss of data or income or any special,
incidental, consequential or indirect
damages howsoever caused.
The availability of products may vary
by region. For more information,
contact your Nokia dealer. This
device may contain commodities,
technology or software subject to
ex p ort l a ws an d r e gu l a tio n s f rom t h e
US and other countries. Diversion
contrary to law is prohibited.
FCC/INDUSTRY CANADA NOTICE
This device complies with Part 15 of
the FCC Rules and Industry Canada
licence-exempt RSS standard(s).
Operation is subject to the following
two conditions: 1. This device may
not cause harmful interference; and
2. This device must accept any
interference received, including
interference that may cause
undesired operation. This
equipment has been tested and
found to comply with the limits for a
Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits
are designed to provide reasonable
protection against harmful
interference in a residential
installation. This equipment
generates, uses and can radiate
radio frequency energy and, if not
installed and used in accordance
with the instructions, may cause
harmful interference to radio
communications. However, there is
no guarantee that interference will
not occur in a particular installation.
If this equipment does cause harmful
interference to radio or television
reception, which can be determined
by turning the equipment off and on,
the user is encouraged to try to
correct the interference by one or
more of the following measures:
ENGLISH
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Reorient or relocate the receiving
antenna. Increase the separation
between the equipment and
receiver. Connect the equipment
into an outlet on a circuit different
from that to which the receiver is
connected. Consult the dealer or an
experienced radio/TV technician for
help. NOTE: FCC Radiation Exposure
Statement: This equipment complies
with FCC radiation exposure limits
set forth for an uncontrolled
environment. This transmitter must
not be co-located or operating in
conjunction with any other antenna
or transmitter. NOTE: Changes or
modifications not expressly
approved by Nokia could void the
user's authority to operate the
equipment.
ENGLISH
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
