Nordson Pro-Meter S-Series Reference guide

Pro-MeterrS-Series Coupled
Dispensers with Integrated Drive
Customer Product Manual
Part 1606702-05
Issued 10/20
NORDSON CORPORATION •AMHERST, OHIO •USA
For parts and technical support, call the Nordson
Industrial Coating Systems Customer Support Center at
(800) 433−9319, or contact your local Nordson Representative.
This document is subject to change without notice.
Check http://emanuals.nordson.com/finishing for the latest version.

Part 1606702-05 E2020 Nordson Corporation
tents
Table of Contents
Safety 1.......................................
Qualified Personnel 1.........................
Intended Use 1..............................
Regulations and Approvals 1..................
Personal Safety 1............................
High-Pressure Fluids 1.....................
Fire Safety 2................................
Halogenated Hydrocarbon Solvent Hazards 2.
Action in the Event of a Malfunction 2...........
Disposal 2..................................
Description 3..................................
Theory of Operation 5........................
Refill Phase 5.............................
Idle Phase 5..............................
Pre-Pressure 5...........................
Dispense/Purge Phase 5...................
Specifications 6..............................
S 15 Dispenser 7.........................
S35 Dispensers 8.........................
S100 Dispensers 11........................
S165 Dispensers 14........................
S300 Dispenser 16.........................
Installation 17..................................
Install the Pro-Meter S-Series
Dispenser to a Fixture 17......................
Connect the Controller Cables 18...............
Connect the Material, Air, and Water Lines 18.....
Operation 19...................................
Startup 19...................................
Shutdown 19.................................
Maintenance 20................................
Troubleshooting 21.............................
Repair 22......................................
Consumable Items 22.........................
Linear Actuator 23............................
Remove the Linear Actuator 23...............
Install the Linear Actuator 23.................
How to Change the S15 Output 24..............
Proximity Sensors 26..........................
Adjust the Retract and Extend
Proximity Sensors 26.......................
Adjust the Refill Proximity Sensor 26..........
Repair (continued)
Hydraulic Section 28..........................
Replace the Inlet and
Outlet Valve Packing Cartridge 28............
Replace the Outlet Valve 28.................
Replace the Inlet Valve 28...................
Replace the Pressure Transducer 28..........
Remove the Gland
and Plunger Assemblies 30..................
Install the Gland
and Plunger Assemblies 30..................
Rebuild the Packing Gland 32................
Replace the Thermostat 34..................
Replace a Heater Cartridge 34...............
Replace the RTD 34........................
Parts 36.......................................
Standard Dispensers 36.......................
S15 120 Volt Heated Dispenser 36...........
S35 120 Volt Heated Dispenser 40...........
S100 120 Volt Heated Dispenser 44..........
S165 120 Volt Heated Dispenser 48..........
E-Net Dispensers 52..........................
S35 120/240 Volt Heated
E-Net Dispensers 52........................
S35 Temperature Controlled
E-Net Dispenser 56.........................
S35 ARW Temperature Conditioned
E-Net Dispenser 58.........................
S100 120/240 Volt Heated E-Net Dispensers 60
S100 Temperature Conditioned
E-Net Dispenser 64.........................
S165 120/240 Volt Heated E-Net Dispensers 66
S300 Temperature Conditioned
E-Net Dispenser 70.........................
Kits 72.......................................
Packing Glands 72.........................
Plunger Rods 72...........................
Inlet Valves 72.............................
Application-Specific Components 73.............
Dispense Gun and Packing Cartridges
for Standard Auto-Flo Type Guns 73..........
Dispense Gun and Packing Cartridges for
Zero-Cavity Auto-Flo Type Guns 73...........
Remote Gun Mounting adapter Block 73.......
Transducers 73............................
Tools 73.....................................
Contact Us
Nordson Corporation welcomes requests for information, comments, and
inquiries about its products. General information about Nordson can be
found on the Internet using the following address:
http://www.nordson.com.
Address all correspondence to:
Nordson Corporation
Attn: Customer Service
555 Jackson Street
Amherst, OH 44001
Notice
This is a Nordson Corporation publication which is protected by copyright.
Original copyright date 2015. No part of this document may be
photocopied, reproduced, or translated to another language without the
prior written consent of Nordson Corporation. The information contained
in this publication is subject to change without notice.
Trademarks
Pro-Meter, Rhino, Nordson, and the Nordson logo are registered
trademarks of Nordson Corporation.
All other trademarks are the property of their respective owners.

Change Record i
Part 1606702-05
E2020 Nordson Corporation
Change Record
Revision Date Change
01 9/15 New release
02 3/18 Removed part number 1084754, changed ft−lb spec on page 23
03 8/18 Added anti-drool dispense gun
04 10/20 Update to current product line
05 10/20 Added E-Net Dispensers

Change Record
ii
Part 1606702-05 E2020 Nordson Corporation

Pro-Meter S-Series Coupled Dispensers with Integrated Drive 1
Part 1606702-05
E2020 Nordson Corporation
Safety
Read and follow these safety instructions. Task- and
equipment-specific warnings, cautions, and instructions
are included in equipment documentation where
appropriate. Make sure all equipment documentation,
including these instructions, is accessible to persons
operating or servicing equipment.
Qualified Personnel
Equipment owners are responsible for making sure that
Nordson equipment is installed, operated, and serviced
by qualified personnel. Qualified personnel are those
employees or contractors who are trained to safely
perform their assigned tasks. They are familiar with all
relevant safety rules and regulations and are physically
capable of performing their assigned tasks.
Intended Use
Use of Nordson equipment in ways other than those
described in the documentation supplied with the
equipment may result in injury to persons or damage to
property.
Some examples of unintended use of equipment include
Susing incompatible materials
Smaking unauthorized modifications
Sremoving or bypassing safety guards or interlocks
Susing incompatible or damaged parts
Susing unapproved auxiliary equipment
Soperating equipment in excess of maximum ratings
Regulations and Approvals
Make sure all equipment is rated and approved for the
environment in which it is used. Any approvals obtained
for Nordson equipment will be voided if instructions for
installation, operation, and service are not followed.
Personal Safety
To prevent injury follow these instructions.
SDo not operate or service equipment unless you are
qualified.
SDo not operate equipment unless safety guards,
doors, or covers are intact and automatic interlocks
are operating properly. Do not bypass or disarm any
safety devices.
SKeep clear of moving equipment. Before adjusting or
servicing moving equipment, shut off the power
supply and wait until the equipment comes to a
complete stop. Lock out power and secure the
equipment to prevent unexpected movement.
SRelieve (bleed off) hydraulic and pneumatic pressure
before adjusting or servicing pressurized systems or
components. Disconnect, lock out, and tag switches
before servicing electrical equipment.
SWhile operating manual spray guns, make sure you
are grounded. Wear electrically conductive gloves or
a grounding strap connected to the gun handle or
other true earth ground. Do not wear or carry
metallic objects such as jewelry or tools.
SIf you receive even a slight electrical shock, shut
down all electrical or electrostatic equipment
immediately. Do not restart the equipment until the
problem has been identified and corrected.
SObtain and read Safety Data Sheets (SDS) for all
materials used. Follow the manufacturer’s
instructions for safe handling and use of materials,
and use recommended personal protection devices.
SMake sure the spray area is adequately ventilated.
STo prevent injury, be aware of less-obvious dangers
in the workplace that often cannot be completely
eliminated, such as hot surfaces, sharp edges,
energized electrical circuits, and moving parts that
cannot be enclosed or otherwise guarded for
practical reasons.
High-Pressure Fluids
High-pressure fluids, unless they are safely contained,
are extremely hazardous. Always relieve fluid pressure
before adjusting or servicing high pressure equipment. A
jet of high-pressure fluid can cut like a knife and cause
serious bodily injury, amputation, or death. Fluids
penetrating the skin can also cause toxic poisoning.
If you suffer a fluid injection injury, seek medical care
immediately. If possible, provide a copy of the SDS for
the injected fluid to the health care provider.
The National Spray Equipment Manufacturers
Association has created a wallet card that you should
carry when you are operating high-pressure spray
equipment. These cards are supplied with your
equipment. The following is the text of this card:

Pro-Meter S-Series Coupled Dispensers with Integrated Drive
2
Part 1606702-05 E2020 Nordson Corporation
WARNING: Any injury caused by high pressure
liquid can be serious. If you are injured or even
suspect an injury:
SGo to an emergency room immediately.
STell the doctor that you suspect an injection injury.
SShow them this card
STell them what kind of material you were spraying
MEDICAL ALERT—AIRLESS SPRAY WOUNDS: NOTE
TO PHYSICIAN
Injection in the skin is a serious traumatic injury. It is
important to treat the injury surgically as soon as
possible. Do not delay treatment to research toxicity.
Toxicity is a concern with some exotic coatings injected
directly into the bloodstream.
Consultation with a plastic surgeon or a reconstructive
hand surgeon may be advisable.
The seriousness of the wound depends on where the
injury is on the body, whether the substance hit
something on its way in and deflected causing more
damage, and many other variables including skin
microflora residing in the paint or gun which are blasted
into the wound. If the injected paint contains acrylic latex
and titanium dioxide that damage the tissue’s resistance
to infection, bacterial growth will flourish. The treatment
that doctors recommend for an injection injury to the
hand includes immediate decompression of the closed
vascular compartments of the hand to release the
underlying tissue distended by the injected paint,
judicious wound debridement, and immediate antibiotic
treatment.
Fire Safety
To avoid a fire or explosion, follow these instructions.
SGround all conductive equipment. Use only
grounded air and fluid hoses. Check equipment and
workpiece grounding devices regularly. Resistance
to ground must not exceed one megohm.
SShut down all equipment immediately if you notice
static sparking or arcing. Do not restart the
equipment until the cause has been identified and
corrected.
SDo not smoke, weld, grind, or use open flames
where flammable materials are being used or stored.
SDo not heat materials to temperatures above those
recommended by the manufacturer. Make sure heat
monitoring and limiting devices are working properly.
SProvide adequate ventilation to prevent dangerous
concentrations of volatile particles or vapors. Refer
to local codes or your material SDS for guidance.
SDo not disconnect live electrical circuits when
working with flammable materials. Shut off power at
a disconnect switch first to prevent sparking.
SKnow where emergency stop buttons, shutoff valves,
and fire extinguishers are located. If a fire starts in a
spray booth, immediately shut off the spray system
and exhaust fans.
SShut off electrostatic power and ground the charging
system before adjusting, cleaning, or repairing
electrostatic equipment.
SClean, maintain, test, and repair equipment
according to the instructions in your equipment
documentation.
SUse only replacement parts that are designed for use
with original equipment. Contact your Nordson
representative for parts information and advice.
Halogenated Hydrocarbon
Solvent Hazards
Do not use halogenated hydrocarbon solvents in a
pressurized system that contains aluminum components.
Under pressure, these solvents can react with aluminum
and explode, causing injury, death, or property damage.
Halogenated hydrocarbon solvents contain one or more
of the following elements:
Element Symbol Prefix
Fluorine F “Fluoro-”
Chlorine Cl “Chloro-”
Bromine Br “Bromo-”
Iodine I “Iodo-”
Check your material SDS or contact your material
supplier for more information. If you must use
halogenated hydrocarbon solvents, contact your Nordson
representative for information about compatible Nordson
components.
Action in the Event of a
Malfunction
If a system or any equipment in a system malfunctions,
shut off the system immediately and perform the
following steps:
SDisconnect and lock out system electrical power.
Close hydraulic and pneumatic shutoff valves and
relieve pressures.
SIdentify the reason for the malfunction and correct it
before restarting the system.
Disposal
Dispose of equipment and materials used in operation
and servicing according to local codes.

Pro-Meter S-Series Coupled Dispensers with Integrated Drive 3
Part 1606702-05
E2020 Nordson Corporation
Description
See Figure 1. The Pro-MeterrS-Series dispensing
meters are designed for high-speed application of
single-component materials. A closed-coupled dispense
valve and electric servo controlled metering allows for
accurate dispensing. Table 1 lists the major
components. See Table 2 for a list of available
dispensers.
3
4
6
5
1
7
2
E-NET S35 T/C ARW PRO-METERS35 HEATED PRO-METER S15 HEATED PRO-METER
Figure 1 Typical Pro-Meter S-Series Dispensers
Table 1 Pro-Meter S-Series Dispensers
Item Description
1Servo-controlled linear actuator—This actuator drives the plunger rod into the cylinder cavity to displace the
material.
2Connectors—Interface connections for controller cables.
3Proximity sensors—The proximity sensors feed positional information to the controller. Two proximity
sensors serve as emergency stops and are are triggered by linear actuator anti-rotation plate. One proximity
sensor indicates that the metering cylinder is full.
Note: E-Net dispensers do not use proximity sensors.
4, 5 Inlet (4) and outlet (5) valves—These high-cycle valves are mounted to the metering cylinder and control the
flow of material into and out of the metering cylinder. The valves also serve as material inlet and outlet ports.
6Metering cylinder—The metering cylinder mounts to the liner actuator through the use of four tie rods.
Positive pressure from a Rhinorbulk unloader fills the metering cylinder. A packing gland and plunger rod is
mounted to the metering cylinder. The plunger rod displaces material when the actuator extends.
7Cord set—Cable connection to system controller or J-box for electric heater functions

Pro-Meter S-Series Coupled Dispensers with Integrated Drive
4
Part 1606702-05 E2020 Nordson Corporation
Table 2 Available Pro Meter S-Series Dispensers
Dispenser Meter (CCs) Packing Gland Type
Temperature Conditioned (T/C)
E−Net Only
S35 Standard and ARW
S100 Standard
S300 Standard
120 V S15 Standard
S35 Standard
S100 Standard
S165 Standard
S300 Standard
240 V S15 Standard
S35 Standard
S100 Standard
S165 Standard
S300 Standard

Pro-Meter S-Series Coupled Dispensers with Integrated Drive 5
Part 1606702-05
E2020 Nordson Corporation
Theory of Operation
Positive pressure from the Rhino bulk unloader fills the
metering cylinder. As the linear actuator retracts,
hydraulic pressure extends the metering cylinder piston
to its starting position. The proximity switches provide
positioning information to the linear actuator and the
system controller.
NOTE: The theory of operation for heated versions is
identical with the exception that the system controller
enables and disables the heater circuit to maintain the
material setpoint temperature.
Operation consists of the 4 phases listed in Table 3.
Table 3 Inlet/Outlet Valve Positions
Operation
Valve Positions
During Operation
Inlet Valve Outlet Valve
Refill Open Closed
Idle Closed Closed
Pre-Pressure Closed Closed
Dispense/Purge Closed Open
Refill Phase
See Figure 2. During the refill phase, the actuator
retracts. The material inlet valve opens. Material flows
from the unloader and fills the metering cylinder.
When the cylinder is full, the plunger is fully retracted and
is registered by the proximity switch. The inlet valve
closes. The metering cylinder is full of material and the
unit is ready to dispense.
Idle Phase
See Figure 2. During the idle phase, the material inlet
and outlet valves remain closed until the dispense
sequence begins.
Pre-Pressure
During the pre-pressure phase, the actuator drives the
plunger into the metering cylinder and pressurizes the
material to a set value. The actuator holds this position.
The controller sends a Ready signal to indicate that the
system is ready for the dispense phase.
Dispense/Purge Phase
See Figure 2. During the dispense phase, the drive
assembly forces the metering cylinder piston into the
metering cylinder. The material outlet valve opens at the
same time and material extrudes proportionally to the
given input signal.
DISPENSE/PURGEPRE-PRESSURE/IDLE
TO OUTLET VALVE
REFILL
FROM INLET VALVE
Figure 2 Metering Cylinder

Pro-Meter S-Series Coupled Dispensers with Integrated Drive
6
Part 1606702-05 E2020 Nordson Corporation
Specifications
Refer to Table 4 for specifications.
Table 4 Specifications
Item Specification
S15 S35 S100 S165 S300
Inlet Port
Outlet Port for
Remote Material
Outlet Valve
3/8 SAE, Size −06 O-ring boss, 9/16-18 UNF 2B thread
Operating Air
Pressure 4.1−7 bar (60−100 psi)
Maximum Fluid
Working Pressure 206 bar (3000 psi)
Maximum Continuous
Fluid Output
Pressure
110 bar (1600 psi)
Note: Contact the Nordson Automotive Systems Group Engineering department if higher fluid
output pressures are required.
Maximum Flow Rate 5 cc/sec
(0.31 in.3/sec)
10 cc/sec
(0.61 in.3/sec)
20 cc/sec
(1.22 in.3/sec)
40 cc/sec
(2.44 in.3/sec)
50 cc/sec
(3.05 in.3/sec)
Maximum Water
Operating Pressure 7 bar (100 psi) 7 bar (100 psi) 7 bar (100 psi) 7 bar (100 psi) 7 bar (100 psi)
Maximum Operating
Temperature
Water Conditioned
and Electric Heat
Versions
82 _C (180 _F) 82 _C (180 _F) 82 _C (180 _F) 82 _C (180 _F) 82 _C (180 _F)
Metering Cylinder 15 cc
(0.91 cu in.)
35 cc
(2.1 cu in.)
100 cc
(6.1 cu in.)
165 cc
(10 cu in.)
300 cc
(18.3 cu in.)
Maximum Motor RPM 207 rpm 415 rpm 300 rpm 708 rpm 884 rpm
Maximum Continuous
Motor Current RMS: 3.4 amps RMS: 10 amps RMS: 10.2 amps RMS: 10.2 amps
Operating Voltages
and Power
Consumption for
Heated Versions
(Heater Circuit Only)
120V/240V
400W
120V/240V
500W
120V/240V
600W
240V
1040W
240V
1200W
Weight (Approximate) 24 lb (11 kg)
Standard
30 lb (14 kg)
E-Net:
38.5 lb (18 kg)
Standard:
49 lb (22 kg)
Stainless Steel:
63 lb (29 kg)
E-Net:
71 lb (32 kg)
Standard:
112 (51 kg)
E-Net:
132 (60 kg)
E-Net:
136 (62 kg)
Dimensions
(Approximate) See Figures 3 through 12.
Wetted Component
Materials
Aluminum, brass, carbon steel, chrome plated carbon steel, stainless steel, tungsten carbide,
Viton, UHMWPE
Air Consumption 0.25 scf/cycle
Instantaneous
Air Flow Rate 15 scfm for quick valve response

Pro-Meter S-Series Coupled Dispensers with Integrated Drive 7
Part 1606702-05
E2020 Nordson Corporation
S 15 Dispenser
GUN OPEN
AIR 1/4 TUBE
GUN CLOSE
AIR 1/4 TUBE
GUN CLOSE
AIR 1/4 TUBE
GUN OPEN
AIR 1/4 TUBE
NOZZLE NUT
3/8 NPS THD
MATERIAL INLET
PORTS 9/16-18 SA
E
INLET VALVE
AUTO-FLO GUN
PRESSURE
TRANSDUCER
PRO-METER S15
HEATED DISPENSER
2X .250
DOWEL
PIN HT
6.446
16.37
Ø
4X M8X1.25 THD THRU
B
A
3.250 in.
8.26 cm.
5.485 in.
13.93 cm.
7.450 in.
18.92 cm.
C
26.34 in.
66.90 cm.
6.446 in.
16.37 cm.
6.941 in.
17.63 cm.
1.300 in.
3.30 cm.
3.250 in.
8.26 cm.
7.069 in.
17.96 cm.
1.300 in.
3.30 cm.
2x .2503
.2501 DOWEL PIN
A
0.001
ABC0.015
Figure 3 S15 Heated Dispenser

Pro-Meter S-Series Coupled Dispensers with Integrated Drive
8
Part 1606702-05 E2020 Nordson Corporation
S35 Dispensers
GUN OPEN
AIR 1/4 TUBE
GUN CLOSE
AIR 1/4 TUBE
GUN CLOSE
AIR 1/4 TUBE
GUN OPEN
AIR 1/4 TUBE
NOZZLE NUT
3/8 NPS THD
MATERIAL INLET
PORTS 9/16-18 SAE
INLET VALVE
AUTO-FLO GUN
PRESSURE
TRANSDUCER
PRO-METER S 35
HEATED DISPENSER
6.446 in.
16.37 cm.
34.64 in.
87.99 cm.
6.941 in.
17.63 cm.
9.981 in.
[ 25.35 cm.]
1.300 in.
[ 3.30 cm.]
4X M8X1.25 THD THRU
2X .250
DOWEL PIN HT
A
3.250 in.
8.26 cm.
5.485 in.
13.93 cm.
7.450 in.
18.92 cm.
Ø2x .2503
.2501 DOWEL PIN
B
C
1.300 in.
[ 3.30 cm.]
3.250 in.
[8.26 cm.]
ABC0.015
A
0.001
Figure 4 S35 Heated Dispenser

Pro-Meter S-Series Coupled Dispensers with Integrated Drive 9
Part 1606702-05
E2020 Nordson Corporation
6.477 in.
8.039 in.
A
2X ø .2503
.2501 DOWEL PIN
4X M8X1.25 THD THRU
4.50 in.
B
C
VALVE OPEN
AIR 1/4 TUBE
VALVE CLOSE
AIR 1/4 TUBE
GUN CLOSE
AIR 1/4 TUBE
GUN OPEN
AIR 1/4 TUBE
NOZZLE NUT
3/8 NPS THD
MATERIAL INLET
PORTS 9/16-18 SAE
INLET VALVE
AUTO-FLO GUN
PRESSURE
TRANSDUCER
0.15 A B C
0.001 A
[20.42 cm]
[16.45 cm]
3.250 in.
[8.255 cm]
1.300 in.
[3.302 cm]
9.982 in.
[25.354 cm]
[11.43 cm]
PRO-METER S 35 HEATED
E-NET DISPENSERS
34.641 in. [87.99 cm]
120V HEATED:
34.83 in. [88.46 cm]
240V HEATED:
7.57 in. [19.22 cm]
240V HEATED:
5.60 in. [14.22 cm]
240V HEATED:
3.37 in. [8.55 cm]
240V HEATED:
1.300 in.
[3.302 cm]
120V HEATED:
3.25 in. [8.26 cm]
120V HEATED:
5.49 in. [13.95 cm]
120V HEATED:
7.45 in. [18.92 cm]
Figure 5 S35 Heated E-Net Dispenser (240V heated dispenser shown)

Pro-Meter S-Series Coupled Dispensers with Integrated Drive
10
Part 1606702-05 E2020 Nordson Corporation
8.039 in.
A
VALVE OPEN
AIR 1/4 TUBE
VALVE CLOSE
AIR 1/4 TUBE
GUN CLOSE
AIR 1/4 TUBE
GUN OPEN
AIR 1/4 TUBE
NOZZLE NUT
3/8 NPS THD
MATERIAL INLET
PORTS 9/16-18 SAE
INLET VALVE
AUTO-FLO GUN
PRESSURE
TRANSDUCER
[20.42 cm]
3.25 in.
[8.26 cm]
5.49 in.
[13.95 cm]
7.45 in.
[18.92 cm]
PRO-METER S 35 T/C AND T/C ARW
E-NET DISPENSERS
34.41 in.
2X ø .2503
.2501 DOWEL PIN
4X M8X1.25 THD THRU
4.50 in.
0.15 A B C
0.001 A
3.250 in.
[8.255 cm]
1.300 in.
[3.302 cm]
9.982 in.
[25.354 cm]
[11.43 cm]
B
C
2x 0.250
DOWEL
PIN HT.
[87.40 cm]
TEMPERATURE
CONDITIONING
PORTS 1/4 TUBE
1.300 in.
[3.302 cm]
Figure 6 S35 T/C and T/C ARW E-Net Dispensers (T/C dispenser shown)

Pro-Meter S-Series Coupled Dispensers with Integrated Drive 11
Part 1606702-05
E2020 Nordson Corporation
S100 Dispensers
GUN OPEN
AIR 1/4 TUBE
GUN CLOSE
AIR 1/4 TUBE
GUN CLOSE
AIR 1/4 TUBE
GUN OPEN
AIR 1/4 TUBE
NOZZLE NUT
3/8 NPS THD
MATERIAL INLET
PORTS 9/16-18 SAE
INLET VALVE
AUTO-FLO GUN
PRESSURE
TRANSDUCER
PRO-METER S 100
HEATED DISPENSER
7.446 in.
18.91 cm.
A
7.547 in.
19.17 cm.
4X M8X1.25 THD THRU
C
B
36.70 in.
93.22 cm.
1.300 in.
3.30 cm.
3.250 in.
8.26 cm.
9.982 in.
25.35 cm.
3.750 in.
9.53 cm.
6.235 in.
15.84 cm.
8.200 in.
20.83 cm.
1.300 in.
3.30 cm.
Ø2x .2503
.2501 DOWEL PIN
2X .250
DOWEL PIN HT
A
0.001
ABC0.015
Figure 7 S100 Heated Dispenser

Pro-Meter S-Series Coupled Dispensers with Integrated Drive
12
Part 1606702-05 E2020 Nordson Corporation
PRO-METER S 100 HEATED
E-NET DISPENSERS
36.70 in.
9.05 in.
A
VALVE OPEN
AIR 1/4 TUBE
VALVE CLOSE
AIR 1/4 TUBE
GUN CLOSE
AIR 1/4 TUBE
GUN OPEN
AIR 1/4 TUBE
NOZZLE NUT
3/8 NPS THD
MATERIAL INLET
PORTS 9/16-18 SAE
INLET VALVE
AUTO-FLO GUN
PRESSURE
TRANSDUCER
[23.00 cm]
[93.22 cm]
1.300 in.
[3.302 cm]
3.250 in.
[8.255 cm]
C
2X ø .2503
.2501 DOWEL PIN
4X M8X1.25 THD THRU
0.15 A B C
0.001 A
B
9.98 in.
[25.35 cm]
3.75 in.
[9.53 cm]
6.24 in.
[15.85 cm]
8.20 in.
[20.83 cm]
1.300 in.
[3.302 cm]
Figure 8 S100 Heated E-Net Dispenser

Pro-Meter S-Series Coupled Dispensers with Integrated Drive 13
Part 1606702-05
E2020 Nordson Corporation
5.06 in.
2 X 0.250
DOWEL
PIN HT.
35.95 in.
7.51 in.
PRO-METER S 100 T/C
E-NET DISPENSER
4X M8X1.25 THD
0.15 A B C
2X ø .2503
.2501 DOWEL PIN
0.001 A
HELICOIL INSERT THRU
C
B
[91.34 cm]
1.300 in.
[3.302 cm]
3.250 in.
[8.255 cm]
9.98 in.
[25.35 cm]
6.24 in.
[15.85 cm]
[19.08 cm] [12.85 cm]
A
VALVE OPEN
AIR 1/4 TUBE
VALVE CLOSE
AIR 1/4 TUBE
GUN CLOSE
AIR 1/4 TUBE
GUN OPEN
AIR 1/4 TUBE
NOZZLE NUT
3/8 NPS THD
MATERIAL INLET
PORTS 9/16-18 SAE
INLET VALVE
AUTO-FLO GUN
PRESSURE
TRANSDUCER
TEMPERATURE
CONDITIONING
PORTS 1/4 TUBE
1.300 in.
[3.302 cm]
Figure 9 S100 T/C E-Net Dispenser

Pro-Meter S-Series Coupled Dispensers with Integrated Drive
14
Part 1606702-05 E2020 Nordson Corporation
S165 Dispensers
GUN OPEN
AIR 1/4 TUBE
GUN CLOSE
AIR 1/4 TUBE
GUN CLOSE
AIR 1/4 TUBE
GUN OPEN
AIR 1/4 TUBE
NOZZLE NUT
3/8 NPS THD
MATERIAL INLET
PORTS 9/16-18 SAE
INLET VALVE
AUTO-FLO GUN
PRESSURE
TRANSDUCER
PRO-METER S 165
HEATED DISPENSER
4X M12X1.75 THD THRU
B
C
8.780 in.
22.30 cm.
1.375 in.
3.49 cm.
7.500 in.
19.05 cm.
11.644 in.
29.57 cm.
Ø
2x .3943
.3939 DOWEL PIN
1.375 in.
3.49 cm.
A
0.001
ABC0.015
2X .431
DOWEL PIN HT
A
9.196 in.
23.36 cm.
45.10 in.
114.55 cm.
4.750 in.
12.07 cm.
7.855 in.
19.95 cm.
9.820 in.
24.94 cm.
Figure 10 S165 Heated Dispenser

Pro-Meter S-Series Coupled Dispensers with Integrated Drive 15
Part 1606702-05
E2020 Nordson Corporation
45.10 in.
11.64 in.
VALVE OPEN
VALVE CLOSE
GUN CLOSE
GUN OPEN
NOZZLE NUT
MATERIAL INLET
INLET VALVE
AUTO-FLO GUN
PRESSURE
TRANSDUCER
AIR 1/4 TUBE
AIR 1/4 TUBE
AIR 1/4 TUBE
AIR 1/4 TUBE
3/8 NPS THD
PORTS 9/16-18 SAE
[114.55 cm]
6.16 in.
[15.65 cm]
4X M12 X 1.75 THD
0.15 A B C
2X M10 DOWEL PINS
0.001 A
C
1.375 in.
[3.50 cm]
B
A
1.375 in.
[3.50 cm]
10.81 in.
[27.46 cm]
7.50 in.
[19.05 cm]
[29.57 cm]
PRO-METER S165
E-NET DISPENSERS
Figure 11 S165 Heated E-Net Dispensers

Pro-Meter S-Series Coupled Dispensers with Integrated Drive
16
Part 1606702-05 E2020 Nordson Corporation
S300 Dispenser
PRO-METER S300 T/C
E-NET DISPENSER
MATERIAL
51.90 in.
2X 0.431
15.479 in.
4X M12 X 1.75 THD
ø.015 A B C
2X M10
ø.001 A
6.63 in.
OUTLET PORT
1-1/16-12 SAE
MATERIAL
INLET PORT
1-1/16−12 SAE
PRESSURE TRANSDUCER
PORTS 7/16−20 SAE
BOTH SIDES
BOTH SIDES
TEMPERATURE
CONDITIONING
PORTS 1/4 TUBE
DOWEL
PIN HT.
[131.83 cm]
[16.84 cm]
10.42 in.
[26.47 cm]
DOWEL PINS
A
C
B
1.250 in
[39.316 cm]
11 in.
[27.94 cm]
[3.180 cm] 1.250 in
[3.180 cm]
Figure 12 S300 T/C E-Net Dispenser
