Nordson Rhino SD3 Reference guide

RhinorSD3/XD3 Hydraulic Section
Customer Product Manual
Part 1611632-05
Issued 04/19
NORDSON CORPORATION •AMHERST, OHIO •USA
For parts and technical support, call the Industrial Coating
Systems Customer Support Center at [phone] or
contact your local Nordson representative.
This document is subject to change without notice.
Check http://emanuals.nordson.com for the latest version.

Part 1611632−05 E2019 Nordson Corporation
tents
Table of Contents
Safety 1.......................................
Qualified Personnel 1.........................
Intended Use 1..............................
Regulations and Approvals 1..................
Personal Safety 2............................
High-Pressure Fluids 2.....................
Fire Safety 3................................
Halogenated Hydrocarbon Solvent Hazards 4.
Action in the Event of a Malfunction 4...........
Disposal 4..................................
Water Requirements for Temperature Conditioning 5
Water Types 5.............................
Corrosion Levels 5...........................
Biocide Water Treatment 5..................
Safety Labels 7..............................
Description 8..................................
Hydraulic Section Versions 8...................
Specifications 9..............................
Theory of Operation 10.........................
Standard Hydraulic Section 10................
Low-Drag Hydraulic Section 10...............
AC Hydraulic Section 12.....................
Repair 14.......................................
Disassemble the Hydraulic Section 14............
Assemble the Hydraulic Section 15..............
Rebuild the Packing Gland 18...................
Replace the Heater Cartridge
(Electrically Heated Hydraulic Sections Only) 20..
Replace the Resistance Temperature Detector (RTD)
(Electrically Heated Hydraulic Sections Only) 20..
Preventative Maintenance 22....................
Troubleshooting 23.............................
Parts 24.......................................
Using the Illustrated Parts List 24...............
Hydraulic Section Packaged Kits 25..............
190cc, Ambient Packaged Kits 25.............
190cc, Temperature-Conditioned Packaged Kits 26
190cc, 240 V, Standard-Wattage
Electrically Heated
Packaged Kits 26...........................
190cc, 240 V, High-Wattage
Electrically Heated
Packaged Kits 27...........................
Drive Train Kits 28.............................
Standard Drive Train Service Kits 28..........
Low-Drag Drive Train Service Kits 28..........
Packing Gland Kits 28..........................
Internal Packing Gland Service Kits 28.........
190 cc Packing Gland Service Kits 28.........
190 cc Ambient Hydraulic Section 30.............
190 cc Ambient Carbon Steel
Hydraulic Sections 31.......................
190 cc Ambient Carbon Steel
Hydraulic Sections, Low-Drag 32.............
190 cc Ambient Stainless Steel
Hydraulic Sections 33.......................
190 cc Ambient Stainless Steel
Hydraulic Sections, Low-Drag 34.............
190 cc Temperature-Conditioned
Hydraulic Sections 36..........................
190 cc Temperature-Conditioned
Carbon Steel Hydraulic Sections 37...........
190 cc Temperature-Conditioned
Carbon Steel Hydraulic Sections, Low-Drag 38.
190 cc Temperature-Conditioned
Stainless Steel Hydraulic Sections 39..........
190 cc Temperature-Conditioned
Stainless Steel Hydraulic Sections, Low-Drag 40
190 cc Electrically Heated Hydraulic Section,
240 V 42.....................................
190 cc Electrically Heated Carbon Steel
Hydraulic Sections, 240 V, Standard-Wattage 43
190 cc Electrically Heated Carbon Steel
Hydraulic Sections, Low-Drag,
240 V, Standard-Wattage 44..................
190 cc Electrically Heated Stainless Steel
Hydraulic Sections, 240 V, Standard-Wattage 45
190 cc Electrically Heated Stainless Steel
Hydraulic Sections, Low-Drag,
240 V, Standard-Wattage 46..................
190 cc Electrically Heated ARW Stainless Steel
Hydraulic Sections, 240 V, Standard-Wattage 47
190 cc Electrically Heated ARW Stainless Steel
Hydraulic Sections, Low-Drag,
240 V, Standard-Wattage 48..................
190 cc Electrically Heated Carbon Steel
Hydraulic Sections, 240 V, High-Wattage 49....
190 cc Electrically Heated Carbon Steel
Hydraulic Sections, Low-Drag,
240 V, High-Wattage 50......................
190 cc Electrically Heated Stainless Steel
Hydraulic Sections, 240 V, High-Wattage 51....
190 cc Electrically Heated Stainless Steel
Hydraulic Sections, Low-Drag, 240 V,
High-Wattage 52............................
190 cc Electrically Heated ARW Stainless Steel
Hydraulic Sections, 240 V, High-Wattage 53....
190 cc Electrically Heated, ARW, Stainless Steel
Hydraulic Sections, Low-Drag, 240 V,
High-Wattage 54............................
190 cc AC Hydraulic Section 56.................
190 cc AC Hydraulic Section 57...............
Consumables 57..............................
Tools 57......................................
Wiring Diagram 58.............................
Contact Us
Nordson Corporation welcomes requests for information, comments, and
inquiries about its products. General information about Nordson can be
found on the Internet using the following address:
http://www.nordson.com.
Address all correspondence to:
Nordson Corporation
Attn: Customer Service
555 Jackson Street
Amherst, OH 44001
Notice
This is a Nordson Corporation publication which is protected by copyright.
Original copyright date 2019. No part of this document may be
photocopied, reproduced, or translated to another language without the
prior written consent of Nordson Corporation. The information contained
in this publication is subject to change without notice.
Trademarks
Rhino, Scoreguard, Nordson, and the Nordson logo are registered
trademarks of Nordson Corporation.
All other trademarks are the property of their respective owners.

Change Record i
Part 1611632−05
E2019 Nordson Corporation
Change Record
Revision Date Change
01 7/17 Released.
02 6/18 Updated shovel and solvent chamber and added 190 cc AC hydraulic
section.
03 6/18 Added temperature-conditioned hydraulic sections.
04 6/18 Added ARW ambient and temperature-conditioned hydraulic sections.
05 04/19 Adding SD3/XD3 heated follower hydraulic section information

Change Record
ii
Part 1611632−05 E2019 Nordson Corporation
This page intentionally left blank.

RhinorSD3/XD3 Hydraulic Section 1
Part 1611632−05
E2019 Nordson Corporation
RhinorSD3/XD3 Hydraulic Section
Safety
Read and follow these safety instructions. Task- and equipment-specific
warnings, cautions, and instructions are included in equipment
documentation where appropriate.
Make sure all equipment documentation, including these instructions, is
accessible to persons operating or servicing equipment.
Qualified Personnel
Equipment owners are responsible for making sure that Nordson equipment
is installed, operated, and serviced by qualified personnel. Qualified
personnel are those employees or contractors who are trained to safely
perform their assigned tasks. They are familiar with all relevant safety rules
and regulations and are physically capable of performing their assigned
tasks.
Intended Use
Use of Nordson equipment in ways other than those described in the
documentation supplied with the equipment may result in injury to persons
or damage to property.
Some examples of unintended use of equipment include
Susing incompatible materials
Smaking unauthorized modifications
Sremoving or bypassing safety guards or interlocks
Susing incompatible or damaged parts
Susing unapproved auxiliary equipment
Soperating equipment in excess of maximum ratings
Regulations and Approvals
Make sure all equipment is rated and approved for the environment in which
it is used. Any approvals obtained for Nordson equipment will be voided if
instructions for installation, operation, and service are not followed.

RhinorSD3/XD3 Hydraulic Section
2
Part 1611632−05 E2019 Nordson Corporation
Personal Safety
To prevent injury follow, these instructions.
SDo not operate or service equipment unless you are qualified.
SDo not operate equipment unless safety guards, doors, or covers are
intact and automatic interlocks are operating properly. Do not bypass or
disarm any safety devices.
SKeep clear of moving equipment. Before adjusting or servicing moving
equipment, shut off the power supply and wait until the equipment
comes to a complete stop. Lock out power and secure the equipment to
prevent unexpected movement.
SRelieve (bleed off) hydraulic and pneumatic pressure before adjusting or
servicing pressurized systems or components. Disconnect, lock out,
and tag switches before servicing electrical equipment.
SWhile operating manual spray guns, make sure you are grounded.
Wear electrically conductive gloves or a grounding strap connected to
the gun handle or other true earth ground. Do not wear or carry metallic
objects such as jewelry or tools.
SIf you receive even a slight electrical shock, shut down all electrical or
electrostatic equipment immediately. Do not restart the equipment until
the problem has been identified and corrected.
SObtain and read Safety Data Sheets (SDS) for all materials used.
Follow the manufacturer’s instructions for safe handling and use of
materials, and use recommended personal protection devices.
SMake sure the spray area is adequately ventilated.
STo prevent injury, be aware of less-obvious dangers in the workplace
that often cannot be completely eliminated, such as hot surfaces, sharp
edges, energized electrical circuits, and moving parts that cannot be
enclosed or otherwise guarded for practical reasons.
High-Pressure Fluids
High-pressure fluids, unless they are safely contained, are extremely
hazardous. Always relieve fluid pressure before adjusting or servicing high
pressure equipment. A jet of high-pressure fluid can cut like a knife and
cause serious bodily injury, amputation, or death. Fluids penetrating the
skin can also cause toxic poisoning.
If you suffer a fluid injection injury, seek medical care immediately. If
possible, provide a copy of the SDS for the injected fluid to the health care
provider.

RhinorSD3/XD3 Hydraulic Section 3
Part 1611632−05
E2019 Nordson Corporation
The National Spray Equipment Manufacturers Association has created a
wallet card that you should carry when you are operating high-pressure
spray equipment. These cards are supplied with your equipment. The
following is the text of this card:
WARNING: Any injury caused by high pressure liquid can be serious. If
you are injured or even suspect an injury:
SGo to an emergency room immediately.
STell the doctor that you suspect an injection injury.
SShow them this card
STell them what kind of material you were spraying
MEDICAL ALERT—AIRLESS SPRAY WOUNDS: NOTE TO PHYSICIAN
Injection in the skin is a serious traumatic injury. It is important to treat the
injury surgically as soon as possible. Do not delay treatment to research
toxicity. Toxicity is a concern with some exotic coatings injected directly into
the bloodstream.
Consultation with a plastic surgeon or a reconstructive hand surgeon may
be advisable.
The seriousness of the wound depends on where the injury is on the body,
whether the substance hit something on its way in and deflected causing
more damage, and many other variables including skin microflora residing
in the paint or gun which are blasted into the wound. If the injected paint
contains acrylic latex and titanium dioxide that damage the tissue’s
resistance to infection, bacterial growth will flourish. The treatment that
doctors recommend for an injection injury to the hand includes immediate
decompression of the closed vascular compartments of the hand to release
the underlying tissue distended by the injected paint, judicious wound
debridement, and immediate antibiotic treatment.
Fire Safety
To avoid a fire or explosion, follow these instructions.
SGround all conductive equipment. Use only grounded air and fluid
hoses. Check equipment and workpiece grounding devices regularly.
Resistance to ground must not exceed one megohm.
SShut down all equipment immediately if you notice static sparking or
arcing. Do not restart the equipment until the cause has been identified
and corrected.
SDo not smoke, weld, grind, or use open flames where flammable
materials are being used or stored.
SDo not heat materials to temperatures above those recommended by
the manufacturer. Make sure heat monitoring and limiting devices are
working properly.

RhinorSD3/XD3 Hydraulic Section
4
Part 1611632−05 E2019 Nordson Corporation
Fire Safety (contd)
SProvide adequate ventilation to prevent dangerous concentrations of
volatile particles or vapors. Refer to local codes or your material SDS
for guidance.
SDo not disconnect live electrical circuits when working with flammable
materials. Shut off power at a disconnect switch first to prevent
sparking.
SKnow where emergency stop buttons, shutoff valves, and fire
extinguishers are located. If a fire starts in a spray booth, immediately
shut off the spray system and exhaust fans.
SShut off electrostatic power and ground the charging system before
adjusting, cleaning, or repairing electrostatic equipment.
SClean, maintain, test, and repair equipment according to the instructions
in your equipment documentation.
SUse only replacement parts that are designed for use with original
equipment. Contact your Nordson representative for parts information
and advice.
Halogenated Hydrocarbon Solvent Hazards
Do not use halogenated hydrocarbon solvents in a pressurized system that
contains aluminum components. Under pressure, these solvents can react
with aluminum and explode, causing injury, death, or property damage.
Halogenated hydrocarbon solvents contain one or more of the following
elements:
Element Symbol Prefix
Fluorine F “Fluoro-”
Chlorine Cl “Chloro-”
Bromine Br “Bromo-”
Iodine I “Iodo-”
Check your material SDS or contact your material supplier for more
information. If you must use halogenated hydrocarbon solvents, contact
your Nordson representative for information about compatible Nordson
components.
Action in the Event of a Malfunction
If a system or any equipment in a system malfunctions, shut off the system
immediately and perform the following steps:
SDisconnect and lock out system electrical power. Close hydraulic and
pneumatic shutoff valves and relieve pressures.
SIdentify the reason for the malfunction and correct it before restarting the
system.
Disposal
Dispose of equipment and materials used in operation and servicing
according to local codes.

RhinorSD3/XD3 Hydraulic Section 5
Part 1611632−05
E2019 Nordson Corporation
Water Requirements for Temperature Conditioning
The temperature conditioning section is constructed of the following
materials. Always refer to this list if different water, corrosion inhibitors or
biocides other than those listed in the following sections are used.
Black Iron Pipe Stainless Steel Nylon
Brass PVC Plastic Copper
Buna Rubber Aluminum Polyurethane
Steel VitonrPTFE
Water Types
Refer to Table 1. To minimize the introduction of contaminants that may
degrade system components, review these guidelines before selecting the
type of water to use.
NOTE: Water types are listed in order of preference.
Corrosion Levels
To maintain proper performance, minimum levels of corrosion to aluminum
and copper must be maintained. To maintain safe operation keep the
corrosion levels of
Saluminum at or below 3 mil/year (0.003 in./yr).
Scopper at or below 1 mil/year (0.001 in./yr).
When adding water to the system, corrosion inhibitor must be added.
CorrShield MD405 corrosion inhibitor is shipped with
temperature-conditioned systems. This is a Molybdate-based corrosion
inhibitor that contains an Azole additive to protect copper and is used in the
concentration of 1.5 ounces per gallon of water to maintain a concentration
of 250−350 ppm.
The Ford Tox number for CorrShield MD 405 is 149163.
The GM FID number for CorrShield MD 405 is 225484.
Refer to the Parts section to order CorrShield MD 405.
Biocide Water Treatment
Do not use the following Biocides:
Soxidizers, such as chlorine, bromine, hydrogen peroxide, iodine, ozone,
etc.
Scationic, or positively charged biocides.
Biocides for use with CorrShield MD405 are BetzDearborn Spectrus NX114.
The recommended concentration of Spectrus NX114 is 150−PPM which is
0.017 oz./gal (0.5 ml/gal).
The Ford Tox Number for Spectrus NX114 is 148270.

RhinorSD3/XD3 Hydraulic Section
6
Part 1611632−05 E2019 Nordson Corporation
Table 1 Water Types
Water Description
1. Distilled No minerals and chemicals
Lacks the nutrients necessary to support biological growth and the minerals that wear
away at system components
Neutral nature reduces interaction with additives used to protect the system
NOTE
Distilled water is the best choice for use in the
temperature conditioning section.
2. Well Contains an abundance of minerals that can support plant and animal life
Contains minerals like calcium and iron that are abrasive; accelerates wear and tear on
components
NOTE
If well water is the only option available, it
must be softened to reduce the mineral
content.
3. City Contains chlorine that can degrade all metals including stainless steel
Hard on most non−metals
Usually contains an abundance of minerals that are capable of supporting plant and
animal life; accelerates wear on components
4. Weld
(Tower)
Often heavily treated both for bacterial suppression and to make it more compatible with
the welding and cooling tower processes
Treatment process usually involves some aggressive chemicals that can degrade
metals, plastics and other materials
Usually contains an abundance of metals and other contaminants picked up from the
welding and cooling tower processes that can interfere with the components of the
temperature control system
5. DI ! CAUTION !
Do not use DI water in this system. DI water
draws free electrons from metal to normalize ion
levels. This process causes degradation of
metals.

RhinorSD3/XD3 Hydraulic Section 7
Part 1611632−05
E2019 Nordson Corporation
Safety Labels
NOTE: Applicable to electrically heated hydraulic sections only.
Table 2 lists the safety labels on this equipment. The safety labels are
provided to help you operate and maintain this equipment safely. See
Figure 1 for the location of the safety labels.
Table 2 Safety Labels
Item Label Description
1WARNING: Electrical hazard
2WARNING: Hot surface hazard
1
2
Figure 1 Safety Labels

RhinorSD3/XD3 Hydraulic Section
8
Part 1611632−05 E2019 Nordson Corporation
Description
The RhinorSD3/XD3 190 cc hydraulic section pressurizes material and
forces it out of the pump. See Figure 2 and refer to Table 3 for a description
of the hydraulic section assembly components.
NOTE: Installation and operation are dependent upon the unloader and
application. Refer to the system documentation for detailed information.
Shovel
Hydraulic Section
Solvent Chamber
Figure 2 Hydraulic Section
Table 3 Hydraulic Section Assembly Components
Item Description
Solvent Chamber
Contains fluid to lubricate the plunger and packing gland
seals; prevents material from hardening on the plunger
rod.
Hydraulic Section The 190 cc hydraulic section pressurizes the material and
forces it out of the pump.
Shovel Forces material into the hydraulic section.
Hydraulic Section Versions
Refer to Table 4 for descriptions of the hydraulic section versions.
Table 4 Hydraulic Section Versions
Version Description
SD3, CS Standard Duty −Carbon Steel
XD3, CS Extreme Duty −Carbon Steel
XD3, SS Extreme Duty −Stainless Steel
ARW Extreme Duty −Stainless Steel
(includes ARW packing gland)
LD Low-Drag
CE CE-Compliant
LW Standard-Wattage
HW High-Wattage

RhinorSD3/XD3 Hydraulic Section 9
Part 1611632−05
E2019 Nordson Corporation
Specifications
Refer to Table 5 for the hydraulic section specifications.
Table 5 Specifications
Item Description
Maximum
Output
174 cu-in./min
2.85 l/min
Maximum
Stroke Rate
Intermittent: 1 stroke per 2 sec (30 strokes/min)
Continuous: 1 stroke per 4 sec (15 strokes/min)
Dynamic
Viscosity
Range
30,000-3 million cps
Wetted
Component
Materials
SD3 Standard Hydraulic Section:
Carbon Steel, Stainless Steel, Brass, Aluminum,
Proprietary Ceramic Coating, Chrome-Plated Carbon
Steel, Vitont, UHMWPE
XD3 Standard Hydraulic Section:
Carbon Steel, Stainless Steel, Brass, Aluminum,
Proprietary Ceramic Coating, Viton, UHMWPE
XD3 Stainless Steel Hydraulic Section:
Stainless Steel 400- and 300-Series, Proprietary
Ceramic Coating, Viton, UHMWPE
ARW Stainless Steel Hydraulic Section:
Stainless Steel 400- and 300-Series, Proprietary
Ceramic Coating, Viton, UHMWPE, Polyester
Voltage/
Wattage
Standard-Wattage Hydraulic Section 240 V, 500 W
High-Wattage Hydraulic Section 240 V, 1000 W

RhinorSD3/XD3 Hydraulic Section
10
Part 1611632−05 E2019 Nordson Corporation
Theory of Operation
Standard Hydraulic Section
See Figure 3.
The standard hydraulic section has a shovel attached to the end of the
hydraulic plunger that projects into the center of the follower plate. The
shovel moves up and down with the plunger, helping to force material into
the hydraulic section. The hydraulic section pressurizes the material and
forces it out of the pump.
When the plunger strokes downward, the piston/upper check opens and the
lower check closes. Material between the upper and lower checks is forced
upward through the piston. The material above the upper check
pressurizes and flows out of the material output port.
During the upward pump stroke, the plunger and shovel are pulled upward
and the piston/upper check closes. The lower check opens and allows
material to pass into the lower pump chamber below the upper check. As
the plunger and piston move upward, material from the upper pump
chamber is forced out of the material outlet port.
The solvent chamber surrounds the plunger. The chamber contains solvent
chamber fluid that lubricates the plunger and packing gland seals. This fluid
keeps material from hardening on the plunger and minimizes wear on the
packing gland seals. The bleed valve is used to bleed air from the pump.
Low-Drag Hydraulic Section
The low-drag hydraulic section operates the same as the standard hydraulic
section, but is equipped with low-drag internal components to increase
efficiency. Low-drag hydraulic sections are required for air motors 160mm
in diameter and below.

RhinorSD3/XD3 Hydraulic Section 11
Part 1611632−05
E2019 Nordson Corporation
PLUNGER
SOLVENT CHAMBER
PACKING GLAND
PISTON/UPPER CHECK
LOWER CHECK
FOLLOWER PLATE
SHOVEL
UP
DOWN
STROKE
STROKE
OUTPUT PORT
OUTPUT PORT
Figure 3 Standard Hydraulic Section

RhinorSD3/XD3 Hydraulic Section
12
Part 1611632−05 E2019 Nordson Corporation
AC Hydraulic Section
See Figure 4.
The AC hydraulic section has a two-piece shovel attached to the end of the
hydraulic plunger that projects into the center of the follower plate. The
shovel moves up and down with the plunger, helping to force material into
the hydraulic section. The hydraulic section pressurizes the material and
forces it out of the pump.
When the plunger strokes downward, the piston/upper check opens and the
lower check closes. Material between the upper and lower checks is forced
upward through the piston. The material above the upper check
pressurizes and flows out of the material output port. During the downward
stroke, the shovel check plate is forced away from the shovel to minimize
the potential for cavitation.
During the upward pump stroke, the plunger and shovel are pulled upward
and the piston/upper check closes. The shovel check plate closes on the
shovel and the lower check opens and allows material to pass into the lower
pump chamber below the upper check. As the plunger and piston move
upward, material from the upper pump chamber is forced out of the material
outlet port.
The solvent chamber surrounds the plunger. The chamber contains solvent
chamber fluid that lubricates the plunger and packing gland seals. This fluid
keeps material from hardening on the plunger and minimizes wear on the
packing gland seals.

RhinorSD3/XD3 Hydraulic Section 13
Part 1611632−05
E2019 Nordson Corporation
UP
DOWN
STROKE
STROKE
PLUNGER
SOLVENT CHAMBER
PACKING GLAND
PISTON/UPPER CHECK
LOWER CHECK
SHOVEL
OUTPUT PORT
FOLLOWER PLATE
OUTPUT PORT
Figure 4 AC Hydraulic Section

RhinorSD3/XD3 Hydraulic Section
14
Part 1611632−05 E2019 Nordson Corporation
Repair
WARNING: Allow only qualified personnel to perform the following tasks.
Follow the safety instructions in this document and all other related
documentation.
SRead and understand this entire section before repairing this equipment.
Some repairs can be made without breaking down the pump.
SRelieve all pressure to the pump before performing repair procedures.
SLet the equipment cool before performing these procedures.
SIf necessary, contact a local Nordson representative with questions
about these procedures.
This section only covers the procedures necessary to perform shop repairs.
Refer to the applicable Rhino unloader manual for procedures on removing
the pump from the unloader.
Disassemble the Hydraulic Section
See Figure 5.
NOTE: The standard hydraulic section includes a one-piece shovel
adapter (17b) and the AC hydraulic section includes a two-piece shovel
adapter (17a).
1. Remove the insulation wrap (20) if applicable.
2. Remove the solvent chamber (4) and O-ring (5) from the packing
gland assembly (2). Discard the O-ring.
3. Perform the following:
a. Remove the socket screws (3) from the packing gland assembly (2).
Insert two socket screws (3) into the threaded holes (6) in the
packing gland assembly (2).
b. Alternate tightening the screws to remove the packing gland
assembly (2) from the upper pump body (1a/b).
4. Remove the shovel adapter (17a/b) from the rod assembly (7).
5. Remove the socket screws (18) securing the follower plate (16) to the
upper pump body (1a/b). Remove the follower plate (16).
NOTE: Note the orientation of the cutout in the follower plate (16) in
relation to the material outlet for re-installation.
6. Remove the bottom housing (14), O-ring (15), lower check plate (13),
and shaft support spacer (12). Discard the O-ring (15).
7. Remove the T/C coil (19) if applicable.
NOTE: Take note of the orientation of the T/C coil (19) connectors.
8. Remove the pump housing cylinder (11) from the upper pump
body (1a/b). Remove and discard the O-rings (10) from the pump
housing cylinder (11).
9. Using either an arbor press or hydraulic press, push the rod
assembly (7), piston assembly (8), and plunger rod (9) out of the pump
housing cylinder (11).

RhinorSD3/XD3 Hydraulic Section 15
Part 1611632−05
E2019 Nordson Corporation
10. Clamp the rod assembly (7) in a vise on the flats specified in Figure 5.
11. Use a deep well socket to remove the plunger rod (9) from the rod
assembly (7). Remove the piston assembly (8).
12. Clean the parts with a compatible solvent.
13. Inspect parts for nicks, scratches, wear, and damage. Replace parts if
necessary.
14. Rebuild the packing gland assembly (2) if necessary. Refer to the
Rebuild the Packing Gland procedure in this section for instructions.
Assemble the Hydraulic Section
See Figure 5.
1. Apply Mobil SHC 634 to the packing gland O-ring (5) and the packing
gland assembly (2) inside diameter (21).
2. Install the packing gland assembly (2) onto the upper pump body (1a/b).
3. Apply Never Seez to the threads of the socket screws (3). Install the
socket screws (3) into the packing gland assembly (2) and tighten to
102-108 NSm (75-80 ft-lb).
4. Apply Mobil SHC 634 to the O-rings (10) and inside diameter of the
pump housing cylinder (11). Install the O-rings (10) onto the pump
housing cylinder (11). Install the pump housing cylinder (11) onto the
upper pump body (1a/b).
5. Assemble the rod assembly (7), piston assembly (8), and plunger
rod (9):
a. Clamp the rod assembly (7) in a vise on the flats specified in
Figure 5.
b. Install the piston assembly (8) onto the rod assembly (7).
c. Apply Never Seez to the upper threads of the rod assembly (7) and
pilot the plunger rod (9) to the threads. Use a deep well socket to
connect the plunger rod (9) to the rod assembly (7) and tighten to
272-298 NSm (200-220 ft-lb).
d. Apply a thin coat of Mobil SHC 634 to the plunger rod (9), piston
assembly (8), and rod assembly (7).
6. Using either an arbor press or hydraulic press, install the rod
assembly (7), piston assembly (8), and plunger rod (9) through the
pump housing cylinder (11) and packing gland assembly (2).
7. Install the shaft support spacer (12) and lower check plate (13) onto the
rod assembly (7), piston assembly (8), and plunger rod (9).
8. Install the bottom housing (14) onto the pump housing cylinder (11).
Apply Mobil SHC 634 to the O-ring (15) and install it onto the bottom
housing (14).
9. Install the follower plate (16) onto the bottom housing (14).
NOTE: The follower plate (16) orientation is critical and should be
installed in relation to the material outlet exactly as it was removed.
10. Install the T/C coil (19) if applicable.
NOTE: The orientation of the T/C coil (19) connections is critical.

RhinorSD3/XD3 Hydraulic Section
16
Part 1611632−05 E2019 Nordson Corporation
11. Apply Never Seez to the threads of the socket screws (18). Perform the
following:
a. Install the socket screws (18) through the follower plate (16) and into
the upper pump body (1a/b).
b. Hand-tighten two opposing socket screws (18) at the same time until
the follower plate (16), bottom housing (14), and pump housing
cylinder (11) are secured to the upper pump body (1a/b).
Hand-tighten the remaining socket (18) screws as shown in Figure 5.
c. After performing the previous step, simultaneously tighten each
screw ⅛‐turn at a time in the sequence shown in Figure 5 to
102-108 NSm (75-80 ft-lb).
12. Apply threadlock adhesive to the lower threads of the rod assembly (7).
Install the shovel adapter (17a/b) to the rod assembly (7) and tighten to
75-81 NSm (55-60 ft-lb).
13. Install the solvent chamber (4) and O-ring (5) onto the packing gland
assembly (2).
14. Install the insulation wrap (20) if applicable.
