CallPilot 5.0 installation
The CallPilot 5.0 Quickstart Guide provides basic instructions on new
hardware installation and basic configuration of a CallPilot 5.0 system. After
using this guide to set up a basic CallPilot configuration, you should be
able to dial a mailbox, leave a message and retrieve a message using the
telephone. For more detailed configuration information, see the appropriate
technical documentation.
This document is designed to be followed from start to finish and is intended
for experienced installers.
Prerequisites to CallPilot 5.0 installation
Before you proceed with installation of a CallPilot 5.0 system using this
guide, you should have the following knowledge and skills:
•Understanding of basic programming and provisioning for CallPilot 5.0.
•Understanding of basic programming and provisioning for the
Communication Server 1000 (CS 1000) or Meridian 1 (M1) system.
•Knowledge of personal safety precautions to take to minimize risk of
injury when installing components.
DANGER
Risk of injury by electric shock
To minimize risk of injury by electric shock, take care when
working with power equipment and connections.
DANGER
Risk of injury by laser
Never look directly into the end of a fiber cable or use an
optical device to look at the end of a fiber cable unless you are
certain that the other end of the cable is not connected. The
laser traveling through a fiber cable can injure the retina.
Nortel CallPilot
Quickstart Guide
NN44200-313 01.02 Standard
5.0 19 May 2008
Copyright © 2007-2008, Nortel Networks
.

10 CallPilot 5.0 installation
•Understanding of electrostatic discharge and how to prevent it.
Electrostatic discharge (ESD) is the transfer of charge between
bodies at different electrical potentials. ESD can change the electrical
characteristics of a semiconductor device and degrade or destroy it.
ESD can also disrupt the normal operation of an electronic system by
causing equipment malfunction or failure. Follow these guidelines to
prevent ESD:
— To dissipate or neutralize electrostatic charges, use proper grounding
and use conductive or dissipative materials.
— When handling modules, always wear an antistatic wrist strap
connected to the same ESD grounding point as the equipment being
worked on. Any charge in your body will go to ground rather than
transferring to hardware modules.
— Always set modules on appropriate antistatic material. Proper
antistatic packaging effectively shields the product from charge
and reduces the generation of charge caused by movement of the
product within the container.
•Knowledge of general practices to protect equipment modules from
damage. Follow these guidelines to prevent damage to equipment
modules:
— Handle modules by the faceplate. Do not touch pins or electrical
connections.
— Do not leave slots open. All slots must be filled with modules or
be covered with slot covers, if empty, in order to maintain safety
compliance, proper cooling, and EMI containment in the shelf.
— Ensure that your environment meets the necessary requirements for
temperature, humidity, and cleanliness. Refer to the environmental
requirements for your switch and server in the CallPilot server
configuration guide for your switch model.
— Replace the optional air filter regularly (approximately every three
months) in order to maintain proper cooling and airflow through the
shelf.
— Do not over-tighten thumb screws or lug nuts. Tighten until snug
plus a quarter turn. If you use a power tool to tighten screws, use a
low torque setting (2–3 lbs/sq in).
CallPilot 5.0 installation tasks
The following is a list of the CallPilot 5.0 installation tasks covered in this
guide, listed in the correct sequence. To link to detailed procedures for
each task, click the text.
•"CS 1000/M1 system status check tasks" (page 13)
Nortel CallPilot
Quickstart Guide
NN44200-313 01.02 Standard
5.0 19 May 2008
Copyright © 2007-2008, Nortel Networks
.

Time requirements 11
•"CallPilot resource configuration" (page 17)
•"CallPilot server preinstallation" (page 37)
•"CallPilot server installation" (page 41)
•"CallPilot server configuration" (page 47)
•"CallPilot server testing" (page 55)
Time requirements
The following table shows the approximate time required to complete each
task in the work flow.
Table 1
Time requirements
Task Time to completion
CS 1000/M1 system status check 15 minutes
CallPilot resource configuration 2 hours
CallPilot server preinstallation 1 hour
CallPilot server installation 1 hour
CallPilot server configuration 2 hours
CallPilot server testing 1.5 hours
Total time to completion = 7 hours 45 minutes
Nortel CallPilot
Quickstart Guide
NN44200-313 01.02 Standard
5.0 19 May 2008
Copyright © 2007-2008, Nortel Networks
.

12 CallPilot 5.0 installation
Nortel CallPilot
Quickstart Guide
NN44200-313 01.02 Standard
5.0 19 May 2008
Copyright © 2007-2008, Nortel Networks
.

13
CS 1000/M1 system status check
This task describes how to check the Communication Server 1000 (CS
1000) or the Meridian 1 (M1) system status.
To successfully install a basic CallPilot system, you must provision or verify
the following parameters on the telephony switch (CS 1000 or M1):
•PBX IP and host name
•VAS ID
•ELAN ID
•system parameters
•ACD
•DFDN
•CDN
•ACD agents
•telephones
CallPilot can be provided only on a per-customer basis on the CS 1000
or M1 system. ELAN messages used for communication between the
telephony switch and CallPilot contain a customer number to which CallPilot
belongs. In these procedures, ensure that you enter the correct customer
number in the overlays.
CS 1000/M1 system status check tasks
The following is a list of tasks you perform to check the status of the CS 1000
or M1 system. To link to detailed procedures for each task, click the text.
•"Checking the current IP address of the PBX (LD 117)" (page 14)
•"Checking the currently configured VAS IDs" (page 14)
•"Checking the ELAN interface status of the PBX (LD 137)" (page 15)
•"Enabling the ELAN interface of the PBX (LD 137)" (page 15)
Nortel CallPilot
Quickstart Guide
NN44200-313 01.02 Standard
5.0 19 May 2008
Copyright © 2007-2008, Nortel Networks
.

14 CS 1000/M1 system status check
•"Checking the status of the ELAN connection to the PBX (LD 48)" (page
15)
Checking the current IP address of the PBX (LD 117)
Perform the following procedure to check the current IP address in the CS
1000 or M1 system.
Step Action
1Connect to the PBX.
2If you have not already done so, log on using the proper account
with the following syntax:
logi <login name>
3Press Enter.
4At the prompt, type the password for the login name and press Enter.
5Enter LD 117.
6Enter STAT HOST to display the IP addresses and host names
configured in the CS 1000 or M1 system.
Note: If there is no IP provisioning completed, see the CS 1000
System and CallPilot Server Configuration guide (NN44200-312)
for advanced provisioning. When provisioning is complete, return
to this guide and continue to the next procedure.
7To exit the overlay, enter ****.
—End—
Checking the currently configured VAS IDs
Step Action
1Connect to the PBX.
2Enter LD 22.
3At the REQ prompt, enter PRT.
4At the TYPE prompt, enter VAS.
5If there are some VAS IDs provisioned, take note of the VAS ID
information. If there are no VAS IDs provisioned, this guide explains
the steps to provision them in the next chapter.
Nortel CallPilot
Quickstart Guide
NN44200-313 01.02 Standard
5.0 19 May 2008
Copyright © 2007-2008, Nortel Networks
.

Checking the status of the ELAN connection to the PBX (LD 48) 15
—End—
Checking the ELAN interface status of the PBX (LD 137)
Perform the following procedure to check the ELAN interface status.
Step Action
1Connect to the PBX.
2Enter LD 137.
3Enter STAT ELNK. The status of the ELAN interface appears.
Note: If the ELAN interface is not configured, continue to
"Enabling the ELAN interface of the PBX (LD 137)" (page 15).
If it is configured, continue to "Checking the status of the ELAN
connection to the PBX (LD 48)" (page 15).
4To exit the overlay, enter ****.
—End—
Enabling the ELAN interface of the PBX (LD 137)
Perform the following procedure to enable the ELAN interface. If it is already
enabled, skip to the next procedure.
Step Action
1Connect to the PBX.
2Enter LD 137.
3Enter CHG ELNK ACTIVE NAME, where NAME is the host name
for the primary IP address.
4To exit the overlay, enter ****.
—End—
Checking the status of the ELAN connection to the PBX (LD 48)
Perform the following procedure to check the status of the ELAN connection
to the PBX.
Nortel CallPilot
Quickstart Guide
NN44200-313 01.02 Standard
5.0 19 May 2008
Copyright © 2007-2008, Nortel Networks
.

16 CS 1000/M1 system status check
Step Action
1Connect to the PBX.
2Enter LD 48.
3Enter STAT ELAN to display a list of current AML links.
Note: Take note of any enabled and active ELANs. This will be
useful when deciding if a new VAS ID and ELAN ID are required.
4To exit the overlay, enter ****.
—End—
Nortel CallPilot
Quickstart Guide
NN44200-313 01.02 Standard
5.0 19 May 2008
Copyright © 2007-2008, Nortel Networks
.

17
CallPilot resource configuration
This task describes how to configure CallPilot 5.0 resources on the
Communication Server 1000 (CS 1000) or Meridian 1 (M1) system.
CallPilot can be provided only on a per-customer basis on the CS 1000
or M1 system. AML messages used for communications between the
telephony switch and CallPilot contain a customer number to which CallPilot
belongs. In these procedures, ensure that you enter the correct customer
number in the overlays.
CallPilot resource configuration tasks
The following is a list of tasks you perform to configure CallPilot 5.0
resources on the CS 1000 or M1 system. To link to detailed procedures
for each task, click the text.
•"Configuring a new ELAN ID and VAS ID (LD 17)" (page 18)
•"Configuring system parameters (LD 17)" (page 19)
•"Defining CallPilot in the customer data block (LD 15)" (page 20)
•"Configuring the Route Data Block (LD 16)" (page 22)
•"Configuring Automatic Call Distribution (LD 23)" (page 23)
•"Configuring the DFDN (LD 23)" (page 24)
•"Configuring the CDN queue (LD 23)" (page 25)
•"Configuring ACD agents (LD 11)" (page 26)
•"Provisioning telephones (LD 11)" (page 27)
•"Enabling card slots (LD 32)" (page 29)
•"Saving CS 1000/M1 changes (LD 43)" (page 30)
Nortel CallPilot
Quickstart Guide
NN44200-313 01.02 Standard
5.0 19 May 2008
Copyright © 2007-2008, Nortel Networks
.

18 CallPilot resource configuration
Configuring a new ELAN ID and VAS ID (LD 17)
Define and configure the ELAN subnet for the AML link and its associated
VAS ID in the configuration record. This provides the Ethernet connection
over which AML messages are exchanged between the CS 1000 or M1
system and CallPilot. A separate ELAN must be created for CallPilot and
Contact Center for the purpose of integration.
Perform this procedure only if there is no VAS ID provisioned or available.
Step Action
1Connect to the PBX.
2Enter LD 17.
3Enter the appropriate values as described in the following table to
configure a new ELAN ID. For prompts not listed in the following
table, press Enter to accept the default.
Table 2
LD 17 - Configuring the ELAN ID
Prompt Response Notes
REQ CHG
TYPE ADAN
ADAN NEW ELAN xx Where xx is the next available
number, 16 – 31.
CTYP ELAN
DES a..a Enter a relevant description (for
example, CallPilot).
LCTL <cr>
4Enter the appropriate values as described in the following table to
configure a new VAS ID. For prompts not listed in the following table,
press Enter to accept the default.
Table 3
LD 17 - Configuring the VAS ID
Prompt Response Notes
REQ CHG
TYPE VAS
VAS NEW
VSID xx Enter the number entered for
the ELAN ID above.
Nortel CallPilot
Quickstart Guide
NN44200-313 01.02 Standard
5.0 19 May 2008
Copyright © 2007-2008, Nortel Networks
.

Configuring system parameters (LD 17) 19
Prompt Response Notes
ELAN xx Enter the number entered for
the ELAN ID above.
SECU YES
5To exit the overlay, enter ****.
Tech tip: To view the new ELAN, enter LD 22. Enter PRT at the REQ
prompt, then ADAN. A list of all provisioned IDs appears. Use the
capture text function in hyperterminal to save a text file of the output.
—End—
Configuring system parameters (LD 17)
Tech tip: To view a list of all provisioned system parameters, enter LD 22
and enter PRT at the REQ prompt, then CFN. Use the capture text function
in hyperterminal to save a text file of the output.
Step Action
1Connect to the PBX.
2Enter LD 17.
3Enter the appropriate values as described in the following table.
For prompts not listed in the following table, press Enter to accept
the default.
Table 4
LD 17 - Configuring system parameters
Prompt Response Notes
REQ CHG
TYPE PARM
NCR xxx Enter the number of DS0
channels multiplied by 2 plus
the current NCR.
For example, if the current NCR
is 500 and there are 24 DS0
channels, enter 548.
Nortel CallPilot
Quickstart Guide
NN44200-313 01.02 Standard
5.0 19 May 2008
Copyright © 2007-2008, Nortel Networks
.

20 CallPilot resource configuration
Prompt Response Notes
CSQI xxx Enter the number of CallPilot
DS0 channels multiplied by 2.
For example, if there are 24
DS0 channels, enter 48.
CSQO xxx Enter the number of CallPilot
DS0 channels multiplied by 2.
For example, if there are 24
DS0 channels, enter 48.
4To exit the overlay, enter ****.
—End—
Defining CallPilot in the customer data block (LD 15)
Tech tip: To view current system parameters, go to LD 21 and enter PRT at
the REQ prompt, and then CDB and the appropriate customer number. The
result is a list of all the current information in the Customer Data Block. Use
the capture text function in hyperterminal to save a text file of the output.
Step Action
1Connect to the PBX.
2Enter LD 15.
3Enter the appropriate values as described in the following table to
add Call Park Allowed and Message Center Included. For prompts
not listed in the following table, press Enter to accept the default.
Table 5
LD 15 - Configuring Call Park Allowed and Message Center Included
Prompt Response Notes
REQ CHG
TYPE ftr
CUST xx Customer number for CallPilot.
OPT CPA MCI
IDEF YES
NO
If Call Forward by Call Type
(CFCT) is enabled on the CS
1000 or M1 switch, enter YES.
Otherwise, enter NO.
Nortel CallPilot
Quickstart Guide
NN44200-313 01.02 Standard
5.0 19 May 2008
Copyright © 2007-2008, Nortel Networks
.
