Novus NVR-3000 Series User manual

u s e r ’s m a n u a l
Applications client for mobile devices
NVR-3000 series NVR’s

Applications client for mobile devices for 3000 series NVR’s
- user manual ver.1.0
All rights reserved © AAT Holding sp. z o.o.
2
ATTENTION!
COPYING EITHER WHOLE OR PART OF THIS MANUAL WITHOUT WRITTEN PERMISSION
OF AAT HOLDING LTD. IS NOT ALLOWED.
Basic client application for NVR-3000 series NOVUS NVR is free of charge.
Depends of the mobile device system application is available respectively on Google Play or AppStore.
All services and products named in this manual may be trademarks or registered trademarks and
therefore may be a property of respective subjects.
In case of applications obtained via websites being property of other subjects or using their
assistance in obtaining them, please familiarize with their terms of usage and privacy rules.
IMPORTANT SAFEGUARDS AND WARNINGS

Applications client for mobile devices for 3000 series NVR’s
- user manual ver.1.0
All rights reserved © AAT Holding sp. z o.o.
3
CONTENTS
TABLE OF CONTENT ....................................................................................... 3
1. FOREWORD INFORMATION ..................................................................... 4
2. SOFTWARE INSTALATION AND OPERATION FOR
IPHONE CLIENT ............................................................................................ 5
2.1 Software installation ............................................................................ 5
2.2 Software operating ............................................................................... 7
3. SOFTWARE INSTALATION AND OPERATION FOR
ANDROID CLIENT....................................................................................... 11
3.1 Software installation ......................................................................... 11
3.2 Software operating ............................................................................. 12

Applications client for mobile devices for 3000 series NVR’s
- user manual ver.1.0
All rights reserved © AAT Holding sp. z o.o.
4
1. FOREWORD INFORMATION
The NOVUS 3000 series NVRs support mobile surveillance by IPhone or Android mobile phones.
There are several kinds of client applications, depending on operating system used in mobile phones.
This manual describes installation process of an application compatible with aforementioned models.
Wireless connection at local network:
Wireless connection using mobile phone networks and internet:
FOREWORD INFORMATION
NOVUS NVR SMARTPHONE
Router /Access Point
WiFiLAN
INTERNET
NOVUS NVR
SMARTPHONE
LAN
Router /Access Point
GPRS
UMTS
3G

Applications client for mobile devices for 3000 series NVR’s
- user manual ver.1.0
All rights reserved © AAT Holding sp. z o.o.
5
2. SOFTWARE INSTALLATION AND OPERATION FOR IPHONE CLIENT
2.1 Software installation
In order to start software installation:
Open App Store application of the IPhone, and search for „IMSeye or IMSeyeHD”.
Please select the „IMSeye or IMSeyeHD” item from the program list and the application information
will appear, then click the icon.
Input password for the iTunes store and then click the OK. Software installation is then started
automatically.
Please enter user ID and password when logging to the iTunes, if there is no account created, user
needs to join the iTunes.
1. FOREWORD INFORMATION
The NOVUS 3000 series NVRs support mobile surveillance by IPhone or Android mobile phones.
There are several kinds of client applications, depending on operating system used in mobile phones.
This manual describes installation process of an application compatible with aforementioned models.
Wireless connection at local network:
Wireless connection using mobile phone networks and internet:
SOFTWARE INSTALLATION AND OPERATION FOR IPHONE CLIENT

Applications client for mobile devices for 3000 series NVR’s
- user manual ver.1.0
All rights reserved © AAT Holding sp. z o.o.
6
SOFTWARE INSTALLATION AND OPERATION FOR IPHONE CLIENT
2.2 Software operation
In order to run the application please select the icon like below:
Following window will appear:
To watch camera please select “Add New Device” button to add NVR to list.
Please choose Address in Login Mode and fill in necessary fields.
Name - Please input any name
IP Address - Please input NVR IP address
Port - provide TCP data connection port default 8000
User ID & Password

Applications client for mobile devices for 3000 series NVR’s
- user manual ver.1.0
All rights reserved © AAT Holding sp. z o.o.
7
SOFTWARE INSTALLATION AND OPERATION FOR IPHONE CLIENT
Select “OK” to confirm settings or press “Back” to return to the device list.
After providing settings NVR will be added to list. Please click on the button next to NVR
to expand available channels and select desired channel.
After establishing connection camera live monitoring will be shown.

Applications client for mobile devices for 3000 series NVR’s
- user manual ver.1.0
All rights reserved © AAT Holding sp. z o.o.
8
SOFTWARE INSTALLATION AND OPERATION FOR IPHONE CLIENT
To add additional camera to view press and choose desired channel to add.
To view live video form in single channel mode double click on displayed channel. To switch back to
split view double press on previewed image.
Single click on window set focus on window and highlights windows with green frame.
When displaying window the following buttons are available :
Start/stop image preview
Displays information about received alarms
Displays control panel for PTZ devices
Enable/disable audio listening
Display other control functions
Capture an image in jpg file to the device memory
Enable/disable video recording
Back to previus video option
Removing the added camera configuration for the active channel
After pressing the PTZ control the following icons are displayed :
Control for PTZ camera movements
Focus control
Zoom control
Aperture control

Applications client for mobile devices for 3000 series NVR’s
- user manual ver.1.0
All rights reserved © AAT Holding sp. z o.o.
9
Video playback
Clicking on button opens window for searching recoded videos in NVR. To start search choose
desired day, define time range an select channel for searching. Then press “Search’ to start searching.
If records are found files with recording are displayed on the list. To start video playback click on
desired file.
SOFTWARE INSTALLATION AND OPERATION FOR ANDROID CLIENT
Date selector
End of recodting
Start of recordings
Channel
Device selector
Record Type Search
Files found

Applications client for mobile devices for 3000 series NVR’s
- user manual ver.1.0
All rights reserved © AAT Holding sp. z o.o.
10
SOFTWARE INSTALLATION AND OPERATION FOR IPHONE CLIENT
The playback window displays the selected file. Use time bar to preview file It is possible to image
from replayed video into jpg file. To end replaying video press “Back” button.
Close video playback
Video progres bar
Start/Stop video replay Capture image to jpg

Applications client for mobile devices for 3000 series NVR’s
- user manual ver.1.0
All rights reserved © AAT Holding sp. z o.o.
11
3. SOFTWARE INSTALLATION AND OPERATION FOR ANDROID CLIENT
3.1 Software installation
In order to start software installation:
Open “Android Market” application inside the Android system and search for IMSeye(new) or
IMSeyeHD application in the search field.
Please choose IMEye or MEyePro item from the program list, next click the Install button and OK,
which starts automatic software installation.
SOFTWARE INSTALLATION AND OPERATION FOR ANDROID CLIENT

Applications client for mobile devices for 3000 series NVR’s
- user manual ver.1.0
All rights reserved © AAT Holding sp. z o.o.
12
SOFTWARE INSTALLATION AND OPERATION FOR ANDROID CLIENT
3.2 Software operation
In order to run the application please select the icon like below:
Following window will appear:
- enter to the Live Preview window
- open videoplayback form NVR
- menu to watch locally saved images and videos
- information about application
- Application settings

Applications client for mobile devices for 3000 series NVR’s
- user manual ver.1.0
All rights reserved © AAT Holding sp. z o.o.
13
SOFTWARE INSTALLATION AND OPERATION FOR ANDROID CLIENT
To add device please select “Click to add device” :
In opened window provide necessary information in following fields:
Device name - friendly name
Connection : - choose “The IP address”
Address - network address, for ex. : 192.168.3.1,
Mobile port - mobile device port from NVR, 8000 by default
User Name & Password
Select “Ok” to save these settings.
Press “Cancel” to return to the main menu

Applications client for mobile devices for 3000 series NVR’s
- user manual ver.1.0
All rights reserved © AAT Holding sp. z o.o.
14
SOFTWARE INSTALLATION AND OPERATION FOR ANDROID CLIENT
To watch camera please select button, then following window will appear:
Press button to select channel for preview.
Click to expand channel list from desired device. Click on channel form list to start display.

Applications client for mobile devices for 3000 series NVR’s
- user manual ver.1.0
All rights reserved © AAT Holding sp. z o.o.
15
SOFTWARE INSTALLATION AND OPERATION FOR WINDOWS MOBILE
After establishing connection camera live monitoring will be shown.
To display video in single view double click on image in split screen. Re-clicking on image in single
view changes back to split screen view. Single clicking on view windows highlights window with
green frame and set window as active.
When displaying video there are following options available :
Start/stop image preview
Displays information about received alarms
Displays control panel for PTZ devices
Enable/disable audio listening
Display other control functions

Applications client for mobile devices for 3000 series NVR’s
- user manual ver.1.0
All rights reserved © AAT Holding sp. z o.o.
16
SOFTWARE INSTALLATION AND OPERATION FOR ANDROID CLIENT
Capture an image in jpg file to the device memory
Enable/disable video recording
Back to previus video option
Removing the added camera configuration for the active channel
After pressing the PTZ control the following icons are displayed :
Control for PTZ camera movements
Focus control
Zoom control
Aperture control
Playback
Click on button to open window allowing for search for desired video files. To search for files
select day , specify time for recordings and choose channel. Then press “Remote Search”. List of files
The list of files that meet the specified assumptions will be displayed. Press on desired file to start
playback.
Use time belt to set desired time for playback.

Applications client for mobile devices for 3000 series NVR’s
- user manual ver.1.0
All rights reserved © AAT Holding sp. z o.o.
17
SOFTWARE INSTALLATION AND OPERATION FOR WINDOWS MOBILE
Date selector
End of records
Start of recordings
Channel
Device selector
Record type Search
Found files
Close video playback
Start/end playback time
Video progres bar
Capture image to jpg
Stop/start playback

2014-08-11 MB
AAT Holding sp. z o.o., 431 Pulawska St., 02-801 Warsaw, Poland
tel.: [phone], fax: [phone]
www.novuscctv.com

i n s t r ukcja obsługi
Oprogramowanie klienckie
na urządzenia mobilne
Rejestratory sieciowe serii NVR-3000

Oprogramowanie klienckie na urządzenia mobilne dla rejestratorów NVR-3000
- instrukcja obsługi wer.1.0
AAT Holding Sp. z o.o, wszystkie prawa zastrzeżone
2
UWAGA!
POWIELANIE W JAKIEJKOLWIEK FORMIE CAŁOŚCI LUB FRAGMENTÓW INSTRUKCJI
BEZ PISEMNEJ ZGODY FIRMY AAT HOLDING Sp. Z.O.O., JEST ZABRONIONE.
Podstawowe wersje oprogramowania klienckiego do rejestratorów sieciowych NOVUS
serii NVR-3000 są oprogramowaniem nieodpłatnym.
Zależnie od systemu operacyjnego uważnego w urządzeniu mobilnym aplikacje są dostępne na
platformach Google Play lub AppStore.
Wszystkie nazwy produktów i usług wymienione w niniejszej instrukcji mogą być znakami
towarowymi lub zastrzeżonymi znakami towarowymi i w takim wypadku są własnością odpowiednich
podmiotów.
W przypadku aplikacji uzyskiwanych w witrynach innych podmiotów lub za ich pośrednictwem należy
wcześniej zapoznać się z warunkami korzystania z takich witryn i stosowanymi zasadami dotyczącymi
prywatności.
UWAGI I OSTRZEŻENIA
