Novus NHDR-4304-H1 User manual

Quick start guide
NHDR-4304-H1
NHDR-4308-H1

NHDR-4304-H1, NHDR-4308-H1 Quick start guide version 1.0
All rights reserved © AAT SYSTEMY BEZPIECZEŃSTWA Sp. z o.o.
2
INFORMACJE
IMPORTANT SAFEGUARDS AND WARNINGS
THE PRODUCT MEETS THE REQUIREMENTS CONTAINED IN THE FOLLOWING DIRECTIVES:
DIRECTIVE 2014/35/EU OF THE EUROPEAN PARLIAMENT
AND OF THE COUNCIL of 26 February 2014 on the harmonisation
of the laws of the Member States relating to the making available on the mar-
ket of electrical equipment designed for use within certain voltage limits.
DIRECTIVE 2014/30/EU OF THE EUROPEAN PARLIMENT
AND OF THE COUNCIL of 26 February 2014 on the harmonisation
of the laws of the Member States relating to electromagnetic compatibility
(OJ L 96, 29.3.2014, p. 79–106, with changes)
DIRECTIVE 2012/19/EU OF THE EUROPEAN PARLIAMENT
AND OF THE COUNCIL of 4 July 2012 on waste electrical and electronic
equipment (WEEE) (OJ L 197, 24.7.2012, p. 38–71,with changes)
DIRECTIVE 2011/65/EU OF THE EUROPEAN PARLIAMENT
AND OF THE COUNCIL of 8 June 2011 on the restriction of the use
of certain hazardous substances in electrical and electronic equipment
(OJ L 174, 1.7.2011, p. 88–110, with changes)

NHDR-4304-H1, NHDR-4308-H1 Quick start guide version 1.0
All rights reserved © AAT SYSTEMY BEZPIECZEŃSTWA Sp. z o.o.
3
SAFETY REQUIREMENTS
ATTENTION!
PRIOR TO UNDERTAKING ANY ACTION THAT IS NOT PROVISIONED FOR THE
GIVEN PRODUCT IN ITS USER’S MANUAL AVAILABLE AT WWW.NOVUSCCTV.COM
AND OTHER DOCUMENTS DELIVERED WITH THE PRODUCT, OR THAT ARISES
FROM THE NORMAL APPLICATION OF THE PRODUCT, ITS MANUFACTURER MUST
BE CONTACTED OR THE RESPONSIBILITY OF THE MANUFACTURER FOR THE
RESULTS OF SUCH AN ACTION SHELL BE EXCLUDED.
1. Prior to undertaking any action please consult the following manual and read all the safety and
operating instructions before starting the device.
2. Please keep this manual for the lifespan of the device in case referring to the contents of this manual
is necessary;
3. All the safety precautions referred to in this manual should be strictly followed, as they have a direct
influence on user’s safety and durability and reliability of the device;
4. All actions conducted by the servicemen and users must be accomplished in accordance with the
user’s manual;
5. The device should be disconnected from power sources during maintenance procedures;
6. Usage of additional devices and components neither provided nor recommended by the producer is
forbidden;
7. You are not allowed to use the device in high humidity environment (i.e. close to swimming pools,
bath tubs, damp basements);
8. Mounting the device in places where proper ventilation cannot be provided (e. g. closed lockers etc.)
is not recommended since it may lead to heat build-up and damaging the device itself as a
consequence;
9. Mounting the device on unstable surface or using not recommended mounts is forbidden.
Improperly mounted device may cause a fatal accident or may be seriously damaged itself. The
device must be mounted by qualified personnel with proper authorization, in accordance with this
user’s manual.
10. Device should be supplied only from a power sources whose parameters are in accordance with
those specified by the producer in the devices technical datasheet. Therefore, it is forbidden to
supply the devices from a power sources with unknown parameters, unstable or not meeting
producer’s requirements;
11. You cannot allow any metal objects get inside the recorder. It might cause serious damage. If a
metal object gets inside the device contact the authorised Novus service immediately.
12. The manufacturer does not bear responsibility for damage or loss of data stored on HDDs or other
media occurred during the usage of the product.
Due to the product is constantly being improved and optimized, some of parameters and
functions described in the manual may have changed without further notice. Please refer to the
latest version of the user manual on the website www.novuscctv.com. The instruction manual on
the website www.novuscctv.com is always the most current version.
The NHDR-4000 series recorders are dedicated to work with NOVUS cameras. Using only
NOVUS products guarantees the highest level of service. Connecting third-party cameras may
result in lower video quality and functional limitations.
The manufacturer reserves the right to printing errors and technical changes without prior
notice.

NHDR-4304-H1, NHDR-4308-H1 Quick start guide version 1.0
All rights reserved © AAT SYSTEMY BEZPIECZEŃSTWA Sp. z o.o.
4
FOREWORD INFORMATION
1. FOREWORD INFORMATION
1.1. Main characteristics
• Digital recorders support high definition analog cameras (720p, 1080p, 4MPX, 5MPX, 8MPX),
AHD, TVI, CVI.
• Support IP cameras up to 5 MPx (hybrid mode).
• AHD recording resolution: 3840 x 2160, 2560 x 1944, 2560 x 1440, 2048 x1536, 1920 x 1080,
1280 x 720, 960 x 480.
• Dual stream recording.
• Supports 1 SATA 3,5” HDDs.**
• Channel assigning to each HDD.
• Operating system based on Linux.
• H.264 and H.265 compression.
• Main monitor 1 x HDMI (max. 4K UltraHD), 1 x VGA (max. FullHD).
• Spot monitor for analog cameras (USB connector).
• Recording compression, resolution, speed and quality defined individually for each camera.
• Channel covering function.
• Intelligent analysis with analog and IP cameras.
• 4/8 alarm inputs, 1 alarm output.*
• 4/8 channel real-time audio recording.*
• PTZ control of analog and IP cameras directly from the device.
• Protocols: Pelco-D, Pelco-P, COAX.
• Special function to add cameras connected to another NHDR-4000 recorders or NVR-4000 as IP
channels.
• RTSP stream connection as IP channels.
• Backup through USB port and through the IP network.
• Software: NHDR-5000 Viewer (application for remote administration, live monitoring and recorded
data search ).
• Self-diagnostic functions with automatic notification.
• User friendly multi-lingual OSD.
• The device can be operated with a USB computer mouse, NV-KBD50 keyboard and remote control.
• Power supply: 12 VDC (100 ~ 240 VAC/12 VDC PSU in-set included).
* Depend on the model, in sequence: NHDR-4304-H1 / NHDR-4308-H1.
** The list of recommended disk models and their capacity is available on Novus Security website in
the Compatible Disk file in the product “Downloadable files” tab.

NHDR-4304-H1, NHDR-4308-H1 Quick start guide version 1.0
All rights reserved © AAT SYSTEMY BEZPIECZEŃSTWA Sp. z o.o.
5
1.2. Recorders’ technical data
FOREWORD INFORMATION
|NHDR-4304-H1 NHDR-4308-H1
Video
Video Input 4 x BNC 8 x BNC
Operating mode AHD 5Mpx, TVI 5Mpx, CVI 4Mpx, analog 960H
Monitor Output main (split screen, full screen, sequence): 1 x HDMI (4K UltraHD ), 1 x VGA (FullHD)
spot: 1 x BNC
IP Streams
DVR mode: 4 x AHD + 0 x IP
Hybrid mode: 4 x AHD + 2 x IP
IP mode: 0 x AHD + 6 x IP
DVR mode: 4 x AHD + 0 x IP
Hybrid mode: 8 x AHD + 4 x IP
IP mode: 0 x AHD + 12 x IP
Supported IP resolution max. 2592 x 1944
Audio
Audio Input/Output 4 x RCA (Line-in) / 1 x HDMI, 1 x RCA 8 x RCA (Line-in) / 1 x HDMI, 1 x RCA
Recording
Compression H.264 / H.265
AHD Recording Speed
120 fps (960 x 576 - 960H)
120 fps (1280 x 720 - HD)
60 fps (1920 x 1080 - FullHD)
64 fps (1280 x 1440 - 4Mpx Lite)
48 fps (1280 x 1944 - 5Mpx Lite)
240 fps (960 x 576 - 960H)
240 fps (1280 x 720 - HD)
120 fps (1920 x 1080 - FullHD)
144 fps (1280 x 1440 - 4Mpx Lite)
120 fps (1280 x 1944 - 5Mpx Lite)
IP Recording Speed Hybrid mode: 60 fps
IP mode: 180 fps
Hybrid mode: 120 fps
IP mode: 360 fps
IP stream size
hybrid mode: 8 Mb/s
in total from all IP cameras
IP mode: 24 Mb/s
in total from all IP cameras
hybrid mode: 16 Mb/s
in total from all IP cameras
IP mode: 48 Mb/s
in total from all IP cameras
Recording Mode continuous, triggered by: REC/PANIC button, alarm input, motion detection, PIR alarm, image
analysis
Schedule individual settings for: each camera, each day of the week, configuration with an accuracy of 30
min, possibility of combining individual recording modes
Prealarm/postalarm up to 3 s/up to 5 min
Playback
Playback Speed 120 fps 240 fps
Recorded Data Search by date/time, events, image analysis events, motion in a defined area, tags
Backup
Backup Methods USB port (HDD or Flash memory), network
Backup File Format JPEG, BMP, PNG, MP4, AVI
Storage
Internal HDDs up to: 1 x HDD 3.5” SATA
Total Capacity 10 TB
Alarm
Alarm Input/Output 4/1 relay 8/1 relay
Camera Alarm Input/
Output supports camera’s alarm input/output
Motion Detection 30 x 44 grid, individual settings of sensitivity
System Reaction to
Alarm Events
buzzer, e-mail, alarm output activation, screen message, recording activation, PTZ, Full Screen,
FTP picture upload, FTP video upload, picture to Cloud, video to Cloud

NHDR-4304-H1, NHDR-4308-H1 Quick start guide version 1.0
All rights reserved © AAT SYSTEMY BEZPIECZEŃSTWA Sp. z o.o.
6
NHDR-4304-H1 NHDR-4308-H1
Intelligent Image Analysis
Number of channels 0 x BNC, 6 x IP (4000 series) 0 x BNC, 12 x IP (4000 series)
Supported functions for
analog cameras Exception, Line cross, Zone entrance, Pedestrian detestion, Sound detection
Supported functions for IP
cameras
Exception, Line cross, Zone entrance, Abandoned object, Object disappearance, Face
detection, Pedestrian detestion, Cross counting, Sound detection
Network
Network Interface 1 x Ethernet - RJ-45 interface, 10/100 Mbit/s
Network Protocols Support HTTP, TCP/IP, IPv4/v6, HTTPS, FTP, DHCP, DNS, DDNS, NTP, SNTP, RTSP, UPnP,
SNMP, SMTP, P2P
PC/MAC Software NMS, Internet Explorer, NHDR-5000 Viewer/NHDR-5000 Viewer
Mobile applications RxCamView (iPhone, Android)
Max. Number of
Connections with DVR 20 (live monitoring: 20, playback: 1, configuration: 20)
Bandwidth 48 Mb/s in total to all client workstations 64 Mb/s in total to all client workstations
PTZ
PTZ Ports 1 x RS-485
PTZ Protocols Pelco-D, Pelco-P
PTZ Functions pan/tilt/zoom, preset commands, patterns
COAX
COAX Functions menu, zoom, focus, PTZ
Auxiliary Interfaces
USB Ports 2 x USB 2.0
Operating system
Operating System Linux
OSD Languages: Polish, English, Russian and others
Control PC mouse and IR remote controller (in-set included), network, NV-KBD50 keyboard
System Diagnostic automatic control of: HDDs, camera connection loss
Security password protection, IP filtering
Installation parameters
Dimensions (mm) 300 (W) x 53 (H) x 227 (D)
Weight 1.1 kg (without HDD)
Power Supply 12 VDC (100 ~ 240 VAC/12 VDC PSU in-set included)
Power Consumption 20 W (with HDD)
Operating Temperature -10°C ~ 55°C
FOREWORD INFORMATION
1.3. Package contents
Unpack the device carefully. After unpacking, please ensure that package contains the following items:
• Digital Video Recorder.
• Power supply 100~240 VAC/12 VDC.
• Power cord.
• USB Mouse.
• IR remote controller.
• User’s manual (short).
If any of the elements has been damaged during transport, pack all the elements back into the original
packaging and contact your supplier.

NHDR-4304-H1, NHDR-4308-H1 Quick start guide version 1.0
All rights reserved © AAT SYSTEMY BEZPIECZEŃSTWA Sp. z o.o.
7
CAUTION!
If the device was brought from a location with lower temperature, please wait until it reaches the
temperature of location it is currently in. Turning the device on immediately after bringing it
from a location with lower ambient temperature is forbidden, as the condensing water vapour
may cause short-circuits and damage the device as a result.
Note: Please familiarize yourself with description and functions of rear panel inputs.
The pictures of the recorders contained in this manual are for illustrative purposes and may
differ slightly from the actual device.
2. STARTING THE DEVICE
2.1. Electrical connection and other rear panel elements.
NHDR-4304-H1
NHDR-4308-H1
STARTING THE DEVICE
13 14 12
1 2 3
4
5 6 7 8 10
11 9
1 2
3
10
11 15
6 4 12
13
5 9 7 8
14

NHDR-4304-H1, NHDR-4308-H1 Quick start guide version 1.0
All rights reserved © AAT SYSTEMY BEZPIECZEŃSTWA Sp. z o.o.
8
1. AUDIO IN: Audio mono inputs (RCA LINE IN type) to connect microphones.
2. AUDIO OUTPUT: Audio output to connect speakers with amplifier (RCA connector).
3. VIDEO IN: Video inputs to connect video signal sources to the DVR.
4. HDMI: HDMI connector to connect main monitor using HDMI cable.
5. VGA: D-SUB connector to connect main monitor using VGA cable.
6. RESET: Hidden Reset button. Pressing the button for 3 seconds resets the administrator
password. Pressing the button for 8 seconds restores the recorder to the factory
settings.
7. SENSOR: Alarm inputs, which may be set as normal open (NO) or normal closed (NC)
in the DVR menu. The ground of the alarm device needs to be connected to
one of the G connectors.
8. ALARM: alarm output, relay 3A 30VDC.
9. RS-485: RS-485 bus connector to connect PTZ camerasor NV-KBD50 keyboard.
10. DC 12V: Power supply connector 12V.
11. CVBS: BNC connector to connect a SPOT monitor.
12. LAN: RJ-45 connector port to connect the local network and internet.
CAUTION! It is forbidden to connect ethernet port of the DVR to the POE port of the POE
Switch. It may damage the device.
13. USB: USB 2.0 port to connect USB mouse, external hard drives or Flash memory
to make a backup.
14. POWER SW: Power switch, plug the power cord and turn this switch on.
15. IR EXT: External IR receiver connector.
2.2. HDD mounting
Note:In order to obtain info on latest compatible HDDs together with their capacities, please
contact your distributor or visit www.novuscctv.com website. AAT SYSTEMY
BEZPIECZEŃSTWA Sp. z o.o. company does not bear responsibility for any issues arising from
usage of unsupported hard drives.
Note: List of compatible HDDs contains all disks supported by DVR model, including
desktop HDDs. It is preffered to use 24x7 hard drives to keep reliability ot the
recording system.
Note: If a hard disk was used in another device, it has to be format. It is needed due to the
irrecoverable data loss result.
Make sure the power supply is not connected before staring the process.
STARTING THE DEVICE

NHDR-4304-H1, NHDR-4308-H1 Quick start guide version 1.0
All rights reserved © AAT SYSTEMY BEZPIECZEŃSTWA Sp. z o.o.
9
Then unscrew the screws on the sides and back of the housing in the places shown in the photo below.
Remove the recorder housing by sliding it backwards and then lifting it up.
SATA and power cables are connected to the mainboard by default and ready to connect HDD. Put the
HDD at the shown place.
Rotate DVR to the side holding HDD by hand, and screw it tightly from the bottom.
STARTING THE DEVICE
HDD

NHDR-4304-H1, NHDR-4308-H1 Quick start guide version 1.0
All rights reserved © AAT SYSTEMY BEZPIECZEŃSTWA Sp. z o.o.
10
Connect SATA and power cable as shown on the picture below.
Install the top cover on the DVR and screw it back.
STARTING THE DEVICE
STARTING THE DEVICE
HDD

NHDR-4304-H1, NHDR-4308-H1 Quick start guide version 1.0
All rights reserved © AAT SYSTEMY BEZPIECZEŃSTWA Sp. z o.o.
11
2.3. Connecting power adapter.
Please connect provided 12V DC adapter to the power port of the DVR like depicted below.
To start the unit switch on the power on back panel. Initialization lasts for approximately 60 seconds.
During this time executing any device functions is prohibited. To shut down the device please use the
menu function.
CAUTION:
Make connection when the power is not applied and the power switch is turned off.
Do not place the power cord under the carpet or rug. The power cord is usually earth-grounded.
However, even if it's not earth-grounded, never modify it on your own for earth-grounding.
Make sure that power adapter is placed near of DVR and secured from accidental disconnection.
STARTING THE DEVICE
12V DC ADAPTER
POWER SWITCH

NHDR-4304-H1, NHDR-4308-H1 Quick start guide version 1.0
All rights reserved © AAT SYSTEMY BEZPIECZEŃSTWA Sp. z o.o.
12
2.4. Connecting monitor
The recorder supports HDMI and VGA interfaces for main monitor.
DVRs support following resolutions: 1024x768 (60Hz), 1280x1024 (60Hz), 1440x900 (60Hz),
1280x720 (50Hz). 1920x1080 (50Hz). 1680x1050 (60Hz), 1600x1200 (60Hz), 1920x1200 (60Hz),
3840x2160 (30Hz).
Default screen resolution is 1280x1024(60Hz). If the monitor native resolution is bigger, the
recorder propose to change it.
Changing the screen resolution is available in main menu of the DVR. In case of monitor does not
display anything after resolution change, please wait a moment, then previous resolution will be
restored.
Note: You can use the HDMI <> DVI converter to connect to the DVI monitor. HDMI cable and
HDMI<>DVI converter it’s not included and you have to buy it separately.
2.5. Connecting alarm ports
NHDR-4304-H1 has 4 alarm inputs, NHDR-4308-H1 has 8 alarm inputs. Both models have one alarm
output. To connect them please refer table below:
NHDR-4304-H1:
NHDR-4308-H1:
Alarm inputs, may be set either as normal open (NO) or normal closed (NC) in DVR menu settings.
Alarm input settings are described in user’s manual (Alarm section in full user’s manual). The ground
of the alarm device needs to be connected to one of the G connectors.
Alarm output is a relay with 2 connectors (con1, con2). Max contact ratings is 3A 30VDC.
STARTING THE DEVICE
87654321Gcon1 con2 RS485+ RS485-
ALARM
OUTPUT PTZALARM INPUT
4321Gcon1 con2 RS485+ RS485-
ALARM PTZALARM INPUT

NHDR-4304-H1, NHDR-4308-H1 Quick start guide version 1.0
All rights reserved © AAT SYSTEMY BEZPIECZEŃSTWA Sp. z o.o.
13
DVR OPERATING
2.6. Connecting ethernet network
DVR has an Ethernet port. It is marked as number 12 on the scheme in 2.1 chapter. It can be connected
to switch to make a connection with PC and IP cameras. Connecting IP camera is described in
chapter 3.3.3.
CAUTION! It is forbidden to connect ethernet port of the DVR to the POE port of switch. It may
damage the devices.
2.7. Front panel description
Front panel
1. IR receiver (behind the panel).
2. Power LED. When the LED is light on, it means DVR is working.
3. HDD LED. Flickering indicates that the recording or searching / playback is in
progress.
4. USB 2.0 port to connect external HDD, Flash memory or USB mouse.
3. DVR OPERATING
3.1. Recorder control
DVR recorder can be controlled in 3 ways: using IR remote controller, USB mouse or NV-KBD50
keyboard.
PWR
HDD
2 3 4
1

NHDR-4304-H1, NHDR-4308-H1 Quick start guide version 1.0
All rights reserved © AAT SYSTEMY BEZPIECZEŃSTWA Sp. z o.o.
14
DVR OPERATING
3.1.1.Controlling via IR remote controller
IR remote controller is included with DVR. IR range depends on battery status and may vary between a
few and several meters.
Controller is supplied with two AAA batteries. Buttons functions are listed below.
3.1.2.Controlling via USB mouse
It is possible to control all DVR functions using mouse with a USB interface. Double clicking on any
camera in split mode (e.g. 2x2, 3x3) switches it to full screen mode. Another double click returns to the
previous display mode.
A single click on a camera shows the channel menu. Moving the cursor down the screen displays the
menu bar. During configuration, the left mouse button select individual items. Some indicated
parameters can be changed by the mouse wheel. The right button allows to leave the menu.
3.1.3.Controlling via external keyboard
The DVR can be controlled by NV-KBD50 keyboard. It has to be connected to RS485 port on DVR
backpanel. All needed DVR settings are described in full version of users manual .
0 - 9 Numeric buttons for channel selection.
ALL Toggles between different display formats: 1, 4, 9.
MENU Enters to main menu. Pressing this button cancel the selection
and leaving the menu.
SUBMENU In live mode open the Popup menu.
Navigation control „left”, „right”. In live mode open the Popup
menu.
Navigation control „up” , „down”.
SEL Button is used for confirm the selection and start to editing
fields. In live mode open the Popup menu.
Switch on playback mode. Open Record Search menu. In live
mode open the Popup menu.
Slow down playback speed.
Fast up playback speed.
Turn on manual record.
Playback pause, press again to play frame by frame.
Stop the playback. In live mode stop the manual recording.

NHDR-4304-H1, NHDR-4308-H1 Quick start guide version 1.0
All rights reserved © AAT SYSTEMY BEZPIECZEŃSTWA Sp. z o.o.
15
DVR OPERATING
3.2. First launch
To start the unit connect the power cable to 12V DC adapter, turn on the power switch on back
panel and wait for initialization. It lasts for approximately 120 seconds. During this time executing
any device functions and pressing any buttons is prohibited. After the first launch DVR displays a
window as below. It allows to change the language. Select the desired one from the Language list.
Default language is English. If you change the language, all the descriptions will be translated
automatically.
Clicking on each field expands drop-down list or displays on-screen keyboard.
New Admin Name - name of administrator account (default: admin).
Password Strenght - the scale showing how strong is the written password. It is updated on the fly
while typing the password in the next fiels. Password strenght can be Low, Medium or High and
marked with Red, Yellow or Green color.
New Admin Password - it is required to create access password. It must contain 5-15 characters.
Confirm password - enter the access password again to confirm.
Show Password - shows password instead of masking marks.
Unlock Pattern Enable - enables an alternative authentication method for the password using the
pattern. It allows to enter administrative settings and make changes. Some settings, such as disk
formatting, import/export settings still require password authentication.
Draw - the function shows when Unlock Pattern function is enabled. It allows to create an unlock
pattern. There is 3x3 board to create a pattern by dragging the mouse cursor. The pattern has to be
confirmed by dragging the mouse cursor again.
Apply - saves settings.

NHDR-4304-H1, NHDR-4308-H1 Quick start guide version 1.0
All rights reserved © AAT SYSTEMY BEZPIECZEŃSTWA Sp. z o.o.
16
DVR OPERATING
Draw - the function shows when Unlock Pattern function is enabled. It allows to create an unlock
pattern. There is 3x3 board to create a pattern by dragging the mouse cursor. The pattern has to be
confirmed by dragging the mouse cursor again.
Apply - saves settings.
The next step is to log in using the created user data.
The Password button switch to login window using defined password.
The Pattern button switch back to previous window.
After authentication the First Launch Wizard opens.

NHDR-4304-H1, NHDR-4308-H1 Quick start guide version 1.0
All rights reserved © AAT SYSTEMY BEZPIECZEŃSTWA Sp. z o.o.
17
DVR OPERATING
3.3 Frist Launch Wizard
The first launch wizard provides a quick way to configure basic DVR settings.
When the Start Wizard will be pressed, subsequent sections of the wizard will appear.
The Next and Previous buttons allow to toggle between consecutive sections. The Cancel button exits
the wizard without saving any changes.
3.3.1.Network Settings

NHDR-4304-H1, NHDR-4308-H1 Quick start guide version 1.0
All rights reserved © AAT SYSTEMY BEZPIECZEŃSTWA Sp. z o.o.
18
DVR OPERATING
This section contains basic network settings:
DHCP - enable network settings retrieval from a DHCP server.
IP Address - network address of the recorder in the local IPv4 network.
Subnet Mask - number dividing in IP address the network part in IPv4 network.
Gateway - IP address of the router for Internet connection in IPv4 network.
IPv6 Address - network address of the recorder in the local IPv6 network and its mask.
IPv6 Gateway - IP address of the router for Internet connection in IPv6 network.
DNS1 - domain server address.
DNS2 - alternative domain server address.
Web Port- the port used to connect with the DVR network plugin by Internet Explorer browser.
Client Port - the port used to connect with the DVR by NHDR-5000Viewer, NMS, RxCamView.
RTSP Port - the port used for RTSP streaming from DVR.
HTTPS - the port used while the connection with HTTPS protocol.
UPNP - enable the UPnP discovery feature. The UPnP function must be supported by the router.
UPNP Status - informs if the UPnP function is active for the port (Active or Inactive).
3.3.2.Time and date settings
This section contains all the date and time options of the recorder.
Date - select day from calandar.
Time - current DVR time. It can be written manually.
Date Format - dispaly format of the date (MM/DD/YY, YY-MM-DD, DD/MM/YY).
Time Format - display format of time (12Hour or 24 Hour).
Time Zone - display a time zone depending on the region.

NHDR-4304-H1, NHDR-4308-H1 Quick start guide version 1.0
All rights reserved © AAT SYSTEMY BEZPIECZEŃSTWA Sp. z o.o.
19
DVR OPERATING
The recorder allows to synchronize time with the NTP server. The server can be selected from
drop-down list. The User-Deifined option allows to enter any IP address of the time server.
The correct network settings and connection are required to allow communication with the NTP
server.
The recorder allows to set daylight saving time.
Time Offset - defines time advancing (1Hour, 2Hour).
DST Mode - defines method of switching by specified Week, or by specified Day.
Start Time - defines first day of DST.
End Time - defines last day of DST.
3.3.3.Adding IP cameras
The next section allows to add IP channels to the recorder. The DVR automatically searches all IP
cameras, NHDR-4000 and NVR-4000 from Novus in local IP network.
There is a list of found devices on the left side, list of connected devices on the right side.

NHDR-4304-H1, NHDR-4308-H1 Quick start guide version 1.0
All rights reserved © AAT SYSTEMY BEZPIECZEŃSTWA Sp. z o.o.
20
DVR OPERATING
The Search button starts researching IP devices. The recorders IP addresses are with sign,
which allow to add separated channels from recorders. If a channel has already been added from the
recorder, then its IP address is indicated by a red color.
There is an arrow in the center of the window which allow to add channels.
If there are selected multiple channels, the following dialog box appears to add a group with the same data.
