SQF
Square Single High Temperature Fan
400°C for 2 hrs
Installation Manual
1.0 SAFETY INFORMATION
• The provision of the electrical supply and the connection of the unit to the mains must be
carried out by a qualified electrician.
• Isolate from power supply before removing any covers. During installation / maintenance ensure
all covers are fitted before switching on the mains supply.
• All-pole disconnection from the mains as shown in the wiring diagram must be incorporated
within the fixed wiring and shall have a minimum contact separation of 3mm in accordance with
latest edition of the wiring regulations.
• This unit must be earthed.
• Ducting must be securely fixed with screws to the spigot to prevent access to live parts. Duct
runs terminating close to the fan must be adequately protected by suitable guards.
• If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or
similarly qualified persons in order to avoid a hazard.
• Precautions must be taken to avoid the back-flow of gases into the room from the open flue of
gas or other fuel-burning appliances.
• This appliance should not be used by children or persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge, unless they have been given supervision
or instruction concerning the safe use of the appliance by a person responsible for their safety.
Children shall not play with the appliance. Cleaning and user maintenance shall not be carried
out by children.
1.1 Hazard Symbols
GENERAL WARNING
Signifies a general warning regarding hazard specified by supplementary information.
ELECTRIC SHOCK
This unit must be completely electrically isolated before any panels are removed. Check
mains supply and control connections.
ROTATING PARTS
This unit contains fast moving rotational parts which may start automatically. It is the
sole responsibility of the installer to adequately guard these components.
REFER TO INSTRUCTION MANUAL
Read and understand the installation and maintenance manual before installing,
operating or maintaining this product.

01. 08. 22. Document Number 671834 2
Nuaire | Western Industrial Estate | Caerphilly | CF83 1NA | nuaire.co.uk
SQF
Installation Manual
1.2 Important Information
This manual contains important information on the safe and
appropriate assembly, transport, commissioning, operation,
maintenance, disassembly and simple troubleshooting of the product.
While the product has been manufactured according to the accepted
rules of current technology, there is still a danger of personal injury or
damage to equipment if the following general safety instructions and
the warnings contained in these instructions are not complied with.
•Read these instructions completely and thoroughly before
working with the product.
•Keep these instructions in a location where they are accessible
to all users at all times.
•Always include the operating instructions when you pass the
product on to third parties.
1.3 Personal Protective Equipment
The following minimum Personal Protective Equipment (PPE) is
recommended when interacting with Nuaire product:
•Protective Steel Toed Shoes - when handling heavy objects.
•Full Finger Gloves (Marigold PU800 or equivalent) - when
handling sheet metal components.
•Semi Fingerless Gloves (Marigold PU3000 3DO or equivalent)
- when conducting light work on the unit requiring tactile
dexterity.
•Safety Glasses - when conducting any cleaning/cutting operation
or exchanging filters.
•Reusable Half Mask Respirators - when replacing filters which
have been in contact with normal room or environmental air.
Nuaire would always recommend a site specific risk assessment by a
competent person to determine if any additional PPE is required.
2.0 INTRODUCTION
The SQF range of fans are designed for in-duct applications.
Manufactured from galvanised steel, they are suitable for in or outdoor
installation and can be installed in a horizontal or vertical attitude.
For full unit description, dimensional, weight and performance details
refer to Nuaire catalogue.
The units are designed for: S1 DUTY - Day to day operation and in the
event of fire a one off emergency use.
EN12101-3 compliant, refer to EC certificate of conformity, 0086-CPR-
672476.
2.1 Code Description
1 2 3 4
SQF 45 T
1. Range: Square Single In-line Fan
2. Motor Poles: 4 or 6
3. Size: 1, 2, 3, 4, 5 or 6 (4 Pole Motors)
1, 2, 3 or 4 (6 Pole Motors)
4. Control Type: No Suffix = Speed Controllable
T = Two Speed Motor Control
3.0 DELIVERY & HANDLING
All equipment is inspected prior to despatch and leaves the factory in
good condition. Upon receipt of the equipment an inspection should
be made and any damage indicated on the delivery note. Particulars of
damage and/or incomplete delivery should be endorsed by the driver
delivering the goods before offloading by the purchaser.
No responsibility will be accepted for damage sustained during the
offloading from the vehicle or on the site thereafter. All claims for
damage and/or incomplete delivery must be reported to Nuaire within
two days of receipt of the equipment.
Always handle the units carefully to avoid damage and distortion. If
mechanical aids are used to lift the unit, spreaders should be employed
and positioned so as to prevent the slings, webbing etc. making contact
with the casing.
Note the weight from the rating plate, lift using slings attached to the
four lifting eyes as (Figure 1).
Care must be taken when handling a unit/attenuator assembly
fitted with flexible connectors as the connectors can be distorted or
damaged.
1 Lifting Unit Via Lifting Eyes

01. 08. 22. Document Number 671834 3
Nuaire | Western Industrial Estate | Caerphilly | CF83 1NA | nuaire.co.uk
SQF
Installation Manual
4.0 INSTALLATION
Installation must be completed by competent persons, in accordance
with good industry practice and should conform to all governing and
statutory bodies regulations i.e. IEE, CIBSE, etc. and EN standards etc.
Before commencing installation check that all material, including
mounting feet and optional ancillaries are available to complete the
work. Every unit is tested and serialised at works and a test certificate
produced, the details are also recorded on the fan side rating plate
which should also be referred to before handling and installation. Any
damage or deviations should be immediately reported to the seller/
supplier/agent quoting the order and rating plate details.
Ensure that there is adequate clearance for the removal of the
motor/fan assembly for maintenance purposes.
The list below states the main characteristics of the SQUIF fan range
certified for operation at 400°c for 2 hours. The unit:
•Is thermally uninsulated.
•Only suitable for non-smoke reservoir applications.
•Is dual purpose i.e. suitable for day-to-day operation and one-off
emergency use.
•Suitable for mounting in horizontal and vertical orientation only.
4.1 Mechanical Installation
Fans are suitable for both internal and external installation and whilst
they can be installed in either the recommended vertical (installation
type A) or alternative horizontal (installation type B) attitude, the
standard brackets provided are suitable only for the more conventional
vertical (A) mounting position.
Where silencers are to be fitted to the unit (for all sizes except
SQF41), installation type A should be used to ensure silencer
splitters are vertically orientated (Figure 2). SQF41 silencers are
square and can be rotated to ensure vertical orientation in either
installation type.
For horizontal (B) mounting (Figure 3), observe the centre of gravity
(approximately 100 - 150mm left of flange) and fit an angle bracket
or unistrut steel bar (not supplied) to brace the unit. Fit AV mounts
equidistant of CG line and at a safe distance so as to level unit.
Rotate the fan impeller by hand to ensure free and smooth rotation and
that no handling or transit damage has occurred, observe the direction
of flow/direction of rotation arrow and ensure that:
•All optional accessories such as support brackets, attenuators,
guards, flexible connectors etc. are assembled to the fan.
•Support brackets are fitted appropriate for the installed attitude -
vertical or horizontal.
•When offering the fan to the ducted system that both inlet and
outlet connections are perfectly aligned.
It is advisable to fit flexible connectors on either side of the fan
unless there is an open-ended inlet or discharge and the fan should
be supported on Anti-Vibration mounts (A.V.'s). The A.V.'s should be
levelled off to maximise isolation and the flexible connectors correctly
aligned with the fan at the correct tension.
A.V. mounts isolate the fan only. Silencers / backdraught dampers
and other "significant mass" accessories should form part of the
fixed ductwork after the flexible connection.
Bracket
A
Note: Installation A silencer
splitters are vertical
2 Recommended Installation - Vertically Mounted Unit - End View
(Bracket By Others)
Bracket
Approx
CG line
AV’s equidistant of CG
Note: Installation B silencer
splitters are horizontal (except SQF41)
B
3 Non-recommended Installation - Horizontally Mounted Unit - End
View (Bracket By Others)
4.2 Electrical Installation
Units are not supplied with electrical isolators, their selection and
provision is the responsibility of the installer.
When the unit is operated in emergency mode smoke extract
operation - all controls must be bypassed.
Ensure the electrical supply is suitable for the fan and that all the wiring,
fuses and overload protection etc. is appropriately sized by comparing
with the rating plate.
Electrical connection is made direct to the motor on all three phase
fans and to a termination box on single phase fans. Where a starter,
speed control, frequency inverter or Ecosmart control is used also refer
to the control installation manual.
It is essential to note that for all three phase motors of 4kW and above
the final connection must be DELTA and:
•If a star/delta starter is to be used connect the six motor
terminals directly to the starter.
•If a frequency inverter or Ecosmart speed control is to be used
connect in DELTA.
•If the fan is to be started direct on line (D.O.L) connect the
motor in DELTA.
4.3 Electrical installation - Motors
Motors are totally enclosed and protected to IP55 (Dust and low
pressure water jets).
Please note the requirements for maintenance of the motor. Failure to
comply with regulations will invalidate any warranty claim.

01. 08. 22. Document Number 671834 4
Nuaire | Western Industrial Estate | Caerphilly | CF83 1NA | nuaire.co.uk
SQF
Installation Manual
4.4 Wiring
Single Phase units with 0.37KW, 0.75KW and 1.1KW motors,
connections are made to the fan side termination box.
3 phase motors are connected directly to the motor terminal box.
3 phase dual wound motors require a two contactor control.
3 phase two speed TAP/PAM wound motors require a three contactor
control.
Fan Unit
L N
230V 1 phase 50 Hz supply only
X L N
4 Wiring - Single Phase - Single Speed
U1 V1 W1
L1
380V 3 phase 60Hz supply
400V 3 phase 50Hz supply
460V 3 phase 60Hz supply
L2 L3 E
W2 U2 V2
5 Wiring - Three Phase (3kW and Below) - Single Speed
W2
L1
U2
L2
V2
L3 E
U1 V1 W1
380V 3 phase 60Hz supply
400V 3 phase 50Hz supply
460V 3 phase 60Hz supply
6 Wiring - Three Phase (4kW and Above) - Single Speed
1U
1V
1W
2U
2V
2W
Motor
terminal
box
380V 3 phase 60Hz supply
400V 3 phase 50Hz supply
460V 3 phase 60Hz supply
L1
L2
Low
Speed
High
Speed
L3
L1
L2
L3
7 Wiring - Three Phase - Two Speed Dual Wound Motor D.O.L.
Starting (Both Speeds), Observe Motor Plate & Connection Details
Motor Terminal Box
Note: High Speed -
Supply: 2U 2V 2W
Link: 1U 1V 1W
Low Speed -
Supply: 1U 1V 1W
1U 1V 1W
400V 3 phase 50Hz supply
C1 C2 C3
L1 L2 L3
A1
A2 A2 A2
A1 A1
1 3 5 1 3 5 1 3 5
2 4 6 2 4 6 2 4 6
2U 2V 2W
E
For low speeds connect
Contactor C1
For High speed connect
Contactor C2 and C3
380V 3 phase 60Hz supply
460V 3 phase 60Hz supply
8 Wiring - Three Phase - Two Speed TAP/PAM Wound Motor
4.5 Inverter Control
Where fans are connected to frequency inverter controls, the electrical
supply to the fan must bypass the inverter under fire conditions.
Screened cable must be used. Maximum length should be 30m and
must be earthed at both ends and continually earthed through any
insulators.
L1 L2 L3
PE/L/L2 L1 UN/L3 V W
3 Phase only
INVERTER SPEED CONTROL
Connections
to motor
Motor
3 phase
3 Phase input
380V 3 phase 60Hz supply
400V 3 phase 50Hz supply
460V 3 phase 60Hz supply
9 Wiring - Three Phase - Matched Frequency Inverter - Single Speed

01. 08. 22. Document Number 671834 5
Nuaire | Western Industrial Estate | Caerphilly | CF83 1NA | nuaire.co.uk
SQF
Installation Manual
5.0 SPECIFIC COMMISSIONING AND SERVICING
REQUIREMENTS
400°C for 2 hours Units for Smoke Extract
Exposure temperature/time: 400°C for 2 hours
These units are used to provide a SAFETY FUNCTION for people
in the event of fire in public premises or in the home: they are
therefore subject to strict constraints concerning their operating and
maintenance.
Operating Constraints
i. Check on the nameplate that the selected unit corresponds to the
maximum exposure temperature and duration.
ii. Non ventilated motors MUST be placed in the airflow from the driven
fan. Ventilated motors can be placed outside the flow.
iii. AFTER THE UNIT HAS BEEN SUBJECTED TO ONE EMERGENCY
DUTY OPERATION, IT MUST BE REPLACED.
iv. With variable speed control. Ensure that the maximum speed never
exceeds the speed of the motor supplied by the mains and that the
delivered power corresponds to the previous definitions. The unit
should be equipped with PTC thermistors connected to the protection
system during S1 duty and switched off during S2 duty (operation
during an emergency).
These qualifications ensure the qualification of the driven fan by the
manufacturer.
Maintenance Constraints
Regular service visits must be performed on the installation AT
LEAST EVERY 6 MONTHS, incorporating the following checks:
i. Checking the insulation resistance (R>100 MOhms, 500V DC)
•If the drain holes are blocked, open them to eliminate any
accumulated condensation.
•If R<100 MOhms, dry the stator in an oven and check the
insulation resistance. If the fault persists, replace the stator.
•The stator must be replaced 5 years after installation or after
20,000 hours of operation.
ii. Cooling check
•Ensure there is no dust or grease in the entire ventilation circuit
(housing fins, motor cover/fan if fitted driven fan).
•Ensure the motor runs normally when switched on for a few
minutes.
iii. Bearing check (C3 or C4 play)
Run the motor during each maintenance visit. When the motor is cold,
a high level of noise may be caused by the texture of the grease. This
does not indicate a bearing fault.
S2 duty only:
The bearings must be replaced by an identical type every 5 years.
Ensure the motor runs normally when switched on for a few minutes.
S1 duty and Emergency in S2 duty:
a) Permanently greased bearings.
400°C range; replace on 2 pole motors after 10,000 hours of operation
and on motors with 4 poles or more after 20,000 hours.
b) Re-greaseable bearings
The information on the motor nameplates must be strictly respected
(grease quantity, grease quality and re-greasing frequency).
The bearings must be replaced after 20,000 hours of operation.
6.0 MAINTENANCE
Isolation - Before commencing work make sure that the unit and
Nuaire control are electrically isolated from the mains supply.
Ensure that all mechanical and electrical connections and fixings are
secure and that inlet and outlet ductwork is free of any obstruction or
debris.
Briefly switch the fan on/off to ascertain correct direction of impeller
rotation, compare with the rotational label fitted and correct if
necessary.
Complete the test by running the fan for approximately 15 minutes,
taking and comparing voltage, full load and starting currents with the
fan rating label. Monitor flexible connections to ensure no leakage and
AV mounts for correct alignment.
It is important that maintenance checks are recorded and that the
schedule is always adhered to, in all cases, the previous report should
be referred to.
6.1 Routine Maintenance
•Clean all areas of unit and treat any areas of corrosion.
•Check all access doors for leakage and if necessary locks should be
adjusted and any replacement gasket materials should be replaced
as required.
•Check that safety grilles are secure and free of obstruction.
6.2 Semi-Annually
•Thoroughly inspect the unit and its components for corrosion,
acting immediately to treat/restore any damaged areas.
•All electrical terminals within the unit should be tightened.
•Check all earth connections.
•Check resilient mounts (where applicable) and replace any that
have any wear or deterioration.
•Check motor for undue wear, signs of overheating and apply
winding insulation and continuity tests.
6.3 Lubrication
Motors are fitted with sealed for life bearings and do not require any
lubrication.
6.4 Motor Repair
Due to unit certification EN12101-3 and in compliance with the
construction products directive, the motor must be returned to the
motor manufacturer for replacement.WARRANTY
The 3 year warranty starts from the day of delivery and includes parts
and labour for the first year. The labour element is subject to full,
free and safe access to the equipment as recommended by the CDM
regulations. The remaining two years covers replacement parts only.
This warranty is void if the equipment is modified without
authorisation, is incorrectly applied, misused, disassembled, or not
installed, commissioned and maintained in accordance with the details
contained in this manual and general good practice.
The product warranty applies to the UK mainland and in accordance
with Clause 14 of our Conditions of Sale. Customers purchasing from
outside of the UK should contact Nuaire International Sales office for
further details.
Failure to maintain the unit as recommended will invalidate the
warranty.

01. 08. 22. Document Number 671834 6
Nuaire | Western Industrial Estate | Caerphilly | CF83 1NA | nuaire.co.uk
SQF
Installation Manual
7.0 END-OF-LIFE AND RECYCLING
Where possible Nuaire use components which can be largely recycled
when the product reaches its end-of-life:
•Fans, motors, controls, actuators, cabling and other electrical
components can be segregated into WEEE recycling streams.
•Sheet metal parts, aluminium extrusion, heating/cooling coils and
other metallic items can be segregated and fully recycled.
•Cardboard packaging, wood, used filters and other paper
components can be largely recycled or fully processed in energy
from waste centres.
•Remaining items can be further segregated for energy from waste
centres or, as a last resort, sent to landfill. Please call After Sales
Support for further information on items not listed above.
Ensure that Nuaire product is made safe from any electrical / water
/ refrigerant supplies before dismantling commences. This work
should only be undertaken by a qualified person in accordance with
local authority regulations and guidelines, taking into account all
site based risks.
8.0 AFTER SALES AND REPLACEMENT PARTS
For technical assistance or further product information, including spare
parts and replacement components, please contact the After Sales
Department.
If ordering spares please quote the serial number of the unit together
with the part number, if the part number is not known please give a full
description of the part required. The serial number will be found on the
identification plate attached to the unit casing.
Telephone [phone]
[e-mail]
Technical or commercial considerations may, from time to time,
make it necessary to alter the design, performance and dimensions
of equipment and the right is reserved to make such changes without
prior notice.

01. 08. 22. Document Number 671834 7
Nuaire | Western Industrial Estate | Caerphilly | CF83 1NA | nuaire.co.uk
SQF
Installation Manual
All parts except for moving parts requiring the correct installation of safety guards
or incorporation into ducts or building fabrications acting as guards comply with
the essential requirements of the Machinery Directive. The machinery shall not be
put into service until the system has been declared to be in conformity with the
provisions of the EC Machinery Directive 1.3.7 to 1.3.8.2 relating to guards/moving
parts.
Product: SQUIF In-Line Fan
Type: SQF
Installation Manual Serial no.: 671834
Relevant EU Council Directives: 2006/42/EC (MACHINERY DIRECTIVE);
Applied EU Harmonised Standards: EN 60204-1; EN ISO 12100; EN ISO 13857;
EN ISO 9001.
Relevant Directives specified in 2014/30/EU (EMC);
EU Declaration of Conformity: 2011/65/EU (RoHS) incl. (EU) 2015/863;
2009/125/EC (ErP) Reg (EU) no. 327/2011;
CP Regulation (EU) No. 305/2011.
EU DECLARATION OF INCORPORATION AND INFORMATION FOR SAFE INSTALLATION,
OPERATION AND MAINTENANCE
INFORMATION FOR SAFE INSTALLATION, OPERATION AND MAINTENANCE
OF NUAIRE VENTILATION EQUIPMENT
To comply with EC Council Directives 2014/30/EU (EMC), 2006/42/EC (Machinery Directive). To be
read in conjunction with the relevant product documentation (see 2.1).
1.0 GENERAL
1.1 The equipment referred to in this Declaration of Incorporation is supplied by Nuaire to be assembled into
a ventilation system which may or may not include additional components.
The entire system must be considered for safety purposes and it is the responsibility of the installer to ensure
that all of the equipment is installed in compliance with the manufacturers recommendations and with due
regard to current legislation and codes of practice.
2.0 INFORMATION SUPPLIED WITH THE EQUIPMENT
2.1 Each item of equipment is supplied with a set of documentation which provides the information required for
the safe installation and maintenance of the equipment.
This may be in the form of a Data sheet and/or Installation and Maintenance instruction.
2.2 Each unit has a rating plate attached to its outer casing.The rating plate provides essential data relating to
the equipment such as serial number, unit code and electrical data. Any further data that may be required will
be found in the documentation.
If any item is unclear or more information is required, contact Nuaire.
2.3 Where warning labels or notices are attached to the unit the instructions given must be adhered to.
3.0 TRANSPORTATION, HANDLING AND STORAGE
3.1 Care must be taken at all times to prevent damage to the equipment. Note that shock to the unit may result
in the balance of the impeller being affected.
3.2 When handling the equipment, care should be taken with corners and edges and that the weight distribution
within the unit is considered. Lifting gear such as slings or ropes must be arranged so as not
to bear on the casing.
3.3 Equipment stored on site prior to installation should be protected from the weather and steps taken to
prevent ingress of contaminants.
4.0 OPERATIONAL LIMITS
4.1 It is important that the specified operational limits for the equipment are adhered to e.g. operational air
temperature, air borne contaminants and unit orientation.
4.2 Where installation accessories are supplied with the specified equipment e.g. wall mounting brackets. They
are to be used to support the equipment only.
Other system components must have separate provision for support.
4.3 Flanges and connection spigots are provided for the purpose of joining to duct work systems.They must not
be used to support the ductwork.
4.4 Local Environment - Humidity. Ambient humidity (the humidity at the unit’s installed location) shall be
within the range: 10 to 95% (for controls, non-condensing).
Air humidity (the humidity of the air passing through the unit) shall be within the range: 10 to 95% (for
controls, non-condensing).
5.0 INSTALLATION REQUIREMENTS
In addition to the particular requirements given for the individual product, the following general requirements
should be noted.
5.1 Where access to any part of equipment which moves, or can become electrically live are not prevented by
the equipment panels or by fixed installation detail (e.g. ducting), then guarding to the appropriate standard
must be fitted.
5.2 The electrical installation of the equipment must comply with the requirements of the relevant local
electrical safety regulations.
5.3 For good EMC engineering practice all control and sensor cables should not be placed within
50mm of 230V cables.
5.4 For fans with electronic speed control, protection against surges L/N-E is recommended on the supply.
5.5 Fans with electronic speed/inverter control should be connected to an Industrial not Public Low Voltage
supply.
6.0 COMMISSIONING REQUIREMENTS
6.1 General pre-commissioning checks relevant to safe operation consist of the following:
Ensure that no foreign bodies are present within the fan or casing.
Check electrical safety e.g. Insulation and earthing.
Check guarding of system.
Check operation of Isolators/Controls.
Check fastenings for security.
6.2 Other commissioning requirements are given in the relevant product documentation.
7.0 OPERATIONAL REQUIREMENTS
7.1 Equipment access panels must be in place at all times during operation of the unit, and must be secured with
the original fastenings.
7.2 If failure of the equipment occurs or is suspected then it should be taken out of service until a competent
person can effect repair or examination (Note that certain ranges of equipment are designed
to detect and compensate for fan failure).
8.0 MAINTENANCE REQUIREMENTS
8.1 Specific maintenance requirements are given in the relevant product documentation.
8.2 It is important that the correct tools are used for the various tasks required.
8.3 If the access panels are to be removed for any reason the electrical supply to the unit must be isolated.
8.4 A minimum period of two minutes should be allowed after electrical disconnection before access panels are
removed. This will allow the impeller to come to rest.
NB: Care should still be taken however since airflow generated at some other point in the system can
cause the impeller to “windmill” even when power is not present.
8.5 Care should be taken when removing and storing access panels in windy conditions.
The relevant technical documentation has been compiled in accordance with Annex
VII (Part 7 of Schedule 2), part B. We undertake, in response to a reasoned request, to
supply it in electronic form to the market surveillance authorities within a reasonable
period.
Signature of manufacture representatives:
Name: Position: Date:
1) A. Thomas Technical Director 30. 10. 20
2) C.Sargent Manufacturing Director 30. 10. 20
Basis of Self Attestation: BS EN ISO 9001, BSI Cert No. FM 665203
Nuaire: A Trading Division of Polypipe, Western Industrial Estate, Caerphilly, CF83 1NA.
EU Authorised Representative: Eurolink Europe Compliance Limited, 25 Herbert Place,
Dublin D02 AY86, Republic of Ireland.
All Standards used were current and valid at the date of signature.

01. 08. 22. Document Number 671834 8
Nuaire | Western Industrial Estate | Caerphilly | CF83 1NA | nuaire.co.uk
SQF
Installation Manual
INFORMATION FOR SAFE INSTALLATION, OPERATION AND MAINTENANCE
OF NUAIRE VENTILATION EQUIPMENT
All parts except for moving parts requiring the correct installation of safety guards
or incorporation into ducts or building fabrications acting as guards comply with the
essential requirements of the Machinery (Safety) Regulations. The machinery shall
not be put into service until the system has been declared to be in conformity with
the provisions of the Supply of Machinery Regulations 2008 clauses 1.3.7 to 1.3.8.2
relating to guards/moving parts.
Product: SQUIF In-Line Fan
Type: SQF
Installation Manual Serial no.: 671834
Relevant UK Regulations: 2008 No. 1597, The Supply of Machinery
(Safety) Regulations 2008;
Applied UK Harmonised Standards: BS EN 60204-1; BS EN ISO 12100;
BS EN ISO 13857; BS EN ISO 9001.
Relevant Regulations specified in No. 1091, EMC Regulations 2016;
UKCA Declaration of Conformity: No. 3032, RoHS regulation 2012;
No. 2617, ErP Regulation 2010;
No. 1359, CP Regulation 2020.
To comply with UK Regulations:The Supply of Machinery (Safety) Regulations 2008 No. 1597; and Electromagnetic
Compatibility Regulations 2016 No. 1091.To be read in conjunction with the relevant product documentation (see 2.1)
1.0 GENERAL
1.1 The equipment referred to in this Declaration of Incorporation is supplied by Nuaire to be assembled into
a ventilation system which may or may not include additional components.
The entire system must be considered for safety purposes and it is the responsibility of the installer to ensure
that all of the equipment is installed in compliance with the manufacturers recommendations and with due
regard to current legislation and codes of practice.
2.0 INFORMATION SUPPLIED WITH THE EQUIPMENT
2.1 Each item of equipment is supplied with a set of documentation which provides the information required for
the safe installation and maintenance of the equipment.
This may be in the form of a Data sheet and/or Installation and Maintenance instruction.
2.2 Each unit has a rating plate attached to its outer casing.The rating plate provides essential data relating to
the equipment such as serial number, unit code and electrical data. Any further data that may be required will
be found in the documentation.
If any item is unclear or more information is required, contact Nuaire.
2.3 Where warning labels or notices are attached to the unit the instructions given must be adhered to.
3.0 TRANSPORTATION, HANDLING AND STORAGE
3.1 Care must be taken at all times to prevent damage to the equipment. Note that shock to the unit may result
in the balance of the impeller being affected.
3.2 When handling the equipment, care should be taken with corners and edges and that the weight distribution
within the unit is considered. Lifting gear such as slings or ropes must be arranged so as not
to bear on the casing.
3.3 Equipment stored on site prior to installation should be protected from the weather and steps taken to
prevent ingress of contaminants.
4.0 OPERATIONAL LIMITS
4.1 It is important that the specified operational limits for the equipment are adhered to e.g. operational air
temperature, air borne contaminants and unit orientation.
4.2 Where installation accessories are supplied with the specified equipment e.g. wall mounting brackets. They
are to be used to support the equipment only.
Other system components must have separate provision for support.
4.3 Flanges and connection spigots are provided for the purpose of joining to duct work systems.They must not
be used to support the ductwork.
4.4 Local Environment - Humidity. Ambient humidity (the humidity at the unit’s installed location) shall be
within the range: 10 to 95% (for controls, non-condensing).
Air humidity (the humidity of the air passing through the unit) shall be within the range: 10 to 95% (for
controls, non-condensing).
5.0 INSTALLATION REQUIREMENTS
In addition to the particular requirements given for the individual product, the following general requirements
should be noted.
5.1 Where access to any part of equipment which moves, or can become electrically live are not prevented by
the equipment panels or by fixed installation detail (e.g. ducting), then guarding to the appropriate standard
must be fitted.
5.2 The electrical installation of the equipment must comply with the requirements of the relevant local
electrical safety regulations.
5.3 For good EMC engineering practice all control and sensor cables should not be placed within
50mm of 230V cables.
5.4 For fans with electronic speed control, protection against surges L/N-E is recommended on the supply.
5.5 Fans with electronic speed/inverter control should be connected to an Industrial not Public Low Voltage
supply.
6.0 COMMISSIONING REQUIREMENTS
6.1 General pre-commissioning checks relevant to safe operation consist of the following:
Ensure that no foreign bodies are present within the fan or casing.
Check electrical safety e.g. Insulation and earthing.
Check guarding of system.
Check operation of Isolators/Controls.
Check fastenings for security.
6.2 Other commissioning requirements are given in the relevant product documentation.
7.0 OPERATIONAL REQUIREMENTS
7.1 Equipment access panels must be in place at all times during operation of the unit, and must be secured with
the original fastenings.
7.2 If failure of the equipment occurs or is suspected then it should be taken out of service until a competent
person can effect repair or examination (Note that certain ranges of equipment are designed
to detect and compensate for fan failure).
8.0 MAINTENANCE REQUIREMENTS
8.1 Specific maintenance requirements are given in the relevant product documentation.
8.2 It is important that the correct tools are used for the various tasks required.
8.3 If the access panels are to be removed for any reason the electrical supply to the unit must be isolated.
8.4 A minimum period of two minutes should be allowed after electrical disconnection before access panels are
removed. This will allow the impeller to come to rest.
NB: Care should still be taken however since airflow generated at some other point in the system can
cause the impeller to “windmill” even when power is not present.
8.5 Care should be taken when removing and storing access panels in windy conditions.
DECLARATION OF INCORPORATION AND INFORMATION FOR SAFE INSTALLATION,
OPERATION AND MAINTENANCE
The relevant technical documentation has been compiled in accordance with Annex
VII (Part 7 of Schedule 2), part B. We undertake, in response to a reasoned request, to
supply it in electronic form to the market surveillance authorities within a reasonable
period.
Signature of manufacture representatives:
Name: Position: Date:
1) A. Thomas Technical Director 01. 01. 21
2) C.Sargent Manufacturing Director 01. 01. 21
Basis of Self Attestation: BS EN ISO 9001, BSI Cert No. FM 665203
Nuaire: A Trading Division of Polypipe, Western Industrial Estate, Caerphilly, CF83 1NA.
All Standards used were current and valid at the date of signature.
