NuAire Genie Plus GPE-100 Series Instruction Manual

Isolation - Before commencing work make sure that the unit,
switched live and uaire control are electrically isolated from
the mains supply.
111. 05. 17. Leaflet Number 671742
Figure 3. Fan Dimensions (mm)
170
170
110
9
72
The EMC Directive
2014/30/EU
The Low Voltage
Directive
2014/35/EU
Fig. 1a. Removing front facia. Fig. 1b. remove 4 screws and front half.
Fig. 2. Pass the supply cable through the cable entry point.
Genie Plus GPE-100 Range
Centrifugal Wall/Ceiling Mounted
Toilet and Bathroom Fans
Installation and Maintenance
99
69
IPX4
1.0 Introduction
These high quality extractor fans are designed to provide effective
ventilation. To achieve this, please read these instructions carefully
BEFORE installing the fan unit. Failure to comply with these
instructions could reduce both the life and performance of the
product and may invalidate the warranty.
This product is suitable for use with up to a maximum of 6.0m of
rigid ducting. (Flexible ducting is not recommended).
This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack
of experience and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way and understand
the hazards involved. Children shall not play with the appliance. Cleaning
and user maintenance shall not be made by children without supervision.
2.0 Installation
The installation must be completed by competent persons in
accordance with good industry practice and should conform to all
governing and statutory bodies i.e. IEE, CIBSE, HVCA etc.
Before commencing any work read the following instructions carefully
and ensure you have the necessary competency to complete the work
safely.
1. Select a suitable position for t e fan t at keeps t e duct as s ort
and as straig t as possible (ideally on t e ceiling or on a wall wit in
400mm of t e ceiling).
2. Cut a ole in t e wall to suit t e outside diameter of t e ducting or
wall-liner. Install t e duct or wall-liner taking care to seal at bot
ends between it and t e wall using proprietary waterproof mastic.
If required, connect furt er ducting to t e wall-liner, sealing
between eac joint or fitting.
3. Remove t e front cover of t e fan by pulling straig t off t e fan
body (Fig. 1a and 1b).
4. Remove and retain t e bag containing four Posidriv® screws for
retaining t e body moulding to t e back-plate (Fig. 1b) and t e
cable clamp and screws.
5. Locate t e fan back-plate into t e wall-liner/duct and mark t e four
retaining screw positions (Fig. 2). Fit screw anc ors suitable for
t e wall construction.
6. Install t e fan taking care to pass t e supply cable t roug t e cable
entry point in t e fan back-plate moulding (Fig. 2).
7. Complete t e wiring by following t e relevant wiring diagram on
t e following page (Fig. 4).
8. Assemble t e fan body to t e back-plate and clip on t e front cover.
3.0 Dimensions
Nuaire: A Trading Division of Polypipe Limited Western Industrial Estate Caerphilly United Kingdom CF83 1NA
T: 029 2088 5911 F: 029 2088 7033 E: [email protected] W: www.nuaire.co.uk

Isolation - Before commencing work make sure that the unit
is electrically isolated from the mains supply.
If in doubt consult an electrician.
4.0 Wiring Instructions
Disconnection from the supply mains must be incorporated within the
fixed wiring in accordance with the wiring regulations and shall have a
minimum contact separation of 3mm in accordance with the latest
edition of the IEE Wiring Regulations.
Only GPE-100-12 SELV models are suitable for shower cubicles or
zones 1 & 2 (in this range).
SL = 230Vac Switched Live L = 230Vac Permanent Live = eutral
Unit Serving Bathroom GPE-100 Figure 4a. Wiring.
Unit Serving Bathroom GPE-100-HPC via pullcord
(Auto humidity only) Figure 4b. Wiring.
Unit Serving Bathroom GPE-100-T / GPE-100-HPC via remote
switch (Optional timer operation) Figure 4c. Wiring.
5.0 Operation
Overrun timer adjustment – models fitted with overrun
timers only
Before making any adjustments, isolate the fan from the power supply.
Remove the front cover and the body moulding. Locate the ‘jumper’ on
the relevant set of pins to achieve the desired run-on time (see Fig. 4d).
Humidity adjustment – humidistat models only
All GP humidistat fans automatically sense a rapid change in humidity
and adjust accordingly. The humidity control does not require manual
adjustment. Humidistat fans, when energised for the first time, will run
and time out as part of the stabilising process.
Performance: 19 l/s at 0 Pa – 91 Pa at 0 l/s
Rating: 230V 50Hz 7.4W IPX4
This product is double insulated and does not require an earth conductor.
Maximum room temperature 40ºC.
Range:
GPE-100 Standard
GPE-100-T Overrun timer
GPE-100-HPC Humidistat and optional overrun timer and
pull-cord switch override
6.0 Maintenance
The fan unit does not require any maintenance. However, for
optimum performance, it is advisable to remove any accumulated
dust with a low power vacuum cleaner.
ote: Installation and Maintenance of the equipment must
be as directed in the instructions provided with the unit.
7.0 Warranty
The 5 year warranty starts from the day of delivery and includes
parts and labour for the first year. The remaining 4 years covers
replacement parts only.
This warranty is void if the equipment is modified without
authorisation, is incorrectly applied, misused, disassembled, or not
installed, commissioned and maintained in accordance with the details
contained in this manual and general good practice.
The product warranty applies to the UK mainland and in accordance
with Clause 14 of our Conditions of Sale. Customers purchasing from
outside of the UK should contact Nuaire International Sales office for
further details.
8.0 After Sales Enquiries
For technical assistance or further product information, including
spare parts and replacement components, please contact the After
Sales Department.
Telephone [phone]
211. 05. 17. Leaflet Number 671742
Installation and Maintenance Genie Plus GPE-100 Range of Centrifugal Fans
L
N
SL
N
L
Fuse 2 amp
(BS 1362)
3 Pole Isolator
Fan Unit
2 Pole Switch
Optional Lamp
Mains
230V
50Hz
L
N
N
L
Fuse 2 amp
(BS 1362) Fan Unit
Mains
230V
50Hz
2 Pole Isolator
L
L
N
N
L
Fuse 2 amp
(BS 1362) Fan Unit
Mains
230V
50Hz
2 Pole Isolator
Remote
Switch
TIMER ADJUST
5 MINS 15 MINS 30 MINS
PULL CORD
HUMIDITY SENSOR
NEUTRAL
LIVE
SWITCHED LIVE
NEUTRAL
LIVE
Figure 4d. Wiring. PCB details (where applicable)
Technical or commercial considerations may, from time to time,
make it necessary to alter the design, performance and
dimensions of equipment and the right is reserved to make such
changes without prior notice.
