Nucraft Two4Six Meeting Table User manual

Two4Six Meeting Table Installation Instructions
ID: 0075
Rev. 03/15/16

Before Beginning Installation
Read through the entire instruction thoroughly
A minimum of 2 people are required for this
assembly
These instructions reflect typical assemblies; They
may not match your specific configuration
Nucraft –Two4Six 2015 2

Required Tools
Drill Driver
#2 and #3 Phillips Bit
Level
3Nucraft –Two4Six 2015

Base Options
4
Nucraft –Two4Six 2015

Top Shapes
5
Nucraft –Two4Six 2015

Table Types
6
Nucraft –Two4Six 2015
Table Type
Pages
Rectangular Table
Pages 7
- 12
Round
Table
Pages 13
–18
Square
Table
Pages 19
- 23

Table Type
7
Nucraft –Two4Six 2015
Rectangular Table w/Post Legs
Rectangular Table w/Open Frame
Soft Rectangle Table w/Open Frame
Soft Rectangle Table w/Post Leg

Step 1
Post Leg Setup
Verify paperwork/customer if the legs
are supposed to be in the standard or
inset locations
Align the holes in the top plate of
the leg to the three predrilled
holes in the table top
*Make sure the legs are angled
toward the outside corners of the
table
Secure with screws
Nucraft –Two4Six 2015
Standard
Inset
8
NOTE: Do not overtighten
The screws as this may
damage the worksurface
HW0741

Step 1
Open Frame Setup
Align the predrilled holes in the top
with the holes in the base and
secure with screws
Nucraft –Two4Six 2015
NOTE: Do not overtighten
The screws as this may
damage the worksurface 9
HW0741

Step 2
Attach Wire Chase (if included)
Nucraft –Two4Six 2015
NOTE: Do not overtighten
The screws as this may
damage the worksurface 10
Attach wire chase by securing the
4 bored locations to the
worksurface.
No pre-drills are provided,
therefore center the wire chase
under the center of the table and
secure.
HW0741

Step 3
Level Table
Place level on top, running
along the length of the top
Check for levelness and extend
or retract glides as needed
Repeat the above procedure
along the width of the top
Double check both directions
Nucraft –Two4Six 2015 11
NOTE: Glides are located
at these locations for
adjustment

Step 4
Installing Power Rail (if applicable)
Insert thumbscrews into predrilled
holes on the bottom of the table top
Part can be attached at ends or
along the length of the table.
Additionally the power rail can be
adjusted toward or away from the
edge of the table
12
Nucraft –Two4Six 2015

Table Type
13
Nucraft –Two4Six 2015
Round Top w/Cylinder Base Round Top w/Open Frame
Round Top w/Post Leg Base

Step 1
Post Leg Setup
Verify paperwork/customer if the legs
are supposed to be in the standard or
inset locations
Align the holes in the top plate of
the leg to the two predrilled
holes in the table top
*Make sure the legs are angled
toward the outside corners of the
table
Secure with screws
Nucraft –Two4Six 2015 14
NOTE: Do not overtighten
The screws as this may
damage the worksurface
HW0741

Step 1
Open Frame/Square Open Frame
Square Open Frame Base:
Align holes in top of base with
the two predrilled holes in top
and secure with screws
Nucraft –Two4Six 2015
NOTE: Do not overtighten
The screws as this may
damage the worksurface 15
HW0741

Step 1
Round Base
Align the 4 plates on the top of the
base with the corresponding holes
in the top and secure with screws
Nucraft –Two4Six 2015 16
NOTE: Do not overtighten
The screws as this may
damage the worksurface
HW0581

Step 2
Level Table
Place level on top, running
along the length of the top
Check for levelness and extend
or retract glides as needed
Repeat the above procedure
along the width of the top
Double check both directions
Nucraft –Two4Six 2015 17
NOTE: Glides are located
at these locations for
adjustment

Step 3
Installing Power Rail (if applicable)
Insert thumbscrews into predrilled
holes on the bottom of the table top
Part can be attached at ends or
along the length of the table.
Additionally the power rail can be
adjusted toward or away from the
edge of the table
18
Nucraft –Two4Six 2015

Table Type
19
Nucraft –Two4Six 2015
Soft Square w/Post Leg Soft Square w/Open Frame
Square Table w/Open Frame Square Table w/Post Leg

Step 1
Post Leg Setup
Verify paperwork/customer if the legs
are supposed to be in the standard or
inset locations
Align the holes in the top plate of
the leg to the two predrilled
holes in the table top
*Make sure the legs are angled
toward the outside corners of the
table
Secure with screws
Nucraft –Two4Six 2015
Standard
Inset
20
NOTE: Do not overtighten
The screws as this may
damage the worksurface
HW0741
