TESANO CONFERENCE TABLE
(current) 5-2015

Before Beginning Installation
• Read through the entire instruction thoroughly
• A minimum of 2 people are required for this
assembly. For 96” tables and larger it is
recommended to have 3 or 4 people available for
the install.
• These instructions reflect typical assemblies; They
may not match your specific configuration
Note: This table will be assembled right-side up
Tesano | 2

Required Tools & Hardware
Drill Driver
#2- Phillips Bit
Laser Level
¼” Allen Wrench
1 2
3 4
5 6
Tesano | 3

Tesano Conference
Tesano | 4

Tesano Exploded
1
2
5
4
6
1. Work Surface
2. Top Beams
3. Mending Plate
4. Base
5. Rail Key
6. Wire Management
7. Power Rail
7
Tesano | 5

Tesano | 6
Step 1
Connecting Rails to Bases
Run glides out of bases
before beginning
assembly
Loosen bolts (shown
above) in the keys
attached to the beam
Insert the beams with rail
keys attached, into each
of the bases
Use labels to attach
correct beams to correct
bases
Note: Dowels are not needed in the base ends

Tesano | 7
Step 2
Installing Top
Insert pins (hardware #4) into
the holes along the top edge
of base end.
Place top onto beams, sliding
one end into the pins
(hardware #4) and dowels
(hardware #6) of one base
Repeat with the base on the
opposite end
Make sure the ends match
labels

Tesano | 8
Step 3
Securing Top
Slide the bases tight to the top
and tighten cams fully.
Attach mending plate along
the center of the metal spacer.
Pilot holes should be present.
Attach smaller mending plates
in between the edge of the
table and the top wood rails.

Tesano | 9
Step 4
Securing Top Rails
Square the base up to the
top before securing the
beams to the base
With the mending plates
secured in place, secure the
top beams to the wood rails
using hardware #4 long silver
screws. The label should be
facing the ground
The beams will be secured by
inserting a screw at the bottom
of the slotted openings found
along one face of the beam
Using the bolts shown at right
insert into side of rail key and
secure

Tesano | 10
Step 5
Fastening Aprons
Locate the aprons between the
inside of the side rail and the
black beam, and fasten them
using supplied silver screws
(hardware #2)
Locate notch, place in apron
toward end of table

Tesano | 11
Step 6
Installing Wire Management
Step (1): Attach wires to receptacles
Step (2): Join the two sides
of the table together with a
connector receptacle
Step (3): Use the hardwires to connect to
an electrical output through the end of the
base

Tesano | 12
Step 7
Installing Wire Management Covers
Locate the wire management
channels.
Ensuring that the power duplex
lines up with the cutout, fasten the
wire management channel using
silver screws (hardware #1) and
black screws (hardware #3).
The label will be facing the top
The silver screws (hardware #1)
must be used on the raised
surface, while the black screws
(hardware #3) should be used on
the lower surface

Tesano | 13
Step 8
Installing Power Rail Unit
The power rail unit will
come with two black
brackets which should be
inserted first into the rail.
The silver bolts should be
inserted into the bracket
before inserting into rail.
Place power unit over
screws
Tighten nuts to secure unit
to the rail.
