Nucraft Flow Series User manual

FLOW Conference Table Installation Instructions
Revised 9-15-2014

Tools Re uired and Initial Notes
Tools Required For Assembly
•2 People
•Phillips Head Screwdriver
•Drill with #2 and #3 Phillips bit
•¼” Allen Wrench
•1/8” Allen Wrench
•5/32” Drill Bit
•Level
•Draw Tight Fastener Tool (Included)
Hardware Included
•BOLT, 3/8” UNC x 5/8” L-HW2248
•BOLT, 5/16-18 x 5/8 Flt Socket head
cap (Post Leg Base ONLY)
•SCREW, 10-12 x 1-1/4” PHIL
•SCREW, #12 x 1” PAN-PHIL
•Draw-Tight Hardware
Initial Notes
•Pictures in instructions may not represent the exact table being installed
•Read all instructions thoroughly prior to beginning the installation
•Tables 120” and less will be shipped with the Beams and Power Island attached to
the bases, so Step 1 can be skipped.

FLOW NT Table

FLOW NT Table
Flow Component
Description
1. Work Surface
2. End Base
3. Center Base
4. Main Beam 1
4
3
2

Installation Step 1 – For tables over 120” (if your table is 120” or less skip to step 3)
•Loosen the clamp bars from the base –
DO NOT remove.
•Locate the labels and match the beams
to the correct placement on the bases
•Attach Main Beam to End Base utilizing
the clamp bars and sliding them into
the main beam. Assure Beam is tight
to the base panel and 1/8” top of the
panel
•Tighten Cap Screws to secure the beam
to the base.
•Attach Main Beam to Center Base.
Assure Beams are tight and flush at
the joint. If there is not a center
base skip to next step
•Tighten the cap screws to secure the
beam to the base.
1/8” above base

Installation Step 2 & 3
•Using a level on the main beam, assure
that the base is sitting level. Adjust the
glides as necessary to assure that the
base is level before proceeding.
•Align the top with the corners of the
bases utilizing the “L” shaped notches
on the underside of the table.
•With multiple piece tops, join the two
halves together utilizing the supplied
draw tight hardware.
•Utilizing the 1” #12 screws provided
with the hardware fasten the table
top to the base using the brackets
that are attached to the base. –
Utilize all holes that are intended to
attach the base to the top.

FLOW Table With Post Leg Bases

FLOW Table with Post Leg Bases Exploded
Flow Post Leg
Component
Description
1. Work Surface
2. End Base
3. Center Base
4. Main Beam
1
4
3
2

Installation Step 1 & 2
•Slide the clamp bars from the end base into
the main beam.
•Tighten the screws that fasten the end base
to the main beam.
•Attach the main beam to the center base per
the photo to the right.
•Move to Step 2 in the Flow or Flow XT
instructions above.
