Nucraft Two4Six Meeting Table User manual

Two4Six Media Table Installation Instructions
ID: 0077
Rev. 03/17/16

Before Beginning Installation
Read through the entire instruction thoroughly
A minimum of 2 people are required for this
assembly
These instructions reflect typical assemblies; They
may not match your specific configuration
Nucraft –Two4Six 2015 2

Required Tools
Drill Driver
#2 and #3 Phillips Bit
Level
3Nucraft –Two4Six 2015

Base Options
4
Nucraft –Two4Six 2015
NOTE: Two different base styles
may be used on one worksurface

Top Shapes
5
Nucraft –Two4Six 2015

Table Type
6
Nucraft –Two4Six 2015
Table Type Pages
Credenza Base
Pages 7
- 13
Slab Base
Pages
14 - 21
Wall Mount
Pages 22
- 27

Credenza Base - Post Leg/Open Leg Setup
7
Nucraft –Two4Six 2015
Credenza Base with Post
Leg and Monitor Panel Credenza Base with Open Frame Leg

Step 1
Setup Credenza
Place the Credenza in the desired
final location
The following steps on this page are for
Monitor Panel Stations
Insert the stanchions into the back of
the credenza
Loosen the glides at the bottom of
the stanchions. The glides should be
fully extended, as they will be
adjusted later
Lift the fixed wall onto the stanchions
as shown at right.
Adjust the glides to level the back
wall
Nucraft –Two4Six 2015 8

Step 2
Attach Legs (Post Leg)
Once the Credenza is fully
assembled, start working on the top
Gently place top upside down on a
soft, padded surface
Post Leg: check with the customer to
see if the legs are supposed to be in
the standard or inset locations
Align the holes in the top plate of
the leg to the two predrilled
holes in the table top
Make sure the legs are angled
toward the outside corners of the
table
Secure with screws
Nucraft –Two4Six 2015
Standard
Inset
9
NOTE: Do not overtighten
The screws as this may
damage the worksurface
HW0741

Step 2
Attach Legs (Open Frame Leg)
Once the Credenza is fully
assembled, start working on the top
Gently place top upside down on a
soft, padded surface
Open Frame Base
Align the predrilled holes in the
top with the holes in the base
and secure with screws
Nucraft –Two4Six 2015 10
NOTE: Do not overtighten
The screws as this may
damage the worksurface
HW0741

Step 3
Attach Credenza Base
Credenza Base:
Set top on credenza and align
the predrilled holes in the top
with the slots in the plates on
the credenza
Insert the adjustment knobs
and adjust the top location to
the customer’s preference
Nucraft –Two4Six 2015 11
Attachment
Plates here

Step 4
Level Table
Place level on top, running
along the length of the top
Check for levelness and extend
or retract glides as needed
Repeat the above procedure
along the width of the top
Double check both directions
Nucraft –Two4Six 2015 12
NOTE: Glides are located
at these locations for
adjustment

Step 5
Installing Power Rail (if applicable)
Insert thumbscrews into predrilled
holes on the bottom of the table top
Part can be attached at ends or
along the length of the table.
Additionally the power rail can be
adjusted toward or away from the
edge of the table
13
Nucraft –Two4Six 2015

Slab Base - Post Leg/Open Leg Setup
14
Nucraft –Two4Six 2015
Slab Base with Post
Leg Slab Base with Open Frame Leg

Step 1
Attach Legs (Post Leg)
Gently place top upside down on a
soft, padded surface
Post Leg: check with the customer to
see if the legs are supposed to be in
the standard or inset locations
Align the holes in the top plate of
the leg to the two predrilled
holes in the table top
Make sure the legs are angled
toward the outside corners of the
table
Secure with screws
Nucraft –Two4Six 2015
Standard
Inset
15
NOTE: Do not overtighten
The screws as this may
damage the worksurface
HW0741

Step 1
Attach Legs (Open Frame Leg)
Gently place top upside down on a
soft, padded surface
Open Frame Base
Align the predrilled holes in the
top with the holes in the base
and secure with screws
Nucraft –Two4Six 2015 16
NOTE: Do not overtighten
The screws as this may
damage the worksurface
HW0741

Step 2a
Attaching Slab Base
Slab base is open on one
face, which should be
against a wall
Electrical wires should be
run from the worksurface,
between the base and the
wall, to the ground
The Slab Base can now be
attached to the wall using z-
brackets
Nucraft –Two4Six 2015 17

Step 2b
Attaching Slab Base (continued)
The removable panel on the
slab base is attached using
the hardware at right
One of these individual parts
is attached on the steel
frame at 4 locations.
A second metal clip is
attached to the panel.
When the panel is attached
correctly, the two parts
should engage as shown.
Nucraft –Two4Six 2015 18

Step 2c
Slab Base (Continued)
Once secured to the wall, insert
the worksurface attachment plate
into the cutout and attach it with
screws
When all electrical routing is
complete, secure L bracket to top
with thumbscrew
Nucraft –Two4Six 2015 19
NOTE: Do not overtighten
The screws as this may
damage the worksurface
HW0747

Step 3
Level Table
Place level on top, running
along the length of the top
Check for levelness and extend
or retract glides as needed
Repeat the above procedure
along the width of the top
Double check both directions
Nucraft –Two4Six 2015 20
NOTE: Glides are located
at these locations for
adjustment
