MA35D1 Buildroot Quick Start

NuDeveloper Ecosystem –Make the engineers’ job easier.NuDeveloper Ecosystem –Make the engineers’ job easier.
Overview
Environment Setup
Programming
System Boot
2
Agenda

NuDeveloper Ecosystem –Make the engineers’ job easier.NuDeveloper Ecosystem –Make the engineers’ job easier.
Overview

NuDeveloper Ecosystem –Make the engineers’ job easier.NuDeveloper Ecosystem –Make the engineers’ job easier.
This slide provides instructions on how to quickly build an MA35D1 image
PC specification standard
。CPU: Intel i5-10400
。Memory: 16 GB DDR RAM
。Storage: 1 TB SSD Disk (200 GB of which is empty space)
。Operation System: Linux OS or Linux Virtual Machine (VMware provide by Nuvoton)
。A MA35D1 Docker container
If you used VMware provide by Nuvoton, you have already created a MA35D1 Docker container
Software Tool
。Programming –NuWriter
4
Overview

NuDeveloper Ecosystem –Make the engineers’ job easier.NuDeveloper Ecosystem –Make the engineers’ job easier.
VMware Setting

NuDeveloper Ecosystem –Make the engineers’ job easier.NuDeveloper Ecosystem –Make the engineers’ job easier.
This VMware Image offers a Linux development environment for MA35D1. If you utilize the VMware Image, you
can bypass the Docker steps for building the Image
User Name: user
Password: user
Buildroot:
6
Start up with VMware
$
cd ~/buildroot/MA35D1_Buildroot
~/
MA35D1_Buildroot$ git pull

NuDeveloper Ecosystem –Make the engineers’ job easier.NuDeveloper Ecosystem –Make the engineers’ job easier.
Docker
Environment Setup

NuDeveloper Ecosystem –Make the engineers’ job easier.NuDeveloper Ecosystem –Make the engineers’ job easier.
•Docker enables the packaging of code and its dependencies into containers.
•Each container is independent and based on the host OS, ensuring they operate in isolation without
impacting each other. Containers run more efficiently than virtual machines, resulting in faster
performance
8
Development Environment –Docker
Host OS
Docker Container
Container1
App 1
Basic OS
based on Host
Container2
App 2
Basic OS
based on Host
Container3
App 3
Basic OS
based on Host

NuDeveloper Ecosystem –Make the engineers’ job easier.NuDeveloper Ecosystem –Make the engineers’ job easier.
The necessary packages must be installed before building
Ubuntu and Debian
9
Environment Setup (1/4)
$
sudo apt-get install gawk wget git-core diffstat unzip texinfo gcc-multilib \
build-essential chrpath socat cpio python python3 python3-pip python3-pexpect \
xz-utils debianutils iputils-ping libsdl1.2-dev xterm curl

NuDeveloper Ecosystem –Make the engineers’ job easier.NuDeveloper Ecosystem –Make the engineers’ job easier.
This demo is under Ubuntu distribution. If you use virtual machine, ensure your RAM at least 5GB
Update existing list of packages
Install a few prerequisite packages which let apt use packages over HTTPS
Add Docker’s official GPG key for the official Docker repository to your system
Set up the stable repository, add the Docker repository to APT sources
10
Environment Setup (2/4)
$
sudo apt-get update
$
sudo apt install apt-transport-https ca-certificates curl software-properties-common
$ curl
-fsSL https://download.docker.com/linux/ubuntu/gpg | sudo apt-key add
$
sudo add-apt-repository "deb [arch=amd64] https://download.docker.com/linux/ubuntu focal stable"

NuDeveloper Ecosystem –Make the engineers’ job easier.NuDeveloper Ecosystem –Make the engineers’ job easier.
6. Update the package database with the Docker packages from the newly added repo
7. Install Docker
8. Download the Docker Script for MA35D1
11
Environment Setup (3/4)
$
sudo apt-get update
$
sudo apt-get install docker-ce docker-ce-cli containerd.io
$
git clone https://github.com/OpenNuvoton/MA35D1_Docker_Script.git

NuDeveloper Ecosystem –Make the engineers’ job easier.NuDeveloper Ecosystem –Make the engineers’ job easier.
9. Enter docker-yocto folder, build docker image.It may take one hour to get about 710 files
10. Enter docker image, and your command line head will be like nuvoton@a24d9e06abe3:~$
12
Environment Setup (4/4)
$
./build.sh
$ ./join.sh
ma35d1_user
nuvoton@a24d9e06abe3:~$

NuDeveloper Ecosystem –Make the engineers’ job easier.NuDeveloper Ecosystem –Make the engineers’ job easier.
Environment Setup

NuDeveloper Ecosystem –Make the engineers’ job easier.NuDeveloper Ecosystem –Make the engineers’ job easier.
Enter Docker container
Download MA35D1 Buildroot (No need to clone with VMware provided by Nuvoton)
14
Download and Update Buildroot
$ ./join.sh
$
git clone https://github.com/OpenNuvoton/MA35D1_Buildroot.git
$
git pull

NuDeveloper Ecosystem –Make the engineers’ job easier.NuDeveloper Ecosystem –Make the engineers’ job easier.
List all default configurations provide by Nuvoton and choose your target board configuration
Set configuration to the target board
15
Download and Update Buildroot
$ ls
configs/n*
$ make
numaker_som_ma35d16a81_defconfig

NuDeveloper Ecosystem –Make the engineers’ job easier.NuDeveloper Ecosystem –Make the engineers’ job easier.
Open Buildroot configuration
16
Install Qt5 Package
$ make
menuconfig
Target packages --->
Graphic libraries and applications --->
[*] directfb
[*] Qt5 --->
-*- qt5base
[*] Compile and install examples (with code)
-*- gui module
[*] widgets module
-*- linuxfb support
[*] directfb support
[*] GIF support
[*] JPEG support
[*] PNG support
[*] Enable Tslib support
[*] qt5declarative
[*] quick module
[*] qt5multimedia
[*] qt5script
[*] qt5sensors
[*] qt5serialbus
-*- qt5serialport

NuDeveloper Ecosystem –Make the engineers’ job easier.NuDeveloper Ecosystem –Make the engineers’ job easier.
17
Install Gstreamer Related Package
Target packages --->
Audio and video applications --->
[*] alsa-utils --->
[*] alsactl
[*] alsamixer
-*- ffmpeg --->
[*] Build ffmpeg
-*- Build libswscale
(all) Enabled encoders
(all) Enabled decoders
(all) Enabled muxers
(all) Enabled demuxers
(all) Enabled parsers
(all) Enabled bitstreams
(all) Enabled protocols
(all) Enabled filters
[*] Enable input devices
[*] Enable output devices
[*] gstreamer 1.x
-*- enable unit test libraries
[*] enable command-line parser
[*] enable tracing subsystem
[*] enable gst-debug trace support
[*] enable plugin registry
[*] install tools
[*] gstreamer1-mm
-*- gst1-plugins-base --->
-*- app
[*] audioconvert
[*] audiomixer
[*] audiorate
[*] audiotestsrc
[*] videoconvert
[*] playback
[*] audioresample
[*] tcp
-*- typefind
[*] videotestsrc
[*] videorate
[*] videoscale
[*] volume
[*] alsa
[*] ogg (*.ogg audio/video)

NuDeveloper Ecosystem –Make the engineers’ job easier.NuDeveloper Ecosystem –Make the engineers’ job easier.
18
Install Gstreamer Related Package
Target packages --->
Audio and video applications --->
-*- gst1-plugins-good --->
[*] jpeg (JPEG support)
[*] png (PNG support)
[*] audiofx
[*] audioparsers
[*] auparse
[*] autodetect
[*] avi (*.avi video)
[*] isomp4
-*- rtp
-*- rtpmanager
[*] rtsp
-*- udp
[*] videobox
[*] videocrop
[*] videofilter
[*] videomixer
[*] wavparse (*.wav audio)
[*] mpg123 (*.mp3 audio)
[*] ossaudio (OSS audio)
[*] v4l2
[*] v4l2-probe (m2m)
[*] gst1-plugins-bad --->
[*] autoconvert
[*] videoparsers
[*] gst1-plugins-ugly --->
[*] mpeg2dec
[*] x264
[*] gst1-libav
[*] gst1-rtsp-server
-*- mpg123

NuDeveloper Ecosystem –Make the engineers’ job easier.NuDeveloper Ecosystem –Make the engineers’ job easier.
If you do not need to install any additional packages to the MA35D1 image, you can start building it
19
Install Package to MA35D1 Image
$ make

NuDeveloper Ecosystem –Make the engineers’ job easier.NuDeveloper Ecosystem –Make the engineers’ job easier.
Once the build is complete, you can find the resulting image at /output/image
The core-image-buildroot-ma35d1-som-256m.rootfs.sdcard can be used to directly program to an SD
card
Alternatively, pack-core-image-buildroot-ma35d1-som-256-sd.bin can be used to program an SD card
through NuWriter
20
Building Finishing
