This document’s purpose is to help hardware engineers design and test
their MIMXRT1170 processor-based designs. It provides information about
board layout recommendations and design checklists to ensure first-pass
success and avoid board bring-up problems. This guide is released along with
the relevant device-specific hardware documentation such as data sheets,
reference manuals, and application notes available on nxp.com.
RT1160 shares the same design with RT1170, so engineers can
also use this document for RT1160.
NOTE
2 Background
The i.MX RT1170 is a new processor family featuring NXP's advanced implementation of the high performance Arm® Cortex®-M7
Core and power efficient Arm Cortex-M4 core. It provides high CPU performance and real-time response.
The i.MX RT1170 has 2 MB of on-chip RAM in total, including a 512 KB RAM which can be flexibly configured as Tightly-Coupled
Memory (TCM) or general purpose On-Chip RAM (OCRAM). The i.MX RT1170 integrates advanced power management module
with DC-DC and LDOs that reduce complexity of external power supply and simplify power sequencing.
It provides various memory interfaces, including SDRAM, Raw NAND FLASH, NOR FLASH, SD/eMMC, Quad SPI, Hyper
RAM/Flash. It also provides a wide range of other interfaces for connecting external peripherals, such as WLAN, BluetoothR, GPS,
displays, and camera sensors. Like other i.MX processors, i.MX RT1170 also has rich audio and video features, including MIPI
CSI/DSI, LCD display, graphics accelerator, camera interface, S/PDIF, and I2S audio interface.
The i.MX RT1170 applications processor can be used in areas such as industrial HMI, IoT, high-end audio appliance, low-end
instrument cluster, Point-of-Sale(PoS), motor control, and home appliances.
3 Power supply
For power supply voltage specifications, refer to the Operating Ranges table in the device data sheets. See Table 1 and Table 2
for power supply decoupling recommendations.
The Figure 1 in this section is applicable to RT1170 silicon and these tables do not include the on-chip LDO output
specification, which can be found in the device data sheet.
NOTE
Contents
1 Introduction......................................1
2 Background..................................... 1
3 Power supply...................................1
4 Clocks..............................................7
5 Debugging and programming..........8
6 Boot, reset, and miscellaneous..... 10
7 Layout recommendations..............18
8 Related resources......................... 22
9 Revision history.............................22
MIMXRT1170HDUG
Hardware Development Guide for the MIMXRT1160/1170 Processor
Rev. 2 — 09/2021 User Guide

Table 1. Processor supply capacitors when on-chip DCDC regulators are used
Power rail 0.1 μF10.22 μF11 μF12.2 μF14.7 μF122 μF1Notes
DCDC_IN 1 1 1 Place 0402 under balls M5, N5,
place 0603 as close as possible to
the processor.
DCDC_ANA 1 Place under ball M7
DCDC_ANA_SENSE 1 Place under ball M6
DCDC_DIG 1 1 Place 0402 under ball K8, place
0603 as close as possible to the
processor.
DCDC_DIG_SENSE 1 Place under ball L7
VDDA_1P8_IN 1 Place under ball M11
VDD_SOC_IN_X 1 2 2 1 Place 0402 under balls H8, H10,
J8, J10, K10, place 0603 as close
as possible to the processor.
VDD_LPSR_IN 1 Place under ball R12
VDD_LPSR_ANA 1 Place under ball P12
VDD_LPSR_DIG 1 Place under ball P11
VDD_SNVS_IN 1 Place under ball U12
VDD_SNVS_ANA 1 Place under ball U14
VDD_SNVS_DIG 1 Place under ball T14
VDD_USB_1P8 1 Place under ball H12, isolate from
1V8 source with series ferrite bead
(120-ohm@100MHz)
VDD_USB_3P3 1 Place under ball G12, isolate from
3V3 source with series ferrite bead
(120-ohm@100MHz)
VDDA_ADC_1P8 1 Place under ball K15
VDDA_ADC_3P3 1 Place under ball J13
VDDA_1P0 1 Place under ball N11
VDD_MIPI_1P8 1 Place under ball F9, isolate from
1V8 source with series ferrite bead
(120-ohm@100MHz)
VDD_MIPI_1P0 1 Place under ball F10, power
source is on-chip LDO regulator
VDDA_1P0
NVCC_SD1 1 Place under ball D14
NVCC_SD2 1 Place under ball G13
NVCC_EMC1_X 1 1 Place 2.2 μF under balls F6, F7
Table continues on the next page...
NXP Semiconductors
Power supply
Hardware Development Guide for the MIMXRT1160/1170 Processor , Rev. 2, 09/2021
User Guide 2 / 24

Table 1. Processor supply capacitors when on-chip DCDC regulators are used (continued)
Power rail 0.1 μF10.22 μF11 μF12.2 μF14.7 μF122 μF1Notes
NVCC_EMC2_X 1 1 Place 2.2 μF under balls H6, J6
NVCC_GPIO 1 1 Place 2.2 μF under ball M12
NVCC_DISP1 1 Place under ball D12
NVCC_DISP2 1 Place under ball E7
NVCC_LPSR 1 Place under ball P7
NVCC_SNVS 1 Place under ball U11
ADC_VREFH 1 Place under ball G16
USB1_VBUS 1 Place under ball D17
USB2_VBUS 1 Place under ball D16
1. 0.1, 0.22, 1, 2.2, 4.7 μF are size 0402, type X5R. 22 uF is size 0603, type X5R.
Table 2. Processor supply capacitors when external PMIC or regulators utilized (on-chip DCDC regulators not used)
Power rail 0.1 μF10.22 μF11 μF12.2 μF14.7 μF122 μF1Notes
VDD_SOC_IN_x 2 3 1 Place 0402 under balls H8, J8, J9,
J10, K10
VDD_LPSR_IN 1 Place under ball R12
VDD_LPSR_ANA 1 Place under ball P12
VDD_LPSR_DIG 1 Place under ball P11
VDDA_ADC_3P3 1 1 Place 1 μF under ball J13, place
0.1 μF near J13, isolate from 3V3
source with series ferrite bead (120-
ohm@100MHz)
ADC_VREFH 1 Place under ball G16
VDDA_ADC_1P8 1 1 Place 1 μF under ball K15, place
4.7 μF near K15, isolate from 1V8
source with series ferrite bead (120-
ohm@100MHz)
VDDA_1P8_IN 1 Place under ball M11
VDDA_1P0 1 Place under ball N11
VDD_SNVS_IN 1 Place under ball U12
VDD_SNVS_ANA 1 Place under ball U14
VDD_SNVS_DIG 1 Place under ball T14
NVCC_SNVS 1 Place under ball U11
NVCC_LPSR 1 Place under ball P7
NVCC_GPIO 1 1 Place 2.2 μF under ball M12
Table continues on the next page...
NXP Semiconductors
Power supply
Hardware Development Guide for the MIMXRT1160/1170 Processor , Rev. 2, 09/2021
User Guide 3 / 24

Table 2. Processor supply capacitors when external PMIC or regulators utilized (on-chip DCDC regulators not used)
(continued)
Power rail 0.1 μF10.22 μF11 μF12.2 μF14.7 μF122 μF1Notes
NVCC_SD1 1 Place under ball D14
NVCC_SD2 1 Place under ball G13
NVCC_DISP1 1 Place under ball D12
NVCC_DISP2 1 Place under ball E7
NVCC_EMC1_X 1 1 Place under balls F7, G6
NVCC_EMC2_X 1 1 Place under balls H6, J6
VDD_MIPI_1P8 1 Place under ball F9, isolate from
1V8 source with series ferrite bead
(120-ohm@100MHz)
VDD_MIPI_1P0 1 Place under ball F10, power
source is on-chip LDO regulator
VDDA_1P0
VDD_USB_1P8 1 Place under ball H12, isolate from
1V8 source with series ferrite bead
(120-ohm@100MHz)
VDD_USB_3P3 1 Place under ball G12, isolate from
3V3 source with series ferrite bead
(120-ohm@100MHz)
USB1_VBUS 1 Place under ball D17
USB2_VBUS 1 Place under ball D16
1. 0.1 μF, 0.22 μF, 1 μF, 2.2 μF, and 4.7 μF are size 0402 and 22 μF is size 0805. Type X6S is used for automotive cluster
and extended temperature range.
Table 3. Power supply and SNVS domain signals
Item Recommendation Description
1.
Power sequence
Comply with the power-up/power-down
sequence guidelines (as described in the data
sheet) to guarantee a reliable operation of
the device.
Any deviation from these sequences may result in
these situations:
• Excessive current during the power-up phase
• Prevention of the device from booting
• Irreversible damage to the processor
(worst-case scenario)
2. SNVS
domain signals
Do not overload the coin cell backup power
rail VDD_SNVS_IN.
Note that these I/Os are associated
with VDD_SNVS_IN (most inputs have on-
chip pull resistors and do not require
external resistors):
Concerning i.MX RT1170:
• The chip internal LDO VDD_SNVS_ANA output power
capacity is 1 mA and should be tied together with
NVCC_SNVS.
Table continues on the next page...
NXP Semiconductors
Power supply
Hardware Development Guide for the MIMXRT1160/1170 Processor , Rev. 2, 09/2021
User Guide 4 / 24

Table 3. Power supply and SNVS domain signals (continued)
Item Recommendation Description
• PMIC_STBY_REQ—configurable output
• PMIC_ON_REQ—push-pull output
• TEST_MODE—on-chip pull-down
• POR—on-chip pull-up
• WAKEUP—the GPIO that wakes the
SoC up in the SNVS mode
• GPIO_SNVS_XX—on-chip pull-down
• Be careful to use SNVS signals to drive external load
as the SNVS GPIO drive is quite low, refer to the i.MX
RT1170 data sheet for details.
• By default, the functionality of GPIO_SNVS_XX pin
is determined by the part number. Tamper function
is available only on tamper-enabled parts, and GPIO
is the only available function on parts which do not
support tamper. The MUX_MODE must be configured
to select the function in both cases.
• The GPIO_SNVS_XX pins will automatically switch to
tamper function in the SNVS mode even on the part
where GPIO function is supported. For more details,
refer to ERR051122.
• Access delay occurs on the GPIO_SNVS_xx signals
due to the module's 32 kHz clock source.
3. Power ripple Maximum ripple voltage limitation. The common limitation for the ripple noise shall be less
than 5 % Vp-p of the supply voltage average value. The
related power rails affected are VDD_XXX, VDD_XXX_IN,
VDDA_1P0, VDD_XXX_ANA, VDD_XXX_DIG.
4. Supply
currents
Maximum supply currents comply with
maximum supply currents in data sheet
Concerning i.MX RT1170:
• The DCDC_DIG_X output power capacity is 850 mA
and DCDC_ANA_X output power capacity is 150 mA.
• Do not use DCDC_ANA_X to drive load higher
than 150mA.
• For frequencies higher than 600 MHz and up to 800
MHz, refer to the CM7 power source guideline table in
the i.MX RT1170 data sheet for automotive products.
Power Sequence Requirements:
• For power supply sequencing requirements, refer to Section 8 of the i.MX RT1170 data sheet.
The power control logic of the IMXRT1170 EVK board is shown in the following figure:
• It will power up SNVS first, then PMIC_REQ_ON will be asserted to enable external DC/DC to power up other power
domains.
• ON/OFF button is used to switch PMIC_REQ_ON to control power modes.
• RESET button and WDOG output are used to reset the system power.
NXP Semiconductors
Power supply
Hardware Development Guide for the MIMXRT1160/1170 Processor , Rev. 2, 09/2021
User Guide 5 / 24

Figure 1. Power control diagram
3.1 On-chip DC/DC module
The internal DC/DC of RT1170 has two outputs, one output (VDD_DIG) typical 0.7 V~1.15 V, another output (VDD_ANA) typical
1.8 V and its switching frequency is about 1.5 MHz.
The DC/DC requires external inductor and capacitors, the illustration is as below Figure 3, please pay attention to the below items:
• The recommended value for the external inductor is about 4.7 μH with the saturation current > 1.5 A and ESR < 0.1 Ω.
• The external bulk capacitor total is about 66 μF, this includes all the capacitors used on DCDC_DIG_X and VDD_SOC_IN.
• DCDC_PSWITCH should delay 1 ms with respect to DCDC_IN to guarantee that DCDC_IN is stable before the DC/DC
starts up.
• If you want to bypass the internal DC/DC, DCDC_PSWITCH and DCDC_MODE must be tied to the ground, others signals
such as DCDC_IN, DCDC_LP, DCDC_LN, DCDC_ANA, DCDC_ANA_SENSE, DCDC_DIG, and DCDC_DIG_SENSE can
be floating.
• Try to keep the DC/DC current loop as small as possible to avoid EMI issues.
NXP Semiconductors
Power supply
Hardware Development Guide for the MIMXRT1160/1170 Processor , Rev. 2, 09/2021
User Guide 6 / 24

Figure 2. DC/DC function diagram
The processor's on-chip DC-DC regulator is suitable for consumer and industrial applications up to 105 degrees
C. For automotive applications, contact your NXP representative.
NOTE
4 Clocks
See Table 4 for the clock configuration. The 32.768-kHz and 24-MHz oscillators are used for the EVK design. For RT1170, it is
necessary to use 32.768-kHz and 24-MHz crystals for the hardware design.
Table 4. Clocks’ configurations
Signal name Recommended connections Description
1.RTC_XTALI/RTC_XTALO For the precision 32.768-kHz oscillator,
connect a crystal between RTC_XTALI
and RTC_XTALO. Choose a crystal with
a maximum ESR (Equivalent Series
Resistance) of 100 k and follow the
manufacturer’s recommendation for the
loading capacitance. Do not use an
external biasing resistor because the bias
circuit is on the chip.
To hit the exact oscillation frequency,
the board capacitors must be reduced to
account for the board and chip parasitics.
The integrated oscillation amplifier is self-
biasing, but relatively weak. Care must be
taken to limit the parasitic leakage from
RTC_XTALI and RTC_XTALO to either
the power or the ground (>100 M). This
de-biases the amplifier and reduces the
start-up margin.
For the external kHz source (if feeding
an external clock into the device),
RTC_XTALI can be driven DC-coupled
with RTC_XTALO floating or driven by a
complimentary signal.
If you want to feed an external
low-frequency clock into RTC_XTALI,
the RTC_XTALO pin must remain
unconnected or driven by a
complementary signal. The logic level
Table continues on the next page...
NXP Semiconductors
Clocks
Hardware Development Guide for the MIMXRT1160/1170 Processor , Rev. 2, 09/2021
User Guide 7 / 24

Table 4. Clocks’ configurations (continued)
Signal name Recommended connections Description
of this forcing clock must not exceed
the VDD_SNVS_DIG level and the
frequency shall be <100 kHz under the
typical conditions.
An on-chip loose-tolerance ring
oscillator of approximately 40 kHz is
available. If RTC_XTALI is tied to GND
and RTC_XTALO is floating, the on-chip
oscillator is engaged automatically.
When a high-accuracy real-time clock is
not required, the system may use the
on-chip 40-kHz oscillator. The tolerance
is ±50 %. The ring oscillator starts faster
than the external crystal and is used
until the external crystal reaches a stable
oscillation. The ring oscillator also starts
automatically if no clock is detected at
RTC_XTALI at any time.
2. XTALI/XTALO For the precision 24-MHz oscillator,
connect a fundamental-mode crystal
between XTALI and XTALO. An typical
80 ESR crystal rated for a maximum drive
level of 250 μW is acceptable.
Alternately, a typical 50 ESR crystal rated
for a maximum drive level of 200 μW may
be used.
For the RT1170 24-MHz OSCILLATOR,
the smaller the ESR, the better the
startup and power consumption.
To use the high-power mode, populate
the 1-Mohm resistor between XTALI
and XTALO.
The SDK software requires 24 MHz on
XTALI/XTALO.
The crystal can be eliminated if an
external 24-MHz oscillator is available
in the system. In this case, please refer
to section of Bypass Configuration (24
MHz) from the reference manual. For
the bypass mode pin connection, the
external bypass clock can be put in from
EXTAL pin, at the same time, XTALO can
be used as other functions.
The logic level of this forcing clock must
not exceed the VDD_LPSR_ANA level.
If this clock is used as a reference
for the USB and Ethernet, then there
are strict frequency tolerance and jitter
requirements. The +-50 ppm accuracy
is required for the Ethernet while the
+-100 ppm accuracy is required for the
USB. See the OSC24M chapter and the
relevant interface specification chapters
for details.
3.CLK1_P/CLK1_N Internal use only These pins are used for NXP internal
testing. The CLK1_P and CLK1_N pair
should be left floating.
5 Debugging and programming
This section provides the JTAG interface summary and recommendations for using the JTAG, SWD debug, and Serial downloader
I/O.
NXP Semiconductors
Debugging and programming
Hardware Development Guide for the MIMXRT1160/1170 Processor , Rev. 2, 09/2021
User Guide 8 / 24

By default, the RT1170 silicon can use both SWD and JTAG modes using the Arm stitching sequence. For the
RT1170EVK board, it defaults to use the SWD debug without any board modification. If you want to use the JTAG
debug, solder out R187, R208, R195, and R78, because some JTAG signals are multiplexed with other functions.
NOTE
The MIMXRT1170-EVK also features a FreeLink circuit, which makes it easier to debug without an external debugger.
Table 5. JTAG interface summary
JTAG signals I/O type On-chip termination1External termination
JTAG_TCK Input Pull-down Not required;
JTAG_TMS Input Pull-up Not required; can use 10 kΩ pull-up
JTAG_TDI Input Pull-up Not required; can use 10 kΩ pull-up
JTAG_TDO 3-state output None Do not use pullup or pull-down
JTAG_TRSTB Input Pull-up Not required; can use 10 kΩ pull-up
JTAG_MOD Input Pull-down Use 4.7 kΩ pull-down or tie to GND
1. For on-chip termination values, refer to Section 8 of the data sheet.
Table 6. JTAG recommendation
Signals Recommendation Description
1. JTAG_TDO Do not add external pull-up or pull-down
resistors on JTAG_TDO.
See Table 5 for a summary of the JTAG interface.
This I/O has an on-chip keeper circuit which
avoids a floating condition.
2. JTAG signals
other than JTAG_TDO
and JTAG_MOD
Ensure that the on-chip pull-up/pull-down
configuration is followed if external resistors
are used with the JTAG signals (except for
JTAG_TDO). For example, do not use an
external pull-down on an input that has an on-
chip pull-up.
External resistors can be used with all JTAG signals
except for JTAG_TDO, but they are not required.
See Table 5 for a summary of the JTAG interface.
3. JTAG_MOD JTAG_MOD is called SJC_MOD in some
documents. Both names refer to the same
signal. JTAG_MOD shall be externally
connected to GND for normal operation in a
system. The termination to GND through an
external pull-down resistor is allowed. Use a
4.7-kΩ resistor.
When JTAG_MOD is low, the JTAG interface is
configured for a common software debug, adding
all the system TAPs to the chain.
When JTAG_MOD is low, the JTAG interface is
also configured to a mode compliant with the IEEE
1149.1 standard.
Table 7. SWD recommendation
Signals Recommendation Description
1. SWD_DIO Same practice as JTAG_TMS On the RT1170EVK board, the SWD debug port is used by default. There
is also a low-cost on-board Freelink debugger using the SWD port.
2. SWD_CLK Same practice as JTAG_CLK
The ROM’s Serial Downloader mode provides a means to download a program image to the chip over USB or UART serial
connection. In this mode, typically a host PC can communicate to the ROM bootloader using serial download protocol. NXP’s ROM
flashloader also uses these same serial connections. It is strongly recommended for all boards to make at least one of the serial
downloader ports (USB1 or UART1) available to be able to make use of NXP’s image and fuse programming enablement.
NXP Semiconductors
Debugging and programming
Hardware Development Guide for the MIMXRT1160/1170 Processor , Rev. 2, 09/2021
User Guide 9 / 24

Table 8. Serial downloader I/Os table
Signals Recommendation Description
1.UART1 The serial downloader provides a means to download a
program image to the chip over the USB and UART serial
connections. In this mode, the ROM programs the WDOG1
for a time-out specified by the fuse WDOG time-out select
(see the Fusemap chapter for details) if the WDOG_ENABLE
eFuse is 1 and continuously polls for the USB and UART
connection. If no activity is found on the USB OTG1 and
UART1 and the watchdog timer expires, the Arm core is reset.
The ROM polls for the UART1 and USB1
activity circularly until the ROM gets 0x5A,
0xA6 from the UART RXD or first HID
report from the USB bus. When an active
connection port is found, the ROM uses it
for the PC downloading.
2. USB1
6 Boot, reset, and miscellaneous
See Table 9 for the boot, reset, and miscellaneous configurations, such as ON/OFF, TEST_MODE, NC pins, and other.
Table 9. Boot configuration
Item Recommendation Description
1. BOOT_CFG[11:0] The BOOT_CFG signals are required
for a proper functionality and operation
and shall not be left floating during
development if BOOT_CFG fuses and
BT_FUSE_SEL are not configured.
See the “System Boot” chapter in
your chip reference manual for the
correct boot configuration. Note that
an incorrect setting may result in an
improper boot sequence.
2. BOOT_MODE[1:0] For logic 0:
• Tie to GND through 100K
external resistor
For logic 1:
• Tie to the NVCC_LPSR power domain
through a 4.7K external resistor
BOOT_MODE1 and BOOT_MODE0
each have on-chip pull-down devices
with a nominal value of 35 kΩ. When
the on-chip fuses determine the boot
configuration, both boot mode inputs can
be disconnected.
3. BOOT_CFG and BOOT_MODE
signals multiplexed with RGMII signals
As the BOOT_CFG pins are multiplexed
with RGMII signals, recommend to
add 22K isolation resistors to avoid
malfunction. For BOOT_MODE pins,
suggest to add 4.7K isolation resistors.
Please refer to the EVK design for
reference and try to avoid signal stubs
in layout.
NXP Semiconductors
Boot, reset, and miscellaneous
Hardware Development Guide for the MIMXRT1160/1170 Processor , Rev. 2, 09/2021
User Guide 10 / 24

Figure 3. Boot mode setting
Table 10. Reset and miscellaneous recommendations
Item Recommendation Description
1. POR_B The POR_B input (if used) must be
immediately asserted at power-up and
remain asserted until after the last power
rail reaches its working voltage. In the
absence of an external reset feeding the
POR_B input, the internal POR module
takes control. See the i.MX RT1170
Reference Manual (IMXRT1170RM) for
further details and to ensure that all
necessary requirements are being met.
See the “System Boot” chapter in your
chip reference manual for the correct
boot configuration. Note that an incorrect
setting may result from an improper boot
sequence. POR_B signal has internal
100K pull up to SNVS domain, should
pull up to VDD_SNVS_ANA if need to
add external pull up resistor, otherwise
it will cause additional leakage during
SNVS mode.
It's recommended to add the external
reset IC to the circuit to guarantee
POR_B is properly processed during
power up/down, please refer to the EVK
design for details. Note:
1. As the Low DCDC_IN detection
threshold is 2.6 V, the reset IC's reset
threshold must be higher than 2.6 V, then
the whole chip is reset before the internal
DCDC module reset to guarantee the
chip safety during power down.
2. For power on reset, on any conditions
ones need to make sure the voltage on
Table continues on the next page...
NXP Semiconductors
Boot, reset, and miscellaneous
Hardware Development Guide for the MIMXRT1160/1170 Processor , Rev. 2, 09/2021
User Guide 11 / 24

Table 10. Reset and miscellaneous recommendations (continued)
Item Recommendation Description
DCDC_PSWITCH PIN is below 0.5 V
before power up.
2. ON/OFF For portable applications, the ON/OFF
input may be connected to the
ON/OFF SPST push-button. The on-
chip debouncing is provided, and this
input has an on-chip pullup. If not used,
ON/OFF can be a no-connect. A 4.7-kΩ
to 10-kΩ series resistor can be used
when the current drain is critical.
A brief connection to GND in
the OFF mode causes the internal
power management state machine to
change the state to ON. In the ON
mode, a brief connection to GND
generates an interrupt (intended to be
a software-controllable power-down).
Approximately five seconds (or more) to
GND causes a forced OFF.
3. TEST_MODE The TEST_MODE input is internally
connected to an on-chip pull-down
device. You may either float this signal
or tie it to GND.
This input is reserved for NXP
manufacturing use.
Table 11. ROM Bootloader Peripheral PinMux
Peripheral Instance Port (IO function) PAD Mode Note
LPUART 1 LPUART1_TX GPIO_AD_24 ALT0 Can be used for serial
downloader mode Refer to Serial
Downloader in
Reference Manual for
more information.
LPUART1_RX GPIO_AD_25 ALT0
LPSPI 1 LPSPI1_SCK GPIO_AD_28 ALT0 Serial NOR/EEPROM connected
to one of the LPSPI ports can be
used as a recovery device.
Refer to Recovery devices
in Reference Manual for
more information.
Note: recovery device boot is
disabled by default. Fuses must
be blown to enable and configure
this option.
LPSPI1_PCS0 GPIO_AD_29 ALT0
LPSPI1_SDO GPIO_AD_30 ALT0
LPSPI1_SDI GPIO_AD_31 ALT0
2 LPSPI2_SCK GPIO_SD_B2_07 ALT6
LPSPI2_PCS0 GPIO_SD_B2_08 ALT6
LPSPI2_SDO GPIO_SD_B2_09 ALT6
LPSPI2_SDI GPIO_SD_B2_10 ALT6
3 LPSPI3_SCK GPIO_DISP_B1_04 ALT9
LPSPI3_PCS0 GPIO_DISP_B1_07 ALT9
LPSPI3_SDO GPIO_DISP_B1_06 ALT9
LPSPI3_SDI GPIO_DISP_B1_05 ALT9
4 LPSPI4_SCK GPIO_DISP_B2_12 ALT9
LPSPI4_PCS0 GPIO_DISP_B2_15 ALT9
LPSPI4_SDO GPIO_DISP_B2_14 ALT9
Table continues on the next page...
NXP Semiconductors
Boot, reset, and miscellaneous
Hardware Development Guide for the MIMXRT1160/1170 Processor , Rev. 2, 09/2021
User Guide 12 / 24

Table 11. ROM Bootloader Peripheral PinMux (continued)
Peripheral Instance Port (IO function) PAD Mode Note
LPSPI4_SDI GPIO_DISP_B2_13 ALT9
SEMC NAND N/A SEMC_DATA00 GPIO_EMC_B1_00 ALT0 Parallel NAND flash connected
to the SEMC is a primary
boot option. Refer to Parallel
NAND flash Boot over SEMC
in Reference Manual for
more information.
SEMC_DATA01 GPIO_EMC_B1_01 ALT0
SEMC_DATA02 GPIO_EMC_B1_02 ALT0
SEMC_DATA03 GPIO_EMC_B1_03 ALT0
SEMC_DATA04 GPIO_EMC_B1_04 ALT0
SEMC_DATA05 GPIO_EMC_B1_05 ALT0
SEMC_DATA06 GPIO_EMC_B1_06 ALT0
SEMC_DATA07 GPIO_EMC_B1_07 ALT0
SEMC_DATA08 GPIO_EMC_B1_30 ALT0
SEMC_DATA09 GPIO_EMC_B1_31 ALT0
SEMC_DATA10 GPIO_EMC_B1_32 ALT0
SEMC_DATA11 GPIO_EMC_B1_33 ALT0
SEMC_DATA12 GPIO_EMC_B1_34 ALT0
SEMC_DATA13 GPIO_EMC_B1_35 ALT0
SEMC_DATA14 GPIO_EMC_B1_36 ALT0
SEMC_DATA15 GPIO_EMC_B1_37 ALT0
SEMC_ADDR09 GPIO_EMC_B1_18 ALT0
SEMC_ADDR11 GPIO_EMC_B1_19 ALT0
SEMC_ADDR12 GPIO_EMC_B1_20 ALT0
SEMC_BA1 GPIO_EMC_B1_22 ALT0
SEMC_CSX0 GPIO_EMC_B1_41 ALT0
uSDHC 1 USDHC1_CD_B GPIO_AD_32 ALT4 eMMC/MMC or SD/eSD
connected to one of the
USDHC ports is a primary boot
option. Refere to Expansion
device in Reference Manual for
more information.
USDHC1_WP GPIO_AD_33 ALT4
USDHC1_VSELECT GPIO_AD_34 ALT4
USDHC1_RESET_B GPIO_AD_35 ALT4
USDHC1_CMD GPIO_SD_B1_00 ALT0
USDHC1_CLK GPIO_SD_B1_01 ALT0
USDHC1_DATA0 GPIO_SD_B1_02 ALT0
USDHC1_DATA1 GPIO_SD_B1_03 ALT0
USDHC1_DATA2 GPIO_SD_B1_04 ALT0
USDHC1_DATA3 GPIO_SD_B1_05 ALT0
Table continues on the next page...
NXP Semiconductors
Boot, reset, and miscellaneous
Hardware Development Guide for the MIMXRT1160/1170 Processor , Rev. 2, 09/2021
User Guide 13 / 24

Table 11. ROM Bootloader Peripheral PinMux (continued)
Peripheral Instance Port (IO function) PAD Mode Note
2 USDHC2_CD_B GPIO_AD_26 ALT11
USDHC2_WP GPIO_AD_27 ALT11
USDHC2_VSELECT GPIO_AD_28 ALT11
USDHC2_DATA3 GPIO_SD_B2_00 ALT0
USDHC2_DATA2 GPIO_SD_B2_01 ALT0
USDHC2_DATA1 GPIO_SD_B2_02 ALT0
USDHC2_DATA0 GPIO_SD_B2_03 ALT0
USDHC2_CLK GPIO_SD_B2_04 ALT0
USDHC2_CMD GPIO_SD_B2_05 ALT0
USDHC2_RESET_B GPIO_SD_B2_06 ALT0
USDHC2_DATA4 GPIO_SD_B2_08 ALT0
USDHC2_DATA5 GPIO_SD_B2_09 ALT0
USDHC2_DATA6 GPIO_SD_B2_10 ALT0
USDHC2_DATA7 GPIO_SD_B2_11 ALT0
FlexSPI1 1 FLEXSPI1_B_DATA
3
GPIO_SD_B2_00 ALT1 QSPI memory attached to
FlexSPI is a primary boot option.
Refer to Serial NOR Flash
Boot via FlexSPI in Reference
Manual for more information.
The ROM will read the 512-
byte FlexSPI NOR configuration
parameters described in FlexSPI
Serial NOR Flash Boot Operation
Reference Manual using the non-
italicized pins.
Note: These pins are a secondary
pinout option for FlexSPI serial
NOR flash boot
FLEXSPI1_B_DATA
2
GPIO_SD_B2_01 ALT1
FLEXSPI1_B_DATA
1
GPIO_SD_B2_02 ALT1
FLEXSPI1_B_DATA
0
GPIO_SD_B2_03 ALT1
FLEXSPI1_B_SCLK GPIO_SD_B2_04 ALT1
FLEXSPI1_B_DQS GPIO_SD_B1_05 ALT8
FLEXSPI1_B_SS0_B GPIO_SD_B1_04 ALT8
FLEXSPI1_B_SS1_B GPIO_SD_B1_03 ALT9
FLEXSPI1_A_DQS GPIO_SD_B2_05 ALT1
FLEXSPI1_A_SS0_B GPIO_SD_B2_06 ALT1
FLEXSPI1_A_SS1_B GPIO_SD_B1_02 ALT9
FLEXSPI1_A_SCLK GPIO_SD_B2_07 ALT1
FLEXSPI1_A_DATA
0
GPIO_SD_B2_08 ALT1
FLEXSPI1_A_DATA
1
GPIO_SD_B2_09 ALT1
Table continues on the next page...
NXP Semiconductors
Boot, reset, and miscellaneous
Hardware Development Guide for the MIMXRT1160/1170 Processor , Rev. 2, 09/2021
User Guide 14 / 24

Table 11. ROM Bootloader Peripheral PinMux (continued)
Peripheral Instance Port (IO function) PAD Mode Note
FLEXSPI1_A_DATA
2
GPIO_SD_B2_10 ALT1
FLEXSPI1_A_DATA
3
GPIO_SD_B2_11 ALT1
FLEXSPI1_A_DQS GPIO_EMC_B2_18 ALT6 Second option
FlexSPI2 (QSPI /
HyperFLASH)
2 FLEXSPI2_B_DATA
7
GPIO_EMC_B1_41 ALT4 Octal serial NOR flash memory
attached to FlexSPI is a
primary boot option. Refer to
Serial NOR Flash Boot via
FlexSPI in Reference Manual
for more information. The ROM
will read the 512-byte FlexSPI
NOR configuration parameters
described in FlexSPI Serial
NOR Flash Boot Operation
in Reference Manual using
the non-italicized pins For
8-bit wide memories the
FLEXSPI_B_DATA[3:0] pins
are combined with the
FLEXSPI_A_DATA[3:0] lines to
get the full 8-bit port.
Note: ROM can configure the
italicized signals based on
the FlexSPI NOR configuration
parameters provided.
FLEXSPI2_B_DATA
6
GPIO_EMC_B2_00 ALT4
FLEXSPI2_B_DATA
5
GPIO_EMC_B2_01 ALT4
FLEXSPI2_B_DATA
4
GPIO_EMC_B2_02 ALT4
FLEXSPI2_B_DATA
3
GPIO_EMC_B2_03 ALT4
FLEXSPI2_B_DATA
2
GPIO_EMC_B2_04 ALT4
FLEXSPI2_B_DATA
1
GPIO_EMC_B2_05 ALT4
FLEXSPI2_B_DATA
0
GPIO_EMC_B2_06 ALT4
FLEXSPI2_B_DQS GPIO_EMC_B2_07 ALT4
FLEXSPI2_B_SS0_B GPIO_EMC_B2_08 ALT4
FLEXSPI2_B_SCLK GPIO_EMC_B2_09 ALT4
FLEXSPI2_A_SCLK GPIO_EMC_B2_10 ALT4
FLEXSPI2_A_SS0_B GPIO_EMC_B2_11 ALT4
FLEXSPI2_A_DQS GPIO_EMC_B2_12 ALT4
FLEXSPI2_A_DATA
0
GPIO_EMC_B2_13 ALT4
FLEXSPI2_A_DATA
1
GPIO_EMC_B2_14 ALT4
FLEXSPI2_A_DATA
2
GPIO_EMC_B2_15 ALT4
FLEXSPI2_A_DATA
3
GPIO_EMC_B2_16 ALT4
FLEXSPI2_A_DATA
4
GPIO_EMC_B2_17 ALT4
Table continues on the next page...
NXP Semiconductors
Boot, reset, and miscellaneous
Hardware Development Guide for the MIMXRT1160/1170 Processor , Rev. 2, 09/2021
User Guide 15 / 24

Table 11. ROM Bootloader Peripheral PinMux (continued)
Peripheral Instance Port (IO function) PAD Mode Note
FLEXSPI2_A_DATA
5
GPIO_EMC_B2_18 ALT4
FLEXSPI2_A_DATA
6
GPIO_EMC_B2_19 ALT4
FLEXSPI2_A_DATA
7
GPIO_EMC_B2_20 ALT4
GPIO_MUX2_IO08 GPIO_EMC_B1_40 ALT5 Second option
GPIO_MUX4_IO03 GPIO_SD_B1_00 ALT5 FlexSPI Reset
SEMC_ADDR09 GPIO_EMC_18 ALT0
SEMC_ADDR11 GPIO_EMC_19 ALT0
SEMC_ADDR12 GPIO_EMC_20 ALT0
SEMC_BA1 GPIO_EMC_22 ALT0
SEMC_RDY GPIO_EMC_40 ALT0
SEMC_CSX0 GPIO_EMC_41 ALT0
SEMC_CSX1 GPIO_B0_00 ALT6
SEMC_CSX2 GPIO_B0_01 ALT6
SEMC_CSX3 GPIO_B0_02 ALT6
SEMC_ADDR08 GPIO_EMC_17 ALT0
FlexSPIN OR Flash-
QSPI
1 FLEXSPI_B_DATA3 GPIO_SD_B1_00 ALT1 QSPI memory attached to
FlexSPI is a primary boot option.
Refer to Serial NOR Flash
Boot via FlexSPI in Reference
Manual for more information.The
ROM will read the 512-byte
FlexSPI described in FlexSPI
Serial NOR Flash Boot Operation
in Reference Manual using the
non italicized pins.
Note: ROM can configure the
italicized signals based on
the FlexSPI NOR configuration
parameters provided.
FLEXSPI_B_DATA2 GPIO_SD_B1_01 ALT1
FLEXSPI_B_DATA1 GPIO_SD_B1_02 ALT1
FLEXSPI_B_DA TA0 GPIO_SD_B1_03 ALT1
FLEXSPI_B_SCLK GPIO_SD_B1_01 ALT1
FLEXSPI_B_DQS GPIO_SD_B0_05 ALT4
FLEXSPI_B_SS0_B GPIO_SD_B0_04 ALT4
FLEXSPI_B_SS1_B GPIO_SD_B0_01 ALT6
FLEXSPI_A_DQS GPIO_SD_B1_05 ALT1
FLEXSPI_A_SS0_B GPIO_SD_B1_06 ALT1
FLEXSPI_A_SS1_B GPIO_SD_B0_00 ALT6
FLEXSPI_A_SCLK GPIO_SD_B1_07 ALT1
FLEXSPI_A_DATA0 GPIO_SD_B1_08 ALT1
FLEXSPI_A_DATA1 GPIO_SD_B1_09 ALT1
FLEXSPI_A_DATA2 GPIO_SD_B1_10 ALT1
Table continues on the next page...
NXP Semiconductors
Boot, reset, and miscellaneous
Hardware Development Guide for the MIMXRT1160/1170 Processor , Rev. 2, 09/2021
User Guide 16 / 24

Table 11. ROM Bootloader Peripheral PinMux (continued)
Peripheral Instance Port (IO function) PAD Mode Note
FLEXSPI_A_DATA3 GPIO_SD_B1_11 ALT1
FlexSPIN OR-
QSPI-2nd Option
1 FLEXSPI_A_SS0_B GPIO_AD_B1_15 ALT0 QSPI memory attached to
FlexSPI is a primary boot option.
Refer to Serial NOR Flash Boot
via FlexSPI in Reference Manual
for more information. The ROM
will read the 512-byte FlexSPI
NOR configuration parameters
described in FlexSPI Serial NOR
Flash Boot Operation Reference
Manual using the non-italicized
pins.
Note: These pins are a secondary
pinout option for FlexSPI serial
NOR flash boot.
FLEXSPI_A_SCLK GPIO_AD_B1_14 ALT0
FLEXSPI_A_DQS GPIO_AD_B1_09 ALT0
FLEXSPI_A_DATA0 GPIO_AD_B1_13 ALT0
FLEXSPI_A_DATA1 GPIO_AD_B1_12 ALT0
FLEXSPI_A_DATA2 GPIO_AD_B1_11 ALT0
FLEXSPI_A_DATA3 GPIO_AD_B1_10 ALT0
Fle xSPIN OR Flash-
Octal
1 FLEXSPI_B_DATA3 GPIO_SD_B1_00 ALT1 Octal serial NOR flash memory
attached to FlexSPI is a
primary boot option. Refer to
Serial NOR Flash Boot via
FlexSPI in Reference Manual
for more information. The ROM
will read the 512-byte FlexSPI
NOR configuration parameters
described in FlexSPI Serial
NOR Flash Boot Operation
in Reference Manual using
the non-italicized pins For
8-bit wide memories the
FLEXSPI_B_DATA[3:0] pins
are combined with the
FLEXSPI_A_DATA[3:0] lines to
get the full 8-bit port.
FlexSPI NOR configuration
parameters provided.
FLEXSPI_B_DATA2 GPIO_SD_B 1_01 ALT1
FLEXSPI_B_DATA1 GPIO_SD_B1_02 ALT1
FLEXSPI_B_DATA0 GPIO_SD_B1_03 ALT1
FLEXSPI_B_SCLK GPIO_SD_B1_01 ALT1
FLEXSPI_B_DQS GPIO_SD_B0_05 ALT4
FLEXSPI_B_SS0_B GPIO_SD_B0_04 ALT4
FLEXSPI_B_SS1_B GPIO_SD_B0_01 ALT6
FLEXSPI_A_DQS GPIO_SD_B1_05 ALT1
FLEXSPI_A_SS0_B GPIO_SD_B1_06 ALT1
FLEXSPI_A_SS1_B GPIO_SD_B0_00 ALT6
FLEXSPI_A_SCLK GPIO_SD_B1_07 ALT1
FLEXSPI_A_DATA0 GPIO_SD_B1_08 ALT1
FLEXSPI_A_DATA1 GPIO_SD_B1_09 ALT1
FLEXSPI_A_DATA2 GPIO_SD_B1_10 ALT1
FLEXSPI_A_DATA3 GPIO_SD_B1_11 ALT1
FlexSPI NAND Flash 1 FLEXSPI_A_DQS GPIO_SD_B1_05 ALT1 Serial NAND memory attached to
FlexSPI is a primary boot option.
Refer to Serial NAND Flash
Boot over FlexSPI in Reference
Manual for more information.
FLEXSPI_A_SS0_B GPIO_SD_B1_06 ALT1
FLEXSPI_A_SCLK GPIO_SD_B1_07 ALT1
FLEXSPI_A_DATA0 GPIO_SD_B1_08 ALT1
FLEXSPI_A_DATA1 GPIO_SD_B1_09 ALT1
FLEXSPI_A_DATA2 GPIO_SD_B1_10 ALT1
Table continues on the next page...
NXP Semiconductors
Boot, reset, and miscellaneous
Hardware Development Guide for the MIMXRT1160/1170 Processor , Rev. 2, 09/2021
User Guide 17 / 24

Table 11. ROM Bootloader Peripheral PinMux (continued)
Peripheral Instance Port (IO function) PAD Mode Note
FLEXSPI_A_DATA3 GPIO_SD_B1_11 ALT1
FlexSPI RESET GPIO1_IO29 GPIO_AD_B1_13 ALT5
ROM does not support boot from FLEXSPI_B port directly. ROM always seeks a valid Flash Configuration Block
from the FLEXSPI_A port and then re-configures the FLEXSPI controller using the valid parameters in the block
read-out. This reconfiguration can include, but is not limited to, FLEXSPI_B port support.
NOTE
7 Layout recommendations
7.1 Stackup
A high-speed design requires a good stackup to have the right impedance for the critical traces.
Figure 4. IMXRT1170EVK stackup
The constraints for the trace width depend on many factors, such as the board stackup and the associated dielectric and copper
thickness, required impedance, and required current (for power traces). The stackup also determines the constraints for routing
and spacing. Consider the following when designing the stackup and selecting the material for your board:
• The board stackup is critical for the high-speed signal quality.
• Preplan the impedance of the critical traces.
• The high-speed signals must have reference planes on adjacent layers to minimize crosstalk.
• The NXP reference design equals Isola FR4.
• The NXP validation boards equal Isola FR4.
• The recommended stackup is six layers, with the layer stack shown in Figure 4.The left- hand image shows the detail
provided by NXP inside the fabrication detail as a part of the Gerber files. The right-hand side shows the solution
suggested by the PCB fabrication company for the requirements. Figure 5 shows the IMXRT1170EVK PCB stackup
implementation:
NXP Semiconductors
Layout recommendations
Hardware Development Guide for the MIMXRT1160/1170 Processor , Rev. 2, 09/2021
User Guide 18 / 24

Figure 5. IMXRT1170EVK stackup implementation
7.2 Placement of bulk and decoupling capacitors
Place the small decoupling capacitors and the larger bulk capacitors on the bottom side of the CPU. The 0402 decoupling
capacitors and the 0603 bulk capacitors must be placed as close as possible to the power balls. Placing the decoupling capacitors
close to the power balls is critical to minimize inductance and ensure the high-speed transient current demand of the processor.
The correct via size, trace width, and trace space are critical to preserve the adequate routing space. The recommended geometry
is as follows:
• For the BGA constraint area:
— The via type is 18/8 mils, the trace width is 4 mils, and the trace space is 3.79 mils.
• For the default area (except for the BGA):
— The via type is 18/8 mils, the trace width is 7 mils, and the trace space is 7 mils.
— The preferred BGA power-decoupling design layout is available at www.nxp.com.
— Use the NXP design strategy for power and decoupling.
7.3 FlexSPI
FlexSPI is a flexible SPI (Serial Peripheral Interface) host controller which supports two SPI channels and up to 4 external
devices. Each channel supports Single/Dual/Quad/ Octal mode data transfer (1/2/4/8 bidirectional data lines). FlexSPI is the most
commonly used external memory.
Please refer to section FlexSPI parameters from the datasheet, there are several sources for the internal sample clock for FlexSPI
read data:
• Dummy read strobe generated by FlexSPI controller and looped back internally
— (FlexSPIn_MCR0[RXCLKSRC] = 0x0)
• Dummy read strobe generated by FlexSPI controller and looped back through the
— DQS pad (FlexSPIn_MCR0[RXCLKSRC] = 0x1)
• Read strobe provided by memory device and input from DQS pad
— (FlexSPIn_MCR0[RXCLKSRC] = 0x3)
So for QSPI Flash without a DQS provided by the memory, only the option of FlexSPIn_MCR0[RXCLKSRC] = 0x1 can achieve
133 MHz SDR R/W speed, and FlexSPI_DQS pin should be left floating.
NXP Semiconductors
Layout recommendations
Hardware Development Guide for the MIMXRT1160/1170 Processor , Rev. 2, 09/2021
User Guide 19 / 24

For Octal Flash where a DQS signal is provided by the memory, need to use the option of FlexSPIn_MCR0[RXCLKSRC] = 0x3
which can achieve 166 MHz DDR R/W, in such case FlexSPI_DQS pin should be connected to the flash directly.
7.4 SDRAM
The SDRAM interface (running at up to 200 MHz) is one of the critical interfaces for the chip routing. The controlled impedance for
the single-ended traces must be 50 Ω. Ideally, route all signals at the same length as the EVK board. See the IMXRT1170-EVK
layout to route all signals at the same length (±50 mils).
The SDRAM routing must be separated into two groups: data and address/control. See the EVK layout to separate all SDRAM
signals into two groups:
• SEMC_DQS signal line should be left floating.
• All data lines and DM[x]
• All address lines and control lines
RT1170EVK is a 6-layer board design, both routing groups refer to the GND plane for the impedance control. One group is routed
at the top layer (the reference plane is the second layer), while the other group is routed at the bottom layer (the reference plane
is the fifth layer).
7.5 USB
Use these recommendations for the USB:
• Route the DP and DM differential pair first.
• Route the DP and DM signals on the top (or bottom) layer of the board.
• The trace width and spacing of the DP and DM signals must meet the differential impedance requirement of 90 Ω.
• Route the traces over the continuous planes (power and ground):
— They must not pass over any power/GND plane slots or anti-etch.
— When placing the connectors, make sure that the ground plane clearouts around each pin have ground continuity
between all pins.
• Maintain the parallelism (skew-matched) between DP and DM, and match the overall differential length difference to less than
5 mils.
• Maintain the symmetric routing for each differential pair.
• Do not route the DP and DM traces under the oscillators or parallel to the clock traces (and/or data buses).
• Minimize the lengths of the high-speed signals that run parallel to the DP and DM pair.
• Keep the DP and DM traces as short as possible.
• Route the DP and DM signals with a minimum amount of corners. Use 45-degree turns instead of 90-degree turns.
• Avoid layer changes (vias) on the DP and DM signals. Do not create stubs or branches.
• Provide the ground return vias within a 50-mil distance from the signal layer-transition vias when transitioning between
different reference ground planes.
• When the USB signals are not used, it is recommended to follow Unused pins recommendation.
7.6 Ethernet
RT1170 has two ethernet controllers, one is 10M/100M ethernet controller with support for IEEE1588 and the other one is gigabit
ethernet controller with support for AVB/TSN. For the RGMII port, the layout is quite critical and below are the guidelines.
• To ensure correct RGMII function, the length of PCB trace should be less than 15cm with a 5pf loading to comply with
maximum 1ns delay regulation and the total trace loading (5pf input loading included) should be within 15pf.
NXP Semiconductors
Layout recommendations
Hardware Development Guide for the MIMXRT1160/1170 Processor , Rev. 2, 09/2021
User Guide 20 / 24
