TWR-MCF51JG Tower Module
User's Manual
Rev. 1.1

TWRMCF51JGUM TWR-MCF51JG Tower Module User's Manual Page 2 of 21
Table of Contents
1TWR-MCF51JG and TWR-MCF51JG-KIT Overview.......................................................................4
1.1 Contents..................................................................................................................................................................................5
1.2 Features ..................................................................................................................................................................................5
1.3 Getting Started.....................................................................................................................................................................6
1.4 Reference Documents.......................................................................................................................................................6
2Hardware Description ...........................................................................................................................7
2.1 MCF51JG Microcontroller................................................................................................................................................7
2.2 Clocking ..................................................................................................................................................................................8
2.3 System Power.......................................................................................................................................................................9
2.4 Debug Interface ................................................................................................................................................................13
2.4.1 OSBDM ................................................................................................................................................................................................. 13
2.5 Accelerometer...................................................................................................................................................................13
2.6 Pushbuttons, LEDs ..........................................................................................................................................................14
2.7 General Purpose Tower Plug-in (TWRPI) Socket...............................................................................................14
2.8 USB.........................................................................................................................................................................................15
3Jumper Table.......................................................................................................................................... 16
4Input/Output Connectors and Pin Usage Table......................................................................... 17
5Tower Elevator Connections ............................................................................................................ 19

TWRMCF51JGUM TWR-MCF51JG Tower Module User's Manual Page 3 of 21
List of Figures
Figure 1. Freescale Tower System Overview .............................................................................................. 4
Figure 2. Callouts on front side of the TWR-MCF51JG ............................................................................... 6
Figure 3. TWR-MCF51JG Block Diagram ..................................................................................................... 7
Figure 4. Main Oscillator Input ................................................................................................................... 8
Figure 5. 32 KHz Oscillator Input................................................................................................................. 9
Figure 6. Accelerometer Circuit ................................................................................................................ 13
Figure 7. USB dual-role interface.............................................................................................................. 16
List of Tables
Table 1. J10, Regulator Power Source Selection......................................................................................... 9
Table 2. J9, Board Power Source Selection............................................................................................... 11
Table 3. J12, Board Power Source Selection............................................................................................. 11
Table 4. General Purpose TWRPI socket pinout ....................................................................................... 15
Table 5. TWR-MCF51JG Jumper Table ...................................................................................................... 16
Table 6. I/O Connectors and Pin Usage Table........................................................................................... 17
Table 7. TWR-MCF51JG Primary Connector Pinout.................................................................................. 19
Revision History
Revision
Date
Changes
0
Initial Release for Rev A pre-production module.
1
Oct. 2012
Updates for Rev B module.

TWRMCF51JGUM TWR-MCF51JG Tower Module User's Manual Page 4 of 21
1TWR-MCF51JG and TWR-MCF51JG-KIT Overview
The TWR-MCF51JG is a Tower Controller Module compatible with the Freescale Tower System. It can
function as a stand-alone, low-cost platform for the evaluation of the ColdFire+ MCF51JG
microcontroller (MCU) devices. The TWR-MCF51JG features the MCF51JG, a ColdFire+ 32-bit
microcontroller built on the Version 1 (V1) ColdFire® core and enabled by innovative 90nm thin film
storage (TFS) flash process technology with FlexMemory. The MCF51Jx families offer a rich
combination of additive peripherals including USB, hardware encryption, and more.
The TWR-MCF51JG is available as a stand-alone product or as a kit (TWR-MCF51JG-KIT) with the Tower
Elevator Modules (TWR-ELEV) and the Tower Prototyping Module (TWR-PROTO). The TWR-MCF51JG
can also be combined with other Freescale Tower peripheral modules to create development
platforms for a wide variety of applications. Figure 1 provides an overview of the Freescale Tower
System.
Figure 1. Freescale Tower System Overview

TWRMCF51JGUM TWR-MCF51JG Tower Module User's Manual Page 5 of 21
1.1 Contents
The TWR-MCF51JG contents include:
TWR-MCF51JG board assembly
3ft A to mini-B USB cable for debug interface and power
3ft A to micro-B USB cable for MCF51JG USB interface
Micro-A to A adapter for MCF51JG USB Host applications
Quick Start Guide
The TWR-MCF51JG-KIT contains:
TWR-MCF51JG MCU module
TWR-ELEV –Primary and Secondary Elevator Modules
TWR-PROTO –Prototyping module
1.2 Features
Figure 2 shows the TWR-MCF51JG with some of the key features called out. The following list
summarizes the features of the TWR-MCF51JG Tower MCU Module:
Tower compatible microcontroller module
MCF51JG256: MCF51JG with 256 Kbytes of flash in a 44-pin MAPLGA package
Dual role USB interface with Micro-AB USB connector
General purpose Tower Plug-in (TWRPI) socket
On-board debug circuit (OSBDM) with virtual serial port
Three axis accelerometer (MMA8451Q)
Two (2) user-controllable LEDs
Two (2) user pushbutton switches & One (1) reset pushbutton switch

TWRMCF51JGUM TWR-MCF51JG Tower Module User's Manual Page 6 of 21
Figure 2. Callouts on front side of the TWR-MCF51JG
1.3 Getting Started
Follow the Quick Start Guide found printed in the TWR-MCF51JG box or the interactive DVD for the list
of recommended steps for getting started. Check for new or revised documentation on the tool
support page for the TWR-MCF51JG: http://www.freescale.com/TWR-MCF51JG.
1.4 Reference Documents
The documents listed below should be referenced for more information on the ColdFire+ devices,
Freescale Tower System, and the TWR-MCF51JG Controller Module. These can be found in the
documentation section of freescale.com/TWR-MCF51JG or freescale.com/coldfire+.
TWR-MCF51JG-QSG: Quick Start Guide
TWR-MCF51JG-SCH: Schematics
TWR-MCF51JG-PWA: Design Package
ColdFire+ Portfolio Product Brief
MCF51JG256 Reference Manual
Tower Configuration Tool
Tower Mechanical Drawing
Switches
LEDs
Reset
Power / OSBDM
Mini-B USB
Connector
MCF51JG Micro-
AB USB Connector
General Purpose
TWRPI Socket
Secondary
Connector
Primary Connector
MMA8451Q
Accelerometer
MCF51JG256
Power Select
Jumpers

TWRMCF51JGUM TWR-MCF51JG Tower Module User's Manual Page 7 of 21
2Hardware Description
The TWR-MCF51JG is a Tower Controller Module featuring the MCF51JG256—a ColdFire+ based
microcontroller with USB 2.0 full-speed OTG controllers in a 44 MAPLGA package. It is intended for use
in the Freescale Tower System but can operate stand-alone. An on-board debug circuit, OSBDM,
provides a BDM interface and a power supply input through a single USB mini B connector. Figure 3
shows a block diagram of the TWR-MCF51JG. The following sections describe the hardware in more
detail.
Figure 3. TWR-MCF51JG Block Diagram
2.1 MCF51JG Microcontroller
The TWR-MCF51JG module features the MCF51JG256CFT. The key features of the microcontroller are:
32-bit ColdFire+ core with FlexMemory, EMAC, and DIV hardware acceleration
50 MHz maximum core operating frequency
44-pin MAPLGA, 5mm x 5mm
1.85V –3.6V operating voltage input range
256 Kbytes of program flash, 64 Kbytes of static RAM
FlexMemory consisting of 32 Kbytes of FlexMemory that can be used as additional non-volatile
flash or up to 2KB of enhanced EEPROM.
10 flexible low power modes, ideal for extending battery life
Cryptographic Acceleration Unit (CAU) and Random Number Generator (RNGA) for secure
communications

TWRMCF51JGUM TWR-MCF51JG Tower Module User's Manual Page 8 of 21
Integrated USB 2.0 Full-Speed Device/Host/OTG Controller supporting connection via USB and
battery charging
Serial audio interface (SAI) providing a direct interface to codecs and to Inter-IC Sound (I2S)
audio devices
Real-time debug support, with six hardware breakpoints that can be configured to halt the
processor or generate debug interrupt
Multi-purpose clock generator with PLL and FLL operation modes; multiple input oscillator or
resonator frequency ranges; two internal trimmable references
SPI, I2C, UART (SCI)
GPIO with pin interrupt support, DMA request capability, digital glitch filtering
2.2 Clocking
The ColdFire+ MCUs start up from an internal digitally controlled oscillator (DCO). Software can enable
the main external oscillator (EXTAL/XTAL) if desired. The external oscillator/resonator for the
Multipurpose Clock Generator (MCG) module can range from 32.768 KHz up to a 32 MHz.
The TWR-MCF51JG provides an 8 MHz ceramic resonator as shown in Figure 4 below and sheet 4 of the
schematics. This oscillator can be used as a clock source for the phase locked loop (PLL) inside the
MCG.
Notes
1. When R7 is not populated (default), configure the crystal oscillator for low-power operation
(MCG_C2[HGO] = 0).
2. The resonator used here has internal load capacitors. Therefore no external or internal load
capacitance within the MCU is required.
Figure 4. Main Oscillator Input
Additionally, the TWR-MCF51JG provides a 32.768 KHz oscillator for an accurate real time clock source.

TWRMCF51JGUM TWR-MCF51JG Tower Module User's Manual Page 9 of 21
Figure 5. 32 KHz Oscillator Input
2.3 System Power
When installed into a Tower System, the TWR-MCF51JG can be powered from either an on-board
source or from another source in the assembled Tower System.
In stand-alone operation, the main power source for the TWR-MCF51JG module is derived from the
5.0V input from either the OSBDM USB mini-B connector (J14), the MCF51JG USB micro-AB connector
(J8), or the EzPort header (J16)when a shunt is placed on jumper J15. Two low-dropout regulators
provide 3.3V and 2.0V supplies from the 5.0V input voltage. Additionally, the 3.3V regulator built into
the MCF51JG can be selected. All the user selectable options can be configured using two headers, J9
and J10.
The J10header is used to select the power source that is supplied to one of the three possible voltage
regulators. The J11header is used to select the regulated board power source. Refer to Table 1 and
Table 2 for details.
Table 1. J10, Regulator Power Source Selection
J10 Shunt Setting
Description
1
2
7
8
1-2
Power from the OSBDM interface (J14) supplied to the on-
board voltage regulators. This is a default setting.
1
2
7
8
5-6
Power from the MCF51JG USB device interface (J8) supplied
to the MCF51JG on-chip regulator. This is a default setting.

TWRMCF51JGUM TWR-MCF51JG Tower Module User's Manual Page 10 of 21
1
2
7
8
6-8
Power from the Tower Primary Connector USB device
interface supplied to the MCF51JG on-chip regulator.
1
2
7
8
3-5
2-4
Power from the MCF51JG USB device interface (J8) supplied
to the on-board voltage regulators.

TWRMCF51JGUM TWR-MCF51JG Tower Module User's Manual Page 11 of 21
Table 2. J9, Board Power Source Selection
J9 Shunt Setting
Description
1
2
7
8
3-5
Board power is supplied by the 3.3V on-board (external)
regulator. This is the default setting.
1
2
7
8
5-7
Board power is supplied by the 2.0V on-board (external)
regulator.
1
2
7
8
1-2
Board power is supplied by the 3.3V MCF51JG on-chip
(internal) regulator.
1
2
7
8
1-3
5-7
Power from the 3.3V MCF51JG on-chip (internal) regulator is
supplied to the 3.3V on-board (external) regulator. Board
power is supplied by the 2.0V on-board (external) regulator.
Note: Take care not to install a shunt on J10 pins 1-2 when J9
is in this configuration. It is recommended to remove the
shunt from J10 1-2 and use it on J9 for this setting.
1
2
7
8
+
―
―
An external battery or other alternate source can be
connected to pins 5 (positive) and 6 (negative, ground).
The 3.3V or 2.0V power supplied to the MCU is routed through a jumper, J12. The jumper shunt can be
removed to allow for either (1) selecting the source of the MCU supply voltage or (2) the measurement
of power consumed by the MCU.
Table 3. J12, Board Power Source Selection
J12 Shunt Setting
Description
3-5
MCU power is supplied by the board power source selection
jumper (J9). This is the default setting.
5-7
MCU power is supplied by the 3.3V MCF51JG on-chip
(internal) regulator. Use this jumper setting if it is desired to
power only the MCU with the on-chip (internal) regulator and
not the rest of the board.

TWRMCF51JGUM TWR-MCF51JG Tower Module User's Manual Page 12 of 21

TWRMCF51JGUM TWR-MCF51JG Tower Module User's Manual Page 13 of 21
2.4 Debug Interface
There are two debug interface options provided: the on-board OSBDM circuit and an external
Background Debug Mode (BDM) connector. The BDM connector is a standard 6-pin connector
providing an external debugger cable with access to the BDM interface of the MCF51JG256.
Alternatively, the on-board OSBDM debug interface can be used to access the debug interface of the
MCF51JG256.
Note: When using an external debug pod to connect to the MCF51JG, be sure to connect the BDM
cable to J17 (JG BDM). Avoid connecting to J18 (JM60 BDM) which is directly next to J17. J18 provides
a debug connection to the OSBDM MCU (MC9S08JM60).
2.4.1 OSBDM
An on-board MC9S08JM60 based Open Source BDM (OSBDM) circuit provides a BDM debug interface
to the MCF51JG. A standard USB A male to mini-B male cable (provided) can be used for debugging via
the USB connector, J14. The OSBDM interface also provides a USB to serial bridge. Drivers for the
OSBDM interface are provided in the P&E Micro OSBDM/OSJTAG Tower Toolkit (available on the
MCF51JG product website). These drivers and more utilities can be found online at
http://www.pemicro.com/osbdm.
2.5 Accelerometer
An MMA8451Q digital accelerometer is connected to the MCF51JG MCU through an I2C interface
(I2C0: PTB2 and PTB3) and two GPIO/IRQ signals (PTC4 and PTC5).
Figure 6. Accelerometer Circuit

TWRMCF51JGUM TWR-MCF51JG Tower Module User's Manual Page 14 of 21
2.6 Pushbuttons, LEDs
The TWR-MCF51JG features, two pushbutton switches (SW1 & SW2) connected to IRQ signals IRQ0
(PTB1) and IRQ3 (PTC1), a pushbutton switch (SW3) connected to the master reset signal, and two
user-controllable LEDs connected to GPIO signals (PTB6 and PTC0).
Refer to Table 6 “I/O Connectors and Pin Usage Table”for more information.
2.7 General Purpose Tower Plug-in (TWRPI) Socket
The TWR-MCF51JG features a socket that can accept a variety of different Tower Plug-in modules
featuring sensors, RF transceivers, and more. The General Purpose TWRPI socket provides access to
I2C, SPI, IRQs, GPIOs, timers, analog conversion signals, TWRPI ID signals, reset, and voltage supplies.
The pinout for the TWRPI Socket is defined in Table 4.
Refer to Table 6 “I/O Connectors and Pin Usage Table” for the specific MCF51JG pin connections to the
General Purpose TWRPI socket.

TWRMCF51JGUM TWR-MCF51JG Tower Module User's Manual Page 15 of 21
Table 4. General Purpose TWRPI socket pinout
Left-side 2x10 Connector
Right-side 2x10 Connector
Pin
Description
1
5V VCC
2
3.3 V VCC
3
GND
4
3.3V VDDA
5
VSS (Analog GND)
6
VSS (Analog GND)
7
VSS (Analog GND)
8
ADC: Analog 0
9
ADC: Analog 1
10
VSS (Analog GND)
11
VSS (Analog GND)
12
ADC: Analog 2
13
VSS (Analog GND)
14
VSS (Analog GND)
15
GND
16
GND
17
ADC: TWRPI ID 0
18
ADC: TWRPI ID 1
19
GND
20
Reset
Pin
Description
1
GND
2
GND
3
I2C: SCL
4
I2C: SDA
5
GND
6
GND
7
GND
8
GND
9
SPI: MISO
10
SPI: MOSI
11
SPI: SS
12
SPI: CLK
13
GND
14
GND
15
GPIO: GPIO0/IRQ
16
GPIO: GPIO1/IRQ
17
GPIO: GPIO2
18
GPIO: GPIO3
19
GPIO: GPIO4/Timer
20
GPIO: GPIO5/Timer
2.8 USB
The MCF51JG features a USB full-speed/low-speed OTG/Host/Device controller with built-in
transceiver. The TWR-MCF51JG routes the USB D+ and D- signals from the MCF51JG MCU to either the
on-board USB connector (J8) or the Tower Primary Connector (allowing the connection to external USB
connectors or additional circuitry on a Tower peripheral module) depending on the value of four
optional resistors: R11/R12 and R13/R14. By default, R11 and R12 are not populated and R13 and R14
are. This connects the MCF51JG USB signals to the on-board USB circuit.
A power supply switch with an enable input signal and over-current flag output signal is used to supply
power to the USB connector when the MCF51JG is operating in host mode. Port pin PTA2 is connected
to the flag output signal and port pin PTA1 is used to drive the enable signal. Both port pins can be
isolated with jumpers if needed.

TWRMCF51JGUM TWR-MCF51JG Tower Module User's Manual Page 16 of 21
Figure 7. USB dual-role interface
3Jumper Table
There are several jumpers on the TWR-MCF51JG that provide configuration selection and signal
isolation. Refer to the following table for details. The default installed jumper settings are shown in
bold with asterisks.
Table 5. TWR-MCF51JG Jumper Table
Jumper
Option
Setting
Description
J1
USB Power Switch Enable
Input Connection
*ON*
Connect PTA1 to USB power switch enable input
OFF
Disconnect PTA1 from USB power switch enable
J2
USB Power Switch Flag
Output Connection
*ON*
Connect PTA2 to USB power switch over-current
flag output
OFF
Disconnect PTA2 from USB power switch over-
current flag output
J4
SCI1/SPI1 Connection
Selection
*1-2*
Connect SCI1_RX/SPI1_MISO to SPI1_MISO
on Primary Edge
2-3
Connect SCI1_RX/SPI1_MISO to SCI1_RX (RXD1)
on Primary Edge
J5
SCI1/SPI1 Connection
Selection
*1-2*
Connect SCI1_TX/SPI1_MOSI to SPI1_MOSI
on Primary Edge
2-3
Connect SCI1_TX/SPI1_MOSI to SCI1_TX (TXD1)
on Primary Edge
J9
Board Power Source
Selection
*3-5*
Refer to Table 2

TWRMCF51JGUM TWR-MCF51JG Tower Module User's Manual Page 17 of 21
J10
Regulator Power Source
Selection
*1-2*
*5-6*
Refer to Table 1
J12
MCU Voltage Selector
*1-2*
Power MCU from board power source selection
jumper (J9).
2-3
Power MCU with output of on-chip voltage
regulator (VOUT33).
J13
OSBDM Mode Selection
ON
OSBDM bootloader mode (OSBDM firmware
reprogramming)
*OFF*
Debugger mode
J15
EzPort Power Connection
ON
Connect on-board 5V supply to EzPort header
(supports powering board from external EzPort
probe)
*OFF*
Disconnect on-board 5V supply from EzPort
header
4Input/Output Connectors and Pin Usage Table
The following table provides details on which MCF51JG pins are using to communicate with the LEDs,
switches, and other I/O interfaces onboard the TWR-MCF51JG.
Note: Some port pins are used in multiple interfaces on-board and many are potentially connected to
off-board resources via the Tower Primary Connector. Take care to avoid attempted simultaneous
usage of mutually exclusive features.
Table 6. I/O Connectors and Pin Usage Table
Feature
Connection
Port Pin
Pin Function
Shared With
OSBDM/USB
Bridge
UART Receive
PTB5
SCI2_RX
SPI2_MISO
UART Transmit
PTB4
SCI2_TX
SPI2_MOSI
USB OTG
Data Negative
USB0_DN
Differential Data
Data Positive
USB0_DP
Differential Data
EZPORT
EZPort Clock
PTB0
EZP_CLK
TWRPI, USB
OTG
EZPort Data Out
PTA6
EZP_DO
TWRPI, SAI
EZPort Data In
PTA7
EZP_DI
TWRPI
EZPort Chip Select
PTB1
EXP_CS_B
IRQ0/SW1
Reset
RESET_B
JG_RESET_B
Switches
SW1
PTB1
IRQ0
EZP_CS_B
SW2
PTC1
IRQ3
FTM1_CH5
SW3
RESET_B
Reset
SAI
SAI Receive FS
PTA6
SAI0_RX_FS
EZPORT, TWRPI

TWRMCF51JGUM TWR-MCF51JG Tower Module User's Manual Page 18 of 21
Feature
Connection
Port Pin
Pin Function
Shared With
SAI Transmit FS
PTD0
SAI0_RX_FS
SPI
SAI Transmit Data
PTD1
SAI0_TXD
SPI
SAI Receive Data
PTA5
SAI0_RXD
FTM1_CH4
SAI Receive Clock
PTA3
SAI0_RX_BCLK
FTM1_CH2,
CLKOUT
SAI Transmit Clock
PTD2
SAI0_TX_BCLK
SPI
SAI Input Clock
PTD3
SAI0_CLKIN/MCLK
SPI
Accelerometer
I2C Clock
PTB2
IIC0_SCL
I2C Data
PTB3
IIC0_SDA
IRQ1
PTC4
IRQ1
SCI1_RTS
IRQ2
PTC5
IRQ2
SCI1_CTS
TWRPI
TWRPI I2C SCL (J7 Pin 3)
PTB2
IIC0_SCL
Accelerometer
TWRPI I2C SDA (J7 Pin 4)
PTB3
IIC0_SDA
Accelerometer
TWRPI SPI MISO (J7 Pin 9)
PTC2
SPI1_MISO
SCI1_RX
TWRPI SPI MOSI (J7 Pin 10)
PTB7
SPI1_MOSI
SCI1_TX
TWRPI SPI SS (J7 Pin 11)
PTC7
SPI1_SS
TWRPI SPI CLK (J7 Pin 12)
PTC3
SPI1_SCLK
TWRPI GPIO0 (J7 Pin 15)
PTA6
GPIO0
SAI0, EZPORT
TWRPI GPIO1 (J7 Pin 16)
PTB0
GPIO1
USB OTG,
EZPORT
TWRPI GPIO2 (J7 Pin 17)
PTA7
GPIO2
EZPORT
TWRPI GPIO3 (J7 Pin 18)
PTA1
GPIO3
FTM1_CH0,
IIC1_SCL
TWRPI GPIO4 (J7 Pin 19)
PTA2
GPIO4
FTM1_CH1,
IIC1_SDA
LEDs
Yellow LED (D5)
PTB6
LED1
Orange LED (D4)
PTC0
LED2

TWRMCF51JGUM TWR-MCF51JG Tower Module User's Manual Page 19 of 21
5Tower Elevator Connections
The TWR-MCF51JG features two expansion card-edge connectors that interface to the Primary and
Secondary Elevator boards in a Tower system. The Primary Connector (comprised of sides A and B) is
utilized by the TWR-MCF51JG while the Secondary Connector (comprised of sides C and D) only makes
connections to the GND pins. Table 7 provides the pinout for the Primary Connector. (NC = No
Connection)
Table 7. TWR-MCF51JG Primary Connector Pinout
Pin #
Side B
Pin #
Side A
Name
Usage
Name
Usage
1
5V
P5V_ELEV
1
5V
P5V_ELEV
2
GND
GND
2
GND
GND
3
3.3V
P3V3
3
3.3V
P3V3
4
ELE_PS_SENSE_1
ELE_PS_SENSE
4
3.3V
P3V3
5
GND
GND
5
GND
GND
6
GND
GND
6
GND
GND
7
SDHC_CLK / SPI1_CLK
PTC3
7
IIC0_SCL
PTB2
8
NC
8
IIC0_SDA
PTB3
9
SDHC_D3 / SPI1_CS0_b
PTC7
9
GPIO9/UART1_CTS
PTC5
10
SDHC_CMD / SPI1_MOSI
SPI1_MOSI
10
NC
11
SDHC_D0 / SPI1_MISO
SPI1_MISO
11
NC
12
NC
12
NC
13
NC
13
NC
14
NC
14
NC
15
NC
15
NC
16
NC
16
NC
17
NC
17
NC
18
NC
18
NC
19
NC
19
NC
20
NC
20
NC
21
GPIO1/UART1_RTS
PTC4
21
I2S0_MCLK
PTD3
22
NC
22
I2S0_DOUT_SCK
PTD2
23
NC
23
I2S0_DOUT_WS
PTD0
24
NC
24
I2S0_DIN0
PTA5
25
NC
25
I2S0_DOUT0
PTD1
26
GND
GND
26
GND
GND
27
NC
27
NC
28
NC
28
NC
29
NC
29
NC
30
NC
30
NC
31
GND
GND
31
GND
GND
32
NC
32
NC
33
NC
33
NC

TWRMCF51JGUM TWR-MCF51JG Tower Module User's Manual Page 20 of 21
Pin #
Side B
Pin #
Side A
Name
Usage
Name
Usage
34
NC
34
NC
35
GPIO4
PTB6
35
NC
36
3.3V
P3V3
36
3.3V
P3V3
37
NC
37
NC
38
NC
38
PWM2
PTA3
39
PWM5
PTC1
39
PWM1
PTA2
40
PWM4
PTA6
40
PWM0
PTA1
41
NC
41
UART0_RX
PTB5
42
NC
42
UART0_TX
PTB4
43
NC
43
UART1_RX
SCI1_RX
44
SPI0_MISO
PTD2
44
UART1_TX
SCI1_TX
45
SPI0_MOSI
PTD1
45
NC
46
SPI0_CS0_b
PTD0
46
NC
47
NC
47
NC
48
SPI0_CLK
PTD3
48
NC
49
GND
GND
49
NC
50
I2C1_SCL
PTA1
50
NC
51
I2C1_SDA
PTA2
51
NC
52
GPIO5
PTC0
52
NC
53
NC
53
NC
54
NC
54
USB0_DN
JG_ELEV_USB0_DN
55
IRQ_H
PTB1
55
USB0_DP
JG_ELEV_USB0_DP
56
IRQ_G
PTB1
56
NC
57
NC
57
USB0_VBUS
USB0_VBUS
58
NC
58
NC
59
NC
59
NC
60
NC
60
NC
61
IRQ_B
PTC1
61
NC
62
IRQ_A
PTC1
62
RSTIN_B
JG_RESET_B
63
NC
63
RSTOUT_B
JG_RESET_B
64
NC
64
CLKOUT0
PTA3
65
GND
GND
65
GND
GND
66
NC
66
NC
67
NC
67
NC
68
NC
68
NC
69
NC
69
NC
70
NC
70
NC
71
NC
71
NC
72
NC
72
NC
73
NC
73
NC
74
NC
74
NC
75
NC
75
NC
75
NC
75
NC
77
NC
77
NC
