NXP Semiconductors TWR-KM34Z50M User manual

TWR-KM34Z50M
Quick Start Guide
Development Kit for Kinetis
KM38/34/33/32/14/13 MCU Families
Tower System
Development Board
Platform
Downloaded from Arrow.com.

2 3
freescale.comQuick Start Guide
TWR-KM34Z50M Freescale Tower System
Development Board Platform
The TWR-KM34Z50M board is designed to work either in standalone mode or as
part of the Freescale Tower System, a modular development board platform that
enables rapid prototyping and tool re-use through reconfigurable hardware. Take
your design to the next level and begin constructing your Tower System rapid
prototyping platform today by visiting freescale.com/Tower for additional Tower
System boards and compatible peripherals.
Get to Know the TWR-KM34Z50M Board
Segment
LCD
Board Power
Selector
K20 GEN
USB
Status LED
RESET b.
TWRPI
VBAT sel.
USB Power/
OpenSDA
K20 GEN SWD
Tamper Sw.
Potentiometer
IRDA
User LEDs
Tamper
Pins
KM34
JTAG/SWD
GPIO
Temperature
Sensor
Figure 1: Front side of TWR-KM34Z50M board
(TWRPI devices not shown)
Analog Inputs/Gen. Out. SW2 SW1
Figure 2: Back side of TWR-KM34Z50M board
U8 K20
OpenSDA
Potentiometer
U6 I2C
EEPROM
Y1 32kHz
RTC Osc.
Battery
Receptacle
U14
K20 GEN
X1 8MHz
Osc.
U3 3V3 Reg.
Downloaded from Arrow.com.Downloaded from Arrow.com.

5
freescale.com
Step-by-Step
Installation Instructions
In this Quick Start Guide, you will learn how to set up the TWR-KM34Z50M board and
run the included demonstrated software. For more detailed information, review the user
manual at freescale.com/TWR-KM34Z50M.
Download Software
and Tools
Download installation
software and documentation
under “Jump Start Your
Design” at freescale.com/
TWR-KM34Z50M.
1
2Install Software
and Tools
Install the OpenSDA Tower Toolkit to install
the OpenSDA and USB-to-Serial drivers.
3Configure the
Hardware
Connect one end of the USB cable to
the PC and the other end to the Power/
OpenSDA mini-B connector (J14) on the
TWR-KM34Z50M board. Allow the PC
to automatically configure the USB drivers
if needed.
4Segment
LCD
All segments are turned on for three
seconds, then potentiometer readings are
displayed. The LEDs should be blinking.
5Move the
Potentiometer
The onboard LCD shows the SAR-ADC
reading.
6Explore
Further
Explore the Kinetis KM “metering” MCU
family, Sigma-Delta ADC performance
and low power modes, 1-ph electro meter
demo in connection with the onboard AC
waveform generator, software peripheral
drivers and more labs at freescale.com/
TWR-KM34Z50M.
4
TWR-KM34Z50M
Features
• MKM34Z5128CLL5 MCU (50 MHz, 128 KB Flash, 16 KB RAM, low power, LQFP 100 package)
• USB interface with mini-AB USB connector
• Large 160-segment glass LCD
• Onboard debug circuit: open source JTAG/SWD (OpenSDA) with virtual serial port
• Three-axis accelerometer/anti-tamper tilt sensor (MMA8491Q)
• Four user-controllable LEDs
• Two user pushbutton switches for GPIO interrupts
• One user pushbutton switch for tamper detection
• One user pushbutton switch for MCU reset
• Potentiometer
• Headers for direct GPIO and ADC access
• External tamper pins
• Independent, battery-operated power supply for real-time clock (RTC) and tamper
detection modules
• Onboard 7-channel sinus signal generator with USB interface for emulating the AC net
waveforms
• IRDA support
• NTC temperature sensor
• General-purpose Tower plug-in (TWRPI) socket
Tools
• Freescale CodeWarrior Development Studio for Microcontrollers V10.5 (CW-MCU10)
• IAR EWARM V6.50 or higher
• Processor Expert software configuration tool with MQX™ Lite RTOS integration available for
CodeWarrior IDE or a standalone for integrating generated code into other IDEs
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

7
freescale.comQuick Start Guide
TWR-KM34Z50M Jumper Options
The following is a list of all the jumper options. The default installed jumper settings are
indicated in the shaded boxes.
6
Option Jumper Setting Description
MCU Power
Connection J1
1-2 Connect VBAT to onboard 3.3 V supply
2-3 Connect VBAT to the higher voltage between MCU supply (MCU_PWR)
or VBATD
VREF Out Selection J2 ON VREF connected to ELEVATOR edge
OFF VREF available on pins
MCU_PWR Selection J6 ON MCU powered from V_BRD 3.3 V on board reg.
OFF MCU can be supplied by ext. Voltage connected to J6–pin 1
Analog Power
Enable J7 ON Connect analog voltages to MCU_PWR
OFF Connect analog voltages to MCU_PWR. external VDDA can be applied
Pot. Enable
(might be hardwired) J8 ON Connect PTG1/AD10 to pot. R20
OFF Disconnect PTG1/AD10 from pot. R20
Temp. Sensor Enable
(might be hardwired) J9 ON Connect PTF0/AD7 to temperature sensor
OFF Disconnect PTF0/AD7 to temperature sensor
Low-Power Current
Measurement J19 ON Low-power current measurement bypassed
OFF Low-power current measurement enabled
OpenSDA Reset
Enabled J20 ON KM34 reset input driven by K20 OpenSDA
OFF KM34 reset input isolated from OpenSDA
DIP Switch S1
Connections S1
ON Connect PTE5 to green LED (D3)
ON Connect PTF1 to red LED (D4)
ON Connect PTD1 to orange LED (D5)
ON Connect PTC1 to yellow LED (D6)
ON Connect IRDA Tx LED (D7) to PTC2
ON Connect IRDA Rx transistor (Q1) to PTC3
ON Connect Serial EEPROM data to I2C0 Data
ON Connect Serial EEPROM clock to I2C0 Clock
ON Connect TILT_ENABLE (MMA8491Q) signal to PTF7
ON Connect VBAT voltage measurement signal to PTF2/AD9
GPIO Header (J10) Signal Connections
MCU Signal J10 Pin MCU Signal
SW3 (Tamper switch) 1 2 SW3 to TAMPER1 (when closed)
SW3 (Tamper switch) 3 4 SW3 to TAMPER2 (when closed)
TILT_XOUT 5 6 TILT_XOUT to TAMPER0
TILT_YOUT 7 8 TILT_YOUT to TAMPER1
TILT_ZOUT 9 10 TILT_ZOUT to TAMPER2
V_BRD 11 12 PTI0/SCI1_RXD
PTI1/SCI1_TXD 13 14 GND
PTE0/I2C0_SDA 15 16 PTD7/I2C0_SCL
PTF6/SPI1_MOSI 17 18 PTF5/SPI1_MISO
PTF4/SPI1_SCK 19 20 PTF3/SPI1_SS
PTA6/AFE_EXT_MOD_IN1 21 22 PTF7/CLKOUT
PTC0/AFE_EXT_MOD_IN2 23 24 PTG0
PTB7/AFE_EXT_CLK_IN 25 26 PTC5/AD0
PTA7/AFE_EXT_CLK_OUT 27 28 PTC6/AD1
VSSA_SAR 29 30 GND
Analog Inputs/Generator Out (J17)
MCU Signal J17 Pin MCU Signal
GEN_OUT0 1 2 EXT_SD_ADP0
GEN_OUT1 3 4 EXT_SD_ADP1
GEN_OUT2 5 6 EXT_SD_ADP2
GEN_OUT3 7 8 EXT_SD_ADP3
GEN_OUT4 9 10 EXT_SAR_AD0
GEN_OUT5 11 12 EXT_SAR_AD1
GEN_OUT6 13 14 EXT_SAR_AD2
VSSA 15 16 EXT_SD_ADM0 (can short to VSSA)
VSSA 17 18 EXT_SD_ADM1
VSSA 19 20 EXT_SD_ADM2
VSSA 21 22 EXT_SD_ADM3
K20 Generator Default Operation (SW5 Settings)
Option Position Setting MCU Signal
DIP SW5
Settings
1 OFF K20 USB communication disabled, K20 in Very Low-Power Stop (VLPS) mode
2 OFF Generator output disabled
1 ON USB communication and KM34 current sensing enabled, green LED ON
2 ON Generator output enabled, amber LED ON
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

Support
Visit freescale.com/support for a list of phone
numbers within your region.
Warranty
Visit freescale.com/warranty for complete
warranty information.
For more information, visit freescale.com/Tower
Join the online Tower community at towergeeks.org
Freescale, the Freescale logo, CodeWarrior, Kinetis and Processor Expert are
trademarks of Freescale Semiconductor, Inc., Reg. U.S. Pat. & Tm. Off. Tower
is a trademark of Freescale Semiconductor, Inc. All other product or service
names are the property of their respective owners.
© 2010–2014 Freescale Semiconductor, Inc.
Doc Number: TWRKM34Z50MQSG REV 1 Agile Number: 926-27540 REV B
Get Started
Download installation software and documentation under
“Jump Start Your Design” at freescale.com/TWR-KM34Z50M.
