O2 X3 Operating instructions

o2.co.uk
O2 (UK) Limited, 260 Bath Road, Slough, Berkshire SL1 4DX
Registered in England No. 1743099. Registered Office as above.
© O2 (UK) Limited 2003. Correct at time of going to press (August 2004)
O2CXXXXN KGL 08/04
O2X3™– How to use it
Send and receive video
messages
Download pictures and
send to your friends
Get the latest sports news

Quick start guide to O2X3
Introduction
Thanks for purchasing an O2X3. The O2X3 has an excellent
set of features including a 1.3 megapixel camera with
flash, a 262,000 colour screen, video capture and playback,
an MP3 player and all the other features you’d expect from
a phone. In the box, you’ll have a handset, battery, stereo
headphones doubling up as a hands-free kit, 32MB
memory card, polishing cloth and a CD-ROM with a USB
cable for connecting the handset to your PC.
Here are some quick instructions on how to get started. If
you want more detail, please refer to the detailed sections
of the guide:
Setting up
•Insert the SIM into the slot on the back of the O2X3
handset, connect the battery to the O2X3 and insert the
memory card into the slot at the bottom of the phone
•Check these items are securely in place, then open the
flip and hold and press until the screen turns on.
Then enter a PIN if necessary*
•You’re now ready to use the O2X3
Charging the handset
•Insert the lead from the charger to the base of the
handset into the charging socket
•Connect the charger to the correct electrical socket. The
phone will start charging
•When the phone is fully charged disconnect the charger
from the socket and then from the phone
* The default PIN code is 4321 or 5555. If you enter an incorrect PIN code three
times in succession, your SIM card will lock and you must enter the PUK code
to unlock it. Please contact O2 customer service in this event.
Quick start guide
iii

Basic Navigation
Here’s how to navigate when using the X3.
•Use to move up, down, left or right
•Press or to select an item
•Press or to go Back or delete
•Press to go back to the standby screen
How to make a call
•Type the number of the person you wish to call by using
the numbered keypad or press to select Contacts and
scroll up and down to find the contact
•Press to dial the number. Your O2X3 will start to dial
the number
•After you’ve connected, press to end the call
How to create and send a text message
•Press to enter the New message screen
•You can now start typing your message using the
keypad. The O2X3 uses ITAP, a predictive text input.
Press to flip through text input options
•Once you’ve finished typing your text, press the
•Type the number in of the person that you wish to send
the text to or select their contact number from your
phonebook
•Press and your message will be sent to the recipient
How to take a picture
•From the idle screen press to select the Camera and
enter the viewfinder mode
•Focus the camera on the picture subject. You can press
to zoom in on the subject and also to adjust
the light
•If you’re taking a picture in dark conditions, you can use
the indoor mode and flash mode. Select Options – Switch
to Indoor or/and Switch on Flash
•Once you’re ready, press to take a picture. The O2X3
will automatically save the picture to the Media Centre
•Press to go back to the viewfinder screen and take
another picture
•To use the 1.3 megapixel feature, select Options –Size
and then select 1.3m. If you’re taking a picture in dark
conditions you can use the flash option – select Options –
Flash On/Off, then take your picture
Quick start guide
iviii

Please note:
It is not possible to send a 1.3 megapixel image via a media
message. To download such images you can use the data
cable. For further information please see page 25.
How to record a video
•From the idle screen press and enter the
viewfinder mode
•Press to start recording. To stop press
•Your video will automatically be saved to the
Media Centre
•Press to go back to the viewfinder screen and shoot
another video
Top tips
•You can assign a picture or small video clip to a contact,
so when that person calls you, their photo or video
appears on screen. See page 44 for details
•Take a picture and then change facial expressions via
Face morphing or add funny animations via Face
dressing. See page 129 and 132 for details
•You can download 1.3 megapixel camera pictures to
your PC via the USB cable and CD-ROM supplied in the
box. See page 25
•From the main menu, select Media Centre – Video and
then select the O2Digital Music Player video for a great
demonstration of video playback
•When the handset is closed, press the volume key
for quick access to the calendar. The calendar will
then be displayed on the external display screen
for you to view
•To take a picture of yourself, when the handset is closed,
press and hold the side camera key for 3 seconds. The
external display will then act as a viewfinder. Once
you’re ready to take your picture, press to capture the
•Use the polishing cloth provided to keep your handset
smudge free!
•You can read texts and view missed calls on the external
screen. Press to read and view
Quick start guide
viv

Contents
Welcome xiii
Chapter 1 – Before using your mobile 1
What’s in the box 2
Handset description 4
External display 8
Main idle screen 10
Icons 11
Function keys 13
Navigation key 15
Chapter 2 – Preparing your mobile for use 17
Inserting your SIM card 18
Using the battery 20
Charging the battery 21
Important battery information 23
Inserting your SD card 24
CD-Rom and USB cable 25
Chapter 3 – Basic functions 27
Turning your mobile on and off 28
Menu navigation 30
Basic functions 34
Making a call 34
Ending a call 35
Receiving calls 35
Making an international call 36
O2 X3 is a trademark of O2 Limited.
viiivii

– Archive 75
– Delete 75
– Message settings 75
Media 77
– Create a media message 77
– Read messages 85
– Inbox 86
– Sent items 87
– Drafts 88
– Archive 89
– Delete 89
– Settings 89
Camera 91
Camera settings 92
Additional camera settings 95
Take a picture 96
Managing your pictures 97
View your pictures 98
Video 99
Video settings 100
Additional video settings 102
Shoot a video clip 103
Enabling long video recording 103
Managing your video clip 104
View your video clips 105
O2Active 106
How to access O2Active 117
How to close your browser 117
x
Making emergency calls 36
Voicemail 38
Chapter 4 – Main menu 41
Contacts 42
Adding contacts to you phonebook 42
Finding contacts in your phonebook 45
Copy 46
Delete 47
Caller groups 48
Memory 49
Calls 51
Missed, dialled and received calls 51
Delete 53
Display 54
Information 54
Operations during a call 57
Call menu 62
Messages 65
Text 65
Media 65
Broadcast 67
Text 68
– Write a text message 68
– Read messages 70
– Inbox 72
– Sent items 72
– Drafts 74
ix

Games 119
O2Games Arcade 119
Media Centre 124
Images 124
Fun ways to edit your images 127
Videos 134
Music Player 138
Create your own ring tones 143
Wallpaper 146
Tools 149
My services 149
Alarm 149
Calendar 152
Calculator 156
Currency converter 157
Clock options 158
Countdown timer 162
Stopwatch 164
Connection settings 165
Settings 167
Date and time 167
Profiles 170
Display 175
Call settings 177
Network 181
Security 182
Power saving 185
Language 185
Memory 187
Factory reset 187
Chapter 5 – Miscellaneous 189
Abbreviations and acronyms 190
Questions and answers 193
Technical data 196
Chapter 6 – Safety 199
Safety information for mobiles 200
Mobile care 201
Memory card 205
Driving safety 206
Electronic devices 207
Other safety guidelines 209
Cautions 210
R&TTE Directive 1999/05/EC 211
xiixi

xiv
Welcome
Thanks for buying the new O2X3 Mobile – we know you
won’t be disappointed.
Quite simply the O2X3 represents the latest that mobiles
have to offer combining new advances in audio, visual and
data technologies.
The first thing to point out is the high quality camera
offering 1.3 megapixel imaging (that’s really high quality)
and the option to record your own video footage. How
cool is that?
xiii
Secondly the O2X3 has a screen that offers 262,000 colours
making your pictures and videos more lifelike than ever.
After all, what good’s a really cool camera if your screen
makes the pictures look rubbish?
You’ve also got yourself a top class personal MP3 player
which will allow you to play MP3 files.
Because the sound and picture quality on the O2X3 is so
good, we figured you’d probably want to create and store
more files than usual so we’ve included a memory
expansion slot with a 32mb miniSD card.
There’s also a cable to connect your mobile directly to your
PC so you can download and email videos or images that
might be too big to send directly from your mobile.

By connecting through O2Active™,
you’ll be able to access streaming
footage of newsclips, sports highlights,
music videos etc.
And at last you have a phone screen
that is worthy of some of the classic
games that are available to download.
All in all, we’re pretty pleased with the
O2X3. We hope you feel the same way.
O2 does not suggest in any way that the celebrities featured in this guide are
endorsing O2 products or services.
©Mr Goodliving Ltd. All Rights Reserved.
About the user guide
This user guide relates only to
the O2X3.
Please note that a small
proportion of the functions
available differ between
Pay & Go and Pay Monthly
customers.
xvixv

Before using your mobile
•What’s in the box
•Handset description
•External display
•Main idle screen
•Icons
•Function keys
•Navigation key
Chapter 1
1xvii

3
What’s in the box
2
Thank you for purchasing your O2X3. Take a look in the
box for the following items. Please check the product
contents to see if you have all the available items as shown.
Your O2X3 – How to use
it guide
32MB SD memory card
Download cable
CD Rom
Polishing cloth
Mobile
phone Charger
battery Hands-free
kit/Stereo
headphones

Handset description
Closed view
Antenna
Camera flash
1.3 megapixel
Camera lens
4000 colour
external display
Earpiece
262,000 colour
main display
Microphone
Right soft key
OK key
Dial/Answer key
Keypad – alphanumeric
Power on/off key
Navigation keys
Clear key
Left soft key
O2Active key
Inside view
54

76
Volume keys
Quick camera access key
Carrying strap holder
Speaker
IrDa Sensor
Battery
Side and back views Bottom view
Charger socket
Hands-free headset/
Data cable jack
miniSD slot
Cover
To view the bottom of your handset correctly, please lift
the rubber cover and twist to the right.

98
External display
When the flip is closed, the external display’s status bar will
show icons for network signal strength, battery power,
alarm (if active), the current time and the current profile in
use. The external display can also alert you to incoming
calls, text messages and missed calls.
Please note:
•To set the time on the external display, please refer to
page 167
•In the default setting, the external display will show the
time. The external display will then temporarily power
off. You can turn it back on by pressing the lower
portion of the volume key on the side of your mobile
•You can set a wallpaper to be displayed when the
external display turns off. For more details please refer
to page 146
•Photos taken using your mobile’s camera can also be set
as wallpapers. Please refer to page 146 for details
•When the mobile’s flip is closed, pressing the upper
portion of the volume key will display the calendar.
Pressing the key repeatedly will display the previous or
next month’s calendar. To close the calendar and return
to the standby screen press the side key
Battery power
Current time
Signal
Name of
operator
Current
profile

Time
Signal
Name of operator
Wallpaper
Press to enter
the camera function
Press to access
your contacts
Press to enter
the main menu
Main idle screen Icons
The icons below appear on the external display and/or the
main display.
Signal strength – The number of bars shows
signal strength
Battery – Current battery charge level
GPRS network – GPRS services have been activated
on your SIM card
Message – Shows that a text message, media
message or video message has been received or that
there are unread messages. If the icon appears in red
on the main display then your message memory is full
WAP message – You’ve a WAP message (This icon
will only appear when there are no incoming or
unread text and media messages)
Voicemail – Indicates that you have Voicemail
messages
Alarm – Appears when an alarm is set
1110

1312
Line in use – Shows the number of the line currently
in use
Silent – Appears when vibration is set as a ring tone.
In the standby screen, press and hold to
activate the silent profile
Normal – Shows the Normal profile is in use. To set a
different profile please refer to page 170
Meeting – Shows that the Meeting profile is in use
Outdoors – Shows that the Outdoors profile is in use
Headset – Shows that the Hands-free profile is in use
Flight Mode – Shows the Flight Mode profile is in use
Divert – Appears when the call divert function is active
Roaming – Indicates roaming has been activated
(It is not your regular network)
Mini SDcard – Indicates the SDcard has been
inserted into your mobile
Power on/ •Long press to turn your mobile on/off
off key •Press to reject an incoming call or cancel
a call being dialled
•Press to return to the standby screen
Send/ •Press to dial or answer a call
Answer key •Press to access the list of the last
missed/dialled/received calls
OK key •Press to open up the main menu
•Press to select when browsing through
the menu
Left soft key •To access the camera function from
standby screen
•Press to select when browsing through
lower menu levels from standby mode
Right soft key •Press to access your contacts
•Press and hold to turn the silent profile
on or off
•Press to select Back when browsing
through the menu
Navigation key •To browse through the menu
Function keys

O2Active key •To access O2Active
Clear key •Press to delete entered digits
•Press to go back when browsing through
the menu
Asterisk key •To insert an asterisk
•Press and hold to select +
Voicemail •Press and hold to access
your Voicemail
# key •To insert #
•Press, when creating a message, to access
predictive text (ITAP) or manual text input
Alphanumeric •Press to enter a digit
keys •Shortcut keys – press and hold to
immediately access a function
Volume key •To adjust the call volume
•When there is an incoming call, press and
hold the upper portion of the volume key
to reject the call; press and hold the lower
portion to silence the ring tone for an
incoming call
Side key •Press to access the camera function
1514
When in standby mode, the navigation
keys can be used to access shortcuts we
have set up for you.
Left – To create a text message
Right – To access the video function
Up – To access profiles
Down – To use the MP3 Music Player
Navigation key

Preparing your mobile for use
•Inserting your SIM card
•Using the battery
•Charging the battery
•Important battery information
•Inserting your SD card
•CD-Rom and USB cable
Chapter 2
1716

1918
To use your mobile, a SIM card is required at all times –
this contains important information about your mobile and
network. The message Insert SIM appears when the SIM
card is not installed.
Please take care of your SIM card and don’t keep it near
magnetic and electronic devices as this can interfere with
data storage and network operations.
•Turn your mobile over and release the battery latch
•Lift the battery off the mobile
Please note:
Do not remove the battery when the mobile is on. Doing
so could cause you to lose personal settings or data stored
either on your SIM card or in the mobile’s memory.
•Slide the SIM card in under the metal grooves in the SIM
card slot, with the SIM card’s metal contacts facing down
and the cut corner at the top right
Please note:
A SIM card can be easily damaged if its metal contacts
become scratched. Therefore, take special care when
holding or inserting it.
If you wish to remove the SIM
card, you must first press down
the stay, then push the SIM card
out of the slot.
Inserting your SIM card
Battery latch
SIM card
Stay SIM card

Power connection
Insert the charger’s contact point into the slot and plug the
charger in at the socket.
Please ensure you insert the charger the right side up.
Please note:
Before you use the battery for the first time, make sure
you charge it for at least four hours. Charging the battery
fully each time will help prolong its lifetime – and is much
better than frequent short bursts of charging.
21
Installing the battery
Insert the bottom of the battery into the groove at the
bottom of the mobile. Then push down the battery until it
locks into place.
Removing the battery
Pull down the tab with one hand and then lift the top of
the battery to separate from the mobile.
Please note:
The battery must be securely placed in the battery
compartment. If the battery is improperly inserted your
mobile will not turn on or the battery may slip off
during use.
Using the battery
20
Charging the battery
Charger socket
Charger connector
