O2 Xda Mantle User manual

115x138
3mm
IV
115x138
3mm
Contents
Getting Started
What’s in the box 1
Installing the SIM card 5
Inserting a SD™ card 6
Installing and charging the battery 7
Turning the device on or off 8
Entering information 8
Synchronising your Xda and PC 9
Setting up ActiveSync® 10
on Windows XP
Setting up Windows® Mobile 10
Device Centre on Windows Vista®
Using your Xda Mantle
Sending a text message 11
Making a call 11
Personalising your Xda Mantle 12
Going online and surfing the Web 13
Sending and receiving email 14
Securing your Xda Mantle 15
Taking a picture 16
Sending an MMS 16
A tour of your Xda Mantle 17
Help and troubleshooting 27

O2 00
5152
13.05.08 lee 115x138
5152 Mantle Guide 02.06 08 3mm
1
O2 00
5152
13.05.08 lee 115x138
5152 Mantle Guide 02.06 08 3mm
2
Xda Mantle battery
Getting started
What’s in the Box
Xda Mantle AC charger for recharging your
Xda Mantle battery

O2 00
5152
13.05.08 lee 115x138
5152 Mantle Guide 02.06 08 3mm
1
O2 00
5152
13.05.08 lee 115x138
5152 Mantle Guide 02.06 08 3mm
2
Connection cable to connect your Xda Mantle
to a PC for synchronising data and charging
Xda Mantle hands-free stereo headset
02 may change the contents of the Xda Mantle box in the future. The images here are purely to illustrate what’s in the box – the actual contents may look slightly different.

O2 00
5152
13.05.08 lee 115x138
5152 Mantle Guide 02.06 08 3mm
3
O2 00
5152
13.05.08 lee 115x138
5152 Mantle Guide 02.06 08 3mm
4
This booklet, your Quick Start Guide Full User Manual available
on the Applications CD

O2 00
5152
13.05.08 lee 115x138
5152 Mantle Guide 02.06 08 3mm
3
O2 00
5152
13.05.08 lee 115x138
5152 Mantle Guide 02.06 08 3mm
4
Warranty card Getting Started CD with Windows
Mobile™ software
CD Contents include:
Microsoft® ActiveSync® 4.5 connectivity
software, Microsoft Office Outlook®
2007 (60-day trial), GPRS Monitor,
Sprite backup tool, Full User Manual.

O2 00
5152
13.05.08 lee 115x138
5152 Mantle Guide 02.06 08 3mm
5
O2 00
5152
13.05.08 lee 115x138
5152 Mantle Guide 02.06 08 3mm
6
Installing the SIM Card
To install the SIM card, slide the back cover latch to the right to unlock the back cover of your
Xda Mantle and remove it. Then slide the SIM card door lock to the left and flip the door
open. Next, insert the SIM card, then close and lock the SIM card door.

O2 00
5152
13.05.08 lee 115x138
5152 Mantle Guide 02.06 08 3mm
5
O2 00
5152
13.05.08 lee 115x138
5152 Mantle Guide 02.06 08 3mm
6
Inserting a SD™ card (this is not included in box).
The SD card slot is behind the rubber cover. Open the cover and then insert the SD card.
Make sure the gold contacts are facing down and then close the cover. If you need to
remove the SD card, simply press it and it will pop out of the slot.
The second SD card slot can be found on page 21. If you want to use a microSD™ card
you need to use an adaptor (not supplied).

O2 00
5152
13.05.08 lee
5152 Mantle Guide 02.06 08
7
O2 00
5152
13.05.08 lee
5152 Mantle Guide 02.06 08
8
Installing and charging the battery
To install the battery, slide the back cover catch to the right to unlock the back cover
of your Xda Mantle and remove it. Place the battery in the slot and replace the cover.
You will receive the new battery partially charged. So before you start using your Xda
Mantle, you will need to fully charge the battery. Charge the battery by plugging in the
AC adapter plug to an electrical outlet. Plug the USB end to the sync connector port at
the bottom of the device.
The battery will be fully charged after about three hours.

O2 00
5152
13.05.08 lee 115x138
5152 Mantle Guide 02.06 08 3mm
7
O2 00
5152
13.05.08 lee 115x138
5152 Mantle Guide 02.06 08 3mm
Turning the device on or off
It’s easy. Just press and hold the Power button for about three to five seconds. This will
turn your Xda Mantle on or off. You’ll see a message on the screen when it’s switching off.
Tap Ye s to turn off the device.
Entering information
Remove the stylus from the back of the device
and use it to input information onscreen. For more
information, please refer to the Full User Manual.
8

O2 00
5152
13.05.08 lee 115x138
5152 Mantle Guide 02.06 08 3mm
O2 00
5152
13.05.08 lee 115x138
5152 Mantle Guide 02.06 08 3mm
10
Synchronising your Xda and PC
Mobile and PC
It’s easy to synchronise your computer with your device. This enables you to keep
information like contacts, tasks, and appointments up – to – date on your Xda Mantle.
Setting up synchronisation software on your PC
The synchronisation software you need will depend on your computers Operating
System (OS).
Either use Microsoft ActiveSync® 4.5 (or later) or Windows Mobile® Device Centre to
synchronise your device with your computer.
9

115x138
3mm
115x138
3mm
10
Setting up ActiveSync® on Windows XP
1. Install ActiveSync 4.5 on your PC from the Getting Started section of your in-box CD.
2. Connect your Xda Mantle to your computer. You’ll see that the Synchronisation Set up
Wizard automatically starts and will guide you to create a synchronisation partnership.
Click Next to proceed.
3. To synchronise your device with your computer, clear the Synchronise directly with
a server running Microsoft® Exchange check box and then click Next.
4. Select the information types that you want to synchronise, then click Next.
5. Click Finish.
Setting up Windows® Mobile Device Centre on Windows Vista®
1. Connect your device to your computer. Windows Mobile Device Centre will open.
On the screen, click Set up your device.
2. Select the information you want to synchronise and click Next.
3. Type in a name for your Xda and click Set Up.
9

O2 00
5152
13.05.08 lee 115x138
5152 Mantle Guide 02.06 08 3mm
11
O2 00
5152
13.05.08 lee 115x138
5152 Mantle Guide 02.06 08 3mm
Using your Xda Mantle
Sending a text message
You can send short text messages (SMS) from your Xda Mantle to other mobile phones.
1. Tap Start > Messaging > SMS/MMS.
2. Tap Menu > New > SMS.
3. Enter the mobile phone number* in To and then write your message. Tap Send.
*Or tap To if you want to choose a contact from your SIM card or contacts list.
Making a call
To make a call, simply do one of the following:
1. Press the Talk button below the screen to open the Phone screen.
2. Tap the keys on the Phone screen to enter the first few digits of a phone number or the
beginning letters of a contact name. This will immediately start to search your contacts.
To use your Xda Mantle hands-free, connect your device to the wired headset or Bluetooth®
headset (not included). Please refer to the Full User Manual if you are unsure how to connect
a Bluetooth headset to your Xda Mantle.

O2 00
5152
13.05.08 lee 115x138
5152 Mantle Guide 02.06 08 3mm
11
O2 00
5152
13.05.08 lee 115x138
5152 Mantle Guide 02.06 08 3mm
Personalising your Xda Mantle
You can personalise the screen appearance of your Xda Mantle. If you want to change the
Today screen:
Tap Start > Settings > Personal tab > Today.
If you want to set the date and time:
Tap Start > Settings > System tab > Clock & Alarm > Time tab.
If you need to manage your power settings:
Tap Start > Settings > System tab > Power > Advanced tab.

O2 00
5152
13.05.08 lee 115x138
5152 Mantle Guide 02.06 08 3mm
13
O2 00
5152
13.05.08 lee 115x138
5152 Mantle Guide 02.06 08 3mm
14
Going online and surfing the Web
To get online, turn on Wi-Fi® on your device. If there is no Wi-Fi hotspot in your area, you
can still connect to the Internet by using the GPRS or dial-up service of your wireless service
provider. Please refer to the Full User Manual to learn how to connect using GPRS or dial-up
settings. If you are using Wi-Fi:
1. Tap Start > Programs > Comm Manager and tap the Wi-Fi button.
2. Select the wireless network you want to connect to and tap OK.
3. Select The Internet and tap Connect.
Note: If you are connecting to a secured wireless network, you may first need to enter a key
to get a network connection. Use Internet Explorer® Mobile (tap Start > Internet Explorer)
to surf the Web.

O2 00
5152
13.05.08 lee 115x138
5152 Mantle Guide 02.06 08 3mm
13
O2 00
5152
13.05.08 lee 115x138
5152 Mantle Guide 02.06 08 3mm
14
Sending and receiving email
You can set up your Xda Mantle to send and receive emails using your preferred email service.
To send or receive email:
1. Tap Start > Messaging > New Email Account.
2. Type in your Email Address and tap Next.
3. If this doesn’t work then manually enter the settings in the following screens.
4. Type in Your Name and Account. Tap Next.
5. Type in the User Name and Password for the email account. Tap Next.
6. Select the frequency to send and receive email. Tap Finish. You can also synchronise your
device with your company’s Microsoft Exchange server to receive work emails. Please refer
to the Full User Manual if you want to access your company email account using your
Xda Mantle.

O2 00
5152
13.05.08 lee 115x138
5152 Mantle Guide 02.06 08 3mm
15
O2 00
5152
13.05.08 lee 115x138
5152 Mantle Guide 02.06 08 3mm
16
Securing your Xda Mantle
You can protect your device from unauthorised access by using the SIM PIN, the device lock
or the key lock.
A. To enable SIM PIN
You will first need to enter a password to enable the SIM PIN before you can use the phone
features of the device.
To use the SIM PIN, tap Start > Settings > Personal tab > Phone and select Require PIN
when phone is used.
B. To enable Fingerprint Sensor
The Xda Mantle features a fingerprint sensor which you can find on the lower side of the device.
To enter the Fingerprint Sensor set-up, tap Start > Settings tab > Lock. For further
information, please refer to the Full User Manual.

O2 00
5152
13.05.08 lee 115x138
5152 Mantle Guide 02.06 08 3mm
15
O2 00
5152
13.05.08 lee 115x138
5152 Mantle Guide 02.06 08 3mm
16
Taking a picture
Use your Xda Mantle to take a picture.
1. Press the Camera button all the way in. The screen will automatically switch to landscape
mode when you use the camera.
2. Tap the screen to change the camera settings.
3. Press Enter to take the shot. The camera comes with an autofocus function to capture
sharp and crisp photos and videos of your subjects. You will need to either press the
Camera button half-way or all the way to take a photo, depending on the option you have
chosen in Shoot Option.
The Full User Manual that comes with your Xda Mantle offers a more complete guide.
Sending an MMS
The photos you take will be automatically saved after you shoot. Or you can choose to delete
them in the Review screen. Press the to send the photo via MMS or email. Please refer
to the Full User Manual for a more complete guide.

O2 00
5152
13.05.08 lee 115x138
5152 Mantle Guide 02.06 08 3mm
17
O2 00
5152
13.05.08 lee 115x138
5152 Mantle Guide 02.06 08 3mm
18
A tour of your Xda Mantle
8
1
12
9
2
4
6
10
3
11
5
7
18
