OAKWORKS CFPM100 User manual

OAKWORKS®
Imaging and Pain
Management Tables
USER MANUAL
www.oakworksmed.com · 717.235.6807
Shop tables & accessories at
ExamTablesDirect.com

© Copyright 2022
OAKWORKS®, Inc.
Printed in U.S.A.
All rights are reserved. No part
of this document may be
photocopied, reproduced or
translated to another language
without prior written consent
of OAKWORKS®, Inc.
OAKWORKS®is a registered
trademark of OAKWORKS®, Inc.
Notice
The information contained within
this document is subject to change
without notice and should not
be construed as a commitment by
OAKWORKS®, Inc.
OAKWORKS®, Inc. encourages
requests for technical specifica-
tions and the like documentation to
ensure accuracy. The appropriate
documentation is available upon
request.
OAKWORKS®, Inc. shall not be
liable for incidental or consequen-
tial damages in connection with or
arising out of the furnishing, per-
formance, or use of this document
and the program material which it
describes.
Shop tables & accessories at
ExamTablesDirect.com

TABLE OF CONTENTS
Product Use Description .......................................................................................................1
Important Safety Instructions
Symbol Identification ........................................................................................................1
Contraindications..............................................................................................................1
Safety Instructions ........................................................................................................2-3
Product Description & Controls Operation
CFPM100................................................................................................................................ 4
CFPM200............................................................................................................................. 5-6
CFPM300............................................................................................................................. 7-8
CFPM400........................................................................................................................... 9-10
CFPM201......................................................................................................................... 11-12
CFPM301......................................................................................................................... 13-14
CFPM302......................................................................................................................... 15-16
CFPMB301 - Bariatric...................................................................................................... 17-18
CFPM401......................................................................................................................... 19-20
CFLU401 - Lithotripsy...................................................................................................... 21-22
CFUR301 - Urology.......................................................................................................... 23-24
CFUR401 - Urology.......................................................................................................... 25-26
Installation
Grounding .....................................................................................................................27
Directions for Use
Bubble Level ..................................................................................................................28
Angle Indicator ...............................................................................................................28
Patient Restraint Strap ...................................................................................................28
Remove / Replace the Table Top Pad ...........................................................................29
Adjusting Crescent Face Pads (integrated headrest tops only).......................................29
Locking Casters Use ......................................................................................................30
Emergency Stop ............................................................................................................30
Weight Capacity & Patient Use.......................................................................................31
Urology Table Bag Hoop ................................................................................................31
Lithotripsy/Urology & Urology Table Lateral Extensions..................................................32
Lithotripsy/Urology & Urology Table End Extensions......................................................33
Lithotripsy Table used as Urology Table.........................................................................33
Carbon Fiber Arm Board.................................................................................................34
Adjustable T-Rail Clamp.................................................................................................34
Spine Positioning System II............................................................................................35
Fluoro Extender..............................................................................................................35
Reference - Usable Imaging Area Diagrams
CFPM 100 - Integrated Headrest & Rectangular Tops...............................................36-37
CFPM200 Through CFPM401 - Integrated Facerest Top................................................38
CFPM200 Through CFPM401 - Rectangular Top............................................................39
CFUR301 & CFUR401 - Urology Top .............................................................................40
CFLU401 - Lithotripsy / Urology Top ..............................................................................41
Cleaning & Disinfection / Inspections / Warranty
Recommended Disinfectants / Cleaners.........................................................................42
Cleaning Process ...........................................................................................................42
Inspections & Maintenance.............................................................................................43
Warranty Information......................................................................................................43
Unique Device Identification (UDI) Information.................................................................44
Specifications
Product Specifications....................................................................................................45
Environmental Conditions...............................................................................................45
Electrical Specifications..................................................................................................45
Guidance and manufacturer’s declaration -
Electromagnetic emissions.............................................................................................46
Recommended separation distances..............................................................................46
Guidance and manufacturer’s declaration -
Product Disposal ............................................................................................................47
Contact Information........................................................................................back cover
Shop tables & accessories at
ExamTablesDirect.com

PRODUCT USE DESCRIPTION / IMPORTANT SAFETY INSTRUCTIONS
1
PRODUCT USE DESCRIPTION
OAKWORKS®Imaging and Pain Management Tables are radiographic tables intended for use with mobile or com-
pact stationary C-arm Imaging Systems. It is ideally suited for pain management imaging and therapeutic proce-
dures. These tables are suitable to use for diagnostic x-ray imaging and imaging during therapeutic procedures
such as spinal injections, vertebroplasty procedures and other pain management procedures. The CFLU and CFUR
Tables are designed for Lithotripsy and Urology procedures. It is intended to be operated by a healthcare profes-
sional in a medical environment. No special training is required but a review of the following Safety Instructions is
important for the safety of the operator and patient. The healthcare professional should read and understand this
entire manual before use with a patient.
NOTE The EMISSIONS characteristics of this equipment make it suitable for use in industrial areas and hospitals
(CISPR 11 class A). If it is used in a residential environment (for which CISPR 11 class B is normally required) this
equipment might not offer adequate protection to radio-frequency communication services. The user might need to
take mitigation measures, such as relocating or re-orienting the equipment.
SYMBOL IDENTIFICATION
This symbol, when used in this manual and on product labels, represents a caution warning.
Be sure to read and comply with all precautions and warnings.
This symbol, when used in this manual and on product labels, warns against an electrical
shock hazard. Be sure to observe and comply with all warnings.
This symbol, when used in this manual and on product labels, indicates the potential of expo-
sure to harmful x-rays. Be sure to read and comply with all warnings.
This symbol, when used in this manual and on product labels, indicates that the table and
components are a Type B Applied Part pursuant to IEC 60601-1.
This symbol, when used in this manual or on product labels, indicates a Protective Earth
(Ground) Terminal.
This symbol, when used in this manual and on product labels, indicates the name and
address of the manufacturer.
This symbol, when used in this manual or on product labels, indicates the country of manufac-
ture along with date of manufacture of the device next to it.
This symbol, when used in this manual or on product labels, indicates alternating current
(AC).
This symbol, when used in this manual or on product labels, indicates direct current (DC).
This symbol is used to indicate that the operator should consult the user manual.
Sitting is prohibited in this area.
~
----
CONTRAINDICATIONS
The Oakworks Imaging and Pain Management Tables should not be used with Imaging systems hav-
ing intensifier screens or film cassettes larger than 12 inches (30 cm) when an oblique angle of view
is being used. The tables are not designed for and should not be used with Magnetic Resonance
Imaging procedures.
US
Shop tables & accessories at
ExamTablesDirect.com

2
IMPORTANT SAFETY INSTRUCTIONS
CAUTION
READ AND SAVE THESE INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
After unpacking your table, inspect it thoroughly for damage. If you suspect a problem do not use the table
and call our customer service department at 717.235.6807.
Improper use of this device can cause injury. Be sure to read all operating instructions prior to use.
Weight limit (patient and accessories): 227 kg / 500 lbs. distributed evenly. (Bariatric Table only: 340 kg /
750 lbs.)
Do not sit beyond warning line on carbon fiber top. On Lithotripsy / Urology Top - Do not sit on any exten-
sions (Weight Limit: 200 lbs. / 91 kg.)
The table utilizes four locking casters to permit movement of the table within the imaging suite. Accidental
movement of the table may occur. Lock casters prior to imaging of the patient. Lock casters when the
patient is mounting & dismounting the table.
The table should not be used adjacent to or stacked with other equipment. If adjacent or stacked use is neces-
sary, the table should be observed to verify normal operation in the configuration in which it will be used.
The use of accessories, transducers, and cables other than those specified (with the exception of transducers
and cables sold by the Manufacturer of this device as replacement parts for internal components) may result in
increased emissions or decreased Immunity of the table.
The table is designed to be a standalone table used with radiographic equipment. This table must not be
modified or incorporated into any other equipment.
There may be pinch points under the table top. Do not have any body part under the top when the table is
in motion.
Be certain that the table is completely lowered prior to discharging an ambulatory patient. The patient may lose
balance and fall.
Patient must be secured with Safety Restraint Strap prior to using the tables.
Medical Electrical Equipment needs special precautions regarding EMC and needs to be installed and put
into service according to the EMC information provided in the specifications at the end of this manual.
Portable and Mobile RF Communications Equipment can affect Medical Electrical Equipment.
This table is not suitable for use in the presence of flammable anesthetic mixture with air or oxygen or nitrous
oxide.
Electrical Shock Hazard. The power supply/control module is located inside the lifting column and under the
top. No user serviceable parts are inside. Refer servicing to qualified personnel. Unplug wall connector prior
to contact with any cables connected to the power supply.
To avoid the risk of electric shock, this equipment must only be connected to an outlet that is properly
grounded. See GROUNDING instructions in this manual.
Grounding reliability can only be achieved when this equipment is connected to an equivalent 3 prong
receptacle marked “Hospital Only” or “Hospital Grade”.
Oakworks medical tables are designed and built to provide many years of dependable service. Please fol-
low local regulations and laws when disposing of the electrical components used in this table.
Do not apply excessive force to the hand/foot control as it may damage the control.
Do not use the hand/foot control if signs of wear or damage are visible as this can cause unintentional mo-
tion.
Shop tables & accessories at
ExamTablesDirect.com

WARNING
To reduce the risk of burns, fire, electric shock or injury to persons:
1. Unplug this furnishing from the electrical outlet before cleaning.
2. Unplug from outlet before adding or removing parts.
3. Never operate this furnishing if it has a damaged cord or plug, if it is not working properly, if it has been
dropped or damaged, or dropped into water. Contact Oakworks Customer Service before use.
4. Keep the cord away from heated surfaces.
5. Never drop or insert any object into any opening.
6. Do not use outdoors.
7. Do not operate where aerosol (spray) products are being used or where oxygen is being administered.
DANGER
The potential of exposure to harmful x-rays exists when this table is in use. The use of adequate
x-ray barrier devices is necessary to provide protection to both the operator and the patient. X-ray
barrier devices are recommended for the patient outside of the intended target area to prevent expo-
sure to scattered radiation from the x-ray generating source.
The tabletop has a typical aluminum filtration equivalence of 1.10 mm as measured at 100 kVp and
a half value (HVL) of 3.6 mm. (NOTE: Bariatric Top has a typical aluminum filtration equivalence of
1.50 mm. as measured at 100 kVp and a half value (HVL) of 3.6 mm.)
• Oakworks Imaging and Pain Management Tables may be used for x-ray imaging where the
x-ray generator is located below the tabletop and the image receptor is located above the table-
top. This is the recommended method. The tables may also be used for x-ray imaging where
the x-ray generator is located above the tabletop and the image receptor is located below the
tabletop. This application will result in greater patient exposure to x-rays. The operator must
weigh this issue with the imaging requirements and patient exposure issues.
• The Imaging and Pain Management Tables may be used with the x-ray generator above the
tabletop and a film cassette located on the tabletop. (See contraindications regarding film cas-
sette size.)
• The x-ray generator should never be located above the tabletop when the O®Imaging
and Pain Management Table and the O®Spine Positioning System/Prone Pillow are
used together. This type of use requires that the x-ray generator is located below the tabletop
and the imaging intensifier or film cassette located above the tabletop.
IMPORTANT SAFETY INSTRUCTIONS
3
Shop tables & accessories at
ExamTablesDirect.com

PRODUCT DESCRIPTION (IMAGING AND PAIN MANAGEMENT FAMILY PRODUCTS)
CFPM100
STANDARD SPECIFICATIONS
Height Motion w/o pad Powered 22”-40” (56-102cm)
Foot Control Height motion
Choice of Tabletop:
- Integrated Headrest
- Rectangular 22” (56cm) W x 84” (214cm) L 24” (61cm) W x 80” (203cm) L
Table Voltage Options 120V/60Hz or 230V/50Hz
Table Capacity 500 lbs. (227 kg) distributed evenly
4” (10 cm.) Locking
Casters Locking / Unlocking Casters for mobile or permanent positioning
Padding 2” (5cm) Comfort Foam™
Crescent Face Pad Integrated Headrest Only
Patient Restraint Strap Must be used during all procedures
Table Weight 343 lbs. (156 kg)
OPTIONS
5” (13cm) Locking Casters

1” (2.5cm) Tabletop Pad
ACCESSORIES
Carbon Fiber Arm Board
Spine Positioning System II
Adjustable T-rail Clamp
Fluoro Extender
Integrated Face Rest
with Crescent Face Pad
Carbon Fiber Integrated Headrest Top
with Removable Table Top Pad
Electronic Lift
Tower
Locking
Casters
Emergency
Stop
Hand Rail
24” X 80” RECTANGULAR TOP
CAUTION
Do not apply excessive force to the foot control as it may damage
the control. Do not use the foot control if signs of wear or damage
are visible as this can cause unintentional motion.
CFPM 100 Foot Control
4
For electrical specs, see Specifications section.
Shop tables & accessories at
ExamTablesDirect.com

PRODUCT DESCRIPTION (IMAGING AND PAIN MANAGEMENT FAMILY PRODUCTS)
CFPM200
STANDARD SPECIFICATIONS
Motion 1 w/o pad Powered 25”-43” (64-109cm) Height Range
Motion 2 Powered ±15° Lateral Tilt
Hand Control All powered motions
Choice of Tabletop:
- Integrated Headrest
- Rectangular 22” (56cm) W x 84” (214cm) L 24” (61cm) W x 80” (203cm) L
Table Voltage Options 120V/60Hz or 230V/50Hz
Table Capacity 500 lbs. (227 kg) distributed evenly
4” (10 cm.) Locking
Casters Locking / Unlocking Casters for mobile or permanent positioning
Padding 2” (5cm) Comfort Foam™
Crescent Face Pad Integrated Headrest Only
Patient Restraint Strap Must be used during all procedures
Table Weight 405 lbs. (184 kg)
OPTIONS
5” (13cm) Locking Casters

Foot Control
1” (2.5cm.) Tabletop Pad
ACCESSORIES
Carbon Fiber Arm Board
Spine Positioning System II
Adjustable T-rail Clamp
Fluoro Extender
Carbon Fiber Integrated Headrest Top
with Removable Table Top Pad
Locking
Casters
Hand Rail
Integrated Face Rest
with Crescent Face Pad Electronic Lift
Tower
Emergency
Stop
24” X 80” RECTANGULAR TOP
For electrical specs, see Specifications section.
5
Shop tables & accessories at
ExamTablesDirect.com

CAUTION
The Foot Control Riser Plate prevents the foot control from getting
caught underneath the base of the table or between the column and
the base as the column descends. This reduces the risk of uninten-
tional movement of the table due to accidental activation of the foot
control buttons.
PRODUCT DESCRIPTION (IMAGING AND PAIN MANAGEMENT FAMILY PRODUCTS)
CONTROL OPERATIONS - CFPM 200
The CFPM 200 offers Vertical Height and Lateral Tilt positioning with electronic ease. Operate the
hand control and optional foot control as shown below to control these functions of the table. Test
each of the table’s functions prior to use with a patient.
CAUTION Do not apply excessive force to the foot control as it may damage the control.
Do not use the hand or foot control if signs of wear or damage are visible as this can cause uninten-
tional motion.
Height Down
Height Up
Tilt Left
Height Up
Tilt Right
Height Down
Tilt Left
Tilt Right
6
Shop tables & accessories at
ExamTablesDirect.com

PRODUCT DESCRIPTION (IMAGING AND PAIN MANAGEMENT FAMILY PRODUCTS)
CFPM300
STANDARD SPECIFICATIONS
Motion 1 w/o pad Powered 26”-43” (66-109cm) Height Range
Motion 2 Powered 15° Trendelenburg Tilt
Powered 11° Reverse Trendelenburg Tilt
Motion 3 Powered ±15° Lateral Tilt
Hand Control All powered motions
Choice of Tabletop:
- Integrated Headrest
- Rectangular 22” (56cm) W x 84” (214cm) L 24” (61cm) W x 80” (203cm) L
Table Voltage Options 120V/60Hz or 230V/50Hz
Table Capacity 500 lbs. (227 kg) distributed evenly
4” (10 cm.) Locking
Casters Locking / Unlocking Casters for mobile or permanent positioning
Padding 2” (5cm) Comfort Foam™
Crescent Face Pad Integrated Headrest Only
Patient Restraint Strap Must be used during all procedures
Table Weight 498 lbs. (226kg)
OPTIONS
5” (13cm) Locking Casters

Foot Control
1” (2.5cm.) Tabletop Pad
ACCESSORIES
Carbon Fiber Arm Board
Spine Positioning System II
Adjustable T-rail Clamp
Fluoro Extender
Carbon Fiber Integrated Headrest Top
with Removable Table Top Pad
Locking
Casters
Hand Rail
Integrated Face Rest
with Crescent Face Pad Electronic Lift
Tower
Emergency
Stop
24” X 80” RECTANGULAR TOP
7
Shop tables & accessories at
ExamTablesDirect.com

CAUTION
The Foot Control Riser Plate prevents the foot control from getting
caught underneath the base of the table or between the column and
the base as the column descends. This reduces the risk of uninten-
tional movement of the table due to accidental activation of the foot
control buttons.
PRODUCT DESCRIPTION (IMAGING AND PAIN MANAGEMENT FAMILY PRODUCTS)
CONTROL OPERATIONS - CFPM 300
The CFPM 300 offers Vertical Height, Trendelenburg Tilt, and Lateral Tilt positioning with electronic
ease. Operate the hand control and optional foot control as shown below to control these functions of
the table. Test each of the table’s functions prior to use with a patient.
CAUTION Do not apply excessive force to the foot control as it may damage the control.
Do not use the hand or foot control if signs of wear or damage are visible as this can cause uninten-
tional motion.
Height Down
Height Up
Tilt Left
Height Up
Tilt Right
Height Down
Reverse Trend.
Trendelenburg
Tilt Left
Tilt Right
Trendelenburg
Reverse Trend.
8
Shop tables & accessories at
ExamTablesDirect.com

PRODUCT DESCRIPTION (IMAGING AND PAIN MANAGEMENT FAMILY PRODUCTS)
STANDARD SPECIFICATIONS
Motion 1 w/o pad Powered 26”-43” (66-109cm) Height Range
Motion 2 Powered 15° Trendelenburg Tilt
Powered 11° Reverse Trendelenburg Tilt
Motion 3 Powered ±15° Lateral Tilt
Motion 4 Powered 10” (25cm) Longitudinal Travel
Hand Control All powered motions
Choice of Tabletop:
- Integrated Headrest
- Rectangular 22” (56cm) W x 84” (214cm) L 24” (61cm) W x 80” (203cm) L
Table Voltage Options 120V/60Hz or 230V/50Hz
Table Capacity 500 lbs. (227 kg) distributed evenly
4” (10 cm.) Locking
Casters Locking / Unlocking Casters for mobile or permanent positioning
Padding 2” (5cm) Comfort Foam™
Crescent Face Pad Integrated Headrest Only
Patient Restraint Strap Must be used during all procedures
Table Weight 498 lbs. (226 kg)
OPTIONS
5” (13cm) Locking Casters

Foot Control
1” (2.5cm) Tabletop Pad
ACCESSORIES
Carbon Fiber Arm Board
Spine Positioning System II
Adjustable T-rail Clamp
Fluoro Extender
CFPM400
For electrical specs, see Specifications section.
Carbon Fiber Integrated Headrest Top
with Removable Table Top Pad
Integrated Face Rest
with Crescent Face Pad Electronic Lift
Tower
Locking
Casters
Emergency
Stop
Hand Rail
24” X 80” RECTANGULAR TOP
9
Shop tables & accessories at
ExamTablesDirect.com

CAUTION
The Foot Control Riser Plate prevents the foot control from getting
caught underneath the base of the table or between the column and
the base as the column descends. This reduces the risk of uninten-
tional movement of the table due to accidental activation of the foot
control buttons.
PRODUCT DESCRIPTION (IMAGING AND PAIN MANAGEMENT FAMILY PRODUCTS)
CONTROL OPERATIONS - CFPM 400
The CFPM 400 offers Vertical Height, Trendelenburg Tilt, Lateral Tilt, and Longitudinal Travel position-
ing with electronic ease. Operate the hand control and optional foot control as shown below to control
these functions of the table. Test each of the table’s functions prior to use with a patient.
CAUTION Do not apply excessive force to the foot control as it may damage the control.
Do not use the hand or foot control if signs of wear or damage are visible as this can cause uninten-
tional motion.
Height Down
Height Up
Tilt Left
Height Up
Tilt Right
Height Down
Longitudinal Back
Longitudinal Forward
Reverse Trend.
Trendelenburg
Longitudinal Forward
Longitudinal Back
Trendelenburg
Reverse Trend.
Tilt Left
Tilt Right
10
Shop tables & accessories at
ExamTablesDirect.com

PRODUCT DESCRIPTION (IMAGING AND PAIN MANAGEMENT FAMILY PRODUCTS)
For electrical specs, see Specifications section.
CFPM201
STANDARD SPECIFICATIONS
Motion 1 w/o pad Powered 25”-42” (64-107cm) Height Range
Motion 2 Powered 15° Trendelenburg Tilt
Powered 11° Reverse Trendelenburg Tilt
Hand Control All powered motions
Choice of Tabletop:
- Integrated Headrest
- Rectangular 22” (56cm) W x 84” (214cm) L 24” (61cm) W x 80” (203cm) L
Table Voltage Options 120V/60Hz or 230V/50Hz
Table Capacity 500 lbs. (227 kg) distributed evenly
4” (10 cm.) Locking
Casters Locking / Unlocking Casters for mobile or permanent positioning
Padding 2” (5cm) Comfort Foam™
Crescent Face Pad Integrated Headrest Only
Patient Restraint Strap Must be used during all procedures
Table Weight 417 lbs. (189 kg)
OPTIONS
5” (13cm) Locking Casters

Foot Control
1” (2.5cm) Tabletop Pad
ACCESSORIES
Carbon Fiber Arm Board
Spine Positioning System II
Adjustable T-rail Clamp
Fluoro Extender
Integrated Face Rest
with Crescent Face Pad
Carbon Fiber Integrated Headrest Top
with Removable Table Top Pad
Electronic Lift
Tower
Locking
Casters
Emergency
Stop
Hand Rail
24” X 80” RECTANGULAR TOP
11
Shop tables & accessories at
ExamTablesDirect.com

CAUTION
The Foot Control Riser Plate prevents the foot control from getting
caught underneath the base of the table or between the column and
the base as the column descends. This reduces the risk of uninten-
tional movement of the table due to accidental activation of the foot
control buttons.
PRODUCT DESCRIPTION (IMAGING AND PAIN MANAGEMENT FAMILY PRODUCTS)
CONTROL OPERATIONS - CFPM 201
The CFPM 201 offers Vertical Height and Trendelenburg Tilt positioning with electronic ease.
Operate the hand control and optional foot control as shown below to control these functions of
the table. Test each of the table’s functions prior to use with a patient.
CAUTION Do not apply excessive force to the foot control as it may damage the control.
Do not use the hand or foot control if signs of wear or damage are visible as this can cause uninten-
tional motion.
Height Down
Height Up
Trendelenburg
Height Up
Reverse Trend.
Height Down
Reverse Trend.
Trendelenburg
12
Shop tables & accessories at
ExamTablesDirect.com

PRODUCT DESCRIPTION (IMAGING AND PAIN MANAGEMENT FAMILY PRODUCTS)
CFPM301
STANDARD SPECIFICATIONS
Motion 1 w/o pad Powered 25”-43” (64-109cm) Height Range
Motion 2 Powered 15° Trendelenburg Tilt
Powered 11° Reverse Trendelenburg Tilt
Motion 3 Powered 10” (25cm) Longitudinal Travel
Hand Control All powered motions
Choice of Tabletop:
- Integrated Headrest
- Rectangular 22” (56cm) W x 84” (214cm) L 24” (61cm) W x 80” (203cm) L
Table Voltage Options 120V/60Hz or 230V/50Hz
Table Capacity 500 lbs. (227 kg) distributed evenly
4” (10 cm.) Locking
Casters Locking / Unlocking Casters for mobile or permanent positioning
Padding 2” (5cm) Comfort Foam™
Crescent Face Pad Integrated Headrest Only
Patient Restraint Strap Must be used during all procedures
Table Weight 538 lbs. (244 kg)
OPTIONS
5” (13cm) Locking Casters

Foot Control
1” (2.5cm) Tabletop Pad
ACCESSORIES
Carbon Fiber Arm Board
Spine Positioning System II
Adjustable T-rail Clamp
Fluoro Extender
Locking
Casters
Integrated Face Rest
with Crescent Face Pad
Carbon Fiber Integrated Headrest Top
with Removable Table Top Pad
Electronic Lift
Tower
Hand Rail
Emergency
Stop
24” X 80” RECTANGULAR TOP
13
Shop tables & accessories at
ExamTablesDirect.com

CAUTION
The Foot Control Riser Plate prevents the foot control from getting
caught underneath the base of the table or between the column and
the base as the column descends. This reduces the risk of uninten-
tional movement of the table due to accidental activation of the foot
control buttons.
PRODUCT DESCRIPTION (IMAGING AND PAIN MANAGEMENT FAMILY PRODUCTS)
CONTROL OPERATIONS - CFPM 301
The CFPM 301 offers Vertical Height, Trendelenburg Tilt, and Longitudinal Travel positioning
with electronic ease. Operate the hand control and optional foot control as shown below to con-
trol these functions of the table. Test each of the table’s functions prior to use with a patient.
CAUTION Do not apply excessive force to the foot control as it may damage the control.
Do not use the hand or foot control if signs of wear or damage are visible as this can cause uninten-
tional motion.
14
Height Down
Height Up
Trendelenburg
Height Up
Reverse Trend.
Height Down
Longitudinal Back
Longitudinal Forward
Reverse Trend.
Trendelenburg
Longitudinal Forward
Longitudinal Back
Shop tables & accessories at
ExamTablesDirect.com

PRODUCT DESCRIPTION (IMAGING AND PAIN MANAGEMENT FAMILY PRODUCTS)
For electrical specs, see Specifications section.
CFPM302
STANDARD SPECIFICATIONS
Motion 1 w/o pad Powered 25”-43” (64-109cm) Height Range
Motion 2 Powered ±15° Lateral Tilt
Motion 3 Powered 10” (25cm) Longitudinal Travel
Choice of Tabletop:
- Integrated Headrest
- Rectangular 22” (56cm) W x 84” (214cm) L 24” (61cm) W x 80” (203cm) L
Table Voltage Options 120V/60Hz or 230V/50Hz
Table Capacity 500 lbs. (227 kg) distributed evenly
4” (10 cm.) Locking
Casters Locking / Unlocking Casters for mobile or permanent positioning
Padding 2” (5cm) Comfort Foam™
Crescent Face Pad Integrated Headrest Only
Patient Restraint Strap Must be used during all procedures
Table Weight 407 lbs. (185 kg)
OPTIONS
5” (13cm) Locking Casters

Foot Control
1” (2.5cm) Tabletop Pad
ACCESSORIES
Carbon Fiber Arm Board
Spine Positioning System II
Adjustable T-rail Clamp
Fluoro Extender
Integrated Face Rest
with Crescent Face Pad
Carbon Fiber Integrated Headrest Top
with Removable Table Top Pad
Electronic Lift
Tower
Locking
Casters
Emergency
Stop
Hand Rail
24” X 80” RECTANGULAR TOP
15
Shop tables & accessories at
ExamTablesDirect.com

CAUTION
The Foot Control Riser Plate prevents the foot control from getting
caught underneath the base of the table or between the column and
the base as the column descends. This reduces the risk of uninten-
tional movement of the table due to accidental activation of the foot
control buttons.
PRODUCT DESCRIPTION (IMAGING AND PAIN MANAGEMENT FAMILY PRODUCTS)
CONTROL OPERATIONS - CFPM 302
The CFPM 302 offers Vertical Height, Longitudinal Travel, and Lateral Tilt positioning with elec-
tronic ease. Operate the hand control and optional foot control as shown below to control these
functions of the table. Test each of the table’s functions prior to use with a patient.
CAUTION Do not apply excessive force to the foot control as it may damage the control.
Do not use the hand or foot control if signs of wear or damage are visible as this can cause uninten-
tional motion.
Height Down
Height Up
Tilt Left
Height Up
Tilt Right
Height Down
Longitudinal Back
Longitudinal Forward
Tilt Left
Tilt Right
Longitudinal Forward
Longitudinal Back
16
Shop tables & accessories at
ExamTablesDirect.com

PRODUCT DESCRIPTION (IMAGING AND PAIN MANAGEMENT FAMILY PRODUCTS)
24” x 80” Bariatric Carbon Fiber
Top with Removable Table Top Pad
CFPMB301 - Bariatric
STANDARD SPECIFICATIONS
Motion 1 w/o pad Powered 26”-44” (66-112 cm) Height Range
Motion 2 Powered 15° Trendelenburg Tilt
Powered 11° Reverse Trendelenburg Tilt
Motion 3 Powered 10” (25cm) Longitudinal Travel
Hand Control All powered motions
Rectangular Top 24” (61cm) W x 80” (203cm) L
Table Voltage Options 120V/60Hz or 230V/50Hz
Table Capacity 750 lbs. (340 kg) distributed evenly
5” (12.5 cm.) Locking
Casters Locking / Unlocking Casters for mobile or permanent positioning
Crescent Face Pad Integrated Headrest Only
Patient Restraint Strap Must be used during all procedures
Table Weight 573 lbs. (260 kg)
OPTIONS

Foot Control
1” (2.5cm) Tabletop Pad
ACCESSORIES
Carbon Fiber Arm Board
Spine Positioning System II
Adjustable T-rail Clamp
Fluoro Extender
For electrical specs, see Specifications section.
Electronic Lift
Tower
Locking
Casters
Emergency
Stop
Hand Rail
17
Shop tables & accessories at
ExamTablesDirect.com
