OAKWORKS CFPMFXH User manual

OAKWORKS®
Imaging Tables
USER MANUAL
www.oakworksmed.com · 717.235.6807
made in the USA
with US & imported parts
CFPM300
Integrated headrest top
CFPM401
Integrated headrest top
CFPMFXH
Integrated headrest top
Rectangular top CFPM100
Integrated headrest top
Rectangular top
CFPM300
Rectangular top
CFPM301
Integrated headrest top
CFPM301
Rectangular top
CFPMB301
Rectangular top - Bariatric Version
CFLU401
Lithotripsy Table
CFPM400
Integrated headrest top
CFPM400
Rectangular top
CFPM401
Rectangular top
CFUR301
Urology Table
CFUR401
Urology Table

© Copyright 2020
OAKWORKS®, Inc.
Printed in U.S.A.
All rights are reserved. No part
of this document may be
photocopied, reproduced or
translated to another language
without prior written consent
of OAKWORKS®, Inc.
OAKWORKS®is a registered
trademark of OAKWORKS®, Inc.
Notice
The information contained within
this document is subject to change
without notice and should not
be construed as a commitment by
OAKWORKS®, Inc.
OAKWORKS®, Inc. encourages
requests for technical specifica-
tions and the like documentation to
ensure accuracy. The appropriate
documentation is available upon
request.
OAKWORKS®, Inc. shall not be
liable for incidental or consequen-
tial damages in connection with or
arising out of the furnishing, per-
formance, or use of this document
and the program material which it
describes.

TABLE OF CONTENTS
Product Use Description .......................................................................................................1
Important Safety Instructions
Symbol Identification ........................................................................................................1
Contraindications..............................................................................................................1
Safety Instructions ........................................................................................................2-3
Product Description & Photo
CFPMFXH............................................................................................................................... 4
CFPM100................................................................................................................................ 5
CFPM300................................................................................................................................ 6
CFPM400................................................................................................................................ 7
CFPM301................................................................................................................................ 8
CFPMB301 - Bariatric ............................................................................................................. 9
CFPM401...............................................................................................................................10
CFLU401 - Lithotripsy ............................................................................................................11
CFUR301 - Urology................................................................................................................12
CFUR401 - Urology................................................................................................................13
Installation
Grounding .....................................................................................................................14
Directions for Use
Hand Control / Foot Control Operations.....................................................................15-16
Bubble Level ..................................................................................................................17
Angle Indicator ...............................................................................................................17
Patient Restraint Strap ...................................................................................................17
Remove / Replace the Table Top Pad ...........................................................................18
Adjusting Crescent Face Pads (integrated headrest tops only).......................................18
Locking Casters Use ......................................................................................................19
Emergency Stop ............................................................................................................19
Weight Capacity & Patient Use.......................................................................................20
Urology Table Bag Hoop ................................................................................................20
Lithotripsy/Urology & Urology Table Lateral Extensions..................................................21
Lithotripsy/Urology & Urology Table End Extensions ......................................................22
Lithotripsy Table used as Urology Table.........................................................................22
Carbon Fiber Arm Board.................................................................................................23
Adjustable T-Rail Clamp .................................................................................................23
Spine Positioning System II............................................................................................24
Fluoro Extender..............................................................................................................24
Reference - Usable Imaging Area Diagrams
CFPMFXH & CFPM 100 - Integrated Headrest & Rectangular Tops..........................25-26
CFPM400, CFPM300, CFPM401 & CFPM301 - Integrated Headrest Top .......................27
CFPM400, CFPM300, CFPM401, CFPM301 & CFPMB301 - Rectangular Top 28
CFUR301 & CFUR401 - Urology Top .............................................................................29
CFLU401 - Lithotripsy / Urology Top ..............................................................................30
Cleaning & Disinfection / Inspections / Warranty
Recommended Disinfectants / Cleaners .........................................................................31
Cleaning Process ...........................................................................................................31
Inspections & Maintenance.............................................................................................32
Warranty Information ......................................................................................................32
Unique Device Identification (UDI) Information .................................................................33
Specifications
Product Specifications ....................................................................................................34
Environmental Conditions ...............................................................................................34
Electrical Specifications..................................................................................................34
Guidance and manufacturer’s declaration -
Electromagnetic emissions .............................................................................................35
Recommended separation distances ..............................................................................35
Guidance and manufacturer’s declaration -
Product Disposal ............................................................................................................36
Contact Information ........................................................................................back cover

PRODUCT USE DESCRIPTION / IMPORTANT SAFETY INSTRUCTIONS
1
PRODUCT USE DESCRIPTION
OAKWORKS®Imaging Tables are radiographic tables intended for use with mobile or compact stationary C-arm
Imaging Systems. It is ideally suited for pain management imaging and therapeutic procedures. These tables are
suitable to use for diagnostic x-ray imaging and imaging during therapeutic procedures such as spinal injections,
vertebroplasty procedures and other pain management procedures. The CFLU and CFUR Tables are designed for
Lithotripsy and Urology procedures. It is intended to be operated by a healthcare professional in a medical environ-
ment. No special training is required but a review of the following Safety Instructions is important for the safety of
the operator and patient. The healthcare professional should read and understand this entire manual before use
with a patient.
NOTE The EMISSIONS characteristics of this equipment make it suitable for use in industrial areas and hospitals
(CISPR 11 class A). If it is used in a residential environment (for which CISPR 11 class B is normally required) this
equipment might not offer adequate protection to radio-frequency communication services. The user might need to
take mitigation measures, such as relocating or re-orienting the equipment.
SYMBOL IDENTIFICATION
This symbol, when used in this manual and on product labels, represents a caution warning.
Be sure to read and comply with all precautions and warnings.
This symbol, when used in this manual and on product labels, warns against an electrical
shock hazard. Be sure to observe and comply with all warnings.
This symbol, when used in this manual and on product labels, indicates the potential of expo-
sure to harmful x-rays. Be sure to read and comply with all warnings.
This symbol, when used in this manual and on product labels, indicates that the table and
components are a Type B Applied Part pursuant to IEC 60601-1.
This symbol, when used in this manual or on product labels, indicates a Protective Earth
(Ground) Terminal.
This symbol, when used in this manual or on product labels, indicates the date of manufacture
of the device.
This symbol, when used in this manual or on product labels, indicates alternating current
(AC).
This symbol, when used in this manual or on product labels, indicates direct current (DC).
This symbol is used to indicate that the operator should consult the user manual.
Sitting is prohibited in this area.
~
----
CONTRAINDICATIONS
The O®Imaging Tables should not be used with Imaging systems having intensifier screens
or film cassettes larger than 12 inches (30 cm) when an oblique angle of view is being used. The
tables are not designed for and should not be used with Magnetic Resonance Imaging procedures.

2
IMPORTANT SAFETY INSTRUCTIONS
CAUTION
READ AND SAVE THESE INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
After unpacking your table, inspect it thoroughly for damage. If you suspect a problem do not use the table
and call our customer service department at 717.235.6807.
Improper use of this device can cause injury. Be sure to read all operating instructions prior to use.
Weight limit (patient and accessories): 227 kg / 500 lbs. distributed evenly. (Bariatric Table only: 340 kg /
750 lbs.)
Do not sit beyond warning line on carbon fiber top. On Lithotripsy / Urology Top - Do not sit on any exten-
sions (Weight Limit: 200 lbs. / 91 kg.)
The table utilizes four locking casters to permit movement of the table within the imaging suite. Accidental
movement of the table may occur. Lock casters prior to accomplishing imaging of the patient. Lock casters
when the patient is mounting & dismounting the table.
The table should not be used adjacent to or stacked with other equipment and that if adjacent or stacked use is
necessary, the table should be observed to verify normal operation in the configuration in which it will be used.
The use of Accessories, transducers, and cables other than those specified (with the exception of transducers
and cables sold by the Manufacturer of this device as replacement parts for internal components) may result in
increased Emissions or decreased Immunity of the table.
The table is designed to be a standalone table used with radiographic equipment. This table must not be
modified or incorporated into any other equipment.
There may be pinch points under the table top. Do not have any body part under the top when the table is
in motion.
Be certain that the table is completely lowered prior to discharging an ambulatory patient. The patient may lose
balance and fall. NOTE: The CFPMFXH is a fixed height table. It is recommended that all patients are assisted
onto the table (physical assistance & step stools with side rails is recommended.)
Patient must be secured with Safety Restraint Strap prior to using the tables.
Medical Electrical Equipment needs special precautions regarding EMC and needs to be installed and
put into service according to the EMC information provided in the specifications at the end of this manual.
(Excluding CFPMFXH)
Portable and Mobile RF Communications Equipment can affect Medical Electrical Equipment. (Excluding
CFPMFXH)
This table is not suitable for use in the presence of flammable anesthetic mixture with air or oxygen or nitrous
oxide.
Electrical Shock Hazard. (Excluding CFPMFXH) The power supply/control module is located inside the lift-
ing column and under the top. No user serviceable parts are inside. Refer servicing to qualified personnel.
Unplug wall connector prior to contact with any cables connected to the power supply.
To avoid the risk of electric shock, this equipment must only be connected an outlet this is properly
grounded. See GROUNDING instructions in this manual.
Grounding reliability can only be achieved when this equipment is connected to an equivalent 3 prong
receptacle marked “Hospital Only” or “Hospital Grade”.
Oakworks medical tables are designed and built to provide many years of dependable service. Please fol-
low local regulations and laws when disposing of the electrical components used in this table.
Do not apply excessive force to the hand/foot control as it may damage the control.
Do not use the hand/foot control if signs of wear or damage are visible as this can cause unintentional mo-
tion.

WARNING
To reduce the risk of burns, fire, electric shock or injury to persons:
1. Unplug this furnishing from the electrical outlet before cleaning.
2. Unplug from outlet before adding or removing parts.
3. Never operate this furnishing if it has a damaged cord or plug, if it is not working properly, if it has been
dropped or damaged, or dropped into water. Contact Oakworks Customer Service before use.
4. Keep the cord away from heated surfaces.
5. Never drop or insert any object into any opening.
6. Do not use outdoors.
7. Do not operate where aerosol (spray) products are being used or where oxygen is being administered.
DANGER
The potential of exposure to harmful x-rays exists when this table is in use. The use of adequate
x-ray barrier devices is necessary to provide protection to both the operator and the patient. X-ray
barrier devices are recommended for the patient outside of the intended target area to prevent expo-
sure to scattered radiation from the x-ray generating source.
The tabletop has a typical aluminum filtration equivalence of 1.10 mm as measured at 100 kVp and
a half value (HVL) of 3.6 mm. (NOTE: Bariatric Top has a typical aluminum filtration equivalence of
1.50 mm. as measured at 100 kVp and a half value (HVL) of 3.6 mm.)
• O®Imaging Tables may be used for x-ray imaging where the x-ray generator is located
below the tabletop and the image receptor is located above the tabletop. This is the recom-
mended method. The tables may also be used for x-ray imaging where the x-ray generator is
located above the tabletop and the image receptor is located below the tabletop. This applica-
tion will result in greater patient exposure to x-rays. The operator must weigh this issue with the
imaging requirements and patient exposure issues.
• The Imaging Tables may be used with the x-ray generator above the tabletop and a film cas-
sette located on the tabletop. (See contraindications regarding film cassette size.)
• The x-ray generator should never be located above the tabletop when the O®Imaging
Table and the O®Spine Positioning System/Prone Pillow are used together. This type
of use requires that the x-ray generator is located below the tabletop and the imaging intensifier
or film cassette located above the tabletop.
IMPORTANT SAFETY INSTRUCTIONS
3

4
PRODUCT DESCRIPTION
STANDARD SPECIFICATIONS
Fixed Height w/o pad 35.5” (90cm)
Choice of Tabletop:
- Integrated Headrest
- Rectangular
22” (56cm) W x 84” (214cm) L
24” (61cm) W x 80” (203cm) L
Table Voltage Options 120V/60Hz or 230V/50Hz
Table Capacity 500 lbs. (227 kg.) distributed evenly
4” (10cm) Locking
Casters
Locking / Unlocking Casters for mobile or
permanent positioning
Padding 2” (5cm) Comfort Foam™
Crescent Face Pad Integrated Headrest Only
Patient Restraint Strap Must be used during all procedures
Table Weight 368 lbs. (167 kg.)
OPTIONS
5” (13cm) Locking Casters
1” (2.5cm) Tabletop Pad
ACCESSORIES
Carbon Fiber Arm Board (Standard or Wide)
Spine Positioning System II
Adjustable T-rail Clamp
Fluoro Extender
CFPMFXH
24” X 80” RECTANGULAR TOP
For electrical specs, see Specifications section.
Carbon Fiber Integrated Headrest Top
with Removable Table Top Pad
Integrated Face Rest
with Crescent Face Pad
Locking
Casters
Hand Rail

PRODUCT DESCRIPTION
For electrical specs, see Specifications section.
CFPM100
STANDARD SPECIFICATIONS
Height Motion w/o pad Powered 22”-40” (56-102cm)
Foot Control Height motion
Choice of Tabletop:
- Integrated Headrest
- Rectangular
22” (56cm) W x 84” (214cm) L
24” (61cm) W x 80” (203cm) L
Table Voltage Options 120V/60Hz or 230V/50Hz
Table Capacity 500 lbs. (227 kg) distributed evenly
4” (10 cm.) Locking
Casters
Locking / Unlocking Casters for mobile or
permanent positioning
Padding 2” (5cm) Comfort Foam™
Crescent Face Pad Integrated Headrest Only
Patient Restraint Strap Must be used during all procedures
Table Weight 343 lbs. (156 kg)
OPTIONS
5” (13cm) Locking Casters

1” (2.5cm) Tabletop Pad
ACCESSORIES
Carbon Fiber Arm Board (Standard or Wide)
Spine Positioning System II
Adjustable T-rail Clamp
Fluoro Extender
5
Integrated Face Rest
with Crescent Face Pad
Carbon Fiber Integrated Headrest Top
with Removable Table Top Pad
Electronic Lift
Tower
Locking
Casters
Emergency
Stop
Hand Rail
24” X 80” RECTANGULAR TOP

6
PRODUCT DESCRIPTION
For electrical specs, see Specifications section.
CFPM300
STANDARD SPECIFICATIONS
Motion 1 w/o pad Powered 26”-43” (66-109cm) Height Range
Motion 2 Powered +15°/-12° Trendelenburg
Motion 3 Powered ±15° Lateral Tilt
Hand Control All powered motions
Choice of Tabletop:
- Integrated Headrest
- Rectangular
22” (56cm) W x 84” (214cm) L
24” (61cm) W x 80” (203cm) L
Table Voltage Options 120V/60Hz or 230V/50Hz
Table Capacity 500 lbs. (227 kg) distributed evenly
4” (10 cm.) Locking
Casters
Locking / Unlocking Casters for mobile or
permanent positioning
Padding 2” (5cm) Comfort Foam™
Crescent Face Pad Integrated Headrest Only
Patient Restraint Strap Must be used during all procedures
Table Weight 498 lbs. (226kg)
OPTIONS
5” (13cm) Locking Casters

Foot Control
1” (2.5cm.) Tabletop Pad
ACCESSORIES
Carbon Fiber Arm Board (Standard or Wide)
Spine Positioning System II
Adjustable T-rail Clamp
Fluoro Extender
Carbon Fiber Integrated Headrest Top
with Removable Table Top Pad
Locking
Casters
Hand Rail
Integrated Face Rest
with Crescent Face Pad
Electronic Lift
Tower
Emergency
Stop
24” X 80” RECTANGULAR TOP

PRODUCT DESCRIPTION
STANDARD SPECIFICATIONS
Motion 1 w/o pad Powered 26”-43” (66-109cm) Height Range
Motion 2 Powered +15°/-12° Trendelenburg Tilt
Motion 3 Powered ±15° Lateral Tilt
Motion 4 Powered 10” (25cm) Longitudinal Travel
Hand Control All powered motions
Choice of Tabletop:
- Integrated Headrest
- Rectangular
22” (56cm) W x 84” (214cm) L
24” (61cm) W x 80” (203cm) L
Table Voltage Options 120V/60Hz or 230V/50Hz
Table Capacity 500 lbs. (227 kg) distributed evenly
4” (10 cm.) Locking
Casters
Locking / Unlocking Casters for mobile or
permanent positioning
Padding 2” (5cm) Comfort Foam™
Crescent Face Pad Integrated Headrest Only
Patient Restraint Strap Must be used during all procedures
Table Weight 498 lbs. (226 kg)
OPTIONS
5” (13cm) Locking Casters

Foot Control
1” (2.5cm) Tabletop Pad
ACCESSORIES
Carbon Fiber Arm Board (Standard or Wide)
Spine Positioning System II
Adjustable T-rail Clamp
Fluoro Extender
CFPM400
For electrical specs, see Specifications section.
7
Carbon Fiber Integrated Headrest Top
with Removable Table Top Pad
Integrated Face Rest
with Crescent Face Pad
Electronic Lift
Tower
Locking
Casters
Emergency
Stop
Hand Rail
24” X 80” RECTANGULAR TOP

8
PRODUCT DESCRIPTION
For electrical specs, see Specifications section.
CFPM301
STANDARD SPECIFICATIONS
Motion 1 w/o pad Powered 25”-43” (64-109cm) Height Range
Motion 2 Powered +15°/-11° Trendelenburg
Motion 3 Powered 10” (25cm) Longitudinal Travel
Hand Control All powered motions
Choice of Tabletop:
- Integrated Headrest
- Rectangular
22” (56cm) W x 84” (214cm) L
24” (61cm) W x 80” (203cm) L
Table Voltage Options 120V/60Hz or 230V/50Hz
Table Capacity 500 lbs. (227 kg) distributed evenly
4” (10 cm.) Locking
Casters
Locking / Unlocking Casters for mobile or
permanent positioning
Padding 2” (5cm) Comfort Foam™
Crescent Face Pad Integrated Headrest Only
Patient Restraint Strap Must be used during all procedures
Table Weight 538 lbs. (244 kg)
OPTIONS
5” (13cm) Locking Casters

Foot Control
1” (2.5cm) Tabletop Pad
ACCESSORIES
Carbon Fiber Arm Board (Standard or Wide)
Spine Positioning System II
Adjustable T-rail Clamp
Fluoro Extender
Locking
Casters
Integrated Face Rest
with Crescent Face Pad
Carbon Fiber Integrated Headrest Top
with Removable Table Top Pad
Electronic Lift
Tower
Hand Rail
Emergency
Stop
24” X 80” RECTANGULAR TOP

PRODUCT DESCRIPTION
24” x 80” Bariatric Carbon Fiber
Top with Removable Table Top Pad
CFPMB301 - Bariatric
STANDARD SPECIFICATIONS
Motion 1 w/o pad Powered 26”-44” (66-112 cm) Height
Range
Motion 2 Powered +15°/-11° Trendelenburg
Motion 3 Powered 10” (25cm) Longitudinal Travel
Hand Control All powered motions
Rectangular Top 24” (61cm) W x 80” (203cm) L
Table Voltage Options 120V/60Hz or 230V/50Hz
Table Capacity 750 lbs. (340 kg) distributed evenly
4” (10 cm.) Locking
Casters
Locking / Unlocking Casters for mobile or
permanent positioning
Padding 2” (5cm) Comfort Foam™
Crescent Face Pad Integrated Headrest Only
Patient Restraint Strap Must be used during all procedures
Table Weight 573 lbs. (260 kg)
OPTIONS
5” (13cm) Locking Casters

Foot Control
1” (2.5cm) Tabletop Pad
ACCESSORIES
Carbon Fiber Arm Board (Standard or Wide)
Spine Positioning System II
Adjustable T-rail Clamp
Fluoro Extender
For electrical specs, see Specifications section.
9
Electronic Lift
Tower
Locking
Casters
Emergency
Stop
Hand Rail

STANDARD SPECIFICATIONS
Motion 1 w/o pad Powered 26”-44” (66-112cm) Height Range
Motion 2 Powered +15°/-12° Trendelenburg Tilt
Motion 3 Powered 10” (25cm) Longitudinal Travel
Motion 4 Powered ±4” (10cm) Lateral Travel
Hand Control All powered motions
Choice of Tabletop:
- Integrated Headrest
- Rectangular
22” (56cm) W x 84” (214cm) L
24” (61cm) W x 80” (203cm) L
Table Voltage Options 120V/60Hz or 230V/50Hz
Table Capacity 500 lbs. (227 kg) distributed evenly
4” (10 cm.) Locking
Casters
Locking / Unlocking Casters for mobile or
permanent positioning
Padding 2” (5cm) Comfort Foam™
Crescent Face Pad Integrated Headrest Only
Patient Restraint Strap Must be used during all procedures
Table Weight 548 lbs. (249 kg)
OPTIONS
5” (13cm) Locking Casters

Foot Control
1” (2.5cm) Tabletop Pad
ACCESSORIES
Carbon Fiber Arm Board (Standard or Wide)
Spine Positioning System II
Adjustable T-rail Clamp
Fluoro Extender
CFPM401
10
PRODUCT DESCRIPTION
For electrical specs, see Specifications section.
Hand Rail
Emergency
Stop
Locking
Casters
Electronic Lift
Tower
Integrated Face Rest
with Crescent Face Pad
Carbon Fiber Integrated Headrest Top
with Removable Table Top Pad
24” X 80” RECTANGULAR TOP

PRODUCT DESCRIPTION
STANDARD SPECIFICATIONS
Motion 1 w/o pad Powered 27”-45” (66-112cm) Height Range Table Weight 618 lbs. (280 kg)
Motion 2 Powered +15°/-12° Trendelenburg Tilt Urology Bag Hoop Clips onto T-rails (bag not included)
Motion 3 Powered 10” (25cm) Longitudinal Travel Intregrated T-rails .38” (1cm) Thick x 1.13” (3cm) High US
Standard
Motion 4 Powered ±4” (10 cm.) Lateral Travel Patient Restraint
Strap
Must be used during all procedures
Hand Control All powered motions 5” (12.5 cm.)
Locking Casters
Locking / Unlocking Casters for mobile or
permanent positioning
Foot Control All powered motions
Main Top Dimensions
23” (58cm) W x 47” (119cm) L (Radiolucent
dimensions: 19” (48cm) W x 23.7” (60cm))
Table Extensions (1) 23” (58cm) W x 28” (71cm) L - End
(1) 23” (58cm) W x 16” (41cm) L OR
23” (58cm) W x 20” (51cm) L - Short
Table Voltage Options 120V/60Hz or 230V/50Hz (2) 8” (20cm) W x 11” (28cm) L - Lateral
Table Capacity 500 lbs. (227 kg) distributed evenly (1) 8” (20cm) W x 14” (36cm) L - Lateral
200 lbs. (91 kg) (on all extensions) (1) 8” (20cm) W x 24” (61cm) L - Lateral
Padding 2” (5cm) Comfort Foam™
OPTIONS

1” (2.5cm) Tabletop Pad
ACCESSORIES
Carbon Fiber Arm Board (Standard or Wide)
Spine Positioning System II
Fluoro Extender
Litho/Urology Drape
CFLU401 - Lithotripsy/Urology Top
Carbon Fiber Top with
Removable Table Top Pad
Locking
Casters
Emergency
Stop
End Extension
Short Extension
Lateral Extensions (4)
T-rail
(along each side)
Hand Rail
(Under end)
For electrical specs, see Specifications section.
11

12
PRODUCT DESCRIPTION
For electrical specs, see Specifications section.
STANDARD SPECIFICATIONS
Motion 1 w/o pad Powered 25”-43” (64-109cm) Height Range
Motion 2 Powered +15°/-11° Trendelenburg Tilt
Motion 3 Powered 10” (25cm) Longitudinal Travel
Hand Control All powered motions
Foot Control All powered motions
Main Top Dimensions 23” (58cm) W x 47” (119cm) L (Radiolucent
dimensions: 19” (48cm) W x 23.7” (60cm))
Table Extensions
(1) 23” (58.4 cm.) W x 28” (71.1 cm.) L -
End
(2) 5” (12.5 cm.) W x 24” (61 cm.) L - Lat-
eral
Integrated T-rails .38” (1cm) Thick x 1.13” (3cm) High US
Standard
Urology Bag Hoop Clips onto T-rails (bag not included)
Table Capacity 500 lbs. (227 kg) distributed evenly
200 lbs. (91 kg) (on all extensions)
4” (10 cm.) Locking
Casters
Locking / Unlocking Casters for mobile or
permanent positioning
Padding 2” (5 cm.) Comfort Foam™
Patient Restraint
Strap
Must be used during all procedures
Table Weight 568 lbs. (258 kg)
OPTIONS
5” (13cm) Locking Casters

1” (2.5cm) Tabletop Pad
ACCESSORIES
Carbon Fiber Arm Board (Standard or Wide)
Spine Positioning System II
Adjustable T-rail Clamp
Fluoro Extender
CFUR301 - Urology Top
Urology Carbon Fiber Top with
Removable Table Top Pad
Hand Rail
(At end)
Emergency
Stop
T-rail
Electronic Lift
Tower
Locking
Casters

PRODUCT DESCRIPTION
STANDARD SPECIFICATIONS
Motion 1 w/o pad Powered 26”-44” (66-112cm) Height Range
Motion 2 Powered +15°/-11° Trendelenburg Tilt
Motion 3 Powered 10” (25cm) Longitudinal Travel
Motion 4 Powered ±4” (10cm) Lateral Travel
Hand Control All powered motions
Foot Control All powered motions
Main Top Dimensions 23” (58cm) W x 47” (119cm) L (Radiolucent
dimensions: 19” (48cm) W x 23.7” (60cm))
Table Extensions (1) 23” (58cm) W x 28” (71cm) L - End
(2) 5” (13cm) W x 24” (61cm) L - Lateral
Integrated T-rails .38” (1cm) Thick x 1.13” (3cm) High US
Standard
Urology Bag Hoop Clips onto T-rails (bag not included)
Table Capacity 500 lbs. (227 kg) distributed evenly
200 lbs. (91 kg) (on all extensions)
4” (10 cm.) Locking
Casters
Locking / Unlocking Casters for mobile or
permanent positioning
Padding 2” (5cm) Comfort Foam™
Patient Restraint
Strap
Must be used during all procedures
Table Weight 590 lbs. (268 kg)
OPTIONS
5” (13cm) Locking Casters

1” (2.5cm) Tabletop Pad
ACCESSORIES
Carbon Fiber Arm Board (Standard or Wide)
Spine Positioning System II
Adjustable T-rail Clamp
Fluoro Extender
CFUR401 - Urology Top
For electrical specs, see Specifications section.
13
Locking
Casters
T-rail Electronic Lift
Tower Emergency
Stop
Hand Rail
(At end)
Urology Carbon Fiber Top with
Removable Table Top Pad

14
The Imaging Tables come completely assembled and ready to use. Plug the cord into a functioning
outlet that is rated for the table. (See Grounding below)
Arrange the power cord and control cords so that they will not create a tripping hazard and where the
controls are located to your liking and are conveniently accessible.
Be sure access to plug is not blocked for disconnecting the table from power.
This product must be grounded. If it should malfunction or break down, grounding provides a path
of least resistance for electrical current to reduce the risk of electric shock. This product is equipped
with a cord having an equipment-grounding conductor and a grounding pin. The pin must be plugged
into an appropriate outlet that is properly installed and grounded in accordance with all local codes
and ordinances. See U.S. sample below.
Improper connection of the equipment-grounding conductor can result in a risk of electric shock.
Check with a qualified electrician or service person if you are in doubt as to whether the product is
properly grounded. Do not modify the plug provided with the product - if it will not fit the outlet; have
a proper outlet installed by a qualified electrician.
Correct Implementation Incorrect Implementation

Grounding Methods
Risk of Electric Shock - Connect this furnishing to a properly grounded outlet only.
DANGER
INSTALLATION
GROUNDING

DIRECTIONS FOR USE
FOOT CONTROL
Used to control table Vertical Height, Trendelenburg, Longitudinal Motion, Lateral Tilt or Lateral Motion.
Control functions dependent upon table’s features. Test each of the table’s functions prior to use with a patient.
CFPM 100 - ONE MOTION
THREE MOTION FOUR MOTION
CAUTION
15
CAUTION Do not apply excessive force to the foot control as it may damage the control.
Do not use the foot control if signs of wear or damage are visible as this can cause unintentional
motion.
The Foot Control Riser Plate prevents
the foot control from getting caught
underneath the base of the table or
between the column and the base as
the column descends. This reduces the
risk of unintentional movement of the
table due to accidental activation of the
foot control buttons.

16
DIRECTIONS FOR USE
HAND CONTROL - THREE MOTION
Used to control table Vertical Height, Trendelenburg, Lateral Tilt OR Vertical Height, Trendelenburg,
Longitudinal Motion. Control functions dependent upon table’s features. Test each of the table’s functions
prior to use with a patient.
HAND CONTROL - FOUR MOTION
Used to control table Vertical Height, Trendelenburg, Longitudinal Motion, Lateral Tilt OR Vertical
Height, Trendelenburg, Longitudinal Motion, Lateral Motion. Control functions dependent upon table’s fea-
tures. Test each of the table’s functions prior to use with a patient.
CAUTION Do not apply excessive force to the hand control as it may damage the control.
Do not use the hand control if signs of wear or damage are visible as this can cause unintentional
motion.
CAUTION Do not apply excessive force to the hand control as it may damage the control.
Do not use the hand control if signs of wear or damage are visible as this can cause unintentional
motion.

DIRECTIONS FOR USE
ANGLE INDICATOR
Standard on CFPM 301, CFPM301B,
CFPM401, CFLU401, CFUR401 and
CFUR301 Tables. Optional on all other
Imaging Tables.
To use angle indicator, simply press “on/
off” button on the left side of the indicator.
NOTE: Do not press “zero” unless table is
in the horizontal position.
CAUTION
PATIENT RESTRAINT STRAPS
Two Patient Restraint Strap must be used at all times during procedures to prevent the patient from
falling off the table.
The strap has hook and loop fasteners attached to the ends. The strap is attached as follows:
1. Place the center of each strap around the patient
at two places. Relocate the straps as necessary
for adequate clearance.
2. Take the ends of each strap down around the
tabletop. Pull each strap snug underneath the
table and press the two ends together.
3. Check both straps to assure adequate patient
restraint prior to using the Trendelenburg func-
tions.
17
BUBBLE LEVELS
Bubble levels are installed on the handle end of the table to aid the operator in determining the hori-
zontal plane.
