OAKWORKS Powerline Series User manual

www.oakworks.com · 717.235.6807
OAKWORKS®
Treatment Tables
USER MANUAL
Powerline Series
Seychelle™ Series
made in the USA
with US & imported parts

© Copyright 2018
OAKWORKS®, Inc.
Printed in U.S.A.
All rights are reserved. No part
of this document may be
photocopied, reproduced or
translated to another language
without prior written consent
of OAKWORKS®, Inc.
OAKWORKS®is a registered
trademark of OAKWORKS®, Inc.
Notice
The information contained within this
document is subject to change
without notice and should not
be construed as a commitment by
OAKWORKS®, Inc.
OAKWORKS®, Inc. encourages requests
for technical specifications and the
like documentation to ensure accu-
racy. The appropriate documentation
is available upon request.
OAKWORKS®, Inc. shall not be
liable for incidental or consequential
damages in connection with or arising
out of the furnishing, performance, or
use of this document and the program
material which it describes.

Product Use Description .............................................................................................................................1
Important Safety Instructions.....................................................................................................................1
Product Description & Photo
Powerline Series............................................................................................................................... 2-3
Seychelle Series................................................................................................................................ 4-5
Installation
Table Assembly ....................................................................................................................................6
Inset Shelf ..............................................................................................................................................6
Directions for Use
Paper Roll Holder Use........................................................................................................................ 7
Wave Backrest Use ............................................................................................................................. 7
Table Extender .................................................................................................................................... 7
QuickLock Face Rest .......................................................................................................................... 8
Cleaning & Disinfection
Recommended Cleaners/Disinfectants ........................................................................................ 9
Cleaning Process................................................................................................................................. 9
Inspections ....................................................................................................................................................10
Warranty Information ................................................................................................................................10
Model Number & Serial Number .............................................................................................................11
Specifications
Product Specifications .................................................................................................................. 12
Environmental Conditions ........................................................................................................... 12
Contact Information .................................................................................................................. back cover
TABLE OF CONTENTS

PRODUCT USE DESCRIPTION / IMPORTANT SAFETY INSTRUCTIONS
1
CAUTION
READ AND SAVE THESE INSTRUCTIONS
This symbol, when used in this manual and on product labels, represents a caution warning. Be
sure to read and comply with all precautions and warnings.
The Backrest section is not designed to support the entire weight of the patient. Do not sit on
the Backrest section.
The table is designed to be a stand alone table. This table must not be modified or incorporated
into any other equipment.
There are potential pinch points around and underneath the tabletop. It is the responsibil-
ity of the operator of this equipment to insure that bystanders are not in the area below or
around this equipment during operation.
Proper operation of this equipment is very important for the safety of the operator, patient,
and any other individuals in the area of this equipment. Directions for use of this equipment
are described in this manual. The operator should read these sections carefully.
Do not use outdoors.
Use this furnishing only for its intended use as described in this manual. Do not use attachments not
recommended by Oakworks.
Weight Limit: (patient and accessories) 500 lbs./227 kg. Do not exceed.
PRODUCT USE DESCRIPTION
The Oakworks Powerline & SeychelleTM Tables are used to support the patient during examinations
and procedures. They are intended to be operated by a professional in a exam/treatment environ-
ment. No special training is required but a review of the following manual is important for the
safety of the operator and patient. The professional should read and understand this entire manu-
al before use with a patient. There are no known contraindications to the use of this equipment.
IMPORTANT SAFETY INSTRUCTIONS

Powerline Flat Top
2
PRODUCT DESCRIPTION
Upholstered Top
Accessory outlets
Paper Roll Holder
Accessory outlets
Table Extender
(accessory)
QuickLock Face
Rest (accessory)
STANDARD SPECIFICATIONS
Height Range Fixed 30”(76 cm.)
Table Capacity 500 lbs. (226 kg.) (patient and accessories)
Widths 27” (69 cm.) or 30” (76 cm.)
Length 72” (183 cm.)
Padding 2.5” (6 cm.) Semi-Firm
Upholstery Terra Touch™
Paper Roll Holder Accommodates up to 21”(53 cm.) rolls
(roll not included)
Table Weight*90 lbs. (41 kg.)
OPTIONS & ACCESORIES
QuickLock Face Rest
Table Extender
Inset Shelf (adds 25 lbs. (11 kg.))
Padding - 1.75”(4 cm.) Firm Response

Powerline Wave Backrest
3
PRODUCT DESCRIPTION
Upholstered Top
Accessory outlets
Inset Shelf (option)
Accessory outlets
Table Extender
(accessory)
QuickLock Face
Rest (accessory)
STANDARD SPECIFICATIONS
Table Height Fixed 30” (76 cm.)
Wave Backrest Manual 0-60º, 6 set positions
Table Capacity 500 lbs. (226 kg.) (patient and accessories)
Widths 27” (69 cm.) or 30” (76 cm.)
Length 72” (183 cm.)
Padding 2.5” (6 cm.) Semi-Firm
Upholstery Terra Touch™
Paper Roll Holder Accommodates up to 21”(53 cm.) rolls
(roll not included)
Table Weight*90 lbs. (41 kg.)
OPTIONS & ACCESORIES
QuickLock Face Rest
Table Extender
Inset Shelf (adds 25 lbs. (11 kg.))
Padding - 1.75”(4 cm.) Firm Response
Paper Roll
Holder
Wave Backrest

Seychelle Flat Top
4
PRODUCT DESCRIPTION
Upholstered Top
Accessory outlets
Inset Shelf (option)
Accessory outlets
Table Extender
(accessory)
QuickLock Face
Rest (accessory)
STANDARD SPECIFICATIONS
Height Range Fixed 30” (76 cm.)
Table Capacity 500 lbs. (226 kg.) (patient and accessories)
Widths 27” (69 cm.) or 30” (76 cm.)
Length 72” (183 cm.)
Padding 3” (8 cm.) Comfort
Upholstery Terra Touch™
Table Weight*90 lbs. (41 kg.)
OPTIONS & ACCESORIES
QuickLock Face Rest
Table Extender
Inset Shelf (adds 25 lbs. (11 kg.))
Padding - 4”(10 cm.) Comfort

Seychelle Wave Backrest
5
PRODUCT DESCRIPTION
Upholstered Top
Accessory outlets
Inset Shelf (option)
Accessory outlets
Table Extender
(accessory)
QuickLock Face
Rest (accessory)
STANDARD SPECIFICATIONS
Table Height Fixed 30” (76 cm.)
Wave Backrest Manual 0-60º, 6 set positions
Table Capacity 500 lbs. (226 kg.) (patient and accessories)
Widths 27” (69 cm.) or 30” (76 cm.)
Length 72” (183 cm.)
Padding 3” (8 cm.) Comfort
Upholstery Terra Touch™
Table Weight*90 lbs. (41 kg.)
OPTIONS & ACCESORIES
QuickLock Face Rest
Table Extender
Inset Shelf (adds 25 lbs. (11 kg.))
Padding - 4”(10 cm.) Comfort
Wave Backrest

6
Tools Required:
9/16” / 14mm Wrench/Socket
The tables are shipped complete in one box. Follow the step
below to fully assemble the table:
1. Remove the table from the box and place it down on the floor with the
top down. Remove all hardware and the Leg Brace.
2. Unfold the legs to a vertical position and remove any protective wrappings.
3. Install the long large bolts, reinforcement plates, spring washers and lock
nuts as shown, two bolts on each leg. Using the large allen wrench and 9/16” /
14mm wrench socket, tighten every bolt/nut connection -- 8 total -- to 12 ft-lbs
minimum or until the spring washers are flat.
4. Install the barrel nut into the leg brace being sure the screw slit is horizontal.
Install the short bolt through the leg rail. Start the bolt into the barrel nut using
your fingers first. After the bolt has started, tighten the bolt using the small
allen wrench. Make sure the leg brace is flush with the adjoining rails while
tightening bolts. Repeat on opposite end of the leg brace.
5. Turn your table right side up. Get up on the table and rock back and forth
to check that all bolts are tight. The table should be very stiff. Dependent
on the environmental conditions of your table, it may be necessary to
periodically re-tighten the hardware.
INSTALLATION
TABLE ASSEMBLY
Barrel Nut
Short Bolt
Leg Brace
SHELF ATTACHMENT
If you have ordered a shelf, drop the shelf into place with the finished side up. The shelf has groves at
both ends that enable it to be held firmly in place by the legs. If necessary, the shelf can be further sta-
bilized by installing the enclosed Velcro™ strips. Place strips on each corner of the shelf’s bottom side,
and on each end of the rails. Make sure not to mismatch Velcro™ strips; place all “hook” or all “loop”
pieces on either the rail or shelf.
LEG HARDWARE
8 -Reinforcement Plates
16 - Spring Washers
4 - Long Large Bolts
4 - Lock Nuts
SUPPLIED PARTS:
LEG BRACE
1 - Wood Leg Brace
2 - Short Bolts
2 - Barrel Nuts
TOOLS
1 - Large Allen Wrench
1 - Small Allen Wrench

7
DIRECTIONS FOR USE
PAPER ROLL HOLDER USE
After the table is set-up,
locate the hole in the leg.
Using the supplied
screw & allen wrench,
secure the paper roll
holder bracket into
place. Repeat step for
the opposite side.
Locate the wooden
dowel & feed it thru
your paper roll. Place the
wooden dowel in the
groove located in each
of the paper roll holder
brackets.
To secure the wooden
dowel, feed it into the
pocket of the groove
on both sides of the
table.
WAVE BACKREST USE
TO RAISE THE BACKREST
Lift the backrest to the desired height and
release. The Backrest support arm will lock in
the nearest slot in the side rail.
TO LOWER THE BACKREST
Lift the backrest slightly, lift and hold the
support arm out of the slot and lower the
backrest to the desired position.
TABLE EXTENDER
CAUTION Do not put excessive weight or pressure on the table extender.
The Table Extender lengthens
the table for your tallest clients
and can improve access to your
patient.
Unfold the dowels and insert
into the outlets.
Locate the Accessory attach-
ment outlets.
CAUTION Do not adjust the Backrest with a patient on the table.
