Information about these operating instructions
Welcome to OASE Living Water. You made a good choice with the purchase of this product FiltoClear
3000/4000/8000.
Prior to commissioning the unit, please read the instructions of use carefully and fully familiarise yourself with the unit.
Ensure that all work on and with this unit is only carried out in accordance with these instructions.
Adhere to the safety information for the correct and safe use of the unit.
Keep these instructions in a safe place! Please also hand over the instructions when passing the unit on to a new
owner.
Symbols used in these instructions
GB
The symbols used in this operating manual have the following meanings:
Risk of injury to persons due to dangerous electrical voltage
This symbol indicates an imminent danger, which can lead to death or severe injuries if the appropriate
measures are not taken.
Risk of personal injury caused by a general source of danger
This
symbol indicates an imminent danger, which can lead to death or severe injuries if the appropriate
measures are not taken.
Important information for trouble-free operation.
Intended use
FiltoClear 3000/4000/8000, referred to in the following as "unit", may only be used as specified in the following:
•For mechanical and biological cleaning of garden ponds
•Operation under observance of the technical data.
The following restrictions apply to the unit:
•Never use the unit to filter fluids other than water.
•Never run the unit without water.
•Do not use for commercial or industrial purposes.
•Do not use in conjunction with chemicals, foodstuff, easily flammable or explosive substances.
Important! Ensure that the filter will not overflow. Danger of emptying the pond.
Use other than that intended
This unit can be dangerous and cause harm to persons if not used in accordance with these instructions. Any use not
in accordance with these instructions or modification(s) to the unit will void the limited warranty.

-EN -
10
Unit configuration and function description
Unit configuration
Figure
(B)
Object
1
Water return socket, for the return of filtered pond water
2
Water inlet socket, for the inlet of soiled pond water
3
Cleaning handle, the foam filters are compressed by pulling the handle up
4
UVC unit head with temperature monitor, holder and control window for UV-C lamp. The UV-C lamp switches off automatically when
overheated and on again once cooled down.
5
Function switch to reverse the water flow. Turn counter-clockwise. 3 positions are available.
I: Water filtering and radiation
II: Foam cleaning („Easy-Clean Technology“)
III: Flushing the UVC unit and the UVC water housing
6
Bypass, optimises the UVC radiation effect at a high flow rate
7
Soiled water drain socket, to drain the soiled water
8
Filter lid
9
Cover cap, with black flat sealing ring inserted
10
Clamping ring to hold filter lid and container together
11
Step, marking the maximum installation depth
12
Container, pressurised when the unit is in operation (max. 2.9 psi / 0,2 bar)
13
Fine foam filter for nitrification and denitrification
14
Coarse foam filter for nitrification
15
Fixing disk, holding foam filters on cleaning rods
16
Cleaning rod, connecting cleaning handle and filter disk
17
Meshed tube, maintaining the foam filter spacing to the UVC water housing
18
UVC water housing, conveying water to the UVC unit
19
Quartz glass tube with UV-C lamp
Function description
Figure (A)
A filter pump (only contained as a set in the scope of delivery) presses the water into a pressure-tight container, where
it passes several cleaning stages before returned into the pond. The soiled water resulting from cleaning the unit can
be used to fertilise the garden.
Figure B
Cleaning stage "filtering": The water flows through the foam filters. Mechanical soiling is retained by the foam filters.
Suspended matter and bio sludge settle on the container bottom. Usseful bacteria settle on the foam filters, cleaning
the water biologically. Their effect starts at a water temperature of 50 °F (+ 10 °C).
Coarse foam filters (blue)
Fine foam filters (red)
high flow rate
low flow rate
Bacteria for nitrification
Bacteria for nitrification and denitrification
Ammonia -> nitrite -> nitrate reaction
Nitrate -> nitrogen reaction
Cleaning stage "radiation": The water is radiated with the ultra-violet light from a UV-C lamp. Green algae die, patho-
genic agents are killed.
Bypass: A bypass ensures that only part of the returning water (approx. 25 %) is radiated. In this manner a sufficient
radiation duration is obtained even at a high circulation rate.
Filter starter: The unit only reaches its full biological cleaning effect after a few weeks. The formation of a bacterial
community on the foam filters can be notably accelerated by adding filter starter bacteria.

-EN -
11
OASE recommend:
– as a reference value for the fish population in the pond: approx. 2 ft (60 cm) fish length in 260 gal (1 m3) pond
water.
– as a pond pump for FiltoClear 3000: pump max. 2100 Gph (8000 l/h).
– as a pond pump for FiltoClear 4000: pump max. 2600 Gph (10000 l/h).
– as a pond pump for FiltoClear 8000: pump max. 4200 Gph (16000 l/h)
Symbols on the unit
D
The warning symbols on the unit have the following meaning:
Risk of personal injury if used incorrectly
Incorrect use of the unit can cause injury or damage to assets. Always read the instructions for use first.
Risk of personal injury caused by a general source of danger
Dangerous UVC radiation. Health hazard for eyes and skin caused by light flash. Only operate the UV-
C
lamp inside the housing.
Symb o ls
The symbols on the unit relating to its use have the following meaning:
Protected against touching dangerous components. Splash water protected.
Protect from direct sun radiation.
Dismantle at temperatures of 0 °C and below.
Installation
Figure (A)
To be taken into consideration for planning:
– Spacing between unit and water: min. 6.6 ft (2 m) (safety spacing!).
– Do not expose the unit to direct sun radiation.
– Water return point. OASE recommend: Route the return hose such that the clean water is indirectly returned to
the pond, e.g. through a water course. In this manner it will be additionally enriched with oxygen.
– Height difference between filter lid and water return point: max. 6.6 ft (2 m).
Installation possibility 1: Bury close to the pond.
Dig a hole close to the pond and place the container into the hole up to the mark (B 11).
Installation possibility 2: Placement close to the pond.
Place the unit close to the pond where it is flood protected (e.g. hidden behind shrubs). The ground must be firm and
level.
Connecting a filter pump
A filter pump is required to operate the pressure filter (only contained as a set in the scope of delivery). Only connect to
the pump by means of pressure hoses approved for at least 2.9 psi (0.2 bar) or the maximum pump pressure.
Hoses with an internal diameter of 1 1/2" or 2" can be connected to the unit.

-EN -
12
Installation
Figure (C)
1 ½" hoses or 2" hoses can be connected to the unit. The respective hose connectors are part of our scope of delivery.
Recommendation: Use 2" hoses to convey the water through the lines at a minimum pressure loss.
If you use a filter starter, fill the product into the container prior to carrying out the following installation steps (Com-
missioning/Start-up).
Fitting the water inlet
How to proceed:
•Push the union nut (26) over the black hose connector (22).
•Insert the flat sealing ring (27) in the union nut (26).
•Screw tighten the hose connector to the water inlet socket (2) using the union nut.
•Push the hose clip (29) over the hose (30).
•Push the hose over the hose connector (up to the stop) and secure using the hose clip.
Fitting the water return
How to proceed:
•Push the union nut (26) over the transparent hose connector (20).
•Place the flow indicator flap (28) into the union nut.
•Screw tighten the hose connector to the water return socket (1) using the union nut.
•Push the hose clip (29) over the hose (30).
•Push the hose over the hose connector and secure with the hose clip. Leave the last segment free for use as a window
to control flow and soiling (D).
Fitting the soiled water drain
The soiled water resulting from cleaning the unit can be used for fertilisation purposes. Recommendation: Connect and
route a drain hose (not included in our scope of delivery) up to a suitable point (e.g. plant bed).
How to proceed:
•Unscrew the cover cap (9) from the soiled water drain socket (7).
•Push the union nut (26) over the transparent hose connector (20).
•Place the flow indicator flap (28) into the union nut.
•Screw tighten the hose connector to the socket using the union nut.
•Push the hose clip (29) over the hose (30).
•Push the hose over the hose connector and secure with the hose clip. Leave the last segment free for use as a window
to control flow and soiling (D).
Closing the soiled water drain
Note!
During filter operation, ensure that the soiled water socket (7) or a drain hose (30) connected to it is always
closed with a cover cap (9) with the flat sealing ring inserted. This prevents unintended emptying of the pond.
How to proceed:
•Push the hose clip (29) over the hose (30).
•Push the hose connector (23) into the hose and secure with the hose clip.
•Close the hose connector using the cover cap with the flat sealing ring (9) inserted.

-EN -
13
Commissioning/start-up
Sensitive electrical components.
Possible consequences: The device will be destroyed.
Protective measure:
Do not connect the unit to a dimmable power supply.
How to proceed:
•Fit the connections (Assembly).
•Check the firm seating of hoses, cover cap for soiled water drain, clamping ring with safety latch.
•Turn the function switch (J 5) to water filtering (40), if it is not already in this position.
•Switch on the pond pump.
•Only switch on the UVC unit when water is flowing through it. You may have to wait for 24 hours.
Connect power plug to the socket. The UVC unit switches on immediately, the blue LED (J 33) is lit.
Operation
The unit is no longer biologically active at water temperatures below 50 °F (10 °C). Take the unit out of operation at
water temperatures below 46 °F (8 °C) or, at the latest, when freezing temperatures are to be expected.
Normal operating condition: The UVC unit is switched on. The UV-C lamp must be replaced after approx. 8000 opera-
ting hours.
Remedy of faults
Malfunction
Cause
Remedy
No water flow through the re-
turn socket.
−Filter pump not switched on.
−Switch on the filter pump
−Supply lines blocked.
−Check supply lines
−Function switch not turned to "Filter water"
−Turn function switch to „Filter water“
UVC lamp display is not lit
−Connection defective or has not been made.
−Check connection (power plug, power fuse)
−Temperature monitor has switched off the UVC
lamp
−Allow the UVC lamp to cool down
−UVC lamp defective
−Replace UVC lamp
−Quartz glass tube not fitted
−Fit quartz glass tube
Filtering performance not satis-
factory
−Function switch not turned to "Filter water"
−Turn function switch to „Filter water“
−Unit has not been in operation long enough
−Wait a few days/weeks
−Water extremely soiled
−Excessive fish and animal population
−Adhere to the reference value
−Foam filters clogged
−Clean foam filters
−Quartz glass tube soiled
−Cleaning the quartz glass tube
−UVC lamp is in operation for more than 8000
hours
−Replace UVC lamp
Wear parts
The UVC lamp, the quartz glass and the foam filters are wear parts and are excluded from the warranty.

-EN -
14
Maintenance and cleaning
Removing/inserting the UVC unit head
Attention! Dangerous electrical voltage!
Possible consequences: Death or severe injury.
Protective measures: Prior to commencing work, disconnect the unit from the mains.
Removing the UVC unit head
Figure (E)
How to proceed:
•Press the blue "Press" button (31) at the UVC unit head (4).
•Slightly turn the UVC unit head counter-clockwise.
•Carefully pull the UVC unit head out of the filter lid (8).
Inserting the UVC unit head
Figure (F)
Note!
The O ring (32) on the closure of the UVC water housing (4) is firmly clamped on. Only remove the O ring
when it must be replaced (e.g. when the O ring is porous).
How to proceed:
•Carefully insert the UVC unit head (4) into the filter lid.
•Turn the UVC unit head clockwise up to the stop.
The blue "Press" button engages (31).
Opening/ closing the container
Attention!
Dangerous electrical voltage!
Possible consequences: Death or severe injury.
Protective measures: Prior to commencing work, disconnect the unit from the mains.
Opening the container
Figure (G)
How to proceed:
•Push back safety latch (36).
•Press the closing hook (35) inwards.
•Open and remove the clamping ring (10).
Closing the container
Figure (H, I)
How to proceed:
•Clean the channel (H 37) around the container rim.
•Grease the lid sealing ring (34) and place flush around the container (38) top edge.
•Press the filter lid (I 8) including the stack of foam filters on the container, if necessary, assist with your own body
weight.
•Place the clamping ring (10) around the container top edge (do not pinch the power cable) and assemble.
•Engage the closing hook (35).
•Push in the safety latch (36).
Cleaning the foam filters
The Easy-Clean function (actuate the cleaning handle and flush with water) allows easy cleaning of foam filters, UVC
unit and UVC water housing.
Figure (J, K, L)
How to proceed:
•Remove the closing cap from the drain hose or the dirty water drain socket (K 7). Attention: Do not lose the sealing
ring in the cap!
•Turn the function switch (5) counter-clockwise to "Cleaning foam filters" (41).
•Vigurously pull up the cleaning handle (3) several times, then push the handle down against the stop ("pumping"
action).
The foam filters will be rinsed by this action.

-EN -
15
•As soon as only clean water appears in the transparent hose connector (20), turn the function switch (5) counter-
clockwise to "Cleaning UVC" (L 42).
The UVC unit and the UVC water housing are flushed.
•As soon as only clean water appears in the transparent hose connector (20), turn the function switch (5) counter-
clockwise to "Filter water" (J 40).
The unit filters the pond water.
•Close the drain hose or the soiled water drain socket (7) using the closing cap (insert sealing ring!) (C 9).
Cleaning the quartz glass tube manually
Figure (E, F)
Attention! Dangerous electrical voltage!
Possible consequences: Death or severe injury.
Protective measures:
Prior to commencing work, disconnect the unit from the mains.
How to proceed:
•Switch off the filter pump.
•Remove the UVC unit head (Cleaning and maintenance\Removing/inserting the UVC unit head).
•Check the quartz glass tube (F 19) and O ring (32) for damage. Replace, if necessary.
•Clean the quartz glass tube externally using a moist cloth.
•Insert the UVC unit head (Cleaning and maintenance\Removing/inserting the UVC unit head).
•Switch on the filter pump.
•Switch on the UVC unit.
Cleaning the unit and washing or replacing the foam filters
Wear of the foam filters is caused by mechanical stress and normal ageing. OASE recommend: Replace old foam fil-
ters with new ones at the beginning of the new season.
Figure (M, N, O)
Attention! Dangerous electrical voltage!
Possible consequences: Death or severe injury.
Protective measures:
Prior to commencing work, disconnect the unit from the mains.
How to proceed:
•Switch off the filter pump.
•Remove all hoses, hose connections (M).
•Remove the UVC unit head (4) (Cleaning and maintenance\Removing/inserting the UVC unit head).
•Open the container (Cleaning and maintenance\Opening the container).
•Remove the lid including the stack of foam filters (N 39) and place on a soft clean surface such that the fixing disk
(15) of the stack of foam filters faces upward.
Disassembling the foam filters
•Check the foam filters, and either wash or replace.
•Remove the filter disk (N 15) after loosening and removing the two screws (43).
•Pull off the foam filters.
Cleaning the parts
Figure B
•Clean the container, clamping ring, lid (remove UVC unit head!) including UVC water housing (18) and the meshed
tube (17) from all anlges with a strong water jet.
•If necessary, wash the foam filters individually by vigurously compressing and releasing the filters under running water.
Assembling the foam filters:
Figure (P, Q)
•Alternately push the blue (14) and then the red (13) foam filter onto the cleaning rods (16), so that the cleaning rods
rest in the two cut-outs.
•Place the fixing disk (15) on the last foam filter such that the end collar (44) points to the foam filters.
•Fasten the fixing disk on the cleaning rods using the two screws (Q 43).
•Reinstate all connections (Assembly).

-EN -
16
Replacing the UVC lamp
Attention! Dangerous electrical voltage.
Possible consequences:
Death or severe injury.
Protective measures:
Isolate the unit prior to reaching into the water and carrying out any work on the unit.
Secure the unit from being switched on inadvertantly.
Attention! Breakable glass.
Possible consequences: Injury to your hands caused by cuts.
Protective measures: Handle the quartz glass and UVC lamp with care.
Note!
•Condensate forms in the quartz glass tube. This condensate cannot be avoided, however, it does not im-
pair function and safety.
•The quartz glass tube can become scratched or blind over time. In this case, sufficient cleaning perfor-
mance of the UVC lamp is no longer guaranteed. The quartz glass tube must be replaced.
•The UVC lamp must be replaced after approx. 8000 operating hours. Only use UVC lamps the designa-
tion and rating of which match the information on the type plate.
Figure (R, S, T, U, V)
How to proceed:
•Remove the UVC unit head (Removing/inserting the UVC unit head).
•Clean the quartz glass tube (R 19) externally using a moist cloth.
•Undo the fastening screw (46) from the retaining ring (45), and unscrew the retaining ring.
•Remove the quartz glass tube including the O ring (S 47).
•Pull the UVC lamp (T 49) out of the lamp base.
•Pull the transport securing elements (48 and 50) from the UVC lamp and push over the new UVC lamp.
•Insert the new UVC lamp.
•Place the quartz glass tube (U 19) over the UVC lamp (49) again.
•Push the O ring (47) and the retaining ring (45) over the quartz glass tube.
•Tighten the retaining ring by turning it up against the stop (51).
•Tighten the fastening screw (46) for the retaining ring (V).
•Reinsert the UVC unit head (Removing/inserting the UVC unit head).
•Switch on the pond pump.
•Connect the power plug of the UVC unit.
Decommissioning/Storage/Over-wintering
•Empty/drain the container, hoses and connections as much as possible.
•Clean thoroughly and check the unit for damage.
•Remove, clean, and store the filter lid with the UVC unit and all filter elements in a dry and frost-free place.
•Ensure that the storage place is inaccessible to children.
•Secure the installation place of the buried container such that it does not pose any risk of accident for persons or
animals.
Disposal
Support us in our endeavour to keep our environment intact, and adhere to the following disposal information!
Use our return system for disposal. Always make electrical
units unusable by cutting the cables!
Disposal with the household waste:
UVC unit (electronics!)
Packaging
UVC lamp (mercury!)
Worn foam filters, sealing rings
Filter container

-ES -
17
-ES -
Indicaciones sobre estas instrucciones de uso
Bienvenido a OASE Living Water. La compra del producto FiltoClear 3000/4000/8000 es una buena decisión.
Lea minuciosamente las instrucciones y familiarícese con el equipo antes de usar el mismo por primera vez. Todos los
trabajos en y con este equipo sólo se deben ejecutar conforme a estas instrucciones.
Tenga necesariamente en cuenta las indicaciones de seguridad para garantizar un uso correcto y seguro del equipo.
Guarde cuidadosamente estas instrucciones. Entregue estas instrucciones al nuevo propietario en caso de cambio de
propietario.
Símbolos en estas instrucciones
D
Los símbolos que se emplean en estas instrucciones de uso tienen el siguiente significado:
Peligro de daños a personas por tensión eléctrica peligrosa
El símbolo indica un peligro inminente que puede provocar la muerte o graves lesiones si no se toman las me-
didas correspondientes.
Peligro de daños de personas por una fuente de peligro general
El símbolo indica un peligro inminente
que puede provocar la muerte o graves lesiones si no se toman las me-
didas correspondientes.
Indicación importante para un funcionamiento sin fallos.
Uso conforme a lo prescrito
FiltoClear 3000/4000/8000en lo sucesivo, "el equipo", solo puede utilizarse de la siguiente manera:
•Para la limpieza mecánica y biológica de estanques de jardín
•Operación observando los datos técnicos.
Para el equipo son válidas las siguientes limitaciones:
•Está prohibido filtrar otros líquidos distintos del agua.
•No opere nunca sin circulación de agua.
•No emplee el equipo para fines industriales.
•No emplee el equipo en combinación con productos químicos, alimentos y sustancias fácilmente inflamables o ex-
plosivas.
¡Importante! Por ninguna razón se debe rebosar el filtro. Existe peligro de que se vacíe el estanque.
Uso no conforme a lo prescrito
Si no se cumplen las indicaciones contenidas en estas instrucciones de uso expira todo tipo de garantía y responsabi-
lidad y se pueden producir peligros para las personas.

-ES -
18
Descripción de la estructura del equipo y de su funcionamiento
Estructura del equipo
Ilustraci
ón (B)
Objeto
1
Racor de retorno del agua, para el retorno del agua de estanque purificada
2
Racor de entrada de agua, para la entrada del agua de estanque sucia
3
Empuñadura de limpieza, tirando hacia arriba se comprimen las esponjas de filtrado
4
Cabeza del equipo UVC con controlador de temperatura, soporte y mirilla para la lámpara UV-C. Desconexión automática de la lámpara
UV-C si está muy caliente, reconexión después del enfriamiento.
5
Conmutador de función para conmutar la circulación de agua. Girar en sentido antihorario Hay 3 posiciones.
I: Filtrar agua y radiar
II: Limpiar las esponjas ("Tecnología Easy-Clean")
III: Enjuagar el equipo UVC y la carcasa de agua UVC
6
Bypass, optimiza el efecto de la radiación UVC con una circulación alta
7
Racor da salida de agua sucia, para la salida del agua sucia
8
Tapa de filtro
9
Tapa de cierre con junta plana negra insertada
10
Anillo de sujeción, une la tapa de filtro y el recipiente
11
Escalón, para marcar la profundidad de montaje máxima
12
Recipiente, está bajo presión (máx. 2.9 psi / 0,2 bar)
13
Esponja de filtrado fina para nitrificación y desnitrificación
14
Esponja de filtrado gruesa para la nitrificación
15
Disco de fijación, mantiene las esponjas de filtrado en las barras de limpieza
16
Barra de limpieza, une la empuñadura de limpieza y el disco de filtrado
17
Tubo de rejilla, separa las esponjas de filtrado de la carcasa de agua UVC
18
Carcasa de agua UVC, guía el agua al equipo UVC
19
Tubo de cuarzo fundido con lámpara UV-C
Descripción del funcionamiento
Ilustración (A)
Una bomba de filtro (sólo incluida en el juego de suministro) presiona el agua en un recipiente hermético en el cual
pasa por diferentes fases de limpieza y retorna después al estanque. El agua sucia que surge durante la limpieza del
equipo se puede utilizar para fertilizar el jardín.
Ilustración (B)
Fase de limpieza “Filtrar”: El agua fluye por las esponjas de filtrado. Las esponjas de filtrado retienen la suciedad me-
cánica. Las partículas en suspensión y el cieno activado bajan al fondo del recipiente. Bacterias útiles habitan en las
esponjas de filtrado y limpian el agua de forma biológica. Su actividad empieza a partir de una temperatura del agua
de 50 °F (+ 10 °C).
Esponjas de filtrado gruesas (azul)
Esponjas de filtrado finas (rojo)
alta velocidad de circulación
más baja velocidad de circulación
Bacterias para la nitrificación
Bacterias para la nitrificación y la desnitrificación
Conversión de amonio ->nitrito ->nitrato
Conversión de nitrato ->nitrógeno
Fase de limpieza “Radiar”: El agua se somete a la luz ultravioleta de una lámpara UV-C. Las algas en suspensión se
destruyen y los agentes patógenos se eliminan.
Bypass: Un bypass garantiza que la radiación influya sólo en una parte del agua que retorna (aprox. 25 %) para lograr
una duración de la radiación suficiente también con una alta circulación.
Activador de filtrado: El equipo alcanza su pleno efecto limpiador biológico sólo después de algunas semanas. La adi-
ción de bacterias activadoras de filtrado acelera considerablemente la colonización de las esponjas de filtrado por bac-
terias de filtrado.

-ES -
19
OASE recomienda:
– como valor orientativo para los peces en el estanque: longitud de todos los peces en 260 gal (1 m3) de agua de
estanque máx. aprox. 2 ft (60 cm).
– como bomba de estanque para FiltoClear 3000: bomba max. 2100 Gph (8000 l/h).
– como bomba de estanque para FiltoClear 4000: bomba max. 2600 Gph (10000 l/h).
– como bomba de estanque para FiltoClear 8000: bomba max. 4200 Gph (16000 l/h).
Símbolos en el equipo
D
Los símbolos de aviso en el equipo tienen el siguiente significado:
Peligro de daños de personas si el equipo no se usa conforme a lo prescrito
El uso incorrecto del equipo puede provocar daños de personas o daños materiales. Es imprescindible
leer las instrucciones de uso antes de utilizar el equipo.
Peligro de daños de personas por una fuente de peligro general
Radiación UV-C peligrosa. Peligro para los ojos y la piel por deslumbrado. Operar la lámpara UV-
C sólo
en la carcasa.
DSímb ol os
Los símbolos de uso en el equipo tienen el siguiente significado:
Protegido contra el contacto con las partes peligrosas. Protegido contra chorros de agua.
Proteger contra la radiación solar directa.
Desinstalar en caso de heladas.
Emplazamiento
Ilustración (A)
Tenga en cuenta para su planificación:
– Distancia del equipo al agua: mín. 6.6 ft (2 m) (distancia de seguridad).
– No exponga el equipo a la radiación solar directa.
– Punto de retorno del agua. OASE recomienda: Tienda la manguera de retorno de forma que el agua purificada
retorne indirectamente al estanque, por ejemplo a través de un riachuelo, para que aumente el contenido de
oxígeno.
– Diferencia de altura entre la tapa de filtro y el punto de retorno del agua: máx. 6.6 ft (2 m)
Posibilidad de emplazamiento 1: Enterrar cerca del estanque.
Excave un hueco cerca del estanque y hunda el equipo hasta la marca (B 11).
Posibilidad de emplazamiento 2: Emplazar cerca del estanque
Coloque el equipo cerca del estanque de forma protegida contra inundaciones (p. ej. escondido detrás de arbustos).
La base debe ser estable y plana.
Conexión de una bomba de filtro
Para la operación del filtro de presión se requiere una bomba de filtro (sólo contenida en el juego de suministro). La
conexión a la bomba sólo es posible a través de mangueras de presión que están autorizadas como mínimo para 2.9
psi (0.2 bar) o la presión máxima de la bomba.
Al equipo se pueden conectar mangueras con un diámetro interior de 1 1/2" o 2".

-ES -
20
Montaje
Ilustración (C)
Al equipo se pueden conectar mangueras de 1 ½" o de 2". El suministro incluye las correspondientes boquillas de
mangueras. Recomendación: Utilice mangueras de 2" para transportar el agua por la tuberías con una pérdida de pre-
sión mínima.
En caso que emplee un activador de filtrado llene el recipiente con este agente antes de ejecutar los siguientes pasos
de montaje (puesta en marcha).
Montaje de la unidad de entrada del agua
Proceda de la forma siguiente:
•Ponga la tuerca racor (26) en la boquilla de manguera negra (22).
•Coloque la junta plana (27) en la tuerca racor (26).
•Fije la boquilla de manguera con la tuerca racor en el racor de entrada de agua (2).
•Coloque la abrazadera de manguera (29) en la manguera (30).
•Coloque la manguera en la boquilla de manguera (hasta el tope) y asegúrela con la abrazadera.
Montaje de la unidad de retorno del agua
Proceda de la forma siguiente:
•Coloque la tuerca racor (26) en la boquilla de manguera transparente (20).
•Coloque el medidor de paso (28) en la tuerca racor.
•Fije la boquilla de manguera con la tuerca racor en el racor de retorno de agua (1).
•Coloque la abrazadera de manguera (29) en la manguera (30).
•Coloque la manguera en la boquilla de manguera y asegúrela con la abrazadera. Deje el último segmento libre como
mirilla para la circulación y la suciedad (D).
Montaje de la unidad de salida de agua sucia
El agua sucia que surge durante la limpieza del equipo se puede utilizar para fertilizar. Recomendación: Conecte una
manguera de salida apropiada (no incluida en el suministro) y tiéndala hasta un punto adecuado (p. ej. un arriate).
Proceda de la forma siguiente:
•Desenrosque la tapa de cierre (9) del racor de salida de agua sucia (7).
•Coloque la tuerca racor (26) en la boquilla de manguera transparente (20).
•Coloque el medidor de paso (28) en la tuerca racor.
•Fije la boquilla de manguera con la tuerca racor en el racor.
•Coloque la abrazadera de manguera (29) en la manguera (30).
•Coloque la manguera en la boquilla de manguera y asegúrela con la abrazadera. Deje el último segmento libre como
mirilla para la circulación y la suciedad (D).
Cierre de la unidad de salida de agua sucia
Nota:
Durante el filtrado el racor de agua sucia (7) o una manguera (30) conectada en este racor siempre tiene que
estar cerrada con una tapa de cierre (9) con junta plana insertada. Esto evita una vaciado no intencionado
del estanque.
Proceda de la forma siguiente:
•Coloque la abrazadera de manguera (29) en la manguera (30).
•Ponga la boquilla de manguera (23) en la manguera y asegúrela con la abrazadera.
•Cierre la boquilla de manguera con la tapa de cierre y la junta plana insertada (9).
