Introduction
This manual helps you to use the Océ CS4236. The manual contains a description of
the product and guidelines to use and operate the Océ CS4236. There are also tips to
increase your knowledge of the product and to help you manage the workflow.
Definition
Attention Getters
Parts of this user manual require your special attention. These parts provide important,
additional information or are about the prevention of damage to your properties.
Note, Attention and Caution
The words Note,Attention and Caution indicate important parts.
The attention getters with the corresponding icons#
IndicatesIconWord
Additional information about the correct operation of
the product or a tip.
Note
Information to prevent damage, for example to the
product, an original or a file.
Attention
Information to prevent personal injury. Caution is
found only in manuals that describe physical products.
The Caution indication has several icons that warn
against various hazards. The icons are shown in the
table part below.
Caution
4
Notes for the reader

Contents
Chapter 1
About this Manual......................................................................................................7
About this Manual..............................................................................................8
Chapter 2
Overview of the Scanner...........................................................................................9
Overview of the scanner..................................................................................10
Chapter 3
Installation.................................................................................................................13
Installation........................................................................................................14
Chapter 4
Switch the scanner ON and OFF.............................................................................21
Main Power switch...........................................................................................22
Sleep and wake modes....................................................................................24
Chapter 5
Loading an original...................................................................................................27
Loading Originals into the scanner................................................................28
Chapter 6
Scan an original........................................................................................................33
Scan an original...............................................................................................34
Chapter 7
Maintenance..............................................................................................................39
Maintenance Overview....................................................................................40
Cleaning............................................................................................................42
Calibration - Scanner Maintenance program................................................49
Replacing the glass plate.................................................................................52
Downloading new firmware............................................................................60
Chapter 8
Océ Scanner Agent...................................................................................................63
Introduction......................................................................................................64
Installation of Océ Scanner Agent..................................................................65
Interface of Océ Scanner Agent......................................................................66
Chapter 9
Océ Scanner Maintenance.......................................................................................75
Installation of the software..............................................................................76
Océ Scanner Maintenance program...............................................................77
5
Contents

Chapter 10
Trouble Shooting......................................................................................................81
Trouble Shooting General...............................................................................82
Problems Related to Scanner Installation......................................................83
Problems Related to Operation of the scanner.............................................85
Problems Related to Scanning Results..........................................................86
Problems Related to Océ Copy Easy..............................................................87
Technical Assistance........................................................................................88
Chapter 11
Appendix...................................................................................................................91
Important safety instructions..........................................................................92
Regulations.......................................................................................................94
Reader's comment sheet ................................................................................96
Addresses of local Océ organisations ...........................................................98
6
Contents

Chapter 1
About this Manual
o

About this Manual
Introduction
This manual explains how to operate and maintain your Océ CS4236 scanner.
The manual assumes basic knowledge of your computer and operating system and does
not repeat material from their documentation.
This user's guide covers the following models:
■Océ CS4336 scanner
■Océ CS4336S scanner
■Océ CS4342S scanner
■Océ CS4354 scanner
Note:
The above model is ENERGY STAR® compliant.
Note:
Be sure to use the CD-ROM that came with your scanner or a newer version. Out-of-
date versions of Océ Scanner Agent software may not detect your scanner model.
Note:
Windows Compatibility - Your scanner and drivers are tested and developed to support
the most current active Microsoft Windows version OS systems. Drivers and interface
support in regard to specific Windows versions will follow the Microsoft Support Life
cycle Policy. The compatibility specifications can therefore change accordingly.
The most current OS compatibility specifications and drivers will be available on Océ's
website. See www.oce.com
Chapter 1 - About this Manual8
About this Manual

Chapter 2
Overview of the Scanner
o

Overview of the scanner
Introduction
Below: The parts, buttons and areas you need to recognize for using the scanner.
Scanner front view
#
Scanner front view
Scanner lid1
Release buttons for opening the scanner lid (for maintenance)2
Operator Panel3
Insert slot for document feeding4
Scanner bed - paper feed area5
Operators panel
#
Operators panel
Paper forward button1
Paper ready indicator2
Error indicator3
Chapter 2 - Overview of the Scanner10
Overview of the scanner

Operators panel
Power button and indicator4
One Touch buttons5
Paper backwards button6
Scanner backside view
#
Scanner backside view
Connection panel1
Release buttons for opening the scanner lid (for maintenance)2
Connection panel
#
Connection panel
USB interface connection1
4 Diagnostic LEDS (for reporting to service provider)2
Main power connection socket3
Main power switch4
Chapter 2 - Overview of the Scanner 11
Overview of the scanner

Chapter 2 - Overview of the Scanner12
Overview of the scanner

Chapter 3
Installation
o

Installation
Introduction
Follow the steps below for a quick and easy installation of your scanner and scanner
drivers.
Attention:
: Do not connect the scanner to the power or the PC.
Attention:
: You must install your scanner's drivers and tools before you connect the scanner or install
any scanner software applications.
Caution:
The scanner is equipped with a three-wire (pin) grounding type plug. If you cannot insert
the plug into your outlet, contact your electrician to replace the plug or outlet to ensure
a grounded power connection. Do not try to defeat or ignore the purpose of the
grounding-type plug.
System requirements
■PC or supported workstation.
■Compatible Windows operating system.
■Enabled USB port on your PC.
■Scanning software and/or compatible third party software.
Chapter 3 - Installation14
Installation

Installation step by step
#
RemarksAction
Note:
: DO NOT YET CONNECT
THE SCANNER TO POWER
OR PC.
Your scanner should be placed
either on the specially designed
stand-alone floor stand or on a
sturdy table. Make sure there is
enough space behind the scanner
to allow the media to run out.
1
Install drivers and tools on your
PC.
1.Insert the CD-ROM into your
PC. Normally the setup program
interface will start automatically.
If it does not, locate the set-
up.exe file on the CD and start
it manually.
2. Follow the instruction of the
wizard.
4. Remove the CD-ROM when
installation is complete.
2
Shut down the PC.
Your PC must be powered off
before connection with the
scanner.
3
Chapter 3 - Installation 15
Installation

RemarksAction
Disconnect the power plug.
Note:
This step is to ensure
your own personal safety
and to help protect your
device from potential
damage.
4
Clean the scanner feeding bed.
This is the flat surface in front
of the insertion slot. Wipe thor-
oughly so dirt and dust are not
dragged into the scan area with
the original.
5
Open the scanner lid. - Press the
lid release buttons.
The internal scan area should be
wiped clean for any dust accumu-
lated during packaging and
shipping. The scan area is under
the scanner lid so you have to
open it.
The scanner lid release buttons
are at the back of the lid.
1. Stand at the front of the scan-
ner.
2. Simultaneously slide the re-
lease buttons towards the scan-
ner's center with your fingers
until you feel them unlock.
3. Use your other fingers to grip
the edge of the lid.
6
Chapter 3 - Installation16
Installation

RemarksAction
Open the scanner lid. - Pull the
lid back.
Retain pressure on the lid release
buttons and your grip on the lid
edge as you pull the lid back-
wards towards your body.
Open the scanner lid all the way
back.
7
Clean the internal scan area.
Wipe the internal scan area free
of dust.
Use a dry cloth.
If you detect smudges on the
glass that cannot be wiped clean
with a dry cloth, refer to this
guide's section Cleaning the scan
area for instructions on thorough-
ly cleaning the scan area in con-
nection with scanner mainte-
nance.
8
Connect the interface cable to
the scanner.
Connect the B-connector (square
shaped end) to the USB connec-
tion socket on your scanner. The
USB connection socket is at the
scanner's back.
9
Connect the other end of the
interface cable to the PC.
Connect the A-connector end
(flat end) to a USB port on your
computer.
10
Chapter 3 - Installation 17
Installation

RemarksAction
Connect the power cable to the
scanner.
Connect the scanner power cable
to the scanner's main power
connection socket.
The main power connection
socket is at the scanner's back-
side.
11
Connect power to the wall out-
let.
Connect the other end of the
scanner power cable to the power
outlet.
Note:
The scanner is equipped
with a three-wire (pin)
grounding type plug. If
you cannot insert the
plug into your outlet,
contact your electrician
to replace the plug or
outlet to ensure a
grounded power connec-
tion. Do not try to de-
feat or ignore the pur-
pose of the grounding-
type plug.
12
Switch on the scanner.
Switch on the main power
switch at the back of the scanner.
13
Chapter 3 - Installation18
Installation

RemarksAction
Switch on your PC and start
Windows.
Windows will detect the new
hardware (scanner) during start-
up and the drivers you installed
in step 2. will be recognized.
Follow Windows' hardware in-
stallation instructions should any
appear on your screen.
14
Verify correct scanner installa-
tion:
1. Locate the scanner icon on the
Windows System Tray. This is
the Océ Scanner Agent program
icon.
2. Left-double-click on the Océ
Scanner Agent system program
icon.
3. Your scanner is installed and
detected if your scanner's name
appears at the top of the Océ
Scanner Agent system Status tab
dialog.
4. If the scanner was not in-
stalled correctly, a message will
inform you that your scanner
could not be detected.
If this is the case turn off power
to all connected devices and re-
peat the installation steps.
15
Lauch Océ Copy Easy.16
Chapter 3 - Installation 19
Installation

Chapter 3 - Installation20
Installation
