UNPACKING
After unpacking the unit, inspect carefully for any damage that may have
occurred during transit. Check for loose, missing, or damaged parts. If
any damage is observed, a shipping damage claim must be filed with the
carrier. DO NOT use the OEMTOOLS®Tool Cabinet or Tool Chest (or set) if
broken, bent, cracked or damaged parts (including labels) are noted. Any
Tool Cabinet that appears damaged in any way, operates abnormally, or is
missing parts should be removed from service immediately. If you suspect
that the Tool Cabinet was subjected to shock load (a load that was dropped
suddenly, unexpectedly, etc.), immediately discontinue use until it has been
checked by a factory authorized service center.
Please read and save these instructions. Read through this owner’s manual carefully before using product. Protect yourself and others by observing all
safety information, warnings, and cautions. Failure to comply with instructions could result in personal injury and/or damage to product or property. Please
retain instructions for future reference.
The following safety information is provided as a guideline to help you operate your Tool Cabinet under the safest possible conditions. Any tool or piece of
equipment can be potentially dangerous to use when safety or safe handling instructions are not known or not followed. The following safety instructions
are to provide the user with the information necessary for safe use and operation. Please read and retain these instructions for the continued safe use
of your Tool Cabinet. Failure to follow instructions listed below may result in serious injury. In addition, make sure that anyone who uses the equipment
understands and follows these safety instructions as well.
Operating Instructions and Parts Manual 24733, 24734, 24735, 24736, 24737, 24738
FOR CUSTOMER SERVICE
Technical Question?
CALL 1-866-458-2472
[email protected]
1
8/19
2019 OEMTOOLS®
WARNING
Blue
24735 Combo
24734 Chest
24733 Cabinet
Black
24738 Combo
24737 Chest
24736 Cabinet
57" CHEST AND CABINET SETS
Thank you very much for choosing an OEMTOOLS®Product!
For future reference, please register your new tool at www.oem-tools.com and complete the owner’s record below:
Model: _______________ Purchase Date: ___________
Save the receipt, warranty and these instructions. It is important that you read the entire manual to become familiar with this product before you begin using it.
This product is designed for certain applications only. OEMTOOLS®cannot be responsible for issues arising from modification. We strongly recommend that this
product is not modified and/or used for any application other than that for which it was designed. If you have any questions relative to a particular application, DO
NOT use the product until you have first contacted customer service to determine if it can or should be performed on the product.
Explanation of Safety Signal Words
WARNING:Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.
CAUTION:Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury.
CAUTION:Used without the safety alert symbol indicates a potentially hazardous situation which, if not avoided, may result in property damage.
NOTES:Provide clarity and helpful information.

2
Operating Instructions and Parts Manual 24733, 24734, 24735, 24736, 24737, 24738
8/19
2019 OEMTOOLS®
57" CHEST AND CABINET SETS
IMPORTANT INSTRUCTIONS
AND SAFETY RULES
1. Know your product. Read this manual carefully. Learn the product’s
applications and limitations, as well as potential hazards specific to it.
2. Maintain labels and nameplates on this product. These carry
important information. If unreadable or missing, contact
OEMTOOLS®for a replacement.
3. Keep work area clean and well lit. Cluttered or dark work areas
invite accidents.
4. Keep children away. All children should be kept away from the
work area. Never let a child handle this product without strict adult
supervision.
5. DO NOT operate this product if under the influence of alcohol or
drugs. Read warning labels on prescriptions to determine if your
judgment or reflexes are impaired while taking drugs. If there is
any doubt, DO NOT attempt to operate.
6. Use safety equipment. Eye protection should be worn at all times
when operating this product. Use ANSI approved safety glasses.
Everyday eyeglasses are NOT safety glasses. Dust mask, non-skid
safety shoes, hard hat or hearing protection should be used in
appropriate conditions.
7. Wear proper apparel. Loose clothing, gloves, neck-ties, rings,
bracelets or other jewelry may present a potential hazard when
operating this product. Keep all apparel clear of the product.
8. DO NOT overreach. Keep proper footing and balance at all times
when operating this product.
9. Check for damage. Check your product regularly. If part of the
product is damaged, it should be carefully inspected to make sure
that it can perform its intended function correctly. If in doubt, the
part should be repaired. Refer all servicing to a qualified technician.
Consult your dealer for advice.
10. Keep away from flammables. DO NOT attempt to operate this
product near flammable materials or combustibles. Failure to
comply may cause serious injury or death.
11. Store idle product out of the reach of children and untrained persons.
This product may be dangerous in the hands of untrained users.
12. Maintain product with care.
13. Keep product dry and clean.
14. DO NOT use a damaged product. Tag damaged products “DO NOT
USE” until repaired.
15. Check for misalignment or binding of moving parts, breakage of parts,
and any other condition that may affect the product’s operation.
16. Use only accessories that are recommended by the manufacturer
for your model. Accessories that may be suitable for one product
may become hazardous when used on another product.
17. If damaged, have the product serviced before using. Many
accidents are caused by poorly maintained products.
18. Product service must be performed only by qualified repair
personnel. Service or maintenance performed by unqualified
personnel could create a risk of injury.
19. When servicing a product, use only identical replacement parts.
Use of unauthorized parts or failure to follow maintenance
instructions could create a risk of injury.
20. Maintain a safe working environment. Keep the work area well lit.
Make sure there is adequate surrounding workspace. Keep the
work area free of obstructions, grease, oil, trash, and other debris.
DO NOT use this product in a damp or wet location.
21. Avoid accidental fire and/or explosion. DO NOT smoke near engine
fuel and battery components.
22. We believe the information contained herein to be reliable.
However, general technical information is given by us without
charge and the user shall employ such information at their own
discretion and risk. We assume no responsibility for results or
damages incurred from the use of such information in whole or in
part. Always refer to specific instructions and technical information
supplied by vehicle manufacturer.
PRODUCT DESCRIPTION
The OEMTOOLS Professional Series Chest and Cabinet are designed to
provide mobile, secure tool storage.
PRODUCT WIDTH DEPTH HEIGHT WEIGHT
24734 / 24737 Chest
57" 24" 24.8" 379.2 Lbs.
24733 / 24736 Cabinet 57" 24" 48.7" 476.2 Lbs.
Drawer Size Width (In.) Depth (In.) Height (In.) Volume
(Cu. In.)
# of
Drawers
Total Volume
(Cu. In.) Slide Capacity
Total Weight
Capacity
Narrow Shallow
22.4 22 2 986 4 3,942 120 Lbs. 480 Lbs.
Narrow Deep 22.4 22 3 1,478 1 1,478 120 Lbs. 120 Lbs.
Wide Shallow 27.1 22 2 1,192 4 4,770 120 Lbs. 480 Lbs.
Wide Deep 27.1 22 3 1,789 1 1,789 120 Lbs. 120 Lbs.
Total
10 11,979 1,200 Lbs.
24734 AND 24737 CHEST DRAWER DIMENSIONS AND SLIDE CAPACITY
Drawer Size Width (In.) Depth (In.) Height (In.) Volume
(Cu. In.)
# of
Drawers
Total Volume
(Cu. In.) Slide Capacity
Total Weight
Capacity
Narrow Shallow
22.4 22 3 1,478 3 4,435 120 Lbs. 360 Lbs.
Narrow Deep 22.4 22 9 4,435 1 4,435 240 Lbs. 240 Lbs.
Wide Shallow 27.1 22 3 1,789 5 8,943 120 Lbs. 600 Lbs.
Wide Deep 27.1 22 6.1 3,637 1 3,637 240 Lbs. 240 Lbs.
Full Length Drawer 49.5 22 3 3,267 1 3,267 120 Lbs. 120 Lbs.
Total
49.5 22 3 3267 11 24,717 1,560 Lbs.
24733 AND 24736 CABINET DRAWER DIMENSIONS AND SLIDE CAPACITY

3
Operating Instructions and Parts Manual 24733, 24734, 24735, 24736, 24737, 24738
8/19
2019 OEMTOOLS®
57" CHEST AND CABINET SETS
SPECIFIC SAFETY INSTRUCTIONS
CAUTION:DO NOT exceed drawer capacity rating (see chart in
Drawer Dimensions, Volume and Capacity section).
CAUTION:ALWAYS place heavier tools in the bottom drawers.
Overloading the top drawers may cause imbalance.
CAUTION:ALWAYS be cautious when maneuvering tool box
through the shop. Large obstructions, cracks in the floor, low ceilings,
etc. may cause the tool box to tip, which could lead to property
damage and/or personal injury
CAUTION:ALWAYS be cautious of pinch points between the
drawers, and top and bottom unit. Never place fingers or extremities
in the drawers while the cart is moving. Keep extremities clear of the
edges of the drawers, openings, and drawer slides when opening or
closing drawers.
CAUTION:ALWAYS lock the casters after moving the units.
CAUTION:ALWAYS be cautious when opening drawers and the
top lid after periods of storage and/or moving the unit. Tools may shift
the drawers and cause unsafe conditions, such as falling tools, pinch
points, and jammed drawers.
TOOL CABINET ASSEMBLY
1. Position the handle into the designated openings.
2. Secure the handle into place using the provided hardware.
REMOVING THE DRAWERS
1. Fully extend the empty drawer.
2. While pushing the release lever up on the left side of the drawer,
pull down the release lever on the right side of the drawer.
REINSTALLING THE DRAWERS
1. Fully extend the empty drawer slides.
2. Insert the brackets on each side of the drawer into the slots on the
slides, being careful that they are properly positioned.
3. Once inserted, close the drawer completely to set the slides properly.
NOTE:DO NOT force the drawers into place; if the drawer gets
stuck, remove and reinstall.
MAINTENANCE
1. Periodically tighten all hardware.
2. Lubricate the drawer slides twice a year.
3. Lubricate the lock with graphite each year.
4. Use a damp microfiber cloth to clean all surfaces.
DRAWER LOCKING MECHANISM
CAUTION: OEMTOOLS will not cover damage to locking tabs, nor
will provide replacement drawers. If safety instructions and the locking
instructions below are followed, the locking mechanism will remain fully
functional. OEMTOOLS is not responsible for damage caused by user
negligence or failure to read and understand the instructions provided in
this manual. A drawer will never be difficult to close unless there is an
obstruction. If the drawer will not close easily, reopen the drawer, check
for obstruction or damaged/worn slides, NEVER slam the drawer shut.
CAUTION: DO NOT slam the drawer closed if the tubular lock has
been engaged. This may cause damage to the internal locking mechanism.
NOTE:It is recommended that you unlock the tubular lock, before
attempting to close any open drawers; however, if you press the
drawer in the drawer will lock.
NOTE:If the drawer was slammed while the locking mechanism
was engaged, and damage to the mechanism is suspected, follow
instructions provided in this manual to remove the drawer. Inspect the
locking tab for damage. Use a screwdriver to straighten the tab.
CHESTS
TROLLEYS
TROLLEYS
SIDE HANDLE
a. Fixed the side handle with screw
b. Must be fixed on the same side as swivel caster.
CASTER
a. Fixed casters, swivel casters.
b. swivel caster must be fixed on the same side.
Chests that have no front locking panel are equipped with a locking mechanism actuated by the lid. When the lid is
closed, tabs in the lock bar engage the pockets on the drawer. When lid is open, tabs are raised clear of pockets.
Locking mechanism used on trolleys is engaged by rotaing cam lock with a key.
Lock pocket
Lock bar tab
Drawers must be fully closed before lid is shut. DO NOT slam the drawers when lid is shut as they will not
lock and slight damage to lock bar tabs or lock pockets may occur.
Should this happen, remove drawer and with a screwdriver straighten out the deformed tab; for lock
Pockets, a pairs should be used.
Drawers should be fully closed before locking mechanism is engaged.
Drawers that are not fully closed after locking mechanism has been
engaged, just close it and will be locked auto.
ATTENTION:
HOW TO REMOVE DRAWERS
LUBRICATION
HOW TO RE-INSTALL DRAWERS
Pull the slide out then match the track and push in.
TOOL CHESTS & TROLLEYS Please read these instructions carefully.
Drawer sliders have a black retaining clip. To
remove drawer, the retaining clips on sliders need to
be released by pushing lever up (Left Hand Side of
Sliders) and down (Right Hand Side of Sliders)
simultaneously, and sliding drawer out.
1. During the installing the drawer, it is regular that you will fell tight when you push in the drawer.
2. Please push the drawer into the end and pull out for 2-3 times to check whether the drawer is
moved smoothly or not.
a. if the drawer moves un-smoothly or tight, even jams up, it means you are failed to install the
drawer, pls. take out drawer and install again.
b. if the drawer moves smoothly, it means you are successful to install the drawer.
Lever Retaining Clip
It is important for the smooth operation of the sliders to lubricate them periodically with a light grease or petroleum jelly.
This should be done at least twice a year or more frequently depending on usage.
Left Hand Side
of Slide, Pushing
Lever Up
Right Hand Side,
Pushing Lever down
CHESTS
TROLLEYS
TROLLEYS
SIDE HANDLE
a. Fixed the side handle with screw
b. Must be fixed on the same side as swivel caster.
CASTER
a. Fixed casters, swivel casters.
b. swivel caster must be fixed on the same side.
Chests that have no front locking panel are equipped with a locking mechanism actuated by the lid. When the lid is
closed, tabs in the lock bar engage the pockets on the drawer. When lid is open, tabs are raised clear of pockets.
Locking mechanism used on trolleys is engaged by rotaing cam lock with a key.
Lock pocket
Lock bar tab
Drawers must be fully closed before lid is shut. DO NOT slam the drawers when lid is shut as they will not
lock and slight damage to lock bar tabs or lock pockets may occur.
Should this happen, remove drawer and with a screwdriver straighten out the deformed tab; for lock
Pockets, a pairs should be used.
Drawers should be fully closed before locking mechanism is engaged.
Drawers that are not fully closed after locking mechanism has been
engaged, just close it and will be locked auto.

4
Operating Instructions and Parts Manual 24733, 24734, 24735, 24736, 24737, 24738
8/19
2019 OEMTOOLS®
57" CHEST AND CABINET SETS
Replacement Part # Description Qty.
24735E Locking Swivel
Casters 2
24738E
24735F Fixed Casters 2
24738F
24735G Keys 2
24738G
24735H Drawer Slides 2
24738H
24735I Gas Struts 2
24748I
Figure Description Qty.
A
Cabinet (24733 / 24736) 1
B Chest (24734 / 24737) 1
C Top Till 1
D Cabinet Handle 1
E Locking Swivel Casters 2
F Fixed Casters 2
G Keys (Not Depicted) 2
PARTS LIST
PRODUCT LAYOUT
CONTACT US
3580 E. Raines Road, Suite 3, Memphis, TN 38118
Tel: [phone]
www.oem-tools.com
OEMTOOLS®3 YEAR WARRANTY
For up to three years from the date of purchase of this OEMTOOLS®product, if you find any defect in material or workmanship (through normal
usage), return it to the place of purchase or to OEMTOOLS®for repair or replacement at our discretion. In order to obtain this service, send your
tool and proof of purchase (transportation pre-paid) to:
OEMTOOLS®Q.A. Dept., 3580 E. Raines Road #3, Memphis, TN 38118.
We will not be responsible for lost or damaged goods during transportation; please insure your package. If our inspection verifies the defect,
we will either repair or replace the product, or we may elect to refund the purchase price if we cannot readily and quickly provide you with a
replacement. We will return repaired products at our expense, but if we determine there is no defect, or that the defect resulted from causes
not within the scope of our warranty, then you must bear the cost of returning the product.
OEMTOOLS®does not provide warranty for products labeled other than OEM® or OEMTOOLS®. OEMTOOLS®will not provide any warranty
for products subjected to abnormal use. Abnormal use includes (but is not limited to) abuse, accident, alteration, neglect, and unauthorized or
unreasonable use or repairs. This warranty does not cover bits, blades, files, batteries, or calibration. We recommend that you maintain your
tools and sharpen or replace blades, bits, files, and batteries as necessary. OEMTOOLS®reserves the right to make any changes in construction
or design at any time without any obligation in incorporating such changes to tools or equipment previously sold.
OEMTOOLS®makes every effort to ensure that its products meet high quality and durability standards, and warrants to the original purchaser
that this product is free from defects in materials and workmanship for the period of three years from the date of purchase. This warranty does
not apply to damage due directly or indirectly to misuse, abuse, negligence or accidents, repairs or alterations outside our facilities, criminal
activity, improper installation, normal wear and tear, or to lack of maintenance.
We shall in no event be liable for death, injuries to persons or property, or for incidental, contingent, special or consequential damages arising
from the use of our product. Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above
limitation of exclusion may not apply to you. THIS WARRANTY IS EXPRESSLY IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED,
INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS. This warranty gives you specific legal rights, and you may also have other
rights, which vary from state to state.
Don’t forget to register your new OEMTOOLS®product at www.oem-tools.com.
D
B
C
E
F
A
