OFFCARR TOP SPIN User manual

INSTRUCTIONS MANUAL
TOP SPIN
OFF CARR Srl Via Dell’Artigianato II, 29 – 35010 Villa del Conte (PD) Italy
Tel. ++39 049 9325733 Fax ++39 049 9325734
[email protected] - www.offcarr.com

2
2
GENERAL INFORMATIONS
WARNINGS
• Please read this manual carefully before carrying out any operation on
TOP SPIN wheelchair.
• Before use the device verify the package conditions (see par. Packaging, transport,
delivery and stocking in this manual).
• Every wheelchair is labelled with an Identification Number (Matricola), the
manufacturer address and CE mark. This label cannot be removed for any reason to
maintain trace-ability and guarantee terms of the device.
• TOP SPIN models are designed and produced to compensate a physical handicap
following 93/42/EEC EN Directive Medical Device Essential Requirements.
According with above Directive, appendix IX, par. III. 1.1., TOP SPIN 1 or TOP SPIN
2 are classified as non-invasive medical device of class 1.
• The use of TOP SPIN or its components is forbidden for any purpose other than
those indicated in this manual.
• For any problems or fault or breakage, please notify immediately to your supplier
reporting the following indications:
a. Model
b. Identification number (“Matricola” printed on the frame gold label).
c. Fault description
Packaging, transport, delivery and stocking.
All wheelchairs are shipped in a closed cardboard cases to protect them from knocks
and dust.
The package includes the wheelchair TOP SPIN 1 or 2 configured as per your request,
and this Instruction manual.
The wheelchair must be transported in trucks that protect it from atmospheric agents, as
indicated on the packing case.
Upon receipt, check the case integrity and in case of problems notify them on the waybill.
Open the package, remove the wheelchair and check if it is not bent or scratched or
damaged. In case of problems note your remark on the waybill and notify them
immediately to the forwarder company.
Once these checks have been carried out, place again the wheelchair in its package
keeping it in a dry place until it will be used.
Do not place any objects over the packing case.

3
3
INDEX
1. PRODUCT DESCRIPTION
2. WHEELCHAIR PREPARATION
3. SET-UP
4. HOW TO USE THE WHEELCHAIR
5. RISKS RELATED TO A MISUSE OF THE WHEELCHAIR
6. INSPECTIONS AND MAINTENANCE
7. GUARANTEE TERMS
8. WARRANTY CARD

4
4
1. PRODUCT DESCRIPTION
TOP SPIN 1
Top SPIN 1 is an ultra-light adjustable wheelchair with a rigid aluminium frame with 3+1
wheels, designed for all kind of tennis court .
Seat and backrest as well the footrest allow a wide range of set-up positions to satisfy
any athlete demand, and reach the convenient barycentre .
The rear wheels camber can be chosen from: 12°, 15° , 18°or 20°.
Rear wheels with a quick release axle can be chosen at the purchasing time between 24”,
26” .
The backrest is available in different heights and can be chosen rigid or foldable to reduce
the volume during transport.
Frame and upholstery can be supplied in different colours.
TOP SPIN 2
Top SPIN 2 is an ultra-light wheelchair with a rigid aluminium frame, specially dedicated
to expert or professional tennis-players.
The footrest can be adjusted in several positions to follow the natural athlete’s leg and
feet position.
The anti-tip device can be easily adjusted to exalt the athlete performances on every
kind of tennis court.
Seat and backrest set-up, as well rear wheels camber, dimension and balancing position
must be chosen at the purchasing time.
Rear wheels are supplied with a quick release axle and the backrest can be requested
pulling down to minimize volume during transport.
Frame and upholstery can be supplied in different colours.

5
5
2. WHEELCHAIR PREPARATION
HOW TO PREPARE THE WHEELCHAIR FOR USE
The wheelchair is shipped with detached rear wheels and folded down backrest when
available.
The backrest can be unfolded rotating it backwards until the blockage pins snaps inside
their hubs.
Assembly the rear wheels to the frame, inserting the quick release axle in the relevant
hubs, keeping the push-button pressed down until the wheels are properly in place.
Verify if the wheels are correctly hooked by trying to pull-out the wheels without pushing
the axle button.
Adjust the anti-tip device according to the ground court characteristics.
For TOP SPIN 1 the anti-tip device is normally supplied with a 2cm space from 3”
wheel to ground. This distance can be adjusted changing the spacer position on the
anti-tip wheel axle as per Fig. 6
For TOP SPIN 2 the anti-tip device housed in a telescopic support, can be easily
adjusted any time without need of extra tools.
Adjust if necessary the footrest position, see Fig. 1
If requested, assembly the supporting handle, see Fig. 7 and Fig. 8
The wheelchair is now ready to be used.
If further adjustments are needed to fulfil the user requirements,
contact your dealer or other qualified person.

6
6
3.
3.3.
3. SET-UP
3.1. FOOTREST DEPT AND HEIGHT ADJUSTMENT (Fig. 1)
Footrest can be adjusted in depth and height acting as follow:
• Remove the screws that hold the foot-plate to the frame.
• Identify the desired foot-rest position in height, depth and tilt.
• Replace and tight properly the fixing screws.
• Adjust properly the foot holding belts
3.2. BACKREST HEIGHT ADJUSTMENT (Fig. 2)
At the purchase time the backrest height has been selected but further adjustments are
still available:
• Lift-up the front side of the backrest upholstery.
• Remove the two screws releasing the telescopic tubes inserted on the backrest
frame.
• Move up or down the two tube according with your wishes (the tubes are pre-
holed with steeps of 2 cm).
• Replace and tight the two fixing screws.
• Fold-down the back upholstery.
3.3. BACKREST UPHOLSTERY TENSION ADJUSTMENT (Fig. 3)
The backrest upholstery tension can be easily adjusted by some Velcro straps inside
the upholstery.
• Lift-up the front side of the backrest upholstery.
• Stretch or loos the Velcro-straps according to your need.
• Fold down the backrest upholstery .
3.4. BACKREST TILT ADJUSTMENT (Fig. 4) (for models with foldable backrest
only)
To find a better seating position, is possible to change the backrest tilt as follow:
• Loose and remove the two screws that hold the backrest frame to safeguards.
• Choose the most convenient position from the three available in the safeguard.
• Replace the screws and tight them properly to allow the folding movement of
the backrest.
3.5. BARICENTRE SET-UP ADJUSTMENT (Fig. 5) (for TOP SPIN 1 only)
To obtain a better weight distribution on the wheels, is possible to modify the position
of the rear wheels axle compared to the seat:
• Loose and remove the screws that joint the two support bars with the seat and
loose the screw that fix the front seat supports.
• Slide the seat forward or backward as you desire, paying attention to the seat
inclination.
• Replace the screws of the back bars support than tight the screw of the front
seat support bars.
• Also the seat tilt can be adjusted operating on the seat support bars.

7
7
4.
4.4.
4. HOW TO USE THE WHEELCHAIR
For a safe end efficient use of the wheelchair on the tennis court, please consult
qualified persons.
4.1. Be sure the anti tip device is properly placed before to start using the wheelchair.
4.2. It is suggested to keep the legs surely fixed in position using if necessary also an
additional Velcro belt.
4.3. An additional safety belt can be used to ensure the athlete stability on the seat.
5.
5.5.
5. RISKS RELATED TO A MISUSE OF THE WHEELCHAIR
5.1. Risk of personal injure due to a lack of maintenance of the device.
5.2. Risk of personal injure due to an incorrect set-up of the wheelchair.
5.3. Risk of falling down if the anti tip device (when removable) is not properly placed.
5.4. Risk of falling down if the quick release axles of the rear wheels are not properly
placed and regularly maintained.
6.
6.6.
6. INSPECTIONS AND MAINTENANCE
6.1. Avoid extended contact of the wheelchair with water to prevent undesired frame
oxidation.
6.2. Avoid contact of the wheelchair with salt water or sea sand. In case clean with tap
water the wheelchair and wipe it immediately.
6.3. Keep the wheelchair far from fire or high temperature sources. The upholstery is
not fireproof.
6.4. Check the tyres pressure once a week.
6.5. Clean the wheelchair at least every three months.
6.6. Check every three months the fixing status of all the screws.
6.7. Check every three months the smooth running of the ball bearings of the wheels.
6.8. If necessary contact a qualified person for part replacement or extraordinary
maintenance.

8
8
7.
7.7.
7. GUARANTEE TERMS
7.1. The frame is guaranteed for three years from the delivery date of the wheelchair.
7.2. Parts subject to normal wear are not covered by the guarantee, unless wear is
caused by a manufacturing fault.
7.3. The guarantee does not cover transport.
7.4. If a fault occurs during the guarantee period, OFF CARR will:
a) Repair the faulty part
b) Replace the faulty part
7.5. The guarantee does not cover damage caused by negligence, improper use,
mishandling or incorrect maintenance by unauthorised personnel or by the user.
7.6. OFF CARR is not responsible for damages caused during transport. The
forwarder company is the only responsible, therefore please inform both the
forwarder company and OFF CARR of any damage that has been caused by the
transport.
7.7. This guarantee does not cover injury or others damages eventually related to a
malfunctioning of the wheelchair.
7.8. The identification number label must never be removed from the wheelchair
frame, otherwise the guarantee is no longer valid.
8.
8.8.
8. WARRENTY CARD
To fill in and forward within 10 days from the receiving of the device
Surname …………………………………………………………………………...
Name ……………………………………………………………………………….
Address …………………………………………………………………………….
……………………………………………………………………………………….
Telephone number ……………………………………………………………….
WHEELCHAIR MODEL : TOP SPIN 1 TOP SPIN 2
Supplier …………………………………………………………………………….
Purchase date …………………………………………………………………….
Frame Identification Number …………………………………………………….
Year ………………………………………………………………………………...
All the information will be treated in accordance with Privacy Tutelage Regulation in
force in Italy.
