OfficeSource PL178L User manual

OFFICE FURNITURE
MODEL NO. PL178L/R
OFFICESOURCE.COM Last Updated: 7/2022
ASSEMBLY INSTRUCTIONS
Remove all wrapping materials, including staples & packing straps before you start to assemble.
Do not tighten any screws or bolts until the unit is completely assembled.
Remove all wrapping materials, including staples & packing straps before you start to assemble.
Do not tighten any screws or bolts until the unit is completely assembled.
Place all wooden parts on a clean and smooth surface such as a rug or carpet to avoid the parts fromPlace all wooden parts on a clean and smooth surface such as a rug or carpet to avoid the parts from
Please follow these instructions for easy assembly.
Thank you for purchasing the Office Source Bow Front Pork Chop Desk.
Side Panel #A
KLIX CAM INSTRUCTIONS
being scratched.being scratched.
Keep all hardware parts out of reach of children.
Check that you have all parts and hardware.
Keep all hardware parts out of reach of children.
Check that you have all parts and hardware.
IMPORTANT !!IMPORTANT !!
Klix Cam
16 Pcs
A
Cam Lock
16 Pcs
21
Back PanelTop Panel
B C
Housing
Cap (Long)
9 Pcs
3 54
Housing
Cap (Short)
7 Pcs
PORKCHOP CRED
Side Panel #B Side Panel #C
D E
6 Hole
L-Bracket
5 Pcs
6
Adjustable
Glide
5 Pcs
7
PL 178L/R GG
Screw
#6 x 58"
30 Pcs
Insert the cam with the arrow
pointing towards the hole in the
edge.
Line up Cam Lock,
turn clockwise.
1 2
Insert the Cam Lock into Klix
Cam. Turn Klix Cam to lock.
3
9
M4 x 65
Allen-Key
1 Pc
PAGE 1 OF 2
®

OFFICE FURNITURE
MODEL NO. PL178L/R
OFFICESOURCE.COM Last Updated: 7/2022
ASSEMBLY INSTRUCTIONS
Attach Housing Cap(3 or 4) to all
Klix Cam(2) by pushing neck
thought center of cam.
Screw Adjustable Glide(5) into
bottom of Side Panel.
4
3
43 or
5
1
B
E
D
C
Attach the L-Bracket(6) to Top
Panel(A), Back Panel(B) and
Side Panel(C,D) as shown.
Tighten Screw(7) securely.
7
6
Attach Back Panel(B) and 3 Side
Panel(C,D,E) to the Top Panel(A) by
using Cam Lock(1) and Klix Cam(2).
TOP
D
B
2
A
C
E
Attach the 3 Side Panel (C,D,E) to the
Back Panel (B) by using Cam Lock (1)
and Klix Cam (2)
PORKCHOP CRED
PL 178L/R GG
PAGE 2 OF 2
®
