OfficeSource PLTECAB6078ECOWF User manual

OFFICESOURCE.COM
Last Updated: 03/2023
MODEL NO. PLTECAB6078ECOWF
ASSEMBLY INSTRUCTIONS
Before assembly, please remove all parts from the carton, verifying that you have the correct quantities, and read all the instructions.
1 of 5
®
ASSEMBLY INSTRUCTIONS
MODEL: PLTECAB6078ECOWF
!ATTENTION !
Ensure all bolts and screws are tightened, check bolts and screws every 6 months.
If any parts are missing, broken, damaged or worn, stop use of product until repairs have been made using factory authorized parts.
Failure to follow these warnings may result in injury.
ASSEMBLY INSTRUCTIONS
Last Updated: 02/2021

OFFICESOURCE.COM
Last Updated: 03/2023
MODEL NO. PLTECAB6078ECOWF
ASSEMBLY INSTRUCTIONS
2 of 5
®
ASSEMBLY INSTRUCTIONS
MODEL: PLTECAB6078ECOWF
Parts List
No. Name Drawing QTY
aColumn 3
bRight Trunk 1
cLeft Trunk 1
dInner Trunk 1
eSide Support 1
fFeet 2
gCenter Post Bracket (Right) 1
hCenter Post Bracket (Left) 1
iCenter Post Bracket (Rear) 1
jCenter Post Base 1
kDesk Top Support Bracket 1
lController 1
mExtension Cable 200cm 1
nHandset 1
oScrew M6x10 8
pScrew M5x6 4
qScrew 4x5 2
rScrew M10x35 8
s Screw M10x20 4
tScrew 5x22 39
uScrew 3x19 2
v4 Allen Key 4 1
v5 Allen Key 5 1
v8 Allen Key 8 1
wGlide 5
xPower Cable 1
v4
o
Step.1
Step.2
Place the Table Leg Frame on the
bottom side of the table top.
a
a
a
e
e
b
l
dd
i
c
gh
o
qq h
p
oo
h
p
Last Updated: 02/2021

OFFICESOURCE.COM
Last Updated: 03/2023
MODEL NO. PLTECAB6078ECOWF
ASSEMBLY INSTRUCTIONS
3 of 5
®
ASSEMBLY INSTRUCTIONS
MODEL: PLTECAB6078ECOWF
Detail A
Extend the trunk to fit table size.
Detail B
A
B
Step.3
Step.4
Put Handset's connecting
line through the hole
below the Left Trunk.
90° 120°
Customized Option : Use Allen Key 4 to Rotate Center Post Bracket
at the angle you want.
m
n
Last Updated: 02/2021

OFFICESOURCE.COM
Last Updated: 03/2023
MODEL NO. PLTECAB6078ECOWF
ASSEMBLY INSTRUCTIONS
4 of 5
®
ASSEMBLY INSTRUCTIONS
MODEL: PLTECAB6078ECOWF
Tighten up the screws.
Detail C
t
k
ww
j
sv5
w
x
w
u
f
r
v8
f
Step.5
Step.
6
C
r
Last Updated: 02/2021

OFFICESOURCE.COM
Last Updated: 03/2023
MODEL NO. PLTECAB6078ECOWF
ASSEMBLY INSTRUCTIONS
5 of 5
®
ASSEMBLY INSTRUCTIONS
MODEL: PLTECAB6078ECOWF
※ Important ※
Reset the table before use :
1. Press and hold ∧&∨for more than 3 seconds.
2. Continue pressing both buttons until both columns are in the lowest position.
3. The table will rebound 2-5mm.
4. Release the buttons, now the table is operational.
Step.7
S2 31 4
