Ohaus Corporation Model:..Defender Indicators T31P and T31XW
Application Note Description: ............Counting Mode setup & use
Updated: 10/25/2007 1of 3 Revision 01
Preparation
In the “Mode” menu turn on PCS
Note: The parts to be counted must be uniform in weight or there will be counting errors. The
parts should weigh at least 10 times the readability of the scale.
1. Press and hold “Menu” until the display shows “Menu” then release
2. He display will show “C.A.L”
3. Repeatedly press and release “No” Until the display shows “M.O.D.E”
4. Press and release “Yes”
5. Repeatedly press and hold “No” until the display shows “PCS”
6. Press and release “Yes”
7. If the display does not show “On” press and release “No” to change it to “On”.
8. Press and release ”Yes”
9. Press and release “Exit”
10. The scale will return to the “Weigh” mode.
To Use the Counting Mode.
Note: Parts counting must be turned on before it can be used.
Setting a new APW (Average Piece Weight).
1. Press and hold “Mode” until the display shows “Count” then release.
2. “CLr.PW” with an inverted triangle over “pcs” is displayed if an APW has already been
stored. If the display shows “Put10pcs” see Storing the first APW below.
3. Press and release “Yes” if you are going to count a new part. Press and release “No” if
you are going to count more of the parts you just counted.
4. Note: You can press and release the “Function Mode” button the see the stored APW.
5. If you pressed “Yes” the display will show “Put10pcs”. If you pressed “No” the display
will show 0

Ohaus Corporation Model:..Defender Indicators T31P and T31XW
Application Note Description: ............Counting Mode setup & use
Updated: 10/25/2007 2of 3 Revision 01
The display shows “Put10pcs”
1. You can change the number to 5, 10,
50, 100 or 200 by repeatedly pressing
and releasing “No”. When the number
you need is displayed put the number of
pieces on the platform and Press and
release “Yes”
2. The display will show the number of
pieces you must put on the pan. Place
that number on the pan and Press and
release “Yes”
3. If a container is to be used you can
place it on the platform and Press and
release tare any time.
4. You can now count bulk pieces
The display shows 0
1. Place your container on the platform
and Press and release “Tare”
2. Place the pieces to be counted in the
container.
Storing the first APW
1. The display shows “Put10pcs”
2. You can change the number to 5, 10, 50, 100 or 200 by repeatedly pressing and releasing
“No”. When the number you need is displayed put the number of pieces on the platform
and Press and release “Yes”
3. The display will show the number of pieces you must put on the pan. Place that number
on the pan and press and release “Yes”
4. If a container is to be used you can place it on the platform and press and release tare any
time.
5. You can now count bulk pieces

Ohaus Corporation Model:..Defender Indicators T31P and T31XW
Application Note Description: ............Counting Mode setup & use
Updated: 10/25/2007 3of 3 Revision 01
To reset the APW when changing to another part
1. Clear the pan
2. Press and hold the “Function-Mode” button until the display shows “Count” then release.
3. “Clr.PW” will be displayed.
4. Press and release “Yes”
5. “Put xxx” will be displayed
6. Continue as above
