Oki Pacemark PM4410 Mounting instructions

Tear Bar/Cutter Software Manual
59318001 my.okidata.com
RT322
RT322

Contents
1. Installing/Uninstalling.............................................................................................4
1.1 Installing (Windwos 2000/XP).................................................................................................................... 4
1.1.1 USB Interface .......................................................................................................................................................... 8
1.1.2 Non-USB Interface ................................................................................................................................................10
1.2 Installing (Windows Vista 32-Bit Edition).............................................................................................16
1.2.1 USB Interface ........................................................................................................................................................20
1.2.2 Non-USB Interface ..............................................................................................................................................21
1.3 Installing ( Windows Vista 64-Bit Edition ) ...........................................................................................25
1.3.1 USB Interface ........................................................................................................................................................26
1.3.2 Non-USB Interface ..............................................................................................................................................30
1.4 Uninstalling ....................................................................................................................................................36
1.4.1 Windows 2000/XP...............................................................................................................................................36
1.4.2 Windows Vista 32-Bit Edition ..........................................................................................................................37
1.4.3 Windows Vista 64-Bit Edition ..........................................................................................................................39
2. Features ..................................................................................................................... 43
2.1 RT322 Driver...................................................................................................................................................43
2.2 ..............................................................................................................44
2.3 Virtual Port Emulator...................................................................................................................................44
3. Windows 2000/XP/Vista Printer Driver Settings ......................................... 45
3.1 Setting the Printer........................................................................................................................................46
3.1.1 Print Mode .............................................................................................................................................................47
3.1.2 Paper Type ............................................................................................................................................................48
3.1.3 Page Cut Type (RT322 Cutter Model Only) ................................................................................................49
3.1.4 Document Cut Type (RT322 Cutter Model Only) .....................................................................................50
3.1.5 Document Feed Type (RT 322 Tear Bar Model Only) ..............................................................................51
3.1.6 Print Speed ............................................................................................................................................................52
3.1.7 Print Density..........................................................................................................................................................53
3.1.8 Vertical Mount (reverse printing) ..................................................................................................................54
3.1.9 Document Top Logo ..........................................................................................................................................55
3.1.10 Page Top Logo......................................................................................................................................................56
3.1.11 Page Bottom Logo..............................................................................................................................................57
3.1.12 Document Bottom Logo...................................................................................................................................58
3.1.13 Peripheral Unit Type...........................................................................................................................................59
3.1.14 Peripheral Unit 1..................................................................................................................................................60
2

3.1.15 Peripheral Unit 2..................................................................................................................................................61
3.1.16 Pulse Width for Cash Drawer 1 .......................................................................................................................62
3.1.17 Buzzer 1 On Time.................................................................................................................................................64
3.1.18 Buzzer 1 OFF Time...............................................................................................................................................65
3.1.19 Buzzer 1: Number of Times Buzzer Sounds................................................................................................66
3.1.20 Buzzer 2 On Time.................................................................................................................................................67
3.1.21
3.1.22 Buzzer 2: Number of Times Buzzer Sounds................................................................................................69
3.2 Setting the Paper Size.................................................................................................................................70
3.2.1 Standard Sizes ......................................................................................................................................................70
3.2.2 .............................................................................................................71
3.3 Device Fonts...................................................................................................................................................73
3.4 Control Fonts..................................................................................................................................................75
3.4.1 Control Font Characters and Their Operations ............................................................................................75
3.4.2 Using the Control Font......................................................................................................................................77
3.5 Barcode Fonts ................................................................................................................................................79
3.5.1 Barcode Font List.................................................................................................................................................79
3.5.2 Entering the Barcode Font...............................................................................................................................80
3.5.3 Using the Barcode Font.....................................................................................................................................82
3.6 Selecting the Print Color............................................................................................................................84
4. (Windows 2000 SP3 or Later/XP/Vista 32-Bit Edition).... 86
4.1 Printer Settings..............................................................................................................................................90
4.1.1 Memory SW Settings .........................................................................................................................................92
4.1.2 NVLogo ...................................................................................................................................................................94
4.1.3 Printer Tests ...........................................................................................................................................................97
4.1.4 Ethernet I/F Setup...............................................................................................................................................99
4.2 Application Settings................................................................................................................................. 105
4.2.1 Virtual Port Emulator ...................................................................................................................................... 106
4.3 Common Data ............................................................................................................................................ 109
4.3.1 Image List............................................................................................................................................................ 110
5. Guidelines for Printing Documents ...............................................................115
5.1 Notes for Printing via a Serial Interface ............................................................................................. 115
5.2 Notes for Using Microsoft Word........................................................................................................... 116
5.3 Restrictions and Precautions................................................................................................................. 118
3
68

1. Installing/Uninstalling
Before using the OKIPOS RT322 with Windows 2000/XP/Vista, you must rst install the driver.
e installation steps vary according to the operating system.erefore, refore to the section for the environment that you
are using.
1.1 Installing ( Windows 2000 / XP)
1.2 Installing ( Windows Vista 32-Bit Edition )
1.3 Installing ( Windows Vista 64-Bit Edition )
1.1 Installing (Windwos 2000/XP)
To install the driver, proceed as follows.
Important: When using a USB interface, turn on the printer’s power aer performing steps 1 to 8
1. For Windows XP click on OKIPOS RT322.msi setup le. For Windows 2000 select the appropriate
OKIPOS RT322.msi setup les depending on the Service Pack.( under Windows2000 SP2 / upper Windows2000 SP3)
2. e following window appears, and the wizard prepares to start the installation.
e time required for installation may be longer than usual depending on the environment used.
4

3. Click the [Next>] button to proceed.
4. Type your user information.
Aer typing your user name and the name of your organization and selecting whether the installed program is to
be available to all users of this computer or only to you, click the [Next>] button.
5

5. Select the type of setup.
Select Complete to install all of the program’s features, and then click the [Next>] button.
For Windows versions prior to Windows 2000 SP3, only the driver functions will be installed.
6. Click the [Install] button to begin the installation.
e program’s features are installed.
6

7. When the installation is complete, the Soware Installation conrmation dialog box will appear.
Click the [ Continue Anyway ] button.
8. e wizard has completed installation of the program.
Click the [Finish] button to close the wizard.
9. e remaining installation steps vary according to the type of interface.
Continue to add the printer according to the steps for the interface that you are using.
1.1.1 USB Interface
1.1.2 Non-USB Interface
7

3. In the following dialog box, select Install the soware automatically (Recommended), and then click the [Next>]
button.
1.1.1 USB Interface
To add a printer, proceed as follows.
1. Connect the printer, and then turn on the printer’s power switch.
e Plug and Play feature detects the connection of the printer hardware and automatically starts installing the driver
soware.
At this time, the following message will appear on the lower right of the Windows desktop.
2. In the following dialog box, select No, not this time, and then click the [Next>] button.
8

4. In the Hardware Installation dialog box, click the [Continue Anyway] button.
5. If installation was completed successfully, the following dialog box will appear.
Click the [Finish] button to complete the installation.
6. From the Windows Start menu, select Printers and Faxes and conrm that RT322 Cutter or RT322 Tear Bar appears
in the folder. If the appropriate printer appears there, installation was completed successfully.
9

1.1.2 Non-USB Interface
To add a printer, proceed as follows.
When using a TCP/IP interface, the port must be congured beforehand.
1. From the Windows Start menu, select Programs – Okidata – RT322 – Utility – Add Printer Wizard (RT322).
2. In the Add Printer Wizard dialog box, click the [Next>] button.
10

3. In the Local or Network Printer dialog box, select Local printer attached to this computer and uncheck Automatically
detect and install my Plug and Play printer. Click the [Next>] button to proceed.
4. In the Select a Printer Port dialog box, select the port to use, and then click the [Next>] button.
11

5. Select the printer to install, and then click the [Next>] button.
6. Specify the printer name that will be used aer installation in Windows-based programs. Type the printer name if you
wish to change it. Additionally, you may set the printer currently being installed as the default printer. Conrm the
settings, and then click the [Next>] button.
12

7. Make the appropriate printer-sharing settings, and then click the [Next>] button.
8. Select Yes to print a test page or No to not print one, and then click the [Next>] button.
Important: When using a serial interface, do not print the test page.
Conrm the printer and printer port settings when printing via a serial
interface. For details, refer to “5.1 Notes for printing via a Serial Interface” at
the end of the manual.
13

9. e settings are displayed. If the settings are correct, click the [Finish] button to add the printer
10. In the Hardware Installation dialog box, click the [Continue Anyway] button.
14

e les are copied.
11. From the Windows Start menu, select Printers and Faxes and conrm that RT322Cutter or RT322 Tear Bar appears in
the folder. If the appropriate printer appears there, installation was completed successfully.
15

1.2 Installing (Windows Vista 32-Bit Edition)
To install the driver, proceed as follows.
Important : When using a USB interface, turn on the printer’s power aer performing steps 1 to 9 .
1. Fom the Windows Startmenu, select Programs - Accessories , right-click Command Prompt, and then Run as
administrator.
2. At the command prompt, perform the OKIPOS Driverset msi installer as follows.
3. In the User Account Control dialog box, click the [Continue] or [Allow] button.
e following window appears, and the wizard prepares to start the installation.
e time required for installation may be longer than usual depending on the environment used.
4. Click the [Next>] button to proceed.
16

5. Type your user information.
Aer typing your user name and the name of your organization and selecting whether the installed program is to be
available to all users of this computer or only to you, click the [Next>] button.
6. Select the type of setup.
Select Complete to install all of the program’s features, and then click the [Next>] button.
17

7. Click the [Install] button to begin the installation.
8. In the soware installation conrmation dialog box, click Install this driver soware anyway to continue
with installation. e conrmation dialog box will appear multiple times.
18

9. e wizard has completed installation of the program.
Click the [Finish] button to close the wizard.
10. e remaining installation steps vary according to the type of interface.
Continue to add the printer according to the steps for the interface that you are using.
1.2.1 USB Interface
1.2.2 Non-USB Interface
19

1.2.1 USB Interface
To add a printer, proceed as follows.
1. Connect the printer, and then turn on the printer’s power switch.
e Plug and Play feature detects the connection of the printer hardware and automatically installs the driver
soware.
If installation was completed successfully, the following message will appear on the lower right of the Windows
desktop.
2. From the Windows Start menu, select Settings – Printers to display the printer setting dialog box.
Conrm that RT322 Cutter or RT Tear Bar appears in the folder. If the appropriate printer appears there, installation
was completed successfully.
20
