Oki B930 Series User manual

Setup Guide. . . . . . . . . . . . . . . 2
Guide d’installation . . . . . . . . 14
Guía de Instalación . . . . . . . . 27
Guia de Configuração . . . . . . 40

2
Check components_______
1Printer
2CD
3Image Drum Cartridge
4Toner Cartridge
5Power cable
6Documentation: (this Setup Guide, Handy
Reference Guide, Safety, Warranty, and
Regulatory Information booklet)
Installation Overview ____
• Space Requirements (see page 2)
• Set up the printer:
- Unpack the printer (see page 3
- If applicable, install the printer on one of the
optional trays (see page 3)
- Install the image drum and the toner
cartridge (see page 3)
- Load paper (see page 4)
• Install the options you purchased:
- Memory Modules (see page 5)
- Compact Flash (see page 5)
- Hard Disk Drive,(see page 5
- Tabloid Tray (see page 6)
- Tandem Tray (see page 6)
- Duplexer (see page 6)
- finisher (see page 8)
- High Capacity Feeder (see page 10)
• Make Computer Connections (see
page 11)
•Powerup(see page 12)
• Print the Demo page (see page 12)
•Loadsoftware(see page 12 [Windows] or
13 [Macintosh])
Space Requirements _____
Note: Space requirements are approximate.
Basic Printer
• Depth (1) = 46 inches (118 cm)
• Width (2) = 47 inches (120 cm)
• Height (3) = 27 inches (69 cm)
Printer with Options
• Depth (1): 46 inches (118 cm)
•Width(2):
- with High Capacity Feeder (HCF) = 47 inches
(118 cm)
- with finisher = 60 inches (153 cm)
- with HCF and finisher = 86 inches (218 cm)
• Height (3):
- with optional tray = 35 inches (89 cm)
- with finisher = 47 inches (119 cm)

3
Set Up the Printer _______
Unpack the Printer
1.Place the printer and any optional components
at your selected location.
Place the Printer on the Optional
Tray
1.If you purchased the optional Tabloid Tray (1)
or Tandem Tray (2), unpack the tray and
remove the cushioning materials.
2. Lock the casters on the tray.
3. Align the holes on the bottom of the printer
with the positioning guides on the tray, and
place the printer on the tray.
4. Remove the printer packing materials and
shipping tape.
Install the Image Drum and the
Toner Cartridge
1.Open the printer’s front cover and side cover.
A
A

4
2. Remove the image drum cartridge from the
package, then remove the protective sheet.
CAUTION! Avoid contact with internal
surfaces. Do not let the drum sit in room
light for more than 5 minutes.
3. Fold the handle (3) down and slide the image
drum Cartridge into the printer. Press the
cartridge firmly into the printer.
4. Remove and discard the protective strip.
5. Remove the toner cartridge from its packing
and shake it from side to side 8 to 10 times to
distribute the toner.
6. Slide the toner cartridge into the printer and
press it firmly in place.
7. Close the printer covers.
Load Paper
Trays 1 and 2
1.Pull out the tray(s).
2. Adjust the paper guides for the paper you are
using.
A

5
3. Fan the paper and add it to the tray, print side
up . Do not exceed the maximum level.
Caution! Align the right width guide with the
paper width correctly. If the right width guide is
not in place, the paper will not be properly fed
and may cause a paper jam.
4. Close the tray(s).
MP Tray (Tray 5)
1.Lower the MPT tray and adjust the paper
guides.
2. Fan the paper and add it to the tray, print side
down . Do not exceed the maximum level.
Install the Options You
Purchased
Install the Optional Memory,
Compact Flash, and/or Hard
Disk Drive (HDD)
1.Make sure the printer is turned off.
2. On the back of the printer, loosen the two
screws on the controller assembly cover, then
remove the cover.
3. Memory Modules: Carefully insert the
module in the slot at the lower left, then
gently push down on the module until the side
braces close to the ends of the RAM module.
4. Compact Flash: In a similar manner to the
memory module above, carefully insert the
Compact Flash module in the slot on the upper
right.
5. Hard Disk Drive: Insert the HDD into the
socket, being careful not to damage the fragile
pins.Seat the Hard Drive over the locating
pins and push firmly to secure the unit
6. Reinstall the cover, securing it with the
screws.

6
Finish the Optional Tabloid Tray
or Tandem Tray Installation
If you purchased the optional tabloid tray or
tandem tray and mounted the printer on it earlier
in the installation, you now need to complete the
installation.
1.Make sure the printer is turned off.
1.Open each drawer, remove the packing
materials, and close the drawer.
-Tabloid Tray
-Tandem, Tray
2. Remove drawer 3 from the printer. Insert the
two locking screws and turn them clockwise to
secure the tray to the printer.
3. Push the drawer back into the printer.
4. Remove the interface access cover (1) from
the back of the printer, connect the tray
interface connector (2) and replace the
interface access cover (3).
5. Level the unit.
Install the Optional Duplexer
1.Make sure the printer is turned off.
2. Unpack the duplexer (duplex unit [1] and exit
module [2]) and remove cushioning materials.
3. Pull the release button to open the front cover.
1
2
1
2
3

7
4. Remove the cover and save for possible reuse.
5. Slide the duplex exit module into position.
6. Close the front cover.
7. Insert the two hooks on the bottom of the
duplex unit into the printer’s receptors (1).
8. Lift the duplex Unit until the upper hooks are
latched in the printer.
9. Open the duplex unit cover by lifting the latch.
10.Twist the 2 locking screws clockwise to secure
the Duplex Unit to the printer.
11..Close the duplex unit cover
12.Remove the access cover from the back of the
printer (1), connect the duplex unit interface

8
cable (2) and replace the printer access cover
(3).
Install the Optional Finisher
1.Make sure the printer is turned off.
2. Unpack the finisher’s horizontal transport unit
and position it on top of the printer.
3. Insert the two mounting screws to secure the
horizontal transport unit.
4. If the duplexer is installed, the guides from
the printer itself must be moved to the
duplexer exit module.
The guides are two pieces of rubber and plastic
that assist in stacking to the top of the printer.
When installing the horizontal transport this
guide needs to be moved from the body of the
printer up to the exit module.
5. Place the mounting bracket in position and
insert the two mounting screws to secure it.
6. .Remove all the packing materials from the
finisher.
7. Slide the finisher into position engaging the
latching hardware.

9
8. Insert the Stacker Lower catch tray.
9. Remove the access cover and plug in the
finisher interface cable.
10.Remove the printer interface cover.
11.Connect the interface connector and replace
the cover.
12.Connect finisher power cord to the printer
accessory power connection.
13.Level the finisher making it parallel to the
printer.
14.Open the finisher door and remove the
internal tags and shipping brackets.

10
15.Move the catch to the right and insert the
staple module.
16.Unpack the paper punch waste container.
17.Insert the punch waste container and fully
seat it. Close the finisher door.
Install the Optional High
Capacity Feeder (HCF)
1.Make sure the printer is turned off,.
2. Unpack the HCF and remove the cushioning
materials.
3. Slide the drawer out and remove the packing
material, then close the drawer.
4. Install the mounting bracket.
5. Slide the HCF to the mounting plate guiding it
on the locating pin until it latches.
6. Remove the shipping hardware and discard.
