olympia electronics GR-427/12L/MAR User manual

Thank you for purchasing this product of
Olympia Electronics. A European
manufacturer.
GENERAL
These luminaires are suitable for marine and
offshore applications where emergency light
is needed. Each luminaire must be
permanently connected to mains power
supply.In normal operation the led strip lights
and the battery is charging. In case of a
mains power supply failure the luminaire will
light the led strip automatically in emergency
mode. When the mains power supply is
restored the device turns to normal operation.
INSTALLATION
To install the luminaire follow the installation
instructions on page 4.
Battery Charging
The battery charging is completely controled.
In this case, is achieved the perfect battery
maintenance , as well as the elongation of its
duration. When the battery has completely
charged, it charges with a maintenance
current.
Battery Cut-off
The luminaire enters in this operation when
the mains power supply fails and battery has
lost its energy. During this operation the
luminaire enters the idle state and battery
consumption is negligible, in order to be
protected from deep discharge.
Manual Test
The manual test can be conducted only if the
main power supply and the battery is
connected. By pressing the test button briefly
an operation test is initiated. During this test
period all indication LEDs are OFF.
Automatic Test
This test includes all the operations that
provide the manual test and is conducted
automatically every 15 days. In order to be
performed, the main power supply and the
battery should be connected.
Automatic Autonomous Test
The Automatic Autonomous Test is conducted
and measures the luminaire`s back up
operation. This test is conducted automatically
every six months. In order to be performed,
the main power supply and the battery should
be connected (the battery should be charged).
If the battery is not charged, the test is
postponed until the battery is completely
charged. If during the Automatic Autonomous
Test the luminaire’s duration is lower than the
nominal, then the battery must be replaced.
Back Up Operation
The autonomous duration of battery during
emergency mode is at least the one that is
923427002_09_002
Page 1 from 4
High Quality European based Manufacturers
GR-427/12L/MAR SELF TESTING MAINTAINED EMERGENCY LUMINAIRE
220-240V AC/50-60Hz
Bayblend FR3010, transparent polycarbonate
TECHNICAL CHARACTERISTICS
OPERATION TEMPERATURE RANGE
RELATIVE HUMIDITY
EXTERNAL DIMENSIONS
CONSTRUCTION MATERIALS
TYPICAL WEIGHT
GUARANTEE
OPERATION VOLTAGE
MAXIMUM POWER CONSUMPTION
BATTERY (Ni-Cd)
CHARGING TIME
INDICATIONS - CONTROLS
BATTERY PROTECTION
MINIMUM AUTONOMOUS DURATION
DEGREES OF COVER PROTECTION
PRODUCED IN ACCORDANCE WITH
ILLUMINATION (230V / EMERGENCY)
ILLUMINATION SOURCE 480 min
24h
Charge, lamp fault, fault indication LED, TEST button
From overcharge and full discharge
IP 42
12 white LED’s
5 to 40 C
o
Up to 95%
3 years (1 year for the battery)
272 x 121 x 50 mm
600gr.
85/85lm
3.6V/3Ah
3.5W / 7VA
EN 60598-1, EN 60598-2-22, ΕΝ 55015, ΕΝ 61547, ΕΝ 61000-3-2, ΕΝ 61000-3-3, IEC 60092-306, IEC 60533

Page 2 from 4
stated in the list of the first page. During
emergency mode, a LED strip test is also
performed.
Resetting Errors
Push the Test button for 5 seconds, to
extinguish all the indicated LED errors. Then
the luminaire enters regular operation mode.
Indication LED status (with connected
mains power supply).
Charge
On: Good charge current.
Οff: No battery (No charging current or
disconnected battery).
Lamp Fault
Οn: Faulty LED strip.
Off: Good LED strip.
Battery Fault
Οff:Battery OK.
Blink (With Charge LED ON): Autonomy or
low battery problem
(the battery must be replaced).
Blink (With Charge LED Off):
No charging current or disconnected battery.
ΑΤΤΕΝΤΙΟΝ!!!
1. Operations for installation, maintainance or
testing must be done by authorized personel
only.
2. The device must be connected to the mains
power supply through a fuse dependent by the
total amount of the line’s power load.
In case of battery or light source replacement,
these must be replaced by parts of the same
type, by the manufacturer or by a competent
person.
t i
in battery recycling
points. Do not incinerate.
3.
4. In case of inactive use for a period greater
than 2 months, disconnect the battery by
pulling out the battery’s connector.
5. I s not allowed to discard batteries
in to common trash bins, they must be
discarded only
Suspended ceiling
Α-3018 mounting springs
1
2
3
Mounting methods
All luminaires, can be mounted either surface or in
suspended ceilings.
Suspended ceiling installation.
On the bottom of the base plastic of the luminaire
there are two Hshaped cut outs. These are used to
install the A-3018 mounting springs.
1. With a sharp tool remove the appropriate plastic
pieces to fit the mounting springs. First place the
edges of the mounting spring to the respective holes
and install the one end of the coil to the support axis.
2. Install the other end of the coil to the other support
axis.
3. Bend the springs and place the luminaire to the
respective suspended ceiling’s hole.
The luminaire’s placement to the suspended ceiling
must be done after the connection with power supply
cables. Mounting the luminaire
in a suspended ceiling
Required
opening in
a suspended
ceiling
260
110
923427002_09_002

Page 3 from 4 923427002_09_002
Installation methods
A-3018
Special mounting
springs for
suspended ceiling
installation
Mounting springs Α-3018
Wall or ceiling installation Suspended ceiling installation
MARKING PANEL SP-115
A marking panel SP-115 can be installed on
the luminaire in 3 different locations. This
marking panel is installed perpendicular to the
diffusor of the luminaire, as shown in the
pictures below. The panel is pre-printed and
has a plastic accessory on each side that is
used to fasten the panel to the luminaires.
There are 2 arrow stickers that can be placed
in each side of the marking panel to point to
the desired direction.
Placing the SP-115 marking panel
Place the plastic mounting accessories of the
marking panel as shown in pictures.
A-3018
SP-115 marking panel
Suspended ceiling installation
with Α-3018 mounting springs
and SP-115 marking panel
Ceiling installation
with SP-115 marking panel
Wall installation with SP-115
marking panel

923427002_09_002
Page 4 from 4
45 6
INSTALLATION INSTRUCTIONS
2
A
Base plastic
Cable entry channels
Luminaire mounting holes
3
B
1
A
B
Diffusor
Reflector
Base plastic
N
LL1
1 To install the luminaire you must dismantle it into 3 parts.
2 Place a flat blade screwdriver in the area Α to release the diffusor’s
plastic hook.
3Place a flat blade screwdriver in the area Bto release the reflector’s
plastic hook.
4 Use the included mounting parts to mount the base plastic. Pass
the mains cable through a cable entry channel. The luminaire
must be connected to a permanent electrical installation to ensure
the immobilization of the cable.
5 Place the battery’s connector to the corresponding connector on the
P.C.B.
6 Connect the mains cables to the respective detachable terminal
block. Ν for neutral, L for live wire and L1 for the maintained
operation. The L1 wire can be connected to an external switch to
control the maintained or non maintained operation of the luminaire.
For permanent maintained operation use two wires to power the
luminaire, Ν for neutral and L for live wire, and link the L and L1.
7 Refit the removed parts in steps 2 and 3 (mind the correct orientation) and the luminaire is ready to operate.
N
N
L
L
External
switch
Link
Controled operation of the luminaire
Permanent maintained operation
NN
L L
L1 L1
NOTE!!
After finishing the installation you must power the luminaire at least for 24 hours for battery
charging to perform the nominal autonomy.
Battery replacement.
It can be done only by a competent person and after the mains interruption.
1. Follow the step 2 and 3 of the installation procedure.
2. Disconnect the connector and remove the old battery.
3. Connect the new battery with the same type (step 5 of the installation procedure) and place it in
the position of the old one.
NOTE: LED= Light Emitting Diode
LABELING EXPLANATION:
X: Self contained 1: Maintained (*)
A: Including test device 480: 480min duration
(*) Maintained operation: The luminaire lights its illumination source, when it is powered by the
mains power supply or not.
Non Maintained operation: The luminaire lights its illumination source, only in apower supply failure.
