olympia electronics GR-470 User manual

GENERAL
o
These devices are used indoors (ta 40 C)
in places where emergency luminaires are
needed. The luminaires GR-470 and GR-
472 are suitable for corridors lighting and
the GR-471 and GR-473 for open area
lighting. Each device must be permanently
connected to mains power supply. In
normal operation the battery is charging. In
case of a mains power supply failure the
device will light the illumination led
automatically in emergency mode. When
the mains power supply is restored the
device turns to normal operation.
INSTALLATION
To install the luminaire follow the
installation instructions οn page 2.
ΑΤΤΕΝΤΙΟΝ!!!
1. Operations for installation, maintainance
or testing must be done by authorized
personel only.
2. The device must be connected to the
mains power supply thru a fuse dependent
by the total amount of the line’s power
load.
3. It is suggested to check every month the
indication LED for battery charging, and by
placing the test card (page 5) an (A-1900)
operation test is initiated, to check the
emergency cirquit. The illumination source
should light as long as the card is present.
In the opposite condition contact the
installer.
4. It is sugested to check every 6 months
the minimum autononous duration by
disconnecting the mains power supply.
Count the time that the luminaire lights and
in case of less time than the minimum
autonomous duration the battery must be
r e p l a c e d . I f the m e a s u r e d t i m e i s
considerably less than the minimum
autonomous duration contact the installer.
In c as e o f b at t er y o r l ig ht s ou rc e
replacement, these must be replaced by
parts of the same type, by the manufacturer
or by a competent person.
5. In case of inactive use for a period
greater than 2 months, disconnect the
ba tt ery by pul li ng o ut the ba tt ery ’s
connector.
6. I s not allowed to discard batteries in t i
to common trash bins, they must
be discarded only in battery
recycling points. Do not incinerate.
Page 1 from 5923473001_09_001
NON-MAINTAINED LUMINARIES
OPERATION TEMPERATURE RANGE
RELATIVE HUMIDITY
CONSTRUCTION MATERIAL
EXTERNAL DIMENSION
WEIGHT
GUARANTEE
OPERATION VOLTAGE
MAXIMUM POWER CONSUMPTION
BATTERY (Ni-Cd)
CHARGE TIME
INDICATIONS
BATTERY PROTECTION
MINIMUM DURATION
DEGREES OF COVER PROTECTION
PRODUCED IN ACCORDANCE WITH
EMERGENCY ILLUMINATION
LIGHT SOURCE
24 hours
Charge LED, Magnetic Test Contact
Deep discharge and overcharge protection
IP42
3,6V/1 Ah
1 white power LED
2,6W / 2,9VA
o
5 to 40 C
Up to 95%
3 years (1 year for the battery)
EN 60598-1, EN 60598-2-22, ΕΝ 55015, ΕΝ 61547, ΕΝ 61000-3-2, ΕΝ 61000-3-3
3 hour1,5 hour
145lm 80lm
470gr.
220-240V AC / 50-60Hz
TECHNICAL CHARACTERISTICS (for LED MODULE specifications see page 4)
Thank you for your trust in our products.
Olympia Electronics - European manufacturer.
GR-470 GR-471 GR-472 GR-473
ABS/PC, PC
158 x 158 x 60,4mm (without decorative bezel)-195 x 195 x 60,4 (with decorative bezel)

Page 2 from 5
INSTALLATION INSTRUCTIONS
ATTENTION!!!
During installation follow this light
direction.
Corridor
lighting
Open
area
lighting
12
Cable
entry
hole
3
NL
923473001_09_001
Initial installation
1. Detach the front cover by applying pressure using a flat blade screw driver. Next, unfasten the
four retaining screws without removing them and remove the diffusor.
2. Install the battery connector to its corresponding connector on the main pcb.
3. Install the cable grommet in the open hole of the plastic base and open a hole in the center of the
grommet using a small screw driver. Pass the power cable through the hole in the grommet (If
required, open another cutout cable entry hole and install the second supplied cable grommet).
Connect the cables as shown in the photograph. Use the supplied self adhesive pad and cable tie
to anchor the cable.
4. Reinstall the diffusor and re-tighten the 4 screws in a diagonally manner with a torque of 0,9 N*m.
NOTE!! After finishing the installation you must power the luminaire for at least 24 hours in
order to completely charge the batteries. The rated autonomous duration can be achieved
after this.
GR-470, GR-472 GR-471, GR-473

Page 3 from 5923473001_09_001
MOUNTING IN SUSPENDED CEILING
1 2
Required opening
14,5*14,5cm
4
3
4
6
8
9
plastic plugs plastic plugs
screws
screws
plastic
mounting
bracket
luminary’s
base
1. Detach the front cover by applying pressure using a flat blade screw driver. Next, unfasten the four
retaining screws (figure 1) without removing them and remove the diffusor.
2. Install the supplied cable grommet (figure 2).
3. Install the two plastic brackets with the four screws (figure 3).
4. Mark the positions of the mounting holes on the brackets.
5. Install the two supplied plaster board plugs by screwing them on the plaster board ceiling.
6.Open a cable entry cutout hole on the plastic base and follow step 3 in the “initial installation”
section.
7. Re-install the front cover that was removed in step 1.
8. Use the supplied screws to fasten the luminaire to the plaster board plugs (figure 8) that were
previously installed on the plaster board ceiling.
9. Finally, install the supplied decorative bezel (figure 9) and the notch on the bezel must be
located on the left side of the luminary (figure 10).

Page 4 from 5923473001_09_001
SURFACE MOUNTING
12
5
4
Other
possible
Cable entry
holes
1. Detach the front cover by applying pressure using a flat blade screw driver. Next, unfasten the four
retaining screws without removing them and remove the diffusor.
2. Use a drill with a 3,5mm bit to open the 4 mounting holes (figure 2) located in the plastic base..
3. Place the luminaire on the desired mounting location and mark and drill these 4 holes. Fit the
supplied 4 plastic mounting plugs to these drilled holes on the mounting location.
4. If the cable entry hole is not suitable then use one of the supplied cables grommets to cover the
holes and open another cable entry cut out hole (figure 3). Follow step 3 of the “ initial installation
procedure”.
5. Mount the base to the desired location by using the supplied screws in each mounting
hole(figure 4).
6. Re-install the cover that was removed in step 1.
MOUNTING IN SUSPENDED CEILING
10

Olympia Electronics S.A.
5.6-6.6V DC
1W
0205183
NOTE: LED= Light Emitting Diode
LABELING EXPLANATION:
X: Self contained
0: Non maintained (*)
A: Including test device
*90: 1.5 hour duration
180: 3 hours duration
(*) Non Maintained operation: The luminaire lights its illumination source, only in power
supply’s failure.
Maintained operation: The luminaire lights its illumination source, when it is powered by the
923473001_09_001
fixed connection between main pcb and led module
55 °C max. across the board
LED MODULE CHARACTERISTICS
Manufacturer
Model Number
Voltage Range
Connections
Nominal Power
Temperature (tc)
TEST
A-1900
Manual TEST with the A-1900 Test card (not included
and is available only on request). In order to test the
device you must place the card in front of the indications
TEST mark and remove it instantly for TEST.
Page 5 from 5
GR-470 GR-471 GR-472
GR-473
CAUTION : Do not view directly with bare eyes
Battery replacement
It can be done only by a competent person and after the mains interruption.
1. Detach the front cover by applying pressure using a flat blade screw driver. Next, unfasten the four
retaining screws without removing them and remove the diffusor.
3. Disconnect the connector and remove the old battery.
4. Connect the new battery with the same type (step 2 of the installation instructions) and place it in
the position of the old one.
5. Replace the removed parts and power the device.
The light source contained in this luminaire shall only be replaced by the manufacturer, or his
agent, or a similar qualified person.
NOTE! The light source is non-user replaceable.

923473001_09_001
WARRANTY
Olympia Electronics guarantees the quality, condition and operation of the goods. The period of
warranty is specified in the official catalogue of Olympia Electronics and also in the technical leaflet,
which accompanies each product. This warranty ceases to exist if the buyer does not follow the
technical instructions included in official documents given by Olympia Electronics or if the buyer
modifies the goods provided or has any repairs or re-setting done by a third party, unless Olympia
Electronics has fully agreed to them in writing. Products that have been damaged can be returned to
the premises of our company for repair or replacement, as long as the warranty period is valid.
Olympia Electronics reserves the right to repair or to replace the returned goods and to or not charge
the buyer depending on the reason of defection. Olympia Electronics reserves the right to charge or
not the buyer the transportation cost.
